1 - NO LONGER AVAILABLE
BDE-000000-00.A127690
000000-00
|
-
|
|
|
|
2 - GUIDE SA
BDE-586415-00.A1
586415-00
|
£16.03
|
£19.24
|
|
|
3 - NO LONGER AVAILABLE
BDE-000000-00.A127691
000000-00
|
-
|
|
|
|
4 - NO LONGER AVAILABLE
BDE-000000-00.A127692
000000-00
|
-
|
|
|
|
5 - LENS
BDE-586045-00.A5
586045-00
|
£1.66
|
£1.99
|
|
|
6 - ROLLER
BDE-586411-00.A1
586411-00
|
£1.78
|
£2.13
|
|
|
7 - TRIGGER
BDE-587114-01.A13
587114-01
|
£1.66
|
£1.99
|
|
|
8 - SWITCH
BDE-581070-00.A20
581070-00
|
£19.90
|
£23.88
|
|
|
9 - HANDLE COVER
BDE-587090-00.A3
587090-00
|
£7.85
|
£9.42
|
|
|
11 - SCREW
BDE-330065-08.A432
330065-08
|
£1.66
|
£1.99
|
|
|
13 - CORD CLAMP
BDE-821070.A8
821070
|
£1.66
|
£1.99
|
|
|
14 - CORDSET (M/PLUG) GB GB
BDE-582319-23.A4
582319-23
|
£30.08
|
£36.10
|
|
|
14 - CORDSET (M/PLUG) LX
BDE-582319-24.A4
582319-24
|
£38.80
|
£46.56
|
|
|
15 - NO LONGER AVAILABLE
BDE-000000-00.A127693
000000-00
|
-
|
|
|
|
16 - STOP
BDE-494477-00.A1
494477-00
|
£3.30
|
£3.96
|
|
|
17 - NO LONGER AVAILABLE
BDE-000000-00.A127694
000000-00
|
-
|
|
|
|
18 - HANDLE
BDE-587085-00.A0
587085-00
|
£7.18
|
£8.62
|
|
|
19 - DRIVER
BDE-586413-00.A1
586413-00
|
£3.22
|
£3.86
|
|
|
20 - BUSHING
BDE-1005496-00.A3
1005496-00
|
£1.66
|
£1.99
|
|
|
21 - NO LONGER AVAILABLE
BDE-000000-00.A127695
000000-00
|
-
|
|
|
|
22 - NO LONGER AVAILABLE
BDE-000000-00.A127696
000000-00
|
-
|
|
|
|
24 - SCREW
BDE-330019-33.A16
330019-33
|
£1.66
|
£1.99
|
|
|
28 - RING
BDE-577746-00.A26
577746-00
|
£1.66
|
£1.99
|
|
|
29 - GUARD SA
BDE-586597-00.A1
586597-00
|
£7.01
|
£8.41
|
|
|
30 - AXLE
BDE-586412-00.A5
586412-00
|
-
|
|
|
|
31 - BELLOWS
BDE-588640-00.A1
588640-00
|
-
|
|
|
|
32 - CARRIER
BDE-586423-00.A5
586423-00
|
£1.66
|
£1.99
|
|
|
33 - SPRING COMPRESSION
BDE-586421-00.A5
586421-00
|
£1.66
|
£1.99
|
|
|
34 - RETAINER
BDE-586422-00.A1
586422-00
|
-
|
|
|
|
35 - ARMATURE 230V GB
BDE-489251-00.A1
489251-00
|
£113.07
|
£135.68
|
|
|
35 - ARMATURE 120V LX
BDE-489252-00.A8
489252-00
|
£113.07
|
£135.68
|
|
|
36 - SCREW
BDE-330019-30.A6
330019-30
|
£1.66
|
£1.99
|
|
|
37 - MOTOR COVER
BDE-585169-00.A4
585169-00
|
£7.64
|
£9.17
|
|
|
38 - CORD PROTECTOR
BDE-403395-00.A38
403395-00
|
£1.66
|
£1.99
|
|
|
39 - FIELD 230V GB
BDE-489254-00.A1
489254-00
