2 - ADJUSTMENT KNOB
BSD-1600591021.A12
1600591021
|
-
|
|
|
|
3 - SPRING CLIP
BSD-1600290034.A32
1600290034
|
-
|
|
|
|
4/10 - SWITCH PLATE
BSD-1605190132.A25
1605190132
|
£3.80
|
£4.56
|
|
|
4/10/1 - SWITCH PLATE
BSD-1605190056.A14
1605190056
|
-
|
|
|
|
4/20/1 - SWITCH KIT
BSD-1607000863.A39
1607000863
|
-
|
|
|
|
4/30 - SWITCH
BSD-1607200131.A26
1607200131
|
-
|
|
|
|
4/40 - SWITCH BUTTON
BSD-1602025029.A0
1602025029
|
£2.74
|
£3.29
|
|
|
4/40/1 - SWITCH BUTTON
BSD-1602025028.A23
1602025028
|
-
|
|
|
|
4/50 - PROTECTIVE CAP
BSD-1605500207.A12
1605500207
|
-
|
|
|
|
4/50/1 - FRAME
BSD-1601015028.A5
1601015028
|
-
|
|
|
|
4/60 - OVAL-HEAD SCREW KT 4.0x14
BSD-1603425001.A23
1603425001
|
£2.64
|
£3.17
|
|
|
4/60/1 - THREAD-FORMING TAP. SCREW KT 4.0x14 MM
BSD-1603435039.A14
1603435039
|
-
|
|
|
|
4/70 - OVAL-HEAD SCREW 4x12 MM
BSD-2914211503.A20
2914211503
|
£2.64
|
£3.17
|
|
|
5 - SEAL
BSD-1600109012.A22
1600109012
|
£2.45
|
£2.94
|
|
|
6/3 - CONNECTION PART
BSD-1607000963.A5
1607000963
|
£19.45
|
£23.34
|
|
|
7 - SUPPRESSION FILTER
BSD-1607328069.A11
1607328069
|
-
|
|
|
|
8 - NAMEPLATE
BSD-1601118926.A0
1601118926
|
-
|
|
|
|
9 - REFERENCE PLATE
BSD-1601118928.A8
1601118928
|
£3.80
|
£4.56
|
|
|
10 - REFERENCE PLATE
BSD-1601118A81.A21
1601118A81
|
£3.34
|
£4.01
|
|
|
12 - COVER PLATE
BSD-1605500190.A27
1605500190
|
£2.52
|
£3.02
|
|
|
13 - HOUSING BASE
BSD-1605190057.A10
1605190057
|
£37.72
|
£45.27
|
|
|
14/2 - UPPER HOUSING
BSD-1605190052.A9
1605190052
|
£38.47
|
£46.16
|
|
|
15 - HOUSING COVER
BSD-1605190053.A1
1605190053
|
-
|
|
|
|
16 - INSERT
BSD-1605190055.A22
1605190055
|
-
|
|
|
|
17 - STICKER
BSD-1601118916.A23
1601118916
|
£3.34
|
£4.01
|
|
|
29 - SWITCH
BSD-1607200134.A3
1607200134
|
£6.94
|
£8.33
|
|
|
30/1 - WIRING HARNESS
BSD-1604449011.A1
1604449011
|
-
|
|
|
|
33 - SWITCH SUPPORT
BSD-1605190059.A15
1605190059
|
£2.05
|
£2.46
|
|
|
42 - THREAD-FORMING TAP. SCREW TORX-T20
BSD-1603435054.A33
1603435054
|
£1.84
|
£2.21
|
|
|
101 - MOTOR 230V
BSD-1607220034.A12
1607220034
|
£276.50
|
£331.80
|
|
|
102 - TOOTHED GEAR Z=8
BSD-1606318011.A17
1606318011
|
£14.08
|
£16.89
|
|
|
106 - RING GEAR Z=112
BSD-1606334006.A9
1606334006
|
-
|
|
|
|
112 - TOOTHED GEAR Z=49
BSD-1606317088.A38
1606317088
|
-
|
|
|
|
112/1 - TOOTHED GEAR Z=49
BSD-1606317088.A39
1606317088
|
-
|
|
|
|
113 - TOOTHED GEAR Z=23
BSD-1606318008.A17
1606318008
|
-
|
|
|
|
114 - DRIVE SHAFT
BSD-1603124130.A9
1603124130
|
-
|
|
|
|
117 - FRICTION WASHER
BSD-1600100032.A9
1600100032
|
£1.74
|
£2.09
|
|
|
118 - SCRAPER
BSD-1600100031.A1
1600100031
|
-
|
|
|
|
119 - FRICTION WASHER
BSD-1600100030.A9
1600100030
|
-
|
|
|
|
