2 - FIELD 230-240V
BSD-1614220219.A10
1614220219
|
£21.52
|
£25.83
|
|
|
3 - ARMATURE 230V
BSD-1614010711.A0
1614010711
|
£41.62
|
£49.95
|
|
|
3/3/5 - FAN
BSD-1616610113.A12
1616610113
|
£2.94
|
£3.53
|
|
|
4/4 - SWITCH
BSD-1617200542.A11
1617200542
|
£22.76
|
£27.31
|
|
|
4/6 - GROMMET dia7.3-dia8.6x76 MM
BSD-2600703018.A78
2600703018
|
£2.74
|
£3.29
|
|
|
4/73 - LENS HEAD SCREW 3x10 ST
BSD-1613435034.A252
1613435034
|
£1.84
|
£2.21
|
|
|
9 - MANUFACTURER'S NAMEPLATE GBH 2-20 D
BSD-1611110Z91.A0
1611110Z91
|
£2.61
|
£3.13
|
|
|
10 - MANUFACTURER'S NAMEPLATE GBH 2-20 D
BSD-1611110Z92.A3
1611110Z92
|
£2.61
|
£3.13
|
|
|
11 - REFERENCE PLATE
BSD-1618B00401.A7
1618B00401
|
-
|
|
|
|
12 - SUPPRESSION FILTER
BSD-1617328032.A28
1617328032
|
£7.72
|
£9.27
|
|
|
14 - BEARING BRACKET
BSD-1615806187.A18
1615806187
|
£2.27
|
£2.72
|
|
|
15 - DAMPING RUBBER
BSD-2603100056.A243
2603100056
|
£1.84
|
£2.21
|
|
|
17 - O-RING
BSD-1610290108.A12
1610290108
|
£1.75
|
£2.10
|
|
|
19 - O-RING 22.0x2.5 MM
BSD-1610210184.A3
1610210184
|
£1.84
|
£2.21
|
|
|
20 - CLAMP HANDLE
BSD-1612026151.A11
1612026151
|
£14.91
|
£17.89
|
|
|
20/2 - DRIVER PIN
BSD-1614690009.A37
1614690009
|
£3.91
|
£4.69
|
|
|
20/3 - SWITCH BUTTON
BSD-1612026035.A261
1612026035
|
£1.75
|
£2.10
|
|
|
20/4 - O-RING 10.5x2.7 MM
BSD-1610210046.A382
1610210046
|
£2.16
|
£2.59
|
|
|
20/5 - COMPRESSION SPRING
BSD-1614611006.A58
1614611006
|
£3.91
|
£4.69
|
|
|
21 - HAMMER PIPE
BSD-16170006B7.A0
16170006B7
|
£66.68
|
£80.01
|
|
|
21/31 - RETAINING RING
BSD-1614601053.A26
1614601053
|
£1.84
|
£2.21
|
|
|
21/32 - RUBBER BUSHING
BSD-1610508051.A36
1610508051
|
£4.48
|
£5.37
|
|
|
21/36 - HOLDING PLATE
BSD-1610551008.A20
1610551008
|
£2.61
|
£3.13
|
|
|
21/38 - CYLINDRICAL GEAR
BSD-1616317084.A8
1616317084
|
£18.96
|
£22.75
|
|
|
21/39 - RETAINING RING
BSD-160460102U.A7
160460102U
|
£1.84
|
£2.21
|
|
|
21/40 - STRAIGHT PIN
BSD-1613100032.A25
1613100032
|
£1.84
|
£2.21
|
|
|
21/41 - RATCHET DISC
BSD-1610102072.A32
1610102072
|
£5.58
|
£6.70
|
|
|
21/44 - FRICTION WASHER
BSD-1610102092.A0
1610102092
|
£1.84
|
£2.21
|
|
|
21/46 - COMPRESSION SPRING
BSD-1614630003.A1
1614630003
|
£2.16
|
£2.59
|
|
|
21/50 - THRUST RING
BSD-1600A00FL3.A26
1600A00FL3
|
£2.80
|
£3.36
|
|
|
21/211 - HAMMER PIPE
BSD-1619P09815.A17
1619P09815
|
£33.22
|
£39.87
|
|
|
22 - GEAR SLEEVE
BSD-1616328053.A1
1616328053
|
£8.67
|
£10.41
|
|
|
26 - HAMMER PISTON
BSD-1600A0013X.A13
1600A0013X
|
-
|
|
|
|
26/26 - HAMMER PISTON
BSD-1618700083.A4
1618700083
|
£11.37
|
£13.64
|
|
|
26/27 - STRIKER
BSD-1618710085.A5
1618710085
|
£10.61
|
£12.73
|
|
|
26/29 - PISTON PIN
BSD-1613100034.A13
1613100034
|
£2.94
|
£3.53
|
|
|
26/37 - GUIDE DISC
BSD-1610100016.A69
1610100016
|
£1.75
|
£2.10
|
|
|
26/65 - O-RING 13.0x3.0 MM
BSD-1610210244.A48
1610210244
|
£2.16
|
£2.59
|
|
|
33 - SWITCHING ELEMENT
BSD-1615820103.A15
1615820103
|
£2.74
|
£3.29
|
|
|
34 - RETAINING RING
BSD-1619P00829.A34
1619P00829
|
£1.75
|
£2.10
