3/5 - FAN
BSD-1616610113.A0
1616610113
|
£2.94
|
£3.53
|
|
|
4 - SWITCH
BSD-1617200542.A2
1617200542
|
£22.76
|
£27.31
|
|
|
5 - POWER SUPPLY CORD GB 230V 4.15m 2 x 1.0mm H07 RN-F
BSD-3604460084.A73
3604460084
|
£22.76
|
£27.31
|
|
|
6 - GROMMET dia7.3-dia8.6x76 MM
BSD-2600703018.A97
2600703018
|
£2.74
|
£3.29
|
|
|
9 - MANUFACTURER'S NAMEPLATE GBH 2-20 D
BSD-1618B0002G.A0
1618B0002G
|
-
|
|
|
|
10 - MANUFACTURER'S NAMEPLATE GBH 2-20 D
BSD-1618B0002H.A3
1618B0002H
|
£1.75
|
£2.10
|
|
|
11 - REFERENCE PLATE
BSD-1618B00401.A0
1618B00401
|
-
|
|
|
|
12 - SUPPRESSION FILTER
BSD-1617328032.A18
1617328032
|
£7.72
|
£9.27
|
|
|
14 - BEARING BRACKET
BSD-1615806187.A6
1615806187
|
£2.27
|
£2.72
|
|
|
15 - DAMPING RUBBER
BSD-2603100056.A235
2603100056
|
£1.84
|
£2.21
|
|
|
17 - O-RING
BSD-1610290108.A1
1610290108
|
£1.75
|
£2.10
|
|
|
19 - O-RING 22.0x2.5 MM
BSD-1610210184.A20
1610210184
|
£1.84
|
£2.21
|
|
|
20/2 - DRIVER PIN
BSD-1614690009.A48
1614690009
|
£3.91
|
£4.69
|
|
|
20/3 - SWITCH BUTTON
BSD-1612026035.A322
1612026035
|
£1.75
|
£2.10
|
|
|
20/4 - O-RING 10.5x2.7 MM
BSD-1610210046.A275
1610210046
|
£2.16
|
£2.59
|
|
|
20/5 - COMPRESSION SPRING
BSD-1614611006.A51
1614611006
|
£3.91
|
£4.69
|
|
|
21 - HAMMER PIPE
BSD-1619P09815.A4
1619P09815
|
£33.22
|
£39.87
|
|
|
22 - GEAR SLEEVE
BSD-1616328053.A12
1616328053
|
£8.67
|
£10.41
|
|
|
26 - HAMMER PISTON
BSD-1618700083.A18
1618700083
|
£11.37
|
£13.64
|
|
|
27 - STRIKER
BSD-1618710085.A16
1618710085
|
£10.61
|
£12.73
|
|
|
28 - STRIKER PIN
BSD-1613124084.A19
1613124084
|
£4.48
|
£5.37
|
|
|
29 - PISTON PIN
BSD-1613100034.A22
1613100034
|
£2.94
|
£3.53
|
|
|
31 - RETAINING RING
BSD-1614601053.A39
1614601053
|
£1.84
|
£2.21
|
|
|
32 - RUBBER BUSHING
BSD-1610508051.A46
1610508051
|
£4.48
|
£5.37
|
|
|
33 - SWITCHING ELEMENT
BSD-1615820103.A3
1615820103
|
£2.74
|
£3.29
|
|
|
34 - RETAINING RING
BSD-1619P00829.A41
1619P00829
|
£1.75
|
£2.10
|
|
|
36 - HOLDING PLATE
BSD-1610551008.A5
1610551008
|
£2.61
|
£3.13
|
|
|
37 - GUIDE DISC
BSD-1610100016.A6
1610100016
|
£1.75
|
£2.10
|
|
|
38 - CYLINDRICAL GEAR
BSD-1616317084.A13
1616317084
|
£18.96
|
£22.75
|
|
|
39 - RETAINING RING
BSD-1614601055.A36
1614601055
|
£1.84
|
£2.21
|
|
|
40 - STRAIGHT PIN
BSD-1613100032.A18
1613100032
|
£1.84
|
£2.21
|
|
|
41 - RATCHET DISC
BSD-1610102072.A16
1610102072
|
£5.58
|
£6.70
|
|
|
44 - FRICTION WASHER
BSD-1610102092.A8
1610102092
|
£1.84
|
£2.21
|
|
|
45 - HOLDING PLATE
BSD-1611016003.A9
1611016003
|
£2.27
|
£2.72
|
|
|
46 - COMPRESSION SPRING
BSD-1614630003.A8
1614630003
|
£2.16
|
£2.59
|
|
|
49 - SWITCHING ELEMENT
BSD-1615820104.A13
1615820104
|
£2.61
|
£3.13
|
|
|
50 - THRUST RING
BSD-1600A00FL3.A38
1600A00FL3
|
£2.80
|
£3.36
|
|
|
51 - SHIFT PLATE
BSD-1610021004.A12
1610021004
|
£1.75
|
£2.10
|
|
|
52 - SHIFT PLATE
BSD-1610021006.A11
1610021006
|
£1.84
|
£2.21
|
|
|
