2 - FIELD 230V
BSD-1614220117.A74
1614220117
|
£16.41
|
£19.69
|
|
|
3 - ARMATURE 230V
BSD-1614010709.A2
1614010709
|
£49.16
|
£58.99
|
|
|
3/5 - FAN
BSD-1616610094.A52
1616610094
|
£2.16
|
£2.59
|
|
|
3/13 - GROOVE BALL BEARING 7x19x6
BSD-1610905025.A103
1610905025
|
£6.85
|
£8.22
|
|
|
3/14 - GROOVE BALL BEARING 9x24x7
BSD-1610905048.A175
1610905048
|
£8.67
|
£10.41
|
|
|
3/49 - END SHIELD
BSD-1615700044.A41
1615700044
|
£2.27
|
£2.72
|
|
|
4/102 - CONNECTING CABLE
BSD-1614449015.A139
1614449015
|
£1.84
|
£2.21
|
|
|
4/1/102 - CONNECTING CABLE
BSD-1614449021.A3
1614449021
|
£1.75
|
£2.10
|
|
|
6 - GROMMET dia7.3-dia8.6x66 MM
BSD-1600703034.A38
1600703034
|
£2.74
|
£3.29
|
|
|
9 - MANUFACTURER'S NAMEPLATE GBH 2-26 DRE
BSD-1611110Z33.A8
1611110Z33
|
£2.61
|
£3.13
|
|
|
10 - MANUFACTURER'S NAMEPLATE GBH 2-26 E
BSD-1611110Z34.A0
1611110Z34
|
£2.74
|
£3.29
|
|
|
11 - REFERENCE PLATE
BSD-1611110X17.A19
1611110X17
|
£3.72
|
£4.47
|
|
|
16 - BRUSH PLATE
BSD-1614336061.A59
1614336061
|
£19.91
|
£23.89
|
|
|
17 - SUPPRESSION FILTER
BSD-1614465011.A6
1614465011
|
£6.85
|
£8.22
|
|
|
19 - SWITCH CONTACT
BSD-1611329024.A37
1611329024
|
£1.84
|
£2.21
|
|
|
24 - TOOTHED SHAFT
BSD-1617000556.A1
1617000556
|
£42.84
|
£51.41
|
|
|
26 - HAMMER PISTON
BSD-1617000557.A87
1617000557
|
£38.47
|
£46.16
|
|
|
26/27 - STRIKER
BSD-1610311018.A40
1610311018
|
£18.96
|
£22.75
|
|
|
26/29 - PISTON PIN
BSD-1613105012.A356
1613105012
|
£3.91
|
£4.69
|
|
|
26/56 - O-RING
BSD-1610210187.A130
1610210187
|
£2.27
|
£2.72
|
|
|
26/71 - SHIM WASHER 1.2 MM
BSD-1610101011.A294
1610101011
|
£1.75
|
£2.10
|
|
|
30 - DRIVE BEARING
BSD-1615819028.A5
1615819028
|
£35.12
|
£42.15
|
|
|
30/35 - PLAIN BEARING
BSD-1610202024.A40
1610202024
|
£5.57
|
£6.68
|
|
|
31 - NEEDLE-ROLLER ASSEMBLY
BSD-1610913016.A4
1610913016
|
£3.72
|
£4.47
|
|
|
32 - CLAMP HANDLE
BSD-1612026037.A101
1612026037
|
£10.82
|
£12.99
|
|
|
32/46 - DRIVER PIN
BSD-1614690002.A135
1614690002
|
£1.84
|
£2.21
|
|
|
32/49 - SWITCH BUTTON
BSD-1612026035.A144
1612026035
|
£1.75
|
£2.10
|
|
|
32/76 - O-RING 10.5x2.7 MM
BSD-1610210046.A132
1610210046
|
£2.16
|
£2.59
|
|
|
32/83 - COMPRESSION SPRING
BSD-1614611006.A269
1614611006
|
£3.91
|
£4.69
|
|
|
36 - HOLDING PLATE
BSD-1611016003.A143
1611016003
|
£2.27
|
£2.72
|
|
|
41 - HOUSING COVER
BSD-1615500343.A24
1615500343
|
£8.67
|
£10.41
|
|
|
44 - PROTECTIVE CAP
BSD-1610508047.A21
1610508047
|
£2.41
|
£2.89
|
|
|
45 - AIR-DEFLECTOR RING
BSD-1610522013.A37
1610522013
|
£2.27
|
£2.72
|
|
|
47 - NEEDLE ROLLER
BSD-1613100030.A54
1613100030
|
£2.80
|
£3.36
|
|
|
48 - TAB WASHER
BSD-1611098008.A98
1611098008
|
£2.27
|
£2.72
|
|
|
54 - RUBBER BUSHING
