1 - MOTOR HOUSING
BSD-1615108026.A16
1615108026
|
-
|
|
|
|
2 - FIELD 230V
BSD-1614220113.A0
1614220113
|
-
|
|
|
|
3/50 - FAN
BSD-1616610072.A80
1616610072
|
£2.16
|
£2.59
|
|
|
4 - SWITCH
BSD-1617200082.A3
1617200082
|
£21.68
|
£26.01
|
|
|
6 - GROMMET dia8.3-dia9.4x95 MM
BSD-2600703011.A625
2600703011
|
£2.80
|
£3.36
|
|
|
7 - CABLE CLIP
BSD-1611035005.A11
1611035005
|
£2.16
|
£2.59
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1611110727.A0
1611110727
|
-
|
|
|
|
10 - MANUFACTURER'S NAMEPLATE
BSD-1611110728.A0
1611110728
|
-
|
|
|
|
12 - SUPPRESSION FILTER
BSD-1607328028.A222
1607328028
|
£5.30
|
£6.36
|
|
|
13 - BRUSH HOLDER
BSD-1614449002.A0
1614449002
|
-
|
|
|
|
17 - HOUSING COVER
BSD-1615132031.A26
1615132031
|
-
|
|
|
|
18 - AIR-DEFLECTOR RING
BSD-1610522008.A40
1610522008
|
£1.75
|
£2.10
|
|
|
20 - INTERMEDIATE FLANGE
BSD-1615700037.A105
1615700037
|
£40.80
|
£48.96
|
|
|
21 - RATCHET SLEEVE SDS-PLUS
BSD-1616490058.A109
1616490058
|
£218.41
|
£262.09
|
|
|
22 - CYLINDRICAL GEAR Z=46
BSD-1616320007.A40
1616320007
|
£7.36
|
£8.83
|
|
|
23 - CYLINDRICAL GEAR Z=6/21
BSD-1616320002.A100
1616320002
|
£24.45
|
£29.34
|
|
|
24 - TOOTHED SHAFT Z=6/10
BSD-1613060010.A0
1613060010
|
£54.42
|
£65.30
|
|
|
26 - HAMMER PISTON
BSD-1618700052.A97
1618700052
|
£13.12
|
£15.75
|
|
|
28 - STRIKER PIN
BSD-1613124026.A114
1613124026
|
£2.80
|
£3.36
|
|
|
29 - PISTON PIN
BSD-1613105012.A222
1613105012
|
£3.72
|
£4.47
|
|
|
30 - DRIVE BEARING
BSD-1615819005.A0
1615819005
|
£31.64
|
£37.97
|
|
|
31 - SUPPORT DISC 0.8 MM
BSD-1610100003.A54
1610100003
|
£1.75
|
£2.10
|
|
|
32 - CLAMP HANDLE
BSD-1612026023.A125
1612026023
|
£2.61
|
£3.13
|
|
|
34 - PROTECTIVE CAP L=17 MM. SDS-PLUS
BSD-1610508008.A46
1610508008
|
£2.16
|
£2.59
|
|
|
35 - RUBBER RING
BSD-1610206021.A99
1610206021
|
£1.75
|
£2.10
|
|
|
37 - DAMPING BUSHING
BSD-1610390011.A5
1610390011
|
£3.72
|
£4.47
|
|
|
38 - SUPPORTING DISC
BSD-1610102022.A22
1610102022
|
£2.16
|
£2.59
|
|
|
39 - STRAIGHT PIN
BSD-1613100013.A129
1613100013
|
£2.16
|
£2.59
|
|
|
40 - HOLDING SPRING
BSD-1614690001.A109
1614690001
|
£1.75
|
£2.10
|
|
|
41 - ROLLER-CAGE ASSEMBLY
BSD-1610920003.A88
1610920003
|
£4.26
|
£5.11
|
|
|
43 - BRUSH PLATE
BSD-2601015047.A121
2601015047
|
-
|
|
|
|
44 - COMPRESSION SPRING
BSD-1614633001.A33
1614633001
|
£2.52
|
£3.02
|
|
|
45 - COMPRESSION SPRING
BSD-1614614001.A53
1614614001
|
£1.75
|
£2.10
|
|
|
49 - CABLE L=130 MM
BSD-2604448005.A228
2604448005
|
£1.75
|
£2.10
|
|
|
54 - O-RING 24.0x2.5 MM
BSD-1610210068.A99
1610210068
|
£1.75
|
£2.10
|
|
|
55 - SEAL RING
BSD-1610206023.A72
1610206023
|
£2.80
|
£3.36
|
|
|
56 - O-RING 14.0x3.0 MM
BSD-1610210070.A81
1610210070
|
£2.61
|
£3.13
|
|
|
58 - O-RING 18.0x3.0 MM
BSD-1610210058.A30
1610210058
|
£2.61
|
£3.13
|
|
|
59 - O-RING 6.0x2.5 MM
BSD-1610210069.A89
1610210069
|
£1.75
|
£2.10
|
|
|
60 - O-RING 10.0x3.5 MM
BSD-1610210073.A64
1610210073
|
£2.16
|
£2.59
|
|
|
61 - ROTARY SHAFT LIP SEAL
BSD-1610283017.A41
1610283017
|
£7.36
|
£8.83
|
|
|
62 - PLAIN BEARING