53 - SHIFT PLATE
BSD-1610021005.A6
1610021005
|
£1.75
|
£2.10
|
|
|
54 - GUIDE ROD
BSD-1613023005.A4
1613023005
|
£1.84
|
£2.21
|
|
|
55 - PROTECTIVE CAP
BSD-1610508052.A8
1610508052
|
£1.75
|
£2.10
|
|
|
60 - SPRING RETAINING RING
BSD-1614601077.A14
1614601077
|
£1.84
|
£2.21
|
|
|
63 - BALL DIN 5401-dia7MM-III-ST
BSD-1903230013.A63
1903230013
|
£2.27
|
£2.72
|
|
|
65 - O-RING 13.0x3.0 MM
BSD-1610210244.A27
1610210244
|
£2.16
|
£2.59
|
|
|
66 - BALL BEARING
BSD-2609110491.A19
2609110491
|
£5.57
|
£6.68
|
|
|
67 - GROOVE BALL BEARING
BSD-1610905047.A7
1610905047
|
£7.36
|
£8.83
|
|
|
68 - PLAIN WASHER
BSD-1600100037.A10
1600100037
|
£1.84
|
£2.21
|
|
|
69 - CHANGE-OVER SWITCH
BSD-1613231030.A7
1613231030
|
£1.84
|
£2.21
|
|
|
71 - TORX OVAL-HEAD SCREW 4x20
BSD-2603490023.A1006
2603490023
|
£1.84
|
£2.21
|
|
|
72 - TORX OVAL-HEAD SCREW
BSD-1613435039.A10
1613435039
|
£1.84
|
£2.21
|
|
|
73 - LENS HEAD SCREW 3x10 ST
BSD-1613435034.A306
1613435034
|
£1.84
|
£2.21
|
|
|
75 - COMPRESSION SPRING
BSD-1614643025.A7
1614643025
|
£1.84
|
£2.21
|
|
|
76 - COMPRESSION SPRING
BSD-1614643023.A10
1614643023
|
£1.84
|
£2.21
|
|
|
77 - SHAFT SEAL
BSD-1619P09722.A5
1619P09722
|
£2.94
|
£3.53
|
|
|
120 - AUXILIARY HANDLE
BSD-1618B00500.A4
1618B00500
|
-
|
|
|
|
120/120 - AUXILIARY HANDLE
BSD-160202507H.A414
160202507H
|
£11.87
|
£14.24
|
|
|
120/124 - CLAMPING BAND dia50 MM
BSD-1611316021.A62
1611316021
|
£2.80
|
£3.36
|
|
|
120/125 - T-HEAD BOLT M8x40 MM
BSD-1613490002.A150
1613490002
|
£4.48
|
£5.37
|
|
|
120/802 - SUPPORT CLAMP
BSD-1617000475.A83
1617000475
|
£10.61
|
£12.73
|
|
|
651 - DEPTH-GAUGE
BSD-2603001009.A8
2603001009
|
£5.57
|
£6.68
|
|
|
801 - MOTOR HOUSING
BSD-16170006B8.A9
16170006B8
|
£28.59
|
£34.31
|
|
|
802 - FIELD 230-240V
BSD-1614220219.A0
1614220219
|
£21.52
|
£25.83
|
|
|
803 - ARMATURE 230V
BSD-1614010B1C.A3
1614010B1C
|
-
|
|
|
|
808 - NAMEPLATE
BSD-160111A3H6.A16
160111A3H6
|
£2.74
|
£3.29
|
|
|
816 - CARBON-BRUSH SET
BSD-1619P01777.A27
1619P01777
|
£11.87
|
£14.24
|
|
|
820 - INTERMEDIATE FLANGE
BSD-16170006BB.A6
16170006BB
|
£21.68
|
£26.01
|
|
|
821 - HAMMER PIPE
BSD-1600A0013V.A0
1600A0013V
|
-
|
|
|
|
822 - CLAMP HANDLE
BSD-1612026151.A46
1612026151
|
£14.91
|
£17.89
|
|
|
824 - JACK SHAFT
BSD-16170006BC.A9
16170006BC
|
£38.46
|
£46.15
|
|
|
826 - HAMMER PISTON
BSD-1600A0013X.A1
1600A0013X
|
-
|
|
|
|
840 - GEAR HOUSING
BSD-16170006BF.A4
16170006BF
|
£27.23
|
£32.68
|
|
|
843 - PROTECTION SLEEVE
BSD-16170006D3.A22
16170006D3
|
£11.87
|
£14.24
|
|
|
847 - PLAIN BEARING
BSD-1600A0013U.A8
1600A0013U
|
-
|
|
|
|
854 - GUIDE ROD
BSD-1600A0013W.A12
1600A0013W
|
-
|
|
|
|
870 - CONNECTING CABLE
BSD-1619P01776.A18
1619P01776
|
£5.58
|
£6.70
|
|
|
890 - GREASE TUBE 225 ML
BSD-1615430020.A73
1615430020
|
£21.52
|
£25.83
|
|
|
891 - GREASE TUBE 225 ML
BSD-1615430001.A49
1615430001
|
£25.05
|
£30.06
|
|