BSD-1610502016.A79
1610502016
|
£1.84
|
£2.21
|
|
|
55 - SEAL RING 53.0x7.0 MM
BSD-1610290226.A58
1610290226
|
£3.72
|
£4.47
|
|
|
57 - O-RING 24.0x2.5 MM
BSD-1610210068.A267
1610210068
|
£1.75
|
£2.10
|
|
|
63 - NEEDLE BEARING dia30xdia37x12 MM
BSD-1610910063.A120
1610910063
|
£5.87
|
£7.04
|
|
|
64/1 - SUPPORTING DISC
BSD-1610190060.A93
1610190060
|
£2.27
|
£2.72
|
|
|
66 - PLAIN BEARING
BSD-1610202021.A109
1610202021
|
£2.74
|
£3.29
|
|
|
68 - ROTARY SHAFT LIP SEAL
BSD-1610283036.A31
1610283036
|
£7.72
|
£9.27
|
|
|
70 - BALL DIN 5401-dia7MM-III-ST
BSD-1903230013.A634
1903230013
|
£2.27
|
£2.72
|
|
|
74 - RETAINING RING
BSD-1614601027.A121
1614601027
|
£1.84
|
£2.21
|
|
|
75 - RETAINING WASHER
BSD-1610101629.A19
1610101629
|
£1.84
|
£2.21
|
|
|
76 - THREAD-FORMING TAP. SCREW
BSD-160343000A.A49
160343000A
|
£1.84
|
£2.21
|
|
|
77 - TORX OVAL-HEAD SCREW 4x25
BSD-2603490024.A1096
2603490024
|
£1.84
|
£2.21
|
|
|
78 - SCREW 4x16
BSD-2603490022.A2985
2603490022
|
£1.84
|
£2.21
|
|
|
79 - THREAD-FORMING TAP. SCREW
BSD-1613435023.A185
1613435023
|
£1.84
|
£2.21
|
|
|
80 - SCREW
BSD-1613435043.A84
1613435043
|
£1.84
|
£2.21
|
|
|
87 - RETAINING RING DIN 7993-A22
BSD-2916540012.A259
2916540012
|
-
|
|
|
|
101 - CONNECTING CABLE
BSD-1614449014.A7
1614449014
|
£2.16
|
£2.59
|
|
|
103 - TORX OVAL-HEAD SCREW 3x10
BSD-2603490017.A496
2603490017
|
£2.27
|
£2.72
|
|
|
106 - PLAIN BEARING
BSD-1614611022.A5
1614611022
|
£2.74
|
£3.29
|
|
|
106/105 - COMPRESSION SPRING
BSD-1614611021.A88
1614611021
|
£1.75
|
£2.10
|
|
|
321/22 - CYLINDRICAL GEAR
BSD-1616312004.A143
1616312004
|
£12.64
|
£15.17
|
|
|
321/28 - STRIKER PIN
BSD-1613124081.A22
1613124081
|
£10.61
|
£12.73
|
|
|
321/33 - HOLDING JACKET
BSD-1610590014.A11
1610590014
|
£2.16
|
£2.59
|
|
|
321/34 - SUPPORTING DISC
BSD-1610190067.A166
1610190067
|
£2.16
|
£2.59
|
|
|
321/37 - STRAIGHT PIN DIN6325-2.5x12-RIKO
BSD-1613100019.A10
1613100019
|
£1.84
|
£2.21
|
|
|
321/38 - CATCH DISK
BSD-1600A008AG.A174
1600A008AG
|
£3.72
|
£4.47
|
|
|
321/42 - THRUST RING
BSD-1610102073.A55
1610102073
|
£5.57
|
£6.68
|
|
|
321/46 - GUIDE BUSHING
BSD-1610390051.A27
1610390051
|
£6.52
|
£7.83
|
|
|
321/50 - COMPRESSION SPRING
BSD-1614611020.A5
1614611020
|
£2.80
|
£3.36
|
|
|
321/58 - O-RING
BSD-1610210178.A2
1610210178
|
£1.84
|
£2.21
|
|
|
321/59 - ROTARY SHAFT LIP SEAL
BSD-1610283035.A61
1610283035
|
£5.87
|
£7.04
|
|
|
321/60 - O-RING 9.0x3.5 MM
BSD-1610210176.A11
1610210176
|
£1.84
|
£2.21
|
|
|
321/62 - O-RING
BSD-1610210179.A54
1610210179
|
£2.61
|
£3.13
|
|
|
321/72 - RETAINING RING
BSD-1604601027.A202
1604601027
|
£1.75
|
£2.10
|
|
|
321/82 - RETAINING RING
BSD-1614601034.A5
