2 - GEAR HOUSING
BSD-2605806082.A13
2605806082
|
£72.18
|
£86.62
|
|
|
3 - GROOVE BALL BEARING 9x24x7 MM
BSD-3600905039.A218
3600905039
|
£12.04
|
£14.45
|
|
|
4 - SOCKET HEAD CAP SCREW DIN 84-AM4x12-8.8
BSD-2910021122.A941
2910021122
|
£2.27
|
£2.72
|
|
|
6 - GUIDE RAIL
BSD-2601038001.A12
2601038001
|
£3.72
|
£4.47
|
|
|
7 - SPRING LOCK WASHER DIN 128-A4-FST
BSD-2916690003.A360
2916690003
|
£1.75
|
£2.10
|
|
|
9 - SOCKET HEAD CAP SCREW DIN 84-AM4x18-5.8
BSD-2910011128.A204
2910011128
|
£1.84
|
£2.21
|
|
|
10 - SHIM 0.10 MM
BSD-2600100611.A12
2600100611
|
£1.75
|
£2.10
|
|
|
10 - SHIM 0.50 MM
BSD-2600100613.A196
2600100613
|
£1.75
|
£2.10
|
|
|
11 - ECCENTRIC COG WHEEL Z=49
BSD-2606319007.A11
2606319007
|
£62.51
|
£75.01
|
|
|
12 - NEEDLE-ROLLER ASSEMBLY
BSD-3600910000.A43
3600910000
|
£4.48
|
£5.37
|
|
|
13 - SHIM 0.20 MM
BSD-2600100586.A24
2600100586
|
£1.84
|
£2.21
|
|
|
13 - SHIM 0.30 MM
BSD-2600100587.A11
2600100587
|
£1.75
|
£2.10
|
|
|
13 - SHIM 0.5 MM
BSD-2600100588.A88
2600100588
|
£1.84
|
£2.21
|
|
|
14 - ROLLER
BSD-2600300005.A11
2600300005
|
£9.11
|
£10.93
|
|
|
15 - NEEDLE ROLLER 1.5x5.8 MM
BSD-2603201037.A104
2603201037
|
£2.74
|
£3.29
|
|
|
16 - RETAINING BRACKET
BSD-2601320018.A2
2601320018
|
£2.94
|
£3.53
|
|
|
17 - SLOTTED ROUND NUT
BSD-2603341007.A3
2603341007
|
£1.75
|
£2.10
|
|
|
18 - LIFTING ROD
BSD-2602305016.A14
2602305016
|
£57.14
|
£68.57
|
|
|
19 - LIFTING ROD
BSD-2602305014.A3
2602305014
|
£54.42
|
£65.30
|
|
|
20 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A1506
2910021118
|
£1.84
|
£2.21
|
|
|
22 - BEARING BOLT
BSD-2603520010.A13
2603520010
|
£17.22
|
£20.67
|
|
|
23 - PRESSURE PLATE
BSD-2601034010.A3
2601034010
|
£6.85
|
£8.22
|
|
|
24 - ROUND NUT
BSD-3603345016.A15
3603345016
|
£13.78
|
£16.54
|
|
|
25 - SPRING LOCK WASHER DIN128-A5-FST
BSD-2916690002.A11
2916690002
|
£1.75
|
£2.10
|
|
|
26 - SEAL BUSHING
BSD-2600300047.A87
2600300047
|
£2.74
|
£3.29
|
|
|
27 - FELT WASHER
BSD-2600108026.A25
2600108026
|
£1.84
|
£2.21
|
|
|
28 - CUPPED WASHER
BSD-2600500017.A21
2600500017
|
£1.75
|
£2.10
|
|
|
29 - SOCKET HEAD CAP SCREW DIN 84-AM3.5x6-5.8
BSD-2910011082.A93
2910011082
|
£1.75
|
£2.10
|
|
|
30 - SUPPORT PLATE
BSD-3602307009.A4
3602307009
|
£81.81
|
£98.17
|
|
|
31 - SOCKET HEAD CAP SCREW DIN 84-AM3.5x8-5.8
BSD-2910011084.A2
2910011084
|
£1.84
|
£2.21
|
|
|
32 - STUD
BSD-2603502015.A14
2603502015
|