BSD-1610202026.A182
1610202026
|
£5.30
|
£6.36
|
|
|
63 - GROOVE BALL BEARING 9x24x7
BSD-1610905048.A409
1610905048
|
£8.67
|
£10.41
|
|
|
64 - BALL BEARING 7x19x6
BSD-2600905032.A1742
2600905032
|
£5.30
|
£6.36
|
|
|
65 - GROOVE BALL BEARING 8x22x7
BSD-1900900228.A115
1900900228
|
£6.61
|
£7.93
|
|
|
66 - BUSHING dia30xdia37x15.7 MM
BSD-1610301000.A38
1610301000
|
£3.34
|
£4.01
|
|
|
67 - NEEDLE BEARING
BSD-1610910064.A338
1610910064
|
£2.52
|
£3.02
|
|
|
68 - ROLLER-CAGE ASSEMBLY
BSD-1610920004.A47
1610920004
|
£3.80
|
£4.56
|
|
|
69 - SUPPORT DISC 1.0 MM
BSD-1610102618.A17
1610102618
|
-
|
|
|
|
70 - BALL DIN 5401-dia7MM-III-ST
BSD-1903230013.A364
1903230013
|
£2.16
|
£2.59
|
|
|
71 - SHIM WASHER 1.2 MM
BSD-1610101011.A0
1610101011
|
£1.75
|
£2.10
|
|
|
72 - RETAINING RING DIN 7993-A32
BSD-2916540018.A43
2916540018
|
£3.72
|
£4.47
|
|
|
73 - RETAINING RING DIN 9045-24
BSD-1614601009.A165
1614601009
|
£1.95
|
£2.34
|
|
|
76 - TAPPING SCREW ST-4.8x57.5-TORX.T20
BSD-1613435009.A113
1613435009
|
£1.75
|
£2.10
|
|
|
77 - TAPPING SCREW DIN 7971-ST3.9x22-F
BSD-2910211021.A325
2910211021
|
£1.75
|
£2.10
|
|
|
78 - TAPPING SCREW ST3.9x19-TORX.T20
BSD-1603435050.A78
1603435050
|
£2.33
|
£2.80
|
|
|
79 - TAPPING SCREW DIN 7971-B 2.9x13
BSD-2910211206.A0
2910211206
|
£1.32
|
£1.58
|
|
|
80 - RECESSED-HEAD SCREW DIN 7981-ST3.5x9.5-F
BSD-2603435015.A335
2603435015
|
£2.16
|
£2.59
|
|
|
81 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A2635
2603410001
|
£1.75
|
£2.10
|
|
|
83 - BALL 5 MM V DIN 5401
BSD-1903230309.A62
1903230309
|
£1.75
|
£2.10
|
|
|
87 - RETAINING RING DIN 7993-A22
BSD-2916540012.A414
2916540012
|
-
|
|
|
|
94 - DETENT PIN
BSD-1613120017.A39
1613120017
|
£1.75
|
£2.10
|
|
|
120 - AUXILIARY HANDLE M8
BSD-1612025041.A17
1612025041
|
£21.42
|
£25.71
|
|
|
121 - SUPPORT CLAMP dia43 MM
BSD-1618040064.A33
1618040064
|
£8.49
|
£10.19
|
|
|
122 - T-HEAD BOLT M8x40 MM
BSD-1613490002.A536
1613490002
|
£4.26
|
£5.11
|
|
|
123 - CLAMPING BAND dia43 MM
BSD-1611316006.A345
1611316006
|
£2.61
|
£3.13
|
|
|
651 - DEPTH-GAUGE SW 6x210 MM
BSD-1613001009.A236
1613001009
|
£3.72
|
£4.47
|
|
|
691 - CARRYING CASE
BSD-1615438250.A0
1615438250
|
-
|
|
|
|
720/8 - AUXILIARY HANDLE dia43 MM
BSD-1612025047.A16
1612025047
|
-
|
|
|
|
803 - ARMATURE WITH FAN 220-240V
BSD-1614010052.A0
1614010052
|
-
|
|
|
|
805 - POWER SUPPLY CORD EU 4.15m 2 x 1.0mm H07 RN-F
BSD-1607000227.A598
1607000227
|
£23.86
|
£28.63
|
|
|
808 - NAMEPLATE
BSD-160111A3HC.A123
160111A3HC
|
£2.61
|
£3.13
|
|
|
811 - CARBON BRUSH
BSD-1607014117.A111
1607014117
|
£10.10
|
£12.12
|
|
|
814 - BRUSH HOLDER
BSD-1617000130.A2
1617000130
|
£3.80
|
£4.56
|
|
|
816 - GEAR HOUSING
BSD-1615806081.A17
1615806081
|
£33.45
|
£40.14
|
|
|
821 - RATCHET SLEEVE
BSD-1617000931.A85
1617000931
|
£283.50
|
£340.20
|
|
|
827 - STRIKER
BSD-1617000338.A133
1617000338
|
£27.23
|
£32.68
|
|
|
833 - PROTECTION SLEEVE
BSD-1617000163.A12
1617000163
|
£7.36
|
£8.83
|
|
|
866 - NEEDLE BEARING dia30xdia37x12 MM
BSD-1610910063.A40
1610910063
|
£5.58
|
£6.70
|
|