|
£37.35
|
£44.82
|
|
|
39 - FIELD 115V LX
BDE-489255-00.A8
489255-00
|
£38.80
|
£46.56
|
|
|
40 - BEARING
BDE-577745-00.A31
577745-00
|
£7.85
|
£9.42
|
|
|
41 - SLEEVE INSULATING
BDE-590191-00.A30
590191-00
|
£1.66
|
£1.99
|
|
|
42 - LEVER
BDE-586435-00.A1
586435-00
|
-
|
|
|
|
43 - AXLE
BDE-586436-00.A4
586436-00
|
£2.26
|
£2.71
|
|
|
44 - BRUSH PAIR 230V GB
BDE-489256-00.A2
489256-00
|
£16.03
|
£19.24
|
|
|
44 - BRUSH PAIR 115V LX
BDE-489257-00.A9
489257-00
|
£18.91
|
£22.69
|
|
|
45 - BRUSH SPRING
BDE-487377-00.A18
487377-00
|
£2.26
|
£2.71
|
|
|
46 - FAN SA
BDE-586611-00.A3
586611-00
|
£14.57
|
£17.48
|
|
|
47 - SCREW
BDE-324119-02.A102
324119-02
|
£1.66
|
£1.99
|
|
|
48 - BAFFLE
BDE-586614-00.A3
586614-00
|
£4.58
|
£5.49
|
|
|
49 - SCREW
BDE-330019-30.A5
330019-30
|
£1.66
|
£1.99
|
|
|
50 - NO LONGER AVAILABLE LX
BDE-000000-00.A127697
000000-00
|
-
|
|
|
|
50 - NO LONGER AVAILABLE GB
BDE-000000-00.A127698
000000-00
|
-
|
|
|
|
51 - MICRO SWITCH
BDE-477287-02.A2
477287-02
|
£11.87
|
£14.24
|
|
|
52 - END CAP
BDE-585170-00.A1
585170-00
|
-
|
|
|
|
53 - SLIDER SA
BDE-491755-00.A0
491755-00
|
£7.01
|
£8.41
|
|
|
54 - RETAINER
BDE-479165-00.A2
479165-00
|
£1.66
|
£1.99
|
|
|
55 - CABLE SA
BDE-586433-00.A0
586433-00
|
-
|
|
|
|
57 - MOTOR HOUSING SA
BDE-586609-04.A1
586609-04
|
-
|
|
|
|
99 - DETENT
BDE-326467-00.A197
326467-00
|
£1.66
|
£1.99
|
|
|
100 - NO LONGER AVAILABLE
BDE-000000-00.A127699
000000-00
|
-
|
|
|
|
101 - MICRO SWITCH
BDE-477287-01.A3
477287-01
|
-
|
|
|
|
102 - SCREW TORX
BDE-324007-11.A185
324007-11
|
£1.66
|
£1.99
|
|
|
103 - FILTER
BDE-488067-00.A9
488067-00
|
£1.66
|
£1.99
|
|
|
104 - COVER
BDE-586031-00.A5
586031-00
|
£4.69
|
£5.63
|
|
|
105 - O RING
BDE-323711-56.A24
323711-56
|
£1.66
|
£1.99
|
|
|
106 - O RING
BDE-323711-48.A20
323711-48
|
£1.66
|
£1.99
|
|
|
107 - ECCENTRIC
BDE-586032-00.A1
586032-00
|
£1.66
|
£1.99
|
|
|
108 - SPRING
BDE-586033-00.A5
586033-00
|
-
|
|
|
|
109 - SLIDER
BDE-586036-00.A5
586036-00
|
£3.30
|
£3.96
|
|
|
110 - SELECTOR
BDE-586038-00.A1
586038-00
|
£1.66
|
£1.99
|
|
|
111 - COVER-TOP
BDE-585168-02.A0
585168-02
|
£3.80
|
£4.56
|
|
|
112 - PISTON KIT
BDE-488689-00.A2
488689-00
|
£30.08
|
£36.10
|
|
|
114 - PIN
BDE-581656-00.A5
581656-00
|
£1.66
