2 - ADJUSTMENT KNOB
BSD-1600591021.A7
1600591021
|
-
|
|
|
|
3 - SPRING CLIP
BSD-1600290034.A14
1600290034
|
-
|
|
|
|
4/10 - SWITCH PLATE
BSD-1605190132.A7
1605190132
|
£3.80
|
£4.56
|
|
|
4/30 - SWITCH
BSD-1607200131.A16
1607200131
|
-
|
|
|
|
4/40 - SWITCH BUTTON
BSD-1602025029.A19
1602025029
|
£2.74
|
£3.29
|
|
|
4/50 - PROTECTIVE CAP
BSD-1605500207.A3
1605500207
|
-
|
|
|
|
4/60 - OVAL-HEAD SCREW KT 4.0x14
BSD-1603425001.A16
1603425001
|
£2.64
|
£3.17
|
|
|
4/70 - OVAL-HEAD SCREW 4x12 MM
BSD-2914211503.A6
2914211503
|
£2.64
|
£3.17
|
|
|
6 - CONNECTION PART
BSD-1605190060.A8
1605190060
|
-
|
|
|
|
7 - SUPPRESSION FILTER
BSD-1607328069.A16
1607328069
|
-
|
|
|
|
8 - NAMEPLATE
BSD-1601118A03.A1
1601118A03
|
-
|
|
|
|
9 - REFERENCE PLATE
BSD-1601118928.A18
1601118928
|
£3.80
|
£4.56
|
|
|
10 - REFERENCE PLATE
BSD-1601118A81.A3
1601118A81
|
£3.34
|
£4.01
|
|
|
12 - COVER PLATE
BSD-1605500190.A36
1605500190
|
£2.52
|
£3.02
|
|
|
13 - HOUSING BASE
BSD-1605190057.A4
1605190057
|
£37.72
|
£45.27
|
|
|
15 - HOUSING COVER
BSD-1605190177.A2
1605190177
|
-
|
|
|
|
16 - INSERT
BSD-1605190055.A8
1605190055
|
-
|
|
|
|
17 - STICKER
BSD-1601118916.A44
1601118916
|
£3.34
|
£4.01
|
|
|
29 - SWITCH
BSD-1607200134.A22
1607200134
|
£6.94
|
£8.33
|
|
|
30 - WIRING HARNESS
BSD-1604449010.A10
1604449010
|
£24.45
|
£29.34
|
|
|
33 - SWITCH SUPPORT
BSD-1605190059.A19
1605190059
|
£2.05
|
£2.46
|
|
|
42/1 - THREAD-FORMING TAP. SCREW TORX-T20
BSD-1603435054.A7
1603435054
|
£1.84
|
£2.21
|
|
|
101 - MOTOR 230V
BSD-1607220034.A5
1607220034
|
£276.50
|
£331.80
|
|
|
102 - TOOTHED GEAR Z=8
BSD-1606318011.A7
1606318011
|
£14.08
|
£16.89
|
|
|
106 - RING GEAR Z=112
BSD-1606334006.A20
1606334006
|
-
|
|
|
|
112 - TOOTHED GEAR Z=49
BSD-1606317088.A23
1606317088
|
-
|
|
|
|
113 - TOOTHED GEAR Z=23
BSD-1606318008.A2
1606318008
|
-
|
|
|
|
117 - FRICTION WASHER
BSD-1600100032.A25
1600100032
|
£1.74
|
£2.09
|
|
|
120 - FRICTION WASHER
BSD-1600100027.A34
1600100027
|
£2.45
|
£2.94
|
|
|
122 - SCRAPER
BSD-1601034040.A19
1601034040
|
£7.78
|
£9.33
|
|
|
125 - RETAINING RING 10 DIN 9045
BSD-2916600006.A23
2916600006
|
£1.84
|
£2.21
|
|
|
126 - SPRING RETAINING RING DIN 471 18x1.2MM
BSD-2916650009.A11
2916650009
|
£1.75
|
£2.10
|
|
|
127 - CARRIER
BSD-1606490040.A8
1606490040
|
£6.16
|
£7.39
|
|
|
129 - ADJUSTING SCREW
BSD-1603490004.A12
1603490004
|
£2.94
|
£3.53
|
|
|
130 - THREAD-FORMING TAP. SCREW M6x25 MM
BSD-1603414010.A73
1603414010
|
£1.84
|
£2.21
|
|
|
131 - HOLDING PLATE
BSD-1601329028.A11
1601329028
|
£1.84
|
£2.21
|
|
|
133 - SEAL
BSD-1600290035.A23
1600290035
|
-
|
|
|
|
135 - LOCKING WASHER DIN 6799-12-FST
BSD-2916080014.A15
2916080014
|
£1.75
|
£2.10
|
|
|
651 - SINGLE-HEAD ENG. WRENCH SW10
BSD-1607950527.A30
1607950527
|
-
|
|
|
|
652 - CATCHER CONTAINER
BSD-1605411031.A19
1605411031
|
£11.87
|
£14.24
|
|
|
653 - OFFSET SCREWDRIVER SW5
BSD-1607950057.A17
1607950057
|
£3.34
|
£4.01
|
|
|
668 - AXLE
BSD-1607000957.A17
1607000957
|
£14.91
|
£17.89
|
|
|
673 - PLAIN WASHER
BSD-1600190030.A71
1600190030
|
£1.84
|
£2.21
|
|
|
673/1 - PLAIN WASHER
BSD-1600190030.A72
1600190030
|
£1.84
|
£2.21
|
|
|
674 - HEX NUT DIN 985-M6-8
BSD-2915061004.A27
2915061004
|
£1.84
|
£2.21
|
|
|
675 - ROUND-HEAD BOLT DIN 603 M6x50
BSD-2910281213.A23
2910281213
|
£1.38
|
£1.66
|
|
|
677 - CAP NUT DIN 1587-M6-M-6
BSD-2915151001.A19
2915151001
|
£4.99
|
£5.99
|
|
|
804 - GEAR HOUSING
BSD-1607000819.A19
1607000819
|
-
|
|
|
|
805 - BEARING FLANGE
BSD-1607000813.A20
1607000813
|
-
|
|
|
|
807 - SUPPORTING FRAME
BSD-1607000829.A5
1607000829
|
£37.72
|
£45.27
|
|
|
808 - PLANETARY-GEAR CARRIER
BSD-1607000874.A17
1607000874
|
£19.45
|
£23.34
|
|
|
809 - PLANETARY-GEAR CARRIER
BSD-1607000820.A6
1607000820
|
£21.68
|
£26.01
|
|
|
814 - UPPER HOUSING
BSD-1605190078.A2
1605190078
|
£37.72
|
£45.27
|
|
|
815 - CUTTING HEAD
BSD-1607000821.A17
1607000821
|
£142.02
|
£170.42
|
|
|
816 - COUNTER BAR
BSD-1601000001.A7
1601000001
|
£23.86
|
£28.63
|
|
|
842 - SWITCH KIT
BSD-1607000863.A29
1607000863
|
-
|
|
|
|
869 - WHEEL dia200 MM
BSD-1609351088.A108
1609351088
|
£12.04
|
£14.45
|
|
|
869/020 - PLUG
BSD-1609351075.A20
1609351075
|
-
|
|
|
|
888 - NAMEPLATE
BSD-160111A3H5.A376
160111A3H5
|
£2.74
|
£3.29
|
|
