3 - THREAD-FORMING TAP. SCREW M4x8
BSD-2603410048.A106
2603410048
|
£1.84
|
£2.21
|
|
|
32 - TORX HEAD SCREW
BSD-F016L69108.A4
F016L69108
|
-
|
|
|
|
40 - MOWER DECK 42/46
BSD-F016L90982.A6
F016L90982
|
£28.59
|
£34.31
|
|
|
41 - HOUSING 46
BSD-F016L90749.A1
F016L90749
|
-
|
|
|
|
43/1 - MOTOR HOOD
BSD-F016L90017.A14
F016L90017
|
£18.96
|
£22.75
|
|
|
43/2 - CARRYING HANDLE
BSD-F016L90018.A53
F016L90018
|
£1.84
|
£2.21
|
|
|
43/4 - TRANSPARENT COVER
BSD-F016L90432.A22
F016L90432
|
£1.84
|
£2.21
|
|
|
43/5 - INDICATOR
BSD-F016L90433.A36
F016L90433
|
£3.91
|
£4.69
|
|
|
43/6 - BUTTON
BSD-1600A022AC.A20
1600A022AC
|
£3.75
|
£4.50
|
|
|
43/7 - BUTTON SPRING
BSD-F016L91168.A7
F016L91168
|
£1.75
|
£2.10
|
|
|
43/8 - GUARD FLAP
BSD-F016L90022.A9
F016L90022
|
£7.72
|
£9.27
|
|
|
43/9 - SPRING
BSD-F016L90868.A1
F016L90868
|
£2.98
|
£3.57
|
|
|
43/10 - GRILLE
BSD-F016L91059.A4
F016L91059
|
-
|
|
|
|
43/11 - STICKER logo l
BSD-F016L90076.A45
F016L90076
|
£2.74
|
£3.29
|
|
|
43/12 - STICKER logo r
BSD-F016L90077.A9
F016L90077
|
£2.74
|
£3.29
|
|
|
43/13 - COVER PANEL
BSD-F016L90021.A2
F016L90021
|
-
|
|
|
|
43/14 - KEY
BSD-F016L90054.A2
F016L90054
|
£7.36
|
£8.83
|
|
|
43/15 - RELEASE LEVER
BSD-F016L90773.A2
F016L90773
|
-
|
|
|
|
43/16 - BUTTON SPRING
BSD-F016L90701.A7
F016L90701
|
£1.75
|
£2.10
|
|
|
43/17 - SWITCH SUPPORT
BSD-F016L90777.A3
F016L90777
|
-
|
|
|
|
43/18 - WIRING HARNESS
BSD-F016L90833.A0
F016L90833
|
-
|
|
|
|
43/19 - BATTERY HOUSING
BSD-F016L90057.A3
F016L90057
|
-
|
|
|
|
43/20 - TORX HEAD SCREW
BSD-F016L68124.A197
F016L68124
|
£1.84
|
£2.21
|
|
|
49 - LINKAGE PART
BSD-F016L90028.A6
F016L90028
|
£10.61
|
£12.73
|
|
|
52/1 - AXLE
BSD-F016L90007.A36
F016L90007
|
£5.57
|
£6.68
|
|
|
52/2 - LINK PIECE
BSD-F016L90033.A44
F016L90033
|
£1.75
|
£2.10
|
|
|
52/3 - LINK PIECE
BSD-F016L90037.A44
F016L90037
|
£1.84
|
£2.21
|
|
|
52/4 - RATCHET CAP
BSD-F016L68095.A131
F016L68095
|
£1.84
|
£2.21
|
|
|
52/805 - WHEEL
BSD-F016105108.A40
F016105108
|
£9.94
|
£11.93
|
|
|
55 - CUTTER BLADE 44cm
BSD-F016L90160.A0
F016L90160
|
£21.68
|
£26.01
|
|
|
58 - SPRING WASHER 1/2
BSD-F016L66173.A53
F016L66173
|
£1.84
|
£2.21
|
|
|
59 - BOLT M10x30
BSD-F016L66141.A49
F016L66141
|
£2.61
|
£3.13
|
|
|
61/1 - AXLE 42/46
BSD-F016L90006.A5
F016L90006
|
£5.57
|
£6.68
|
|
|
61/2 - LINK PIECE
BSD-F016L90032.A23
F016L90032
|
£1.84
|
£2.21
|
|
|
61/3 - SPACER
BSD-F016L90036.A23
F016L90036
|
£1.84
|
£2.21
|
|
|
61/4 - RATCHET CAP
BSD-F016L68095.A130
F016L68095
|
£1.84
|
£2.21
|
|
|
61/805 - WHEEL
BSD-F016105369.A4
F016105369
|
-
|
|
|
|
75/1/1 - HANDLE
BSD-F016L90012.A3
F016L90012
|
£17.22
|
£20.67
|
|
|
75/1/2 - BUSHING
BSD-F016L90064.A1
F016L90064
|
£1.84
|
£2.21
|
|
|
75/3 - WIRING UNIT
BSD-F016L90850.A3
F016L90850
|
£19.91
|
£23.89
|
|
|
75/3/1 - CONNECTOR HOUSING
BSD-F016L67218.A33
F016L67218
|
£5.57
|
£6.68
|
|
|
75/3/2 - CONNECTION CABLE
BSD-F016L90848.A1
F016L90848
|
-
|
|
|
|
75/3/803 - SWITCH KIT
BSD-F016104163.A34
F016104163
|
£15.65
|
£18.78
|
|
|
75/5 - SLEEVE
BSD-F016L90070.A22
F016L90070
|
£2.16
|
£2.59
|
|
|
75/6 - HANDLE
BSD-F016L90066.A18
F016L90066
|
£5.57
|
£6.68
|
|
|
75/7 - HANDLE
BSD-F016L90067.A21
F016L90067
|
£5.58
|
£6.70
|
|
|
75/8 - LOCKING PIN
BSD-F016L90068.A18
F016L90068
|
£1.84
|
£2.21
|
|
|
75/9 - LEVER
BSD-F016L91109.A1
F016L91109
|
-
|
|
|
|
75/10 - COMPRESSION SPRING
BSD-F016L90074.A2
F016L90074
|
£1.84
|
£2.21
|
|
|
75/11 - BUTTON
BSD-F016L91039.A5
F016L91039
|
-
|
|
|
|
75/14 - SCREW M5x8 Csk Hd.