|
£1.99
|
|
|
117 - O RING
BDE-584703-00.A7
584703-00
|
£4.69
|
£5.63
|
|
|
118 - CRANKSHAFT >352010
BDE-N513280.A7
N513280
|
£112.86
|
£135.43
|
|
|
119 - O RING
BDE-323711-26.A10
323711-26
|
£1.66
|
£1.99
|
|
|
120 - HOUSING SA
BDE-489243-00.A0
489243-00
|
£161.75
|
£194.10
|
|
|
130 - O RING
BDE-577744-07.A14
577744-07
|
£1.66
|
£1.99
|
|
|
131 - SLIDER
BDE-586034-00.A1
586034-00
|
£2.26
|
£2.71
|
|
|
132 - CYLINDER KIT
BDE-N146117.A3
N146117
|
£76.16
|
£91.39
|
|
|
135 - BUSH
BDE-584715-00.A7
584715-00
|
£2.78
|
£3.34
|
|
|
136 - O RING
BDE-584706-00.A11
584706-00
|
£3.30
|
£3.96
|
|
|
137 - RAM
BDE-489180-00.A7
489180-00
|
£24.39
|
£29.27
|
|
|
139 - BUSH
BDE-478650-00.A19
478650-00
|
£2.26
|
£2.71
|
|
|
140 - SPRING
BDE-584726-00.A7
584726-00
|
£2.26
|
£2.71
|
|
|
151 - REPAIR KIT
BDE-1007908-00.A5
1007908-00
|
£110.21
|
£132.25
|
|
|
152 - SPACER
BDE-479974-00.A20
479974-00
|
£1.66
|
£1.99
|
|
|
153 - GEAR
BDE-488688-00.A6
488688-00
|
£10.85
|
£13.02
|
|
|
154 - BEARING BALL
BDE-577745-02.A7
577745-02
|
£7.18
|
£8.62
|
|
|
155 - BEARING NEEDLE
BDE-489245-00.A1
489245-00
|
£10.85
|
£13.02
|
|
|
156 - BEARING BRASS BUSH
BDE-489239-00.A6
489239-00
|
£3.80
|
£4.56
|
|
|
157 - SEAL
BDE-586022-00.A14
586022-00
|
£1.82
|
£2.19
|
|
|
158 - BEARING
BDE-330003-39.A21
330003-39
|
£2.78
|
£3.34
|
|
|
159 - SEAL
BDE-327141-08.A19
327141-08
|
£5.88
|
£7.06
|
|
|
160 - HOUSING SA
BDE-489247-00.A0
489247-00
|
-
|
|
|
|
161 - PIN
BDE-586392-00.A1
586392-00
|
£1.82
|
£2.19
|
|
|
162 - SEAL
BDE-586403-00.A1
586403-00
|
£1.66
|
£1.99
|
|
|
165 - CLUTCH SA
BDE-N079392.A1
N079392
|
£192.14
|
£230.57
|
|
|
177 - SPRING COMPRESSION
BDE-491804-00.A1
491804-00
|
£2.71
|
£3.25
|
|
|
178 - NO LONGER AVAILABLE
BDE-000000-00.A127700
000000-00
|
-
|
|
|
|
179 - SHAFT
BDE-494609-00.A0
494609-00
|
£36.42
|
£43.70
|
|
|
180 - NO LONGER AVAILABLE
BDE-000000-00.A127701
000000-00
|
-
|
|
|
|
181 - BEARING BALL
BDE-323872-06.A1
323872-06
|
£14.57
|
£17.48
|
|
|
182 - CUP
BDE-586394-00.A1
586394-00
|
-
|
|
|
|
183 - NO LONGER AVAILABLE
BDE-000000-00.A127702
000000-00
|
-
|
|
|
|
184 - NO LONGER AVAILABLE
BDE-000000-00.A127703
000000-00
|
-
|
|
|
|
185 - BALL
BDE-368247.A4
368247
|
£1.66
|
£1.99
|
|
|
186 - NO LONGER AVAILABLE