120 - FRICTION WASHER
BSD-1600100027.A19
1600100027
|
£2.45
|
£2.94
|
|
|
122 - SCRAPER
BSD-1601034040.A31
1601034040
|
£7.78
|
£9.33
|
|
|
125 - RETAINING RING 10 DIN 9045
BSD-2916600006.A21
2916600006
|
£1.84
|
£2.21
|
|
|
126 - SPRING RETAINING RING DIN 471 18x1.2MM
BSD-2916650009.A13
2916650009
|
£1.75
|
£2.10
|
|
|
127 - CARRIER
BSD-1606490040.A18
1606490040
|
£6.16
|
£7.39
|
|
|
129 - ADJUSTING SCREW
BSD-1603490004.A21
1603490004
|
£2.94
|
£3.53
|
|
|
130 - THREAD-FORMING TAP. SCREW M6x25 MM
BSD-1603414010.A55
1603414010
|
£1.84
|
£2.21
|
|
|
131 - HOLDING PLATE
BSD-1601329028.A28
1601329028
|
£1.84
|
£2.21
|
|
|
133 - SEAL
BSD-1600290035.A7
1600290035
|
-
|
|
|
|
135 - LOCKING WASHER DIN 6799-12-FST
BSD-2916080014.A18
2916080014
|
£1.75
|
£2.10
|
|
|
135/1 - LOCKING WASHER DIN 6799-12-FST
BSD-2916080014.A19
2916080014
|
£1.75
|
£2.10
|
|
|
651 - SINGLE-HEAD ENG. WRENCH SW10
BSD-1607950527.A19
1607950527
|
-
|
|
|
|
652 - CATCHER CONTAINER
BSD-1605411031.A35
1605411031
|
£11.87
|
£14.24
|
|
|
653 - OFFSET SCREWDRIVER SW5
BSD-1607950057.A30
1607950057
|
£3.34
|
£4.01
|
|
|
668 - AXLE
BSD-1607000957.A25
1607000957
|
£14.91
|
£17.89
|
|
|
670/1 - CONNECTOR
BSD-1606491001.A10
1606491001
|
-
|
|
|
|
673 - PLAIN WASHER
BSD-1600190030.A42
1600190030
|
£1.84
|
£2.21
|
|
|
673/1 - PLAIN WASHER
BSD-1600190030.A43
1600190030
|
£1.84
|
£2.21
|
|
|
674 - HEX NUT DIN 985-M6-8
BSD-2915061004.A21
2915061004
|
£1.84
|
£2.21
|
|
|
674/1 - CAP NUT DIN 1587-M6-M-6
BSD-2915151001.A28
2915151001
|
£4.99
|
£5.99
|
|
|
675 - ROUND-HEAD BOLT DIN 603 M6x50
BSD-2910281213.A29
2910281213
|
£1.38
|
£1.66
|
|
|
675/1 - ROUND-HEAD BOLT DIN 603 M6x55
BSD-2910281215.A23
2910281215
|
-
|
|
|
|
677 - CAP NUT DIN 1587-M6-M-6
BSD-2915151001.A29
2915151001
|
£4.99
|
£5.99
|
|
|
804 - GEAR HOUSING
BSD-1607000817.A0
1607000817
|
-
|
|
|
|
805 - BEARING FLANGE
BSD-1607000813.A12
1607000813
|
-
|
|
|
|
807 - SUPPORTING FRAME
BSD-1607000829.A15
1607000829
|
£37.72
|
£45.27
|
|
|
808 - PLANETARY-GEAR CARRIER
BSD-1607000874.A8
1607000874
|
£19.45
|
£23.34
|
|
|
808/01 - PLANETARY-GEAR CARRIER
BSD-1607000814.A10
1607000814
|
-
|
|
|
|
809 - PLANETARY-GEAR CARRIER
BSD-1607000815.A10
1607000815
|
-
|
|
|
|
815 - CUTTING HEAD
BSD-1601000002.A2
1601000002
|
-
|
|
|
|
816 - COUNTER BAR
BSD-1601000001.A16
1601000001
|
£23.86
|
£28.63
|
|
|
821 - FRICTION WASHER
BSD-1600100029.A10
1600100029
|
-
|
|
|
|
842 - SWITCH KIT
BSD-1607000863.A48
1607000863
|
-
|
|
|
|
869 - WHEEL dia200 MM
BSD-1609351088.A120
1609351088
|
£12.04
|
£14.45
|
|
|
869/020 - PLUG
BSD-1609351075.A8
1609351075
|
-
|
|
|
|
869/030 - DECORATIVE COVER
BSD-1609351074.A0
1609351074
|
-
|
|
|
