1 - MOTOR HOUSING
BSD-1615108019.A3
1615108019
|
-
|
|
|
|
2 - FIELD 220-230V
BSD-2604220429.A95
2604220429
|
£23.86
|
£28.63
|
|
|
3/50 - FAN
BSD-1616610072.A66
1616610072
|
£2.27
|
£2.72
|
|
|
4 - SWITCH
BSD-2607200179.A3
2607200179
|
-
|
|
|
|
5 - POWER SUPPLY CORD I 4.15m 2 x 1.0mm H07 RN-F
BSD-1614460039.A14
1614460039
|
£16.74
|
£20.09
|
|
|
6 - GROMMET dia8.3-dia9.4x95 MM
BSD-2600703011.A679
2600703011
|
£2.94
|
£3.53
|
|
|
7 - CABLE CLIP
BSD-1611035005.A48
1611035005
|
£2.16
|
£2.59
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1611110206.A2
1611110206
|
-
|
|
|
|
10 - MANUFACTURER'S NAMEPLATE
BSD-1611110207.A1
1611110207
|
-
|
|
|
|
12 - SUPPRESSION CAPACITOR
BSD-1617328022.A1
1617328022
|
-
|
|
|
|
17 - HANDLE
BSD-1615133022.A10
1615133022
|
-
|
|
|
|
18 - AIR-DEFLECTOR RING
BSD-1610522008.A14
1610522008
|
£1.84
|
£2.21
|
|
|
20 - INTERMEDIATE FLANGE
BSD-1615700037.A55
1615700037
|
£40.80
|
£48.96
|
|
|
21 - RATCHET SLEEVE SDS-PLUS
BSD-1616490058.A81
1616490058
|
£218.41
|
£262.09
|
|
|
22 - CYLINDRICAL GEAR Z=46
BSD-1616320007.A91
1616320007
|
£7.36
|
£8.83
|
|
|
23 - CYLINDRICAL GEAR Z=6/21
BSD-1616320002.A85
1616320002
|
£24.45
|
£29.34
|
|
|
24 - TOOTHED SHAFT Z=6/10
BSD-1613060010.A59
1613060010
|
£54.42
|
£65.30
|
|
|
26 - HAMMER PISTON
BSD-1618700052.A15
1618700052
|
£13.78
|
£16.54
|
|
|
28 - STRIKER PIN
BSD-1613124026.A30
1613124026
|
£2.80
|
£3.36
|
|
|
29 - PISTON PIN
BSD-1613105012.A139
1613105012
|
£3.91
|
£4.69
|
|
|
30 - DRIVE BEARING
BSD-1615819005.A95
1615819005
|
£31.64
|
£37.97
|
|
|
31 - SUPPORT DISC 0.8 MM
BSD-1610100003.A134
1610100003
|
£1.84
|
£2.21
|
|
|
32 - CLAMP HANDLE
BSD-1612026023.A80
1612026023
|
£2.74
|
£3.29
|
|
|
34 - PROTECTIVE CAP L=24 MM
BSD-1610508016.A17
1610508016
|
-
|
|
|
|
35 - RUBBER RING
BSD-1610206021.A13
1610206021
|
£1.84
|
£2.21
|
|
|
37 - DAMPING BUSHING
BSD-1610390011.A64
1610390011
|
£3.72
|
£4.47
|
|
|
38 - SUPPORTING DISC
BSD-1610102022.A63
1610102022
|
£2.16
|
£2.59
|
|
|
39 - STRAIGHT PIN
BSD-1613100013.A60
1613100013
|
£2.16
|
£2.59
|
|
|
40 - HOLDING SPRING
BSD-1614690001.A84
1614690001
|
£1.84
|
£2.21
|
|
|
41 - ROLLER-CAGE ASSEMBLY
BSD-1610920003.A115
1610920003
|
£4.26
|
£5.11
|
|
|
44 - COMPRESSION SPRING
BSD-1614633001.A80
1614633001
|
£2.64
|
£3.17
|
|
|
45 - COMPRESSION SPRING
BSD-1614614001.A83
1614614001
|
£1.84
|
£2.21
|
|
|
48 - CONNECTING CABLE L=193 MM
BSD-2604448043.A50
2604448043
|
£1.75
|
£2.10
|
|
|
49 - CONNECTING CABLE L=193 MM
BSD-2604448043.A51
2604448043
|
£1.75
|
£2.10
|
|
|
50 - EARTH CONDUCTOR dia0.35 MM
BSD-2604448010.A57
2604448010
|
-
|
|
|
|
54 - O-RING 24.0x2.5 MM
BSD-1610210068.A29
1610210068
|
£1.75
|
£2.10
|
|
|
55 - SEAL RING
BSD-1610206023.A159
1610206023
|
£2.94
|
£3.53
|
|
|
56 - O-RING 14.0x3.0 MM
BSD-1610210070.A27
1610210070
|
£2.74
|
£3.29
|
|
|
58 - O-RING 18.0x3.0 MM
BSD-1610210058.A110
1610210058
|
£2.74
|
£3.29
|
|
|
59 - O-RING 6.0x2.5 MM
BSD-1610210069.A146
1610210069
|
£1.84
|
£2.21
|
|
|
60 - O-RING 10.0x3.5 MM
BSD-1610210073.A121
1610210073
|
£2.16
|
£2.59
|
|
|
61 - ROTARY SHAFT LIP SEAL
BSD-1610283017.A94
1610283017
|
£7.36
|
£8.83
|
|
|
62 - PLAIN BEARING
BSD-1610202026.A145
1610202026
|
£5.57
|
£6.68
|
|
|
65 - GROOVE BALL BEARING 8x22x7
BSD-1900900228.A93
1900900228
|