1614601034
|
£2.27
|
£2.72
|
|
|
321/83 - RETAINING RING A22 DIN 7993
BSD-1604601028.A23
1604601028
|
£1.84
|
£2.21
|
|
|
651 - DEPTH-GAUGE SW 6x210 MM
BSD-1613001009.A44
1613001009
|
£3.91
|
£4.69
|
|
|
691/895 - LOCK
BSD-1615438409.A70
1615438409
|
£6.85
|
£8.22
|
|
|
691/895 - LOCK
BSD-1615438431.A44
1615438431
|
£6.52
|
£7.83
|
|
|
801 - MOTOR HOUSING
BSD-1617000558.A6
1617000558
|
£33.45
|
£40.14
|
|
|
804 - ON-OFF SWITCH
BSD-16170006D4.A18
16170006D4
|
£21.52
|
£25.83
|
|
|
805 - POWER SUPPLY CORD EU 4.15m 2 x 1.0mm H07 RN-F
BSD-1607000392.A28
1607000392
|
£21.52
|
£25.83
|
|
|
806 - END SPLICE DIN 46 228-A1-6
BSD-1900452012.A198
1900452012
|
£1.75
|
£2.10
|
|
|
808 - NAMEPLATE
BSD-160111A3H5.A86
160111A3H5
|
£2.74
|
£3.29
|
|
|
811 - CARBON-BRUSH SET
BSD-1617000525.A19
1617000525
|
£11.87
|
£14.24
|
|
|
811 - CARBON-BRUSH SET 10 x 1 617 000 525
BSD-1607000485.A95
1607000485
|
£75.79
|
£90.95
|
|
|
820 - INTERMEDIATE FLANGE
BSD-16170006DX.A31
16170006DX
|
£31.79
|
£38.15
|
|
|
821 - PIPE
BSD-1617000564.A38
1617000564
|
£66.68
|
£80.01
|
|
|
822 - AUXILIARY HANDLE
BSD-160202508X.A109
160202508X
|
£19.91
|
£23.89
|
|
|
822/120 - AUXILIARY HANDLE
BSD-160202507H.A82
160202507H
|
£11.87
|
£14.24
|
|
|
822/124 - CLAMPING BAND dia50 MM
BSD-1611316021.A177
1611316021
|
£2.80
|
£3.36
|
|
|
822/125 - T-HEAD BOLT M8x40 MM
BSD-1613490002.A317
1613490002
|
£4.48
|
£5.37
|
|
|
822/802 - SUPPORT CLAMP
BSD-1617000475.A9
1617000475
|
£10.61
|
£12.73
|
|
|
823 - TOOTHED SHAFT
BSD-1617000579.A4
1617000579
|
£39.61
|
£47.53
|
|
|
825 - TOOL HOLDING FIXTURE
BSD-1617000598.A10
1617000598
|
£59.87
|
£71.84
|
|
|
840 - GEAR HOUSING
BSD-1617000581.A15
1617000581
|
£48.38
|
£58.06
|
|
|
843 - PROTECTION SLEEVE
BSD-1617000582.A8
1617000582
|
£11.87
|
£14.24
|
|
|
861 - SWITCHING ELEMENT
BSD-1615820097.A2
1615820097
|
£5.30
|
£6.36
|
|
|
864 - SUPPORTING DISC
BSD-1617000A07.A63
1617000A07
|
£11.87
|
£14.24
|
|
|
870 - DRILL CHUCK SHANK 1/2. SDS-Plus
BSD-1613523011.A107
1613523011
|
-
|
|
|
|
870/2 - COUNTERSUNK-HEAD SCREW M6x27-Kdia11
BSD-2603421207.A24
2603421207
|
£1.84
|
£2.21
|
|
|
871 - CHUCK
BSD-1608571088.A170
1608571088
|
£28.59
|
£34.31
|
|
|
872 - CHUCK WRENCH SG2
BSD-2607950007.A647
2607950007
|
£6.85
|
£8.22
|
|
|
883 - RETAINING RING A22 DIN 7993
BSD-1604601028.A24
1604601028
|
£1.84
|
£2.21
|
|
|
894 - GREASE TUBE 225 ML
BSD-1615430020.A5
1615430020
|
£21.52
|
£25.83
|
|
|
895 - OIL RESERVOIR 1000 ML
BSD-1615430019.A77
1615430019
|
£59.53
|
£71.44
|
|
|
896 - GREASE TUBE 225 ML
BSD-1615430001.A4
1615430001
|
£25.05
|
£30.06
|
|
|
897 - GREASE TUBE 225 ML
BSD-1615430002.A60
1615430002
|
£45.67
|
£54.80
|
|
