1 - MOTOR HOUSING
BSD-3605108580.A3
3605108580
|
£24.45
|
£29.34
|
|
|
2 - FIELD 240V
BSD-1604220362.A8
1604220362
|
-
|
|
|
|
3 - ARMATURE 230-240V
BSD-3604010501.A5
3604010501
|
-
|
|
|
|
4 - SWITCH
BSD-2607200251.A7
2607200251
|
-
|
|
|
|
5 - POWER SUPPLY CORD GB 4.25m 2 x 1.5mm H05RR-F
BSD-2610993632.A3
2610993632
|
£65.08
|
£78.10
|
|
|
6 - GROMMET dia7.4 MM
BSD-3600703509.A10
3600703509
|
-
|
|
|
|
7 - CABLE CLIP
BSD-2601035001.A2943
2601035001
|
£1.84
|
£2.21
|
|
|
8 - MANUFACTURER'S NAMEPLATE
BSD-2610913461.A0
2610913461
|
-
|
|
|
|
9 - REFERENCE PLATE
BSD-2610998944.A1
2610998944
|
-
|
|
|
|
12 - SUPPRESSION FILTER
BSD-1617328025.A48
1617328025
|
-
|
|
|
|
13 - GROOVE BALL BEARING
BSD-2610913173.A16
2610913173
|
£15.46
|
£18.55
|
|
|
14 - BALL BEARING
BSD-3600905510.A11
3600905510
|
£6.94
|
£8.33
|
|
|
19 - TAPPING SCREW
BSD-2610910566.A41
2610910566
|
£1.38
|
£1.66
|
|
|
22 - HOUSING
BSD-2610997103.A5
2610997103
|
£58.76
|
£70.51
|
|
|
23 - RETAINING CLIP DIN 471-15x1-FSt
BSD-2916650006.A58
2916650006
|
£1.75
|
£2.10
|
|
|
24 - RETAINING PLATE
BSD-3600034505.A10
3600034505
|
£3.72
|
£4.47
|
|
|
25 - HEX NUT M15
BSD-3603300501.A4
3603300501
|
£4.26
|
£5.11
|
|
|
27 - COVER PLATE
BSD-2610997099.A21
2610997099
|
£22.60
|
£27.12
|
|
|
28 - ROD
BSD-2610997093.A5
2610997093
|
£6.94
|
£8.33
|
|
|
29 - POINTER
BSD-2610997094.A14
2610997094
|
£6.16
|
£7.39
|
|
|
30 - HOUSING COVER
BSD-3605500593.A4
3605500593
|
-
|
|
|
|
33 - SWING-PLATE
BSD-3601021509.A8
3601021509
|
£8.67
|
£10.41
|
|
|
34 - TORSION SPRING
BSD-3604651502.A36
3604651502
|
£2.33
|
£2.80
|
|
|
35 - SHOULDER SCREW M4
BSD-3603415556.A9
3603415556
|
£2.45
|
£2.94
|
|
|
36 - KNOB
BSD-3603231539.A39
3603231539
|
£2.45
|
£2.94
|
|
|
37 - INDICATOR RING
BSD-3600209500.A12
3600209500
|
£3.99
|
£4.79
|
|
|
38 - SPRING WASHER
BSD-3600100528.A2
3600100528
|
£1.95
|
£2.34
|
|
|
39 - WASHER
BSD-3600100527.A41
3600100527
|
£2.52
|
£3.02
|
|
|
40 - ADJUSTING SLEEVE
BSD-3600360507.A10
3600360507
|
-
|
|
|
|
41 - LOCKING PIECE
BSD-3600400507.A31
3600400507
|
£2.94
|
£3.53
|
|
|
42 - SPRING LOCK WASHER DIN 128-A4-FST
BSD-2916690003.A869
2916690003
|
£1.75
|
£2.10
|
|
|
43 - LOCKING LEVER
BSD-3602000510.A40
3602000510
|
£2.74
|
£3.29
|
|
|
44 - LOCK BOLT
BSD-3603450503.A14
3603450503
|
£5.01
|
£6.01
|
|
|
45 - LOCK SPRING
BSD-3604651503.A4
3604651503
|
£2.45
|
£2.94
|
|
|
46 - DEPTH-GAUGE
BSD-2610997191.A36
2610997191
|
£13.41
|
£16.09
|
|
|
47 - RATCHET CAP
BSD-2600590006.A570