£6.61
|
£7.93
|
|
|
66 - BUSHING dia30xdia37x15.7 MM
BSD-1610301000.A82
1610301000
|
£3.34
|
£4.01
|
|
|
67 - NEEDLE BEARING
BSD-1610910064.A282
1610910064
|
£2.64
|
£3.17
|
|
|
70 - BALL DIN 5401-dia7MM-III-ST
BSD-1903230013.A447
1903230013
|
£2.27
|
£2.72
|
|
|
71 - SHIM WASHER 1.2 MM
BSD-1610101011.A96
1610101011
|
£1.75
|
£2.10
|
|
|
72 - RETAINING RING DIN 7993-A32
BSD-2916540018.A66
2916540018
|
£3.91
|
£4.69
|
|
|
73 - RETAINING RING DIN 9045-24
BSD-1614601009.A139
1614601009
|
£2.05
|
£2.46
|
|
|
74 - SOCKET HEAD CAP SCREW DIN 84-AM4x25-5.8
BSD-2910011132.A24
2910011132
|
£1.32
|
£1.58
|
|
|
76 - TAPPING SCREW ST-4.8x57.5-TORX.T20
BSD-1613435009.A53
1613435009
|
£1.75
|
£2.10
|
|
|
77 - TAPPING SCREW ST3.9x19-TORX.T20
BSD-1603435050.A132
1603435050
|
£2.33
|
£2.80
|
|
|
78 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A500
2910211019
|
£1.84
|
£2.21
|
|
|
79 - TAPPING SCREW DIN 7971-B 2.9x13
BSD-2910211206.A78
2910211206
|
£1.38
|
£1.66
|
|
|
79 - TAPPING SCREW DIN 7971-ST2.9x9.5-F
BSD-2910211005.A425
2910211005
|
£1.84
|
£2.21
|
|
|
80 - RECESSED-HEAD SCREW DIN 7981-ST3.5x9.5-F
BSD-2603435015.A396
2603435015
|
£2.27
|
£2.72
|
|
|
81 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A2680
2603410001
|
£1.84
|
£2.21
|
|
|
83 - BALL 5 MM V DIN 5401
BSD-1903230309.A108
1903230309
|
£1.84
|
£2.21
|
|
|
84 - SPRING LOCK WASHER DIN 128-A4-FST
BSD-2916690003.A962
2916690003
|
£1.75
|
£2.10
|
|
|
87 - RETAINING RING DIN 7993-A22
BSD-2916540012.A355
2916540012
|
-
|
|
|
|
88 - CONNECTING CABLE L=145 MM
BSD-1614431018.A24
1614431018
|
-
|
|
|
|
89 - CONNECTING CABLE L=80 MM
BSD-1614431019.A1
1614431019
|
-
|
|
|
|
90 - CHANGE-OVER SWITCH
BSD-2607200140.A9
2607200140
|
-
|
|
|
|
94 - DETENT PIN
BSD-1613120017.A115
1613120017
|
£1.84
|
£2.21
|
|
|
120 - AUXILIARY HANDLE M8
BSD-1612025041.A9
1612025041
|
£21.42
|
£25.71
|
|
|
121 - SUPPORT CLAMP dia43 MM
BSD-1618040064.A25
1618040064
|
£8.92
|
£10.70
|
|
|
122 - T-HEAD BOLT M8x40 MM
BSD-1613490002.A533
1613490002
|
£4.48
|
£5.37
|
|
|
123 - CLAMPING BAND dia43 MM
BSD-1611316006.A242
1611316006
|
£2.61
|
£3.13
|
|
|
691 - CARRYING CASE
BSD-1615438250.A3
1615438250
|
-
|
|
|
|
720/8 - AUXILIARY HANDLE dia43 MM
BSD-1612025047.A24
1612025047
|
-
|
|
|
|
751 - DEPTH-GAUGE SW 6x210 MM
BSD-1613001009.A321
1613001009
|
£3.91
|
£4.69
|
|
|
751 - DEPTH-GAUGE SW 6x210 MM
BSD-1613001005.A242
1613001005
|
-
|
|
|
|
751 - DEPTH-GAUGE SW 6x210 MM
BSD-1613001006.A12
1613001006
|
-
|
|
|
|
803 - ARMATURE WITH FAN 220-230V
BSD-1614010039.A16
1614010039
|
-
|
|
|
|
808 - NAMEPLATE
BSD-160111A3HD.A38
160111A3HD
|
£2.74
|
£3.29
|
|
|
811 - CARBON BRUSH
BSD-1617014114.A44
1617014114
|
£10.61
|
£12.73
|
|
|
814 - PARTS SET
BSD-1617000131.A10
1617000131
|
-
|
|
|
|
816 - GEAR HOUSING
BSD-1615806079.A3
1615806079
|
-
|
|
|
|
821 - RATCHET SLEEVE
BSD-1617000931.A11
1617000931
|
£283.50
|
£340.20
|
|
|
827 - STRIKER
BSD-1617000338.A75
1617000338
|
£28.59
|
£34.31
|
|
|
833 - PROTECTION SLEEVE S2S
BSD-1617000168.A4
1617000168
|
£5.87
|
£7.04
|
|
|
843 - BRUSH PLATE
BSD-2601015047.A55
2601015047
|
-
|
|
|
|
863 - GROOVE BALL BEARING 9x24x7
BSD-1610905048.A350
1610905048
|
£8.67
|
£10.41
|
|
|
864 - GROOVE BALL BEARING 7x19x6
BSD-1610905025.A208
1610905025
|
£6.85
|
£8.22
|
|