|
|
|
43 - GEAR HOUSING
BSD-16170006BF.A0
16170006BF
|
£27.23
|
£32.68
|
|
|
43/47 - PLAIN BEARING
BSD-1610202031.A0
1610202031
|
£5.58
|
£6.70
|
|
|
43/77 - SHAFT SEAL
BSD-1610283019.A132
1610283019
|
£7.72
|
£9.27
|
|
|
45 - HOLDING PLATE
BSD-1611016003.A16
1611016003
|
£2.27
|
£2.72
|
|
|
49 - SWITCHING ELEMENT
BSD-1615820104.A2
1615820104
|
£2.61
|
£3.13
|
|
|
54 - GUIDE ROD
BSD-1600A0013W.A0
1600A0013W
|
-
|
|
|
|
54/51 - SHIFT PLATE
BSD-1610021004.A2
1610021004
|
£1.75
|
£2.10
|
|
|
54/52 - SHIFT PLATE
BSD-1610021006.A2
1610021006
|
£1.84
|
£2.21
|
|
|
54/53 - SHIFT PLATE
BSD-1610021005.A15
1610021005
|
£1.75
|
£2.10
|
|
|
54/54 - GUIDE ROD
BSD-1613023005.A16
1613023005
|
£1.84
|
£2.21
|
|
|
54/75 - COMPRESSION SPRING
BSD-1614643025.A17
1614643025
|
£1.84
|
£2.21
|
|
|
54/76 - COMPRESSION SPRING
BSD-1614643023.A0
1614643023
|
£1.84
|
£2.21
|
|
|
55 - PROTECTIVE CAP
BSD-1610508052.A19
1610508052
|
£1.75
|
£2.10
|
|
|
60 - SPRING RETAINING RING
BSD-1614601077.A30
1614601077
|
£1.84
|
£2.21
|
|
|
63 - BALL DIN 5401-dia7MM-III-ST
BSD-1903230013.A86
1903230013
|
£2.27
|
£2.72
|
|
|
66 - BALL BEARING
BSD-2609110491.A16
2609110491
|
£5.57
|
£6.68
|
|
|
67 - GROOVE BALL BEARING
BSD-1610905047.A1
1610905047
|
£7.36
|
£8.83
|
|
|
68 - PLAIN WASHER
BSD-1600100037.A0
1600100037
|
£1.84
|
£2.21
|
|
|
69 - CHANGE-OVER SWITCH
BSD-1613231030.A1
1613231030
|
£1.84
|
£2.21
|
|
|
71 - TORX OVAL-HEAD SCREW 4x20
BSD-2603490023.A973
2603490023
|
£1.84
|
£2.21
|
|
|
72 - TORX OVAL-HEAD SCREW
BSD-1613435039.A1
1613435039
|
£1.84
|
£2.21
|
|
|
73 - LENS HEAD SCREW 3x10 ST
BSD-1613435034.A251
1613435034
|
£1.84
|
£2.21
|
|
|
120 - AUXILIARY HANDLE
BSD-160202508X.A3
160202508X
|
£19.91
|
£23.89
|
|
|
120/120 - AUXILIARY HANDLE
BSD-160202507H.A456
160202507H
|
£11.87
|
£14.24
|
|
|
120/124 - CLAMPING BAND dia50 MM
BSD-1611316021.A117
1611316021
|
£2.80
|
£3.36
|
|
|
120/125 - T-HEAD BOLT M8x40 MM
BSD-1613490002.A86
1613490002
|
£4.48
|
£5.37
|
|
|
120/802 - SUPPORT CLAMP
BSD-1617000475.A68
1617000475
|
£10.61
|
£12.73
|
|
|
651 - DEPTH-GAUGE
BSD-2603001009.A0
2603001009
|
£5.57
|
£6.68
|
|
|
801 - MOTOR HOUSING
BSD-16170006B8.A15
16170006B8
|
£28.59
|
£34.31
|
|
|
805 - POWER SUPPLY CORD EU 4.15m 2 x 1.0mm H07 RN-F
BSD-1607000392.A154
1607000392
|
£21.52
|
£25.83
|
|
|
807 - CABLE CLIP
BSD-1611035007.A25
1611035007
|
£1.84
|
£2.21
|
|
|
808 - NAMEPLATE
BSD-160111A3H6.A14
160111A3H6
|
£2.74
|
£3.29
|
|
|
816 - CARBON-BRUSH SET
BSD-1617014146.A8
1617014146
|
£12.64
|
£15.17
|
|
|
820 - INTERMEDIATE FLANGE
BSD-16170006BB.A1
16170006BB
|
£21.68
|
£26.01
|
|
|
824 - JACK SHAFT
BSD-16170006BC.A14
16170006BC
|
£38.46
|
£46.15
|
|
|
828 - STRIKER PIN
BSD-1613124084.A5
1613124084
|
£4.48
|
£5.37
|
|
|
843 - PROTECTION SLEEVE
BSD-16170006D3.A15
16170006D3
|
£11.87
|
£14.24
|
|
|
870 - CONNECTING CABLE
BSD-1619P01776.A3
1619P01776
|
£5.58
|
£6.70
|
|
|
873 - LENS HEAD SCREW 3x10 ST
BSD-1613435034.A254
1613435034
|
£1.84
|
£2.21
|
|