2600590006
|
£1.84
|
£2.21
|
|
|
48 - SPRING WASHER
BSD-3916060500.A22
3916060500
|
£1.84
|
£2.21
|
|
|
49 - OVAL-HEAD SCREW DIN 7985-M4X12-4.8-H
BSD-2910641122.A57
2910641122
|
£2.27
|
£2.72
|
|
|
50 - WING SCREW M6x25 MM
BSD-1613480009.A62
1613480009
|
£1.88
|
£2.25
|
|
|
51 - AIR-DEFLECTOR RING
BSD-3600590507.A10
3600590507
|
-
|
|
|
|
52 - HANDLE COVER LT
BSD-3605133526.A10
3605133526
|
£8.49
|
£10.19
|
|
|
53 - HANDLE COVER RT
BSD-3605133528.A5
3605133528
|
£10.61
|
£12.73
|
|
|
54 - SCREW
BSD-2610915161.A11
2610915161
|
-
|
|
|
|
55 - SPRING RETAINING RING DIN 471-12x1-FSt
BSD-2916650003.A5
2916650003
|
£1.75
|
£2.10
|
|
|
56 - SPRING WASHER
BSD-2610992432.A2
2610992432
|
£2.45
|
£2.94
|
|
|
57 - COMPRESSION SPRING
BSD-3604613508.A5
3604613508
|
£2.45
|
£2.94
|
|
|
58 - GUIDE PIECE
BSD-3603120502.A32
3603120502
|
£2.64
|
£3.17
|
|
|
59 - BELLOWS
BSD-2610990698.A3
2610990698
|
£11.37
|
£13.64
|
|
|
60 - COMPRESSION SPRING
BSD-2610997100.A0
2610997100
|
£2.33
|
£2.80
|
|
|
61 - BLADE TERMINAL
BSD-1604477005.A38
1604477005
|
£2.74
|
£3.29
|
|
|
62 - RETAINING SNAP RING
BSD-3604680502.A4
3604680502
|
£2.45
|
£2.94
|
|
|
63 - COUNTERSUNK-HEAD SCREW DIN 965-M4x12-8.8
BSD-2910871122.A79
2910871122
|
-
|
|
|
|
64 - INSERT
BSD-3601010519.A27
3601010519
|
£2.64
|
£3.17
|
|
|
65 - CHIP DEFLECTOR
BSD-2610912599.A3
2610912599
|
-
|
|
|
|
66 - INSERT
BSD-3601010517.A8
3601010517
|
£2.64
|
£3.17
|
|
|
67 - O-RING
BSD-3600210507.A7
3600210507
|
£2.33
|
£2.80
|
|
|
70 - SOCKET HEAD CAP SCREW
BSD-3603410504.A27
3603410504
|
£2.64
|
£3.17
|
|
|
71 - BALL DIN 5401-4 MM-III-ST
BSD-1903230007.A504
1903230007
|
£1.84
|
£2.21
|
|
|
73 - SET RING
BSD-2610996090.A32
2610996090
|
-
|
|
|
|
77 - CONNECTING CABLE
BSD-3604445718.A12
3604445718
|
-
|
|
|
|
90 - TAB WASHER
BSD-1601030022.A488
1601030022
|
£1.84
|
£2.21
|
|
|
91 - O-RING 12.0x2.0 MM
BSD-1610210233.A31
1610210233
|
£2.94
|
£3.53
|
|
|
650/1 - SINGLE-HEAD ENG. WRENCH SW19
BSD-1907950511.A60
1907950511
|
£11.78
|
£14.13
|
|
|
731 - COLLET 1/4
BSD-2608570101.A13
2608570101
|
£23.32
|
£27.99
|
|
|
731 - COLLET 8 MM
BSD-2608570102.A2
2608570102
|
£26.24
|
£31.49
|
|
|
731 - COLLET 6 MM
BSD-2608570100.A2
2608570100
|
£24.99
|
£29.99
|
|
|
810 - CARBON-BRUSH SET
BSD-3604321513.A8
3604321513
|
£13.12
|
£15.75
|
|
|
816 - BRUSH HOLDER
BSD-3604336510.A0
3604336510
|
-
|
|
|
|
821 - SPRING
BSD-3604652501.A44
3604652501
|
£3.91
|
£4.69
|
|
|
826 - BASE
BSD-2610997116.A2
2610997116
|
£53.78
|
£64.54
|
|
