2 - FIELD 100-110V
BSD-3604220535.A1
3604220535
|
-
|
|
|
|
3 - ARMATURE 110V
BSD-3604011627.A0
3604011627
|
-
|
|
|
|
4 - FAN HOUSING
BSD-3605702592.A3
3605702592
|
£81.81
|
£98.17
|
|
|
5 - HOUSING COVER
BSD-3605500575.A2
3605500575
|
£8.17
|
£9.80
|
|
|
6 - SEALING CAP
BSD-3605500596.A2
3605500596
|
£2.52
|
£3.02
|
|
|
7 - BASE PLATE
BSD-3605702595.A19
3605702595
|
£120.11
|
£144.13
|
|
|
8 - INTERMEDIATE PLATE
BSD-3600190515.A21
3600190515
|
-
|
|
|
|
9 - HANDLE
BSD-3605133519.A20
3605133519
|
-
|
|
|
|
10 - HANDLE
BSD-3605133520.A2
3605133520
|
-
|
|
|
|
12 - TOOTHED LOCK WASHER
BSD-3600190516.A1
3600190516
|
£2.61
|
£3.13
|
|
|
13 - ON-OFF SWITCH
BSD-3607200510.A9
3607200510
|
-
|
|
|
|
14 - SUPPRESSION FILTER
BSD-1607328034.A2
1607328034
|
£4.48
|
£5.37
|
|
|
15 - FASTENING CLAMP
BSD-3601032500.A53
3601032500
|
£7.72
|
£9.27
|
|
|
16 - TAPPING SCREW DIN 7981-ST3.5x13-C-H
BSD-2910611011.A22
2910611011
|
-
|
|
|
|
17 - POWER SUPPLY CORD GB 4.25m 2 x 1.5mm H05RR-F
BSD-2610992448.A2
2610992448
|
£23.86
|
£28.63
|
|
|
19 - SHOULDER SCREW M4
BSD-3603415556.A1
3603415556
|
£2.45
|
£2.94
|
|
|
21 - BRUSH HOLDER
BSD-1604336008.A252
1604336008
|
£22.60
|
£27.12
|
|
|
22 - THREADED SPINDLE
BSD-3603500500.A13
3603500500
|
-
|
|
|
|
23 - TAPPING SCREW DIN 7981-ST3.9x13-C-H
BSD-2910611018.A59
2910611018
|
-
|
|
|
|
24 - TAPPING SCREW DIN 7981-ST3.9x16-C-H
BSD-2910611019.A614
2910611019
|
£2.94
|
£3.53
|
|
|
25 - HEX SOCKET HEAD CAP SCREW DIN 912-M6x16-8.8
BSD-2910141197.A400
2910141197
|
£1.84
|
£2.21
|
|
|
26 - SPIRAL SPRING
BSD-1614652001.A12
1614652001
|
£3.91
|
£4.69
|
|
|
28 - TAB WASHER
BSD-1611331007.A74
1611331007
|
£1.32
|
£1.58
|
|
|
29 - TAPPING SCREW B 4.8x68 MM
BSD-1613412001.A55
1613412001
|
£1.75
|
£2.10
|
|
|
30 - GROOVE BALL BEARING 6200-2 RS/C 3
BSD-1900905276.A27
1900905276
|
-
|
|
|
|
31 - SPRING RETAINING RING
BSD-3600119507.A11
3600119507
|
-
|
|
|
|
32 - GROOVE BALL BEARING
BSD-3600900526.A29
3600900526
|
£31.64
|
£37.97
|
|
|
33 - FIXING PLATE
BSD-3600034503.A19
3600034503
|
-
|
|
|
|
34 - REC CT-SUNK TAPPING SCREW
BSD-3603415559.A10
3603415559
|
£2.05
|
£2.46
|
|
|
35 - HEX NUT
BSD-3603301522.A13
3603301522
|
-
|
|
|
|
37 - RETAINING BRACKET
BSD-3601961500.A21
3601961500
|
-
|
|
|
|
38 - COMPRESSION SPRING
BSD-3604613502.A10
3604613502
|
-
|
|
|
|
39 - SCREW DIN 7982-ST4.8x19
BSD-2910611034.A24
2910611034
|
-
|
|
|
|
40 - SCREW 4x13 MM
BSD-3603415540.A26
3603415540
|
£2.74
|
£3.29
|
|
|
41 - DEPTH-GAUGE
BSD-2610997191.A42
2610997191
|
£13.41
|
£16.09
|
|
|
43 - LEAF SPRING
BSD-3601254501.A0
3601254501
|
£8.92
|
£10.70
|
|
|
44 - LOCKING LEVER
BSD-3602033500.A11
3602033500
|
£1.75
|
£2.10
|
|
|
45 - AXLE
BSD-3603053503.A11
3603053503
|
-
|
|
|
|
46 - COMPRESSION SPRING
BSD-3604613503.A11
3604613503
|
£2.61
|
£3.13
|
|
|
47 - OVAL-HEAD SCREW DIN 7985-M4x8-8.8-H
BSD-2910951118.A17
2910951118
|
£1.84
|
£2.21
|
|
|
47/1 - PLAIN WASHER DIN 125-A4.3-ST
BSD-2916011010.A206
2916011010
|
£1.84
|
£2.21
|
|
|
48 - HEX NUT DIN 985-M10-10
BSD-2915065007.A9
2915065007
|
-
|
|
|
|
49 - ADJUSTING NUT
BSD-2603345015.A9
2603345015
|
-
|
|
|
|
50 - GUIDE PIECE
BSD-3603120501.A0
3603120501
|
-
|
|
|
|
51 - CATCH LEVER
BSD-3602000511.A0
3602000511
|
-
|
|
|
|
52 - CLAMPING SPRING
BSD-3604651501.A0
3604651501
|
-
|
|
|
|
53 - ADJUSTING ECCENTRIC
