4 - ON-OFF SWITCH
BSD-2607200371.A31
2607200371
|
-
|
|
|
|
5 - POWER SUPPLY CORD CH 230V 4.15m 2 x 1.0mm H05 RN-F
BSD-1604460440.A42
1604460440
|
£21.52
|
£25.83
|
|
|
6 - GROMMET dia9.2-dia12x120 MM
BSD-3600703011.A636
3600703011
|
£2.80
|
£3.36
|
|
|
6 - GROMMET dia11.5-dia15.0x150 MM
BSD-1600703009.A121
1600703009
|
£5.58
|
£6.70
|
|
|
7 - FASTENING CLAMP
BSD-1601302014.A34
1601302014
|
£2.61
|
£3.13
|
|
|
12 - HOUSING COVER
BSD-1615500259.A6
1615500259
|
-
|
|
|
|
13 - GEAR HOUSING
BSD-1615806055.A1
1615806055
|
-
|
|
|
|
14 - HANDLE COVER
BSD-1615132024.A17
1615132024
|
-
|
|
|
|
15 - FAN
BSD-1616610052.A32
1616610052
|
-
|
|
|
|
17 - RUBBER RING
BSD-1610206017.A75
1610206017
|
-
|
|
|
|
18 - AIR-DEFLECTOR RING
BSD-1610522005.A14
1610522005
|
-
|
|
|
|
20 - BEARING PEDESTAL
BSD-1615820087.A3
1615820087
|
-
|
|
|
|
24 - CRANKSHAFT
BSD-1613124019.A12
1613124019
|
-
|
|
|
|
25 - ECCENTRIC BOLT
BSD-1613180002.A4
1613180002
|
-
|
|
|
|
26 - PRESSURE SPINDLE
BSD-1613105010.A13
1613105010
|
-
|
|
|
|
27 - COMPRESSION SPRING
BSD-1604612002.A18
1604612002
|
-
|
|
|
|
28 - SUPPRESSION FILTER
BSD-1607328028.A200
1607328028
|
£5.30
|
£6.36
|
|
|
29 - SHIM WASHER 1.8 MM
BSD-1610101610.A14
1610101610
|
-
|
|
|
|
30 - SHIM 0.2 MM
BSD-1610132004.A11
1610132004
|
-
|
|
|
|
31 - CONNECTING ROD
BSD-1612001030.A12
1612001030
|
-
|
|
|
|
32 - CYLINDRICAL GEAR Z=53/6
BSD-1616317025.A4
1616317025
|
-
|
|
|
|
33 - SPRING RETAINING RING DIN 471-32x1.5-FSt
BSD-2916650018.A13
2916650018
|
-
|
|
|
|
34 - HAMMER PISTON
BSD-1618700051.A12
1618700051
|
-
|
|
|
|
35 - HOLLOW SHAFT Z=6
BSD-1616130005.A17
1616130005
|
-
|
|
|
|
36 - STRIKER
BSD-1618710046.A3
1618710046
|
-
|
|
|
|
37 - COMPRESSION SPRING
BSD-1614618001.A9
1614618001
|
-
|
|
|
|
38 - BACKUP RING
BSD-1610328010.A3
1610328010
|
-
|
|
|
|
39 - SPRING RETAINING RING DIN 471 25x1.2
BSD-2916650014.A109
2916650014
|
£1.75
|
£2.10
|
|
|
40 - BEARING SLEEVE
BSD-1616334009.A13
1616334009
|
-
|
|
|
|
41 - O-RING 62.0x4.0 MM
BSD-1610210089.A7
1610210089
|
-
|
|
|
|
42 - DRILLING SPINDLE Z=6
BSD-1618597041.A12
1618597041
|
-
|
|
|
|
43 - BEARING SLEEVE
BSD-1618597040.A2
1618597040
|
-
|
|
|
|
44 - FRICTION WASHER
BSD-1610120023.A3
1610120023
|
-
|
|
|
|
46 - STRAIGHT PIN
BSD-1613101004.A2
1613101004
|
-
|
|
|
|
47 - SUPPORTING DISC 3.0 MM
BSD-1610102016.A6
1610102016
|
-
|
|
|
|
48 - O-RING 11.0x7.0 MM
BSD-1610210035.A29
1610210035
|
£2.52
|
£3.02
|
|
|
49 - BACKUP RING