BSD-F016L36542.A205
F016L36542
|
£2.62
|
£3.14
|
|
|
75/15 - TORX HEAD SCREW
BSD-F016L68124.A199
F016L68124
|
£1.84
|
£2.21
|
|
|
75/804 - SWITCH ASSEMBLY
BSD-F016105448.A0
F016105448
|
£28.59
|
£34.31
|
|
|
78/1 - BOTTOM HANDLE
BSD-F016L90013.A37
F016L90013
|
£12.64
|
£15.17
|
|
|
78/2 - RELEASE MECHANISM
BSD-F016L90063.A41
F016L90063
|
£1.84
|
£2.21
|
|
|
78/3 - COMPRESSION SPRING
BSD-F016L90841.A9
F016L90841
|
£1.84
|
£2.21
|
|
|
78/4 - RELEASE MECHANISM
BSD-F016L90062.A2
F016L90062
|
£2.74
|
£3.29
|
|
|
78/5 - SCREW M5x8 Csk Hd.
BSD-F016L36542.A206
F016L36542
|
£2.62
|
£3.14
|
|
|
78/6 - BRACKET
BSD-F016L90082.A7
F016L90082
|
£5.58
|
£6.70
|
|
|
78/7 - PIVOT PIN
BSD-F016L90014.A6
F016L90014
|
£1.75
|
£2.10
|
|
|
99 - BALANCE WEIGHTS
BSD-F016L69400.A17
F016L69400
|
£22.60
|
£27.12
|
|
|
121 - CLIP
BSD-F016L91066.A46
F016L91066
|
£1.75
|
£2.10
|
|
|
122 - SPRING
BSD-F016L90072.A39
F016L90072
|
£2.94
|
£3.53
|
|
|
131 - COVER
BSD-F016L91046.A15
F016L91046
|
-
|
|
|
|
132 - COVER
BSD-F016L91047.A22
F016L91047
|
-
|
|
|
|
160 - COVER
BSD-F016L90060.A2
F016L90060
|
£2.74
|
£3.29
|
|
|
161 - COVER
BSD-F016L90061.A39
F016L90061
|
£2.61
|
£3.13
|
|
|
163 - TORX OVAL-HEAD SCREW M6x50
BSD-1613490011.A13
1613490011
|
£2.27
|
£2.72
|
|
|
500 - TORX HEAD SCREW
BSD-F016L68124.A198
F016L68124
|
£1.84
|
£2.21
|
|
|
501 - PLAIN WASHER
BSD-8716107299.A1
8716107299
|
-
|
|
|
|
502 - SELF-CUTTING SCREW
BSD-F016L37433.A158
F016L37433
|
£1.75
|
£2.10
|
|
|
503 - THREAD-FORMING TAP. SCREW M4x8
BSD-2603410048.A109
2603410048
|
£1.84
|
£2.21
|
|
|
650 - SLIDE-IN ACCU PACKAGE 36V 2.0 Ah Li
BSD-2607336913.A16
2607336913
|
£195.26
|
£234.31
|
|
|
650 - SLIDE-IN ACCU PACKAGE 36V. 4.0Ah. LI
BSD-2607337047.A40
2607337047
|
£263.33
|
£316.00
|
|
|
650 - SLIDE-IN ACCU PACKAGE BBS 36V. 4.0Ah
BSD-2607337047.A31
2607337047
|
£263.33
|
£316.00
|
|
|
650 - BATTERY PACK PBA 36V 2.0Ah H-B 72Wh
BSD-1607A3502V.A3
1607A3502V
|
£187.56
|
£225.07
|
|
|
650 - BATTERY PACK
BSD-1607A35058.A0
1607A35058
|
£306.81
|
£368.17
|
|
|
651 - CHARGER EU 230V/14.4-36V
BSD-2607225657.A37
2607225657
|
£73.75
|
£88.50
|
|
|
651 - FAST CHARGER EU AL 36V-20/36V
BSD-2607226273.A1
2607226273
|
-
|
|
|
|
652 - DEFLECTOR PLATE
BSD-F016L90830.A1
F016L90830
|
£22.60
|
£27.12
|
|
|
801 - DC MOTOR
BSD-F016105449.A4
F016105449
|
-
|
|
|
|
802 - ELECTRONICS MODULE
BSD-F016105441.A0
F016105441
|
-
|
|
|
|
883 - COLLECTION BOX
BSD-F016105378.A4
F016105378
|
£59.53
|
£71.44
|
|
|
883/1/10 - PIN
BSD-F016L91107.A6
F016L91107
|
-
|
|
|
|
883/1/11 - SOCKET INSERT
BSD-F016L91108.A27
F016L91108
|
-
|
|
|
|
883/1/2 - HANDLE
BSD-F016L90040.A26
F016L90040
|
£2.19
|
£2.63
|
|
|
883/1/3 - COVER
BSD-F016L90557.A9
F016L90557
|
£2.27
|
£2.72
|
|
|
883/1/4 - PIVOT PLATE
BSD-F016L91038.A21
F016L91038
|
-
|
|
|
