1 - SCREW PLUG
BSD-1609390382.A2
1609390382
|
-
|
|
|
|
2 - SPIRAL SPRING
BSD-1609390383.A1
1609390383
|
-
|
|
|
|
4 - OVAL-HEAD SCREW
BSD-1609390384.A2
1609390384
|
-
|
|
|
|
5 - ON-OFF SWITCH
BSD-1609390385.A1
1609390385
|
-
|
|
|
|
6 - SUPPRESSION CAPACITOR
BSD-1609390386.A2
1609390386
|
-
|
|
|
|
7 - HANDLE
BSD-1609390387.A1
1609390387
|
-
|
|
|
|
8 - HEX NUT
BSD-1609390388.A2
1609390388
|
-
|
|
|
|
9 - OVAL-HEAD SCREW
BSD-1609390389.A1
1609390389
|
-
|
|
|
|
10 - OVAL-HEAD SCREW
BSD-1609390390.A2
1609390390
|
-
|
|
|
|
11 - CLAMPING PLATE
BSD-1609390314.A1
1609390314
|
-
|
|
|
|
11/54 - HEX SOCKET HEAD CAP SCREW
BSD-1609390315.A3
1609390315
|
-
|
|
|
|
13 - POWER SUPPLY CORD CH 2.65m 2 x 1.0mm H05 VV-F
BSD-1604460110.A18
1604460110
|
-
|
|
|
|
14 - HANDLE
BSD-1609390392.A1
1609390392
|
-
|
|
|
|
15 - BRUSH HOLDER
BSD-1609390393.A2
1609390393
|
-
|
|
|
|
16 - SOCKET HEAD CAP SCREW
BSD-1609390394.A1
1609390394
|
-
|
|
|
|
17 - OVAL-HEAD SCREW
BSD-1609390395.A2
1609390395
|
-
|
|
|
|
18 - ROUND-HEAD SCREW
BSD-1609390396.A1
1609390396
|
-
|
|
|
|
20 - MOTOR HOUSING
BSD-1609390397.A2
1609390397
|
-
|
|
|
|
21 - GROOVE BALL BEARING
BSD-1609390398.A1
1609390398
|
-
|
|
|
|
22 - PROTECTIVE CAP
BSD-1609390399.A2
1609390399
|
-
|
|
|
|
23 - INSULATING SLEEVE
BSD-1609390400.A1
1609390400
|
-
|
|
|
|
24 - POLE SHOE 230-240V
BSD-1609390401.A2
1609390401
|
-
|
|
|
|
25 - SELF-LOCKING NUT
BSD-1609390402.A1
1609390402
|
-
|
|
|
|
26 - AIR-DEFLECTOR RING
BSD-1609390403.A2
1609390403
|
-
|
|
|
|
27 - ARMATURE 230-240V
BSD-1609390404.A1
1609390404
|
-
|
|
|
|
28 - COVERING HOOD
BSD-1609390405.A2
1609390405
|
-
|
|
|
|
29 - GROOVE BALL BEARING
BSD-1609390406.A1
1609390406
|
-
|
|
|
|
30 - SOCKET HEAD CAP SCREW
BSD-1609390407.A2
1609390407
|
-
|
|
|
|
31 - INTERMEDIATE BEARING
BSD-1609390408.A1
1609390408
|
-
|
|
|
|
32 - HEX SOCKET HEAD CAP SCREW
BSD-1609390315.A5
1609390315
|
-
|
|
|
|
33 - SPRING LOCK WASHER
BSD-1609390410.A7
1609390410
|
-
|
|
|
|
34 - LOCKING WASHER
BSD-1609390411.A0
1609390411
|
-
|
|
|
|
35 - TOOTHED GEAR
BSD-1609390412.A3
1609390412
|
-
|
|
|
|
36 - SHIM WASHER
BSD-1609390413.A0
1609390413
|
-
|
|
|
|
37 - COUNTERSUNK-HEAD SCREW
BSD-1609390414.A3
1609390414
|
-
|
|
|
|
38 - CONICAL SPRING WASHER
BSD-1609390415.A0
1609390415
|
-
|
|
|
|
39 - GROOVE BALL BEARING
BSD-1609390416.A6
1609390416
|
-
|
|
|
|
40 - SOCKET HEAD CAP SCREW
BSD-1609390417.A0
1609390417
|
-