BSD-1610508006.A27
1610508006
|
-
|
|
|
|
50 - BRUSH HOLDER
BSD-1604336017.A106
1604336017
|
£7.36
|
£8.83
|
|
|
51 - SPIRAL SPRING
BSD-1604652006.A241
1604652006
|
£1.75
|
£2.10
|
|
|
52 - HOUSING COVER
BSD-1615500257.A0
1615500257
|
-
|
|
|
|
54 - BACKUP RING
BSD-1610220011.A12
1610220011
|
-
|
|
|
|
55 - O-RING 24.0x5.0 MM
BSD-1610210061.A13
1610210061
|
-
|
|
|
|
56 - ROTARY SHAFT LIP SEAL dia 26x15x7.5 MM
BSD-1610283015.A27
1610283015
|
£4.75
|
£5.70
|
|
|
58 - SEALING FRAME
BSD-1611015025.A4
1611015025
|
-
|
|
|
|
60 - O-RING 14.0x2.3 MM
BSD-1610210026.A26
1610210026
|
£1.75
|
£2.10
|
|
|
61 - HOLDING SPRING
BSD-1614680000.A3
1614680000
|
-
|
|
|
|
62 - CONTROL LEVER
BSD-1612026015.A2
1612026015
|
-
|
|
|
|
64 - O-RING 45x2.5MM
BSD-1900210145.A53
1900210145
|
£1.75
|
£2.10
|
|
|
65 - INTERMEDIATE RING
BSD-1610300051.A18
1610300051
|
-
|
|
|
|
66 - BALL DIN 5401-5 G28
BSD-1903230009.A554
1903230009
|
£1.75
|
£2.10
|
|
|
67 - BALL DIN 5401-6 G28
BSD-1903230011.A377
1903230011
|
£2.61
|
£3.13
|
|
|
69 - O-RING 18.0x3.0 MM
BSD-1610210058.A85
1610210058
|
£2.61
|
£3.13
|
|
|
70 - BIT HOLDER
BSD-1618598131.A25
1618598131
|
-
|
|
|
|
70/3 - PROTECTION SLEEVE
BSD-1610499009.A21
1610499009
|
-
|
|
|
|
70/4 - COMPRESSION SPRING
BSD-1614632000.A23
1614632000
|
-
|
|
|
|
70/6 - PROTECTIVE CAP L=17 MM. SDS-PLUS
BSD-1610508008.A60
1610508008
|
£2.16
|
£2.59
|
|
|
70/7 - BALL DIN 5401-dia7MM-III-ST
BSD-1903230013.A413
1903230013
|
£2.16
|
£2.59
|
|
|
70/8 - THRUST RING
BSD-1610251002.A15
1610251002
|
-
|
|
|
|
70/10 - HOLDING PLATE
BSD-1610190007.A23
1610190007
|
-
|
|
|
|
70/11 - RETAINING SNAP RING
BSD-1610250003.A35
1610250003
|
£5.58
|
£6.70
|
|
|
70/13 - RETAINING RING DIN 7993-A22
BSD-2916540012.A372
2916540012
|
-
|
|
|
|
72 - ROTARY SHAFT LIP SEAL dia13.8xdia26x7.5 MM
BSD-1610283014.A18
1610283014
|
-
|
|
|
|
74 - NEEDLE BEARING dia35xdia42x12 MM
BSD-1610910051.A42
1610910051
|
-
|
|
|
|
75 - NEEDLE BEARING dia14xdia22x13 MM
BSD-1610910056.A33
1610910056
|
-
|
|
|
|
76 - NEEDLE BEARING
BSD-1610910069.A1
1610910069
|
-
|
|
|
|
77 - NEEDLE BEARING dia8xdia12x10 MM
BSD-1610910057.A44
1610910057
|
£2.80
|
£3.36
|
|
|
78 - GROOVE BALL BEARING 25x47x12
BSD-1900900275.A34
1900900275
|
-
|
|
|
|
80 - GROOVE BALL BEARING 10x26x8
BSD-1610905002.A27
1610905002
|
-
|
|
|
|
81 - GROOVE BALL BEARING
BSD-1900900410.A11
1900900410
|
-
|
|
|
|
82 - LUBRICATING FELT
BSD-1610205003.A39
1610205003
|
-
|
|
|
|
