1 - MOTOR HOUSING
BSD-1615108026.A20
1615108026
|
-
|
|
|
|
2 - FIELD 110-120V
BSD-2604220428.A23
2604220428
|
£28.59
|
£34.31
|
|
|
3/50 - FAN
BSD-1616610072.A99
1616610072
|
£2.27
|
£2.72
|
|
|
4 - ON-OFF SWITCH
BSD-2607200180.A1
2607200180
|
-
|
|
|
|
5 - POWER SUPPLY CORD GB 110V 4.15m 2 x 1.0mm H07 RN-F
BSD-1614460061.A29
1614460061
|
£21.68
|
£26.01
|
|
|
6 - GROMMET dia8.3-dia9.4x95 MM
BSD-2600703011.A632
2600703011
|
£2.94
|
£3.53
|
|
|
7 - CABLE CLIP
BSD-1611035005.A4
1611035005
|
£2.16
|
£2.59
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1611110723.A3
1611110723
|
-
|
|
|
|
10 - MANUFACTURER'S NAMEPLATE
BSD-1611110724.A2
1611110724
|
-
|
|
|
|
12 - SUPPRESSION FILTER
BSD-2607329096.A201
2607329096
|
£7.72
|
£9.27
|
|
|
13 - BRUSH HOLDER
BSD-2604337003.A117
2604337003
|
£2.16
|
£2.59
|
|
|
13/1 - CARB BRUSH HOLD W-SUPR
BSD-1614465003.A2
1614465003
|
-
|
|
|
|
14 - SUPPRESSOR BOX L=93/85 MM
BSD-2604465071.A50
2604465071
|
-
|
|
|
|
17 - HOUSING COVER
BSD-1615132031.A17
1615132031
|
-
|
|
|
|
18 - AIR-DEFLECTOR RING
BSD-1610522008.A30
1610522008
|
£1.84
|
£2.21
|
|
|
20 - INTERMEDIATE FLANGE
BSD-1615700037.A121
1615700037
|
£40.80
|
£48.96
|
|
|
21 - RATCHET SLEEVE S2S
BSD-1616490035.A3
1616490035
|
£61.70
|
£74.04
|
|
|
22 - CYLINDRICAL GEAR Z=46
BSD-1616320007.A50
1616320007
|
£7.36
|
£8.83
|
|
|
23 - CYLINDRICAL GEAR Z=6/21
BSD-1616320002.A111
1616320002
|
£24.45
|
£29.34
|
|
|
24 - TOOTHED SHAFT Z=6/10
BSD-1613060010.A19
1613060010
|
£54.42
|
£65.30
|
|
|
26 - HAMMER PISTON
BSD-1618700052.A98
1618700052
|
£13.78
|
£16.54
|
|
|
28 - STRIKER PIN
BSD-1613124026.A95
1613124026
|
£2.80
|
£3.36
|
|
|
29 - PISTON PIN
BSD-1613105012.A204
1613105012
|
£3.91
|
£4.69
|
|
|
30 - DRIVE BEARING
BSD-1615819005.A10
1615819005
|
£31.64
|
£37.97
|
|
|
31 - SUPPORT DISC 0.8 MM
BSD-1610100003.A41
1610100003
|
£1.84
|
£2.21
|
|
|
32 - CLAMP HANDLE
BSD-1612026023.A109
1612026023
|
£2.74
|
£3.29
|
|
|
34 - PROTECTIVE CAP L=24 MM
BSD-1610508016.A4
1610508016
|
-
|
|
|
|
35 - RUBBER RING
BSD-1610206021.A101
1610206021
|
£1.84
|
£2.21
|
|
|
37 - DAMPING BUSHING
BSD-1610390011.A14
1610390011
|
£3.72
|
£4.47
|
|
|
38 - SUPPORTING DISC
BSD-1610102022.A30
1610102022
|
£2.16
|
£2.59
|
|
|
39 - STRAIGHT PIN
BSD-1613100013.A147
1613100013
|
£2.16
|
£2.59
|
|
|
40 - HOLDING SPRING