BSD-3602202500.A11
3602202500
|
-
|
|
|
|
54 - PLAIN WASHER DIN 125-A4.3-ST
BSD-2916011010.A207
2916011010
|
£1.84
|
£2.21
|
|
|
55 - HEX NUT DIN 985-M4-8
BSD-2915061002.A24
2915061002
|
£1.84
|
£2.21
|
|
|
56 - SCREW B 4.8x45 MM
BSD-3603415560.A144
3603415560
|
£1.84
|
£2.21
|
|
|
57 - COMPRESSION SPRING
BSD-3604619502.A2
3604619502
|
£2.61
|
£3.13
|
|
|
58 - HEX NUT DIN 439-BM10-04
BSD-2915055108.A9
2915055108
|
-
|
|
|
|
59 - SPRING WASHER
BSD-3916060500.A9
3916060500
|
£1.84
|
£2.21
|
|
|
61 - MANUFACTURER'S NAMEPLATE
BSD-3601119785.A2
3601119785
|
-
|
|
|
|
63 - PROTECTIVE SHIELD
BSD-3605510526.A9
3605510526
|
-
|
|
|
|
65 - REC CT-SUNK TAPPING SCREW DIN 7982-ST4.8x18-F-H
BSD-2910601433.A20
2910601433
|
-
|
|
|
|
74 - AIR-DEFLECTOR RING
BSD-3600590504.A11
3600590504
|
-
|
|
|
|
75 - TAB WASHER
BSD-1601030022.A500
1601030022
|
£1.84
|
£2.21
|
|
|
76 - SPRING WASHER
BSD-3916060501.A2
3916060501
|
-
|
|
|
|
78 - TAPPING SCREW DIN 7981-ST4.8x25-C-H
BSD-2910611036.A2
2910611036
|
-
|
|
|
|
82 - SOCKET HEAD CAP SCREW
BSD-3603410504.A16
3603410504
|
£2.64
|
£3.17
|
|
|
652/1 - SINGLE-HEAD ENG. WRENCH SW12
BSD-1607950514.A9
1607950514
|
-
|
|
|
|
652/8 - THREADED SPINDLE M 12x1 MM
BSD-3603523501.A11
3603523501
|
-
|
|
|
|
652/9 - GUIDE BUSHING
BSD-3605703531.A2
3605703531
|
-
|
|
|
|
652/10 - SOCKET HEAD CAP SCREW
BSD-3603415553.A30
3603415553
|
£2.74
|
£3.29
|
|
|
652/11 - DEPTH-GAUGE
BSD-3603029500.A0
3603029500
|
-
|
|
|
|
652/14 - WING SCREW M6x20 MM
BSD-1613480008.A404
1613480008
|
£1.84
|
£2.21
|
|
|
736 - COLLET 12 MM
BSD-2608570113.A7
2608570113
|
£29.16
|
£34.99
|
|
|
736 - COLLET 1/2
BSD-2608570114.A2
2608570114
|
£29.99
|
£35.99
|
|
|
736 - COLLET 1/4
BSD-2608570110.A2
2608570110
|
£28.32
|
£33.99
|
|
|
736 - COLLET 3/8
BSD-2608570112.A2
2608570112
|
-
|
|
|
|
736 - COLLET 10 MM
BSD-2608570126.A9
2608570126
|
-
|
|
|
|
736 - COLLET 8
BSD-2608570111.A9
2608570111
|
£28.32
|
£33.99
|
|
|
736 - COLLET 6
BSD-2608570109.A9
2608570109
|
£29.74
|
£35.69
|
|
|
753 - VACUUM ADAPTER
BSD-3608939626.A20
3608939626
|
-
|
|
|
|
753/3 - BRUSH-COVER
BSD-3607929500.A11
3607929500
|
-
|
|
|
|
753/4 - COUNTERSUNK-HEAD SCREW DIN 963-M5x25-4.8
BSD-2910761164.A20
2910761164
|
-
|
|
|
|
753/5 - KNURLED NUT
BSD-3603345509.A12
3603345509
|
£2.80
|
£3.36
|
|
|
753/6 - PLAIN WASHER DIN 433-5.3-ST
BSD-2916011011.A129
2916011011
|
£1.75
|
£2.10
|
|
|
753/7 - SPRING WASHER
BSD-3600100520.A1
3600100520
|
£2.16
|
£2.59
|
|
|
797 - PARALLEL-GUIDE
BSD-3607000620.A11
3607000620
|
-
|
|
|
|
797/2 - LOCKING PIECE
BSD-3600400508.A1
3600400508
|
£10.61
|
£12.73
|
|
|
797/3 - ADJUSTMENT KNOB
BSD-3600360508.A5
3600360508
|
£5.58
|
£6.70
|
|
|
797/4 - GUIDE ROD 10 MM
BSD-3603001518.A16
3603001518
|
-
|
|
|
|
797/5 - WING SCREW M6x20 MM
BSD-1613480008.A405
1613480008
|
£1.84
|
£2.21
|
|
|
797/6 - STICKER
BSD-3601119780.A0
3601119780
|
-
|
|
|
|
800 - CARBON-BRUSH SET
BSD-1607014103.A136
1607014103
|
£15.65
|
£18.78
|
|
|
801 - MOTOR HOUSING
BSD-3605108589.A13
3605108589
|
-
|
|
|
|
809 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A2326
2603410001
|
£1.84
|
£2.21
|
|
|
842 - SPRING RETAINING RING DIN 471 25x1.2
BSD-2916650014.A90
2916650014
|
£1.84
|
£2.21
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A3337
160111A3H3
|
£2.74
|
£3.29
|
|