|
|
|
|
41 - BEARING FLANGE
BSD-1609390418.A3
1609390418
|
-
|
|
|
|
42 - BEARING SLEEVE
BSD-1609390419.A0
1609390419
|
-
|
|
|
|
43 - WOODRUFF KEY
BSD-1609390420.A3
1609390420
|
-
|
|
|
|
44 - DRIVE SHAFT
BSD-1609390421.A0
1609390421
|
-
|
|
|
|
45 - STUD
BSD-1609390422.A3
1609390422
|
-
|
|
|
|
46 - DRIVE BEARING
BSD-1609390423.A0
1609390423
|
-
|
|
|
|
47 - GROOVE BALL BEARING
BSD-1609390416.A7
1609390416
|
-
|
|
|
|
48 - SPRING RETAINING RING
BSD-1609390424.A3
1609390424
|
-
|
|
|
|
49 - SPRING RETAINING RING
BSD-1609390425.A0
1609390425
|
-
|
|
|
|
50 - BALL PIN
BSD-1609390426.A3
1609390426
|
-
|
|
|
|
51 - DRIVE FLANGE
BSD-1609390427.A0
1609390427
|
-
|
|
|
|
52 - LIFTING ROD
BSD-1609390428.A3
1609390428
|
-
|
|
|
|
53 - SPRING LOCK WASHER
BSD-1609390410.A6
1609390410
|
-
|
|
|
|
54 - HEX SOCKET HEAD CAP SCREW
BSD-1609390315.A6
1609390315
|
-
|
|
|
|
56 - SOCKET HEAD CAP SCREW
BSD-1609390431.A0
1609390431
|
-
|
|
|
|
57 - GEAR HOUSING
BSD-1609390432.A3
1609390432
|
-
|
|
|
|
58 - SOCKET HEAD CAP SCREW
BSD-1609390433.A0
1609390433
|
-
|
|
|
|
59 - NEEDLE BEARING
BSD-1609390434.A3
1609390434
|
-
|
|
|
|
60 - BEARING SLEEVE
BSD-1609390435.A0
1609390435
|
-
|
|
|
|
61 - PAD
BSD-1609390436.A3
1609390436
|
-
|
|
|
|
62 - ROUND-HEAD SCREW
BSD-1609390437.A0
1609390437
|
-
|
|
|
|
63 - FASTENING CLAMP
BSD-1609390438.A3
1609390438
|
-
|
|
|
|
64 - CABLE CLIP
BSD-2601035001.A1938
2601035001
|
£1.75
|
£2.10
|
|
|
65 - SLEEVE TERMINAL
BSD-1609390440.A0
1609390440
|
-
|
|
|
|
66 - STICKER
BSD-1601110251.A1
1601110251
|
-
|
|
|
|
69 - INSULATING PLATE
BSD-1609390442.A0
1609390442
|
-
|
|
|
|
70 - BUTT CONNECTOR
BSD-1609390443.A3
1609390443
|
-
|
|
|
|
71 - BUTT CONNECTOR
BSD-1609390444.A0
1609390444
|
-
|
|
|
|
72 - BLADE TERMINAL
BSD-1609390445.A3
1609390445
|
-
|
|
|
|
150 - END SPLICE DIN 46 228-A1-6
BSD-1900452012.A292
1900452012
|
£1.75
|
£2.10
|
|
|
650 - PARTS SET
BSD-1609390441.A3
1609390441
|
-
|
|
|
|
650/1 - CLAMPING JAW
BSD-1609390381.A3
1609390381
|
-
|
|
|
|
650/2 - HEX SOCKET HEAD CAP SCREW
BSD-1609390315.A2
1609390315
|
-
|
|
|
|
650/3 - HEXAGON-SOCKET KEY
BSD-1609390316.A3
1609390316
|
-
|
|
|
|
650/4 - KEY HOLDER
BSD-1609390391.A2
1609390391
|
-
|
|
|
|
700 - CARRYING CASE
BSD-1605438038.A2
1605438038
|
-
|
|
|
|
810 - CARBON-BRUSH SET
BSD-1609390317.A0
1609390317
|
-
|
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A4785
160111A3H3
|
£2.61
|
£3.13
|
|