£3.72
|
£4.47
|
|
|
33 - STRAIGHT PIN 4H8x8 DIN 7
BSD-2917500093.A2
2917500093
|
£1.75
|
£2.10
|
|
|
35 - REFERENCE PLATE
BSD-3601110100.A0
3601110100
|
-
|
|
|
|
37 - ROLLER
BSD-2600300011.A3
2600300011
|
£1.84
|
£2.21
|
|
|
38 - NEEDLE ROLLER
BSD-1903201521.A2
1903201521
|
£1.75
|
£2.10
|
|
|
39 - SOCKET HEAD CAP SCREW DIN 84-AM4x25-8.8
BSD-2910021132.A30
2910021132
|
£1.84
|
£2.21
|
|
|
95 - STICKER
BSD-3601110072.A5
3601110072
|
-
|
|
|
|
103 - SPIRAL SPRING
BSD-2604652000.A70
2604652000
|
-
|
|
|
|
104 - PLAIN WASHER DIN 433-3.2-ST 50
BSD-2916011005.A658
2916011005
|
£1.84
|
£2.21
|
|
|
105 - CLAMPING SADDLE
BSD-2601321005.A40
2601321005
|
-
|
|
|
|
106 - SCREW AND WASHER ASSEMBLY DIN7985-M3x6-Z1-4.8
BSD-2914501011.A102
2914501011
|
£1.75
|
£2.10
|
|
|
107 - FIELD 220-230V
BSD-2604220269.A0
2604220269
|
-
|
|
|
|
108 - HEX NUT DIN 934-M 3-m-8
BSD-2915011003.A58
2915011003
|
£1.84
|
£2.21
|
|
|
109 - SOCKET HEAD CAP SCREW DIN 84-BM3x50-5.8
BSD-2910011074.A9
2910011074
|
£1.84
|
£2.21
|
|
|
110 - SPRING LOCK WASHER A3-FSt
BSD-2916690001.A100
2916690001
|
-
|
|
|
|
111 - BRUSH HOLDER
BSD-2601323016.A18
2601323016
|
£2.94
|
£3.53
|
|
|
112 - PLAIN WASHER dia 2.6 MM-ST
BSD-2916021007.A6
2916021007
|
-
|
|
|
|
113 - HEX NUT DIN 439-BM 3
BSD-2915051103.A45
2915051103
|
£1.84
|
£2.21
|
|
|
114 - SHIM
BSD-2600100699.A51
2600100699
|
£1.84
|
£2.21
|
|
|
115 - SHIM
BSD-2600150002.A53
2600150002
|
-
|
|
|
|
116 - GROOVE BALL BEARING 625-2Z DIN 625
BSD-1900905015.A379
1900905015
|
£30.42
|
£36.51
|
|
|
117 - SHIM 0.3 MM
BSD-2600100612.A1
2600100612
|
£2.61
|
£3.13
|
|
|
118 - SEAL RING
BSD-2600113019.A46
2600113019
|
£2.80
|
£3.36
|
|
|
119 - ARMATURE 220V
BSD-2604010281.A0
2604010281
|
-
|
|
|
|
120 - INSULATING PART
BSD-2601322002.A45
2601322002
|
£1.75
|
£2.10
|
|
|
121 - FAN
BSD-2606610038.A8
2606610038
|
-
|
|
|
|
122 - SWITCH
BSD-2607200045.A93
2607200045
|
-
|
|
|
|
123 - COUNTERSUNK-HEAD SCREW M 3x6 DIN 63-5.8
BSD-2910501048.A46
2910501048
|
-
|
|
|
|
125 - GROMMET dia6.5-dia6.9x95 MM
BSD-2600703012.A1585
2600703012
|
£2.94
|
£3.53
|
|
|
125 - GROMMET dia8.3-dia9.4x95 MM
BSD-2600703011.A35
2600703011
|
£2.94
|
£3.53
|
|
|
126 - CABLE CLIP
BSD-2601035005.A55
2601035005
|
£1.84
|
£2.21
|
|
|
127 - TAPPING SCREW DIN 7971-BZ3.5x13
BSD-2910211011.A58
2910211011
|
£1.84
|
£2.21
|
|
|
128 - TUBULAR RIVET A2.5x0.3x4DIN7340-MS
BSD-2917170554.A24
