2 - FIELD 230V
BSD-1614220208.A16
1614220208
|
£16.41
|
£19.69
|
|
|
3 - ARMATURE 230V
BSD-1614010262.A20
1614010262
|
£54.42
|
£65.30
|
|
|
3/13 - GROOVE BALL BEARING 7x19x6
BSD-1610905032.A64
1610905032
|
£5.30
|
£6.36
|
|
|
3/14 - GROOVE BALL BEARING 9x24x7
BSD-1610905048.A23
1610905048
|
£8.67
|
£10.41
|
|
|
3/49 - END SHIELD
BSD-1615700044.A81
1615700044
|
£2.16
|
£2.59
|
|
|
4/4 - SWITCH
BSD-1617200532.A50
1617200532
|
£21.68
|
£26.01
|
|
|
4/5 - POWER SUPPLY CORD EU 4.15m 2 x 1.0mm H07 RN-F
BSD-1607000392.A134
1607000392
|
£21.52
|
£25.83
|
|
|
4/6 - GROMMET dia7.3-dia8.6x66 MM
BSD-1600703034.A68
1600703034
|
£2.61
|
£3.13
|
|
|
4/102 - CONNECTING CABLE
BSD-1614449015.A56
1614449015
|
£1.75
|
£2.10
|
|
|
4/103 - LENS HEAD SCREW 3x10 ST
BSD-1613435034.A265
1613435034
|
£1.75
|
£2.10
|
|
|
9 - MANUFACTURER'S NAMEPLATE GBH 2-28 DV
BSD-1611110W00.A5
1611110W00
|
£2.80
|
£3.36
|
|
|
10 - MANUFACTURER'S NAMEPLATE GBH 2-28 DV
BSD-1611110W01.A3
1611110W01
|
£2.80
|
£3.36
|
|
|
11 - REFERENCE PLATE
BSD-1611110W02.A13
1611110W02
|
£2.61
|
£3.13
|
|
|
12 - ADAPTER MODULE
BSD-1600A0032J.A22
1600A0032J
|
£1.75
|
£2.10
|
|
|
16 - BRUSH PLATE
BSD-1614336093.A33
1614336093
|
£18.96
|
£22.75
|
|
|
19 - SWITCH CONTACT
BSD-1611329024.A70
1611329024
|
£1.75
|
£2.10
|
|
|
24 - TOOTHED SHAFT
BSD-16170006EJ.A31
16170006EJ
|
£36.62
|
£43.95
|
|
|
24/61 - SWITCHING ELEMENT
BSD-1615820097.A69
1615820097
|
£5.30
|
£6.36
|
|
|
24/65 - GROOVE BALL BEARING
BSD-1610905016.A167
1610905016
|
£10.10
|
£12.12
|
|
|
26 - HAMMER PISTON
BSD-16170006A5.A75
16170006A5
|
£41.62
|
£49.95
|
|
|
26/27 - STRIKER
BSD-1610311019.A57
1610311019
|
£21.52
|
£25.83
|
|
|
26/29 - PISTON PIN
BSD-1613105020.A51
1613105020
|
£5.30
|
£6.36
|
|
|
26/56 - O-RING 17.0x3.0 MM
BSD-1610210121.A121
1610210121
|
£2.61
|
£3.13
|
|
|
26/71 - GUIDE DISC
BSD-1610100016.A33
1610100016
|
£1.75
|
£2.10
|
|
|
32 - CLAMP HANDLE
BSD-1612026037.A19
1612026037
|
£10.82
|
£12.99
|
|
|
32/46 - DRIVER PIN
BSD-1614690002.A229
1614690002
|
£1.75
|
£2.10
|
|
|
32/49 - SWITCH BUTTON
BSD-1612026035.A302
1612026035
|
£1.75
|
£2.10
|
|
|
32/76 - O-RING 10.5x2.7 MM
BSD-1610210046.A297
1610210046
|
£2.16
|
£2.59
|
|
|
32/83 - COMPRESSION SPRING
BSD-1614611006.A24
1614611006
|
£3.72
|
£4.47
|
|
|
36 - BEARING HOLDER
BSD-1615808106.A29
1615808106
|
£1.75
|
£2.10
|
|
|
41 - HOUSING COVER
BSD-1615500428.A36
1615500428
|
£10.10
|
£12.12
|
|
|
45 - AIR-DEFLECTOR RING
BSD-1610522015.A24
1610522015
|
£2.16
|
£2.59
|
|
|
47 - CONTROL ELEMENT