83 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A2700
2603410001
|
£1.75
|
£2.10
|
|
|
84 - TAPPING SCREW B 4.8x68 MM
BSD-1613412001.A43
1613412001
|
£1.75
|
£2.10
|
|
|
85 - SCREW B 4.8x45 MM
BSD-3603415560.A211
3603415560
|
£1.75
|
£2.10
|
|
|
86 - TAPPING SCREW DIN 7971-BZ4.8x32
BSD-2910211037.A116
2910211037
|
£1.75
|
£2.10
|
|
|
87 - TAPPING SCREW DIN 7971-ST3.9x22-F
BSD-2910211021.A206
2910211021
|
£1.75
|
£2.10
|
|
|
88 - TAPPING SCREW DIN 7971-ST3.9x13-F
BSD-2910211018.A472
2910211018
|
£1.75
|
£2.10
|
|
|
89 - TAPPING SCREW DIN 7971-BZ3.9x9.5
BSD-2910211017.A130
2910211017
|
-
|
|
|
|
90 - HEX SOCKET HEAD CAP SCREW DIN 912-M 5x30-8.8
BSD-2910141166.A98
2910141166
|
£1.75
|
£2.10
|
|
|
94 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A38
2910021118
|
£1.75
|
£2.10
|
|
|
95 - SOCKET HEAD CAP SCREW DIN 84-BM4x30-8.8
BSD-2910021134.A177
2910021134
|
£1.75
|
£2.10
|
|
|
99 - HEX SOCKET HEAD CAP SCREW DIN 912-M5x40-8.8
BSD-2910141170.A93
2910141170
|
£2.61
|
£3.13
|
|
|
100 - TAPPING SCREW BZ 3.9x19 DIN 7972
BSD-2910601120.A39
2910601120
|
-
|
|
|
|
110 - NAMEPLATE
BSD-1601110449.A11
1601110449
|
-
|
|
|
|
115 - DEPTH-GAUGE SW 6x330 MM
BSD-1613001003.A14
1613001003
|
£4.25
|
£5.10
|
|
|
120 - AUXILIARY HANDLE M8
BSD-1612025019.A349
1612025019
|
£6.52
|
£7.83
|
|
|
121 - SUPPORT CLAMP
BSD-1618040077.A11
1618040077
|
-
|
|
|
|
122 - STUD BOLT M8
BSD-1613521001.A32
1613521001
|
£5.58
|
£6.70
|
|
|
123 - CLAMPING BAND dia43 MM
BSD-1611316003.A88
1611316003
|
£2.61
|
£3.13
|
|
|
124 - STRAIGHT PIN
BSD-1613100012.A66
1613100012
|
£2.61
|
£3.13
|
|
|
125 - WING SCREW M6x25 MM
BSD-1613480009.A41
1613480009
|
£1.88
|
£2.25
|
|
|
126 - HEX NUT M6
BSD-1613300006.A78
1613300006
|
£1.32
|
£1.58
|
|
|
127 - CLAMPING PLATE
BSD-1611030009.A25
1611030009
|
-
|
|
|
|
650 - CARRYING CASE
BSD-1615438070.A1
1615438070
|
-
|
|
|
|
801 - PARTS SET
BSD-1617000086.A4
1617000086
|
-
|
|
|
|
802 - PARTS SET 220-230V
BSD-1617000140.A0
1617000140
|
-
|
|
|
|
803 - ARMATURE 220-230V
BSD-1614010027.A14
1614010027
|
-
|
|
|
|
808 - NAMEPLATE
BSD-160111A3HC.A140
160111A3HC
|
£2.61
|
£3.13
|
|
|
810 - CARBON-BRUSH SET
BSD-1614014106.A2
1614014106
|
-
|
|
|
|
813 - AUXILIARY HANDLE
BSD-1612025020.A35
1612025020
|
£26.12
|
£31.35
|
|
|
821 - BEVEL GEAR Z=33
BSD-1616333005.A7
1616333005
|
-
|
|
|
|
822 - PARTS SET Z=9/48
BSD-1617000929.A1
1617000929
|
-
|
|
|
|
876 - NEEDLE BEARING dia14xdia22x13 MM
BSD-1610910056.A41
1610910056
|
-
|
|
|