BDE-000000-00.A127704
000000-00
|
-
|
|
|
|
187 - DISC
BDE-586390-00.A2
586390-00
|
-
|
|
|
|
188 - NO LONGER AVAILABLE
BDE-000000-00.A127705
000000-00
|
-
|
|
|
|
189 - NO LONGER AVAILABLE
BDE-000000-00.A127706
000000-00
|
-
|
|
|
|
190 - BEARING
BDE-330003-26.A3
330003-26
|
-
|
|
|
|
191 - NO LONGER AVAILABLE
BDE-000000-00.A127707
000000-00
|
-
|
|
|
|
192 - RETAINER LX
BDE-488097-00.A10
488097-00
|
£4.69
|
£5.63
|
|
|
192 - RETAINER GB
BDE-488097-00.A11
488097-00
|
£4.69
|
£5.63
|
|
|
193 - SPRING LX
BDE-488096-00.A0
488096-00
|
£1.66
|
£1.99
|
|
|
193 - SPRING GB
BDE-488096-00.A1
488096-00
|
£1.66
|
£1.99
|
|
|
194 - AXLE LX
BDE-586436-00.A5
586436-00
|
£2.26
|
£2.71
|
|
|
194 - AXLE GB
BDE-586436-00.A6
586436-00
|
£2.26
|
£2.71
|
|
|
195 - COUNTERWEIGHT GB
BDE-490613-00.A11
490613-00
|
£34.00
|
£40.80
|
|
|
195 - COUNTERWEIGHT LX
BDE-490613-00.A12
490613-00
|
£34.00
|
£40.80
|
|
|
196 - RETAINER LX
BDE-488098-00.A4
488098-00
|
£4.69
|
£5.63
|
|
|
196 - RETAINER GB
BDE-488098-00.A5
488098-00
|
£4.69
|
£5.63
|
|
|
200 - SEAL
BDE-487238-01.A24
487238-01
|
£7.85
|
£9.42
|
|
|
201 - RING
BDE-487205-00.A20
487205-00
|
£1.66
|
£1.99
|
|
|
202 - WASHER
BDE-487241-00.A26
487241-00
|
£9.41
|
£11.29
|
|
|
203 - RUBBER
BDE-487244-00.A4
487244-00
|
£3.80
|
£4.56
|
|
|
204 - SLEEVE
BDE-487236-00.A7
487236-00
|
£7.85
|
£9.42
|
|
|
205 - LOCKING RING
BDE-579784-00.A25
579784-00
|
£24.39
|
£29.27
|
|
|
206 - SPRING
BDE-487218-00.A9
487218-00
|
£1.66
|
£1.99
|
|
|
207 - KEY
BDE-489672-00.A24
489672-00
|
£7.18
|
£8.62
|
|
|
208 - BUSH
BDE-487249-00.A26
487249-00
|
£9.41
|
£11.29
|
|
|
209 - GUIDE BUSH
BDE-590377-00.A11
590377-00
|
£1.66
|
£1.99
|
|
|
210 - SPRING
BDE-487216-00.A20
487216-00
|
£1.66
|
£1.99
|
|
|
220 - GUIDE
BDE-584696-00.A12
584696-00
|
£3.30
|
£3.96
|
|
|
221 - COVER
BDE-585167-01.A9
585167-01
|
£7.18
|
£8.62
|
|
|
223 - SCREW
BDE-949886-32.A1
949886-32
|
£1.66
|
£1.99
|
|
|
224 - LIP SEAL
BDE-327141-07.A1
327141-07
|
£2.78
|
£3.34
|
|
|
225 - BEARING SET
BDE-488679-00.A14
488679-00
|
£24.39
|
£29.27
|
|
|
226 - RING
BDE-488787-00.A3
488787-00
|
£1.66
|
£1.99
|
|
|
227 - HOUSING FRONT
BDE-488678-00.A5
488678-00
|
£47.08
|
£56.49
|
|
|
228 - BUSH
BDE-589096-00.A8
589096-00
|
£2.26
|
£2.71
|
|
|
229 - DAMPER