BSD-1616312010.A9
1616312010
|
£5.58
|
£6.70
|
|
|
54 - RUBBER BUSHING
BSD-1610502016.A50
1610502016
|
£1.75
|
£2.10
|
|
|
55 - O-RING 59.5x5.0 MM
BSD-1610290104.A30
1610290104
|
£3.72
|
£4.47
|
|
|
57 - O-RING 24.0x2.0 MM
BSD-1610210208.A76
1610210208
|
£1.75
|
£2.10
|
|
|
76 - THREAD-FORMING TAP. SCREW
BSD-160343000A.A129
160343000A
|
£1.75
|
£2.10
|
|
|
77 - TORX OVAL-HEAD SCREW 4x25
BSD-2603490024.A305
2603490024
|
£1.75
|
£2.10
|
|
|
79 - THREAD-FORMING TAP. SCREW
BSD-1613435042.A20
1613435042
|
£1.75
|
£2.10
|
|
|
80 - SCREW
BSD-1613435043.A17
1613435043
|
£1.75
|
£2.10
|
|
|
101 - CONNECTING CABLE
BSD-1614449014.A105
1614449014
|
£2.16
|
£2.59
|
|
|
105 - COMPRESSION SPRING
BSD-1614643027.A18
1614643027
|
£1.75
|
£2.10
|
|
|
106 - PROTECTIVE SLEEVE
BSD-1610590024.A18
1610590024
|
£2.16
|
£2.59
|
|
|
109 - THREAD-FORMING TAP. SCREW
BSD-160343508E.A11
160343508E
|
£1.75
|
£2.10
|
|
|
120 - AUXILIARY HANDLE
BSD-160202508X.A24
160202508X
|
£18.96
|
£22.75
|
|
|
120/120 - AUXILIARY HANDLE
BSD-160202507H.A394
160202507H
|
£11.30
|
£13.56
|
|
|
120/124 - CLAMPING BAND dia50 MM
BSD-1611316021.A107
1611316021
|
£2.80
|
£3.36
|
|
|
120/125 - T-HEAD BOLT M8x40 MM
BSD-1613490002.A109
1613490002
|
£4.26
|
£5.11
|
|
|
120/802 - SUPPORT CLAMP
BSD-1617000475.A101
1617000475
|
£10.10
|
£12.12
|
|
|
203 - PROTECTIVE CAP
BSD-1610508047.A112
1610508047
|
£2.29
|
£2.75
|
|
|
206 - BALL dia7.3 MM
BSD-1613230003.A12
1613230003
|
£1.75
|
£2.10
|
|
|
207 - RETAINING RING
BSD-1614601027.A22
1614601027
|
£1.75
|
£2.10
|
|
|
208 - RETAINING WASHER
BSD-1610101629.A64
1610101629
|
£1.75
|
£2.10
|
|
|
209 - FRICTION WASHER
BSD-1610102638.A12
1610102638
|
£3.72
|
£4.47
|
|
|
211 - RETAINING RING DIN 7993-A22
BSD-2916540012.A89
2916540012
|
-
|
|
|
|
321 - TOOLHOLDER
BSD-16170006CA.A12
16170006CA
|
£98.11
|
£117.73
|
|
|
321/22 - CYLINDRICAL GEAR
BSD-1616312004.A74
1616312004
|
£12.04
|
£14.45
|
|
|
321/28 - STRIKER PIN
BSD-1613124098.A24
1613124098
|
£21.52
|
£25.83
|
|
|
321/33 - HOLDING JACKET
BSD-1610590020.A28
1610590020
|
£6.52
|
£7.83
|
|
|
321/34 - SUPPORTING DISC
BSD-1610190067.A132
1610190067
|
£2.16
|
£2.59
|
|
|
321/37 - STRAIGHT PIN DIN6325-2.5x12-RIKO
BSD-1613100019.A198
1613100019
|
£1.75
|
£2.10
|
|
|
321/38 - CATCH DISK
BSD-1600A008AG.A20
1600A008AG
|
£3.72
|
£4.47
|
|
|
321/42 - THRUST RING
BSD-1610102084.A64
1610102084
|
£8.67
|
£10.41
|
|
|
321/46 - GUIDE BUSHING
BSD-1610390068.A49
1610390068
|
£16.41
|
£19.69
|
|
|
321/50 - COMPRESSION SPRING
BSD-1614615008.A27