2917170554
|
£1.75
|
£2.10
|
|
|
129 - SUPPRESSION FILTER
BSD-2607329048.A41
2607329048
|
-
|
|
|
|
130 - FASTENING CLAMP
BSD-2601301002.A50
2601301002
|
£2.16
|
£2.59
|
|
|
131 - HEX SCREW
BSD-2603527004.A44
2603527004
|
£1.84
|
£2.21
|
|
|
132 - CONNECTING TERMINAL
BSD-2604490005.A11
2604490005
|
£1.84
|
£2.21
|
|
|
133 - SOCKET HEAD CAP SCREW
BSD-2603410009.A34
2603410009
|
£1.32
|
£1.58
|
|
|
135 - HOUSING COVER
BSD-3600508023.A41
3600508023
|
£14.08
|
£16.89
|
|
|
136 - COUNTERSUNK-HEAD SCREW DIN 63-AM3.5x8-5.8
BSD-2910501084.A43
2910501084
|
-
|
|
|
|
138 - STICKER
BSD-3601007011.A2
3601007011
|
-
|
|
|
|
140 - GROOVED NAIL
BSD-3603133000.A207
3603133000
|
£2.61
|
£3.13
|
|
|
142 - CABLE CLIP
BSD-2601099015.A89
2601099015
|
£1.75
|
£2.10
|
|
|
143 - CABLE
BSD-2604411061.A93
2604411061
|
-
|
|
|
|
147 - RETAINING PIN
BSD-2603123013.A26
2603123013
|
-
|
|
|
|
160 - PRESS-IN NUT
BSD-2603349039.A6
2603349039
|
£1.75
|
£2.10
|
|
|
161 - PRESS-IN NUT
BSD-2603349038.A20
2603349038
|
-
|
|
|
|
652 - SCRAPER
BSD-2601030010.A2
2601030010
|
£2.61
|
£3.13
|
|
|
700 - GUIDE 70 MM. T42D
BSD-2608135023.A16
2608135023
|
£66.14
|
£79.37
|
|
|
700 - GUIDE 130 MM. T42A
BSD-2608135020.A1
2608135020
|
£67.06
|
£80.47
|
|
|
700 - GUIDE 220 MM. T42B
BSD-2608135021.A16
2608135021
|
£69.99
|
£83.99
|
|
|
700 - GUIDE 300 MM. T42C
BSD-2608135022.A1
2608135022
|
£76.12
|
£91.34
|
|
|
701 - SAW BLADE SET 70 MM. T 43D
BSD-2607018013.A2
2607018013
|
£20.99
|
£25.19
|
|
|
701 - SAW BLADE SET 130 MM. T43A
BSD-2607018010.A15
2607018010
|
£28.48
|
£34.17
|
|
|
701 - SAW BLADE SET 220 MM. T43B
BSD-2607018011.A2
2607018011
|
£28.48
|
£34.17
|
|
|
701 - SAW BLADE SET 300 MM. T43C
BSD-2607018012.A15
2607018012
|
£31.22
|
£37.47
|
|
|
710 - SHARPENING SET
BSD-2608133000.A2
2608133000
|
-
|
|
|
|
710/10 - WHETSTONE
BSD-3607950012.A7
3607950012
|
-
|
|
|
|
800 - MOTOR HOUSING
BSD-2605108032.A6
2605108032
|
-
|
|
|
|
801 - GEAR COVER
BSD-2605500905.A15
2605500905
|
£120.11
|
£144.13
|
|
|
802 - BASE PLATE
BSD-2608000908.A1
2608000908
|
£72.38
|
£86.86
|
|
|
805 - CARBON-BRUSH SET
BSD-2604320905.A10
2604320905
|
-
|
|
|
|
807 - UN. FLANGE-MTD. MOTOR 230V
BSD-3607220022.A0
3607220022
|
-
|
|
|
|
841 - POWER SUPPLY CORD EU 4.15m 2 x 1.0mm H07 RN-F
BSD-1607000227.A263
1607000227
|
£23.86
|
£28.63
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A1699
160111A3H3
|
£2.74
|
£3.29
|
|