BDE-589223-00.A0
589223-00
|
£1.66
|
£1.99
|
|
|
230 - BUSH
BDE-584727-00.A16
584727-00
|
£2.26
|
£2.71
|
|
|
240 - O RING
BDE-488546-00.A12
488546-00
|
£3.80
|
£4.56
|
|
|
250 - SPINDLE SA
BDE-488676-00.A10
488676-00
|
£165.92
|
£199.11
|
|
|
251 - SEAL
BDE-N014007.A19
N014007
|
£10.85
|
£13.02
|
|
|
252 - O RING
BDE-488546-00.A13
488546-00
|
£3.80
|
£4.56
|
|
|
252 - O RING
BDE-1005597-00.A7
1005597-00
|
£3.30
|
£3.96
|
|
|
253 - BEARING
BDE-488685-00.A5
488685-00
|
£24.39
|
£29.27
|
|
|
254 - BEAT PIECE
BDE-488681-00.A12
488681-00
|
£37.35
|
£44.82
|
|
|
255 - WASHER
BDE-488680-00.A5
488680-00
|
£9.41
|
£11.29
|
|
|
256 - O RING
BDE-577744-06.A4
577744-06
|
£7.85
|
£9.42
|
|
|
257 - BUSH
BDE-488686-00.A10
488686-00
|
£18.91
|
£22.69
|
|
|
260 - HANDLE SIDE SA
BDE-N021520
N021520
|
£63.87
|
£76.64
|
|
|
261 - CLAMPING INSERT
BDE-N021312.A11
N021312
|
£5.88
|
£7.06
|
|
|
262 - HANDLE
BDE-N021120.A20
N021120
|
£14.57
|
£17.48
|
|
|
263 - LOCKING RING
BDE-326553-00.A35
326553-00
|
£4.69
|
£5.63
|
|
|
264 - CLAMP
BDE-479333-00.A12
479333-00
|
£10.85
|
£13.02
|
|
|
265 - BUSH
BDE-326552-00.A36
326552-00
|
£7.18
|
£8.62
|
|
|
266 - PIN
BDE-N079374.A36
N079374
|
£1.66
|
£1.99
|
|
|
800 - GREASE 80 GMS
BDE-578970-06.A33
578970-06
|
£55.32
|
£66.38
|
|
|
801 - BIT GREASE 50G
BDE-328771-07.A52
328771-07
|
£7.18
|
£8.62
|
|
|
821 - RATING PLATE GB
BDE-N041692
N041692
|
-
|
|
|
|
821 - RATING PLATE LX
BDE-N041693
N041693
|
-
|
|
|
|
826 - LABEL
BDE-487395-01.A47
487395-01
|
£1.66
|
£1.99
|
|
|
830 - LABEL
BDE-488183-00.A0
488183-00
|
-
|
|
|
|
836 - S.T.CIRCLIP REMOVER
BDE-559651-99.A12
559651-99
|
£131.46
|
£157.75
|
|
|
836 - S.T.CIRCLIP REMOVER
BDE-559652-99.A10
559652-99
|
£24.39
|
£29.27
|
|
|
837 - S.T.BEARING EXTRACTOR
BDE-559653-99.A12
559653-99
|
£12.17
|
£14.60
|
|
|
838 - S.T.BEARING EXTRACTOR
BDE-559657-99.A7
559657-99
|
£60.94
|
£73.13
|
|
|
840 - S.T.SEAL FITTING TOOL
BDE-559659-99.A9
559659-99
|
£24.39
|
£29.27
|
|
|
845 - S.T.SUPPORT JIG
BDE-559656-99.A38
559656-99
|
£71.44
|
£85.73
|
|
|
847 - SERVICE KIT 230V GB
BDE-491210-00.A0
491210-00
|
-
|
|
|
|
847 - SERVICE KIT 115V LX
BDE-491211-00.A3
491211-00
|
£57.22
|
£68.66
|
|
|
861 - KITBOX
BDE-381297-94.A4
381297-94
|
£29.32
|
£35.18
|
|