1614615008
|
£5.58
|
£6.70
|
|
|
321/58 - O-RING 18.0x3.5 MM
BSD-1610210105.A147
1610210105
|
£4.26
|
£5.11
|
|
|
321/59 - SHAFT SEAL
BSD-1600A009VC.A23
1600A009VC
|
£2.80
|
£3.36
|
|
|
321/60 - O-RING 9.5x3.5 MM
BSD-1610210209.A12
1610210209
|
£1.75
|
£2.10
|
|
|
321/72 - RETAINING RING
BSD-1604601027.A80
1604601027
|
£1.75
|
£2.10
|
|
|
321/86 - RETAINING RING
BSD-1614601034.A152
1614601034
|
£2.16
|
£2.59
|
|
|
321/87 - RETAINING RING A22 DIN 7993
BSD-1604601028.A217
1604601028
|
£1.75
|
£2.10
|
|
|
340 - GEAR HOUSING
BSD-16170006BY.A3
16170006BY
|
£46.37
|
£55.64
|
|
|
340/39 - COVER
BSD-1615500429.A2
1615500429
|
£6.61
|
£7.93
|
|
|
340/48 - TAB WASHER
BSD-1611098008.A30
1611098008
|
£2.16
|
£2.59
|
|
|
340/63/63 - NEEDLE BEARING dia30xdia37x12 MM
BSD-1610910063.A203
1610910063
|
£5.58
|
£6.70
|
|
|
340/63/64 - BUSHING
BSD-1610390069.A35
1610390069
|
£2.16
|
£2.59
|
|
|
340/68 - ROTARY SHAFT LIP SEAL
BSD-1610283036.A175
1610283036
|
£7.36
|
£8.83
|
|
|
340/78 - SCREW 4x16
BSD-2603490022.A915
2603490022
|
£1.75
|
£2.10
|
|
|
688 - DEPTH-GAUGE SW 6x210 MM
BSD-1613001009.A634
1613001009
|
£3.72
|
£4.47
|
|
|
801 - MOTOR HOUSING
BSD-16170006BS.A19
16170006BS
|
£37.27
|
£44.72
|
|
|
808 - NAMEPLATE
BSD-160111A3H5.A433
160111A3H5
|
£2.61
|
£3.13
|
|
|
811 - CARBON-BRUSH SET
BSD-1617000525.A219
1617000525
|
£11.30
|
£13.56
|
|
|
820 - INTERMEDIATE FLANGE
BSD-16170006BT.A18
16170006BT
|
£46.37
|
£55.64
|
|
|
821 - TOOL HOLDING FIXTURE
BSD-16170006C9.A6
16170006C9
|
£63.50
|
£76.20
|
|
|
823 - GEAR SLEEVE
BSD-16170006BW.A20
16170006BW
|
£24.45
|
£29.34
|
|
|
825 - TOOL HOLDING FIXTURE
BSD-16170006CB.A5
16170006CB
|
£12.04
|
£14.45
|
|
|
828 - STRIKER PIN
BSD-1617000697.A27
1617000697
|
£48.38
|
£58.06
|
|
|
830 - DRIVE BEARING
BSD-16170006BX.A16
16170006BX
|
£37.72
|
£45.27
|
|
|
861 - SWITCHING ELEMENT
BSD-1615820097.A70
1615820097
|
£5.30
|
£6.36
|
|
|
870 - DRILL CHUCK SHANK 1/2. SDS-Plus
BSD-1613523011.A10
1613523011
|
-
|
|
|
|
870/2 - COUNTERSUNK-HEAD SCREW M6x27-Kdia11
BSD-2603421207.A96
2603421207
|
£1.75
|
£2.10
|
|
|
871 - CHUCK dia1.5-13 MM. 1/2
BSD-1608571069.A102
1608571069
|
£23.86
|
£28.63
|
|
|
872 - CHUCK WRENCH SG2
BSD-2607950007.A1739
2607950007
|
£6.52
|
£7.83
|
|
|
891 - WEIGHT
BSD-16170006BZ.A16
16170006BZ
|
£6.52
|
£7.83
|
|
|
892 - GREASE TUBE 225 ML
BSD-1615430002.A21
1615430002
|
£45.67
|
£54.80
|
|
|
893 - GREASE TUBE 225 ML
BSD-1615430001.A63
1615430001
|
£23.86
|
£28.63
|
|
|
895 - LOCK
BSD-1615438409.A12
1615438409
|
£6.52
|
£7.83
|
|