BSD-1614690001.A123
1614690001
|
£1.84
|
£2.21
|
|
|
41 - ROLLER-CAGE ASSEMBLY
BSD-1610920003.A95
1610920003
|
£4.26
|
£5.11
|
|
|
44 - COMPRESSION SPRING
BSD-1614633001.A40
1614633001
|
£2.64
|
£3.17
|
|
|
45 - COMPRESSION SPRING
BSD-1614614001.A46
1614614001
|
£1.84
|
£2.21
|
|
|
49 - CABLE L=130 MM
BSD-2604448005.A247
2604448005
|
£1.84
|
£2.21
|
|
|
50 - CABLE
BSD-2604448003.A121
2604448003
|
-
|
|
|
|
54 - O-RING 24.0x2.5 MM
BSD-1610210068.A97
1610210068
|
£1.75
|
£2.10
|
|
|
55 - SEAL RING
BSD-1610206023.A70
1610206023
|
£2.94
|
£3.53
|
|
|
56 - O-RING 14.0x3.0 MM
BSD-1610210070.A79
1610210070
|
£2.74
|
£3.29
|
|
|
57 - O-RING 34.0x2.0 MM
BSD-1610210084.A26
1610210084
|
£1.84
|
£2.21
|
|
|
58 - O-RING 18.0x3.0 MM
BSD-1610210058.A32
1610210058
|
£2.74
|
£3.29
|
|
|
59 - O-RING 6.0x2.5 MM
BSD-1610210069.A91
1610210069
|
£1.84
|
£2.21
|
|
|
60 - O-RING 10.0x3.5 MM
BSD-1610210073.A66
1610210073
|
£2.16
|
£2.59
|
|
|
61 - ROTARY SHAFT LIP SEAL
BSD-1610283017.A30
1610283017
|
£7.36
|
£8.83
|
|
|
62 - PLAIN BEARING
BSD-1610202026.A195
1610202026
|
£5.57
|
£6.68
|
|
|
63 - GROOVE BALL BEARING 9x24x7
BSD-1610905048.A396
1610905048
|
£8.67
|
£10.41
|
|
|
64 - BALL BEARING 7x19x6
BSD-2600905032.A1734
2600905032
|
£5.57
|
£6.68
|
|
|
65 - GROOVE BALL BEARING 8x22x7
BSD-1900900228.A129
1900900228
|
£6.61
|
£7.93
|
|
|
66 - BUSHING dia30xdia37x15.7 MM
BSD-1610301000.A44
1610301000
|
£3.34
|
£4.01
|
|
|
67 - NEEDLE BEARING
BSD-1610910064.A326
1610910064
|
£2.64
|
£3.17
|
|
|
70 - BALL DIN 5401-dia7MM-III-ST
BSD-1903230013.A370
1903230013
|
£2.27
|
£2.72
|
|
|
71 - SHIM WASHER 1.2 MM
BSD-1610101011.A13
1610101011
|
£1.75
|
£2.10
|
|
|
72 - RETAINING RING DIN 7993-A32
BSD-2916540018.A35
2916540018
|
£3.91
|
£4.69
|
|
|
73 - RETAINING RING DIN 9045-24
BSD-1614601009.A176
1614601009
|
£2.05
|
£2.46
|
|
|
76 - TAPPING SCREW ST-4.8x57.5-TORX.T20
BSD-1613435009.A126
1613435009
|
£1.75
|
£2.10
|
|
|
77 - TAPPING SCREW DIN 7971-ST3.9x22-F
BSD-2910211021.A310
2910211021
|
£1.75
|
£2.10
|
|
|
78 - TAPPING SCREW ST3.9x19-TORX.T20
BSD-1603435050.A94
1603435050
|
£2.33
|
£2.80
|
|
|
79 - TAPPING SCREW DIN 7971-ST2.9x9.5-F
BSD-2910211005.A384
2910211005
|
£1.84
|
£2.21
|
|
|
79 - TAPPING SCREW DIN 7971-B 2.9x13
BSD-2910211206.A5
2910211206
|
£1.38
|
£1.66
|
|
|
80 - RECESSED-HEAD SCREW DIN 7981-ST3.5x9.5-F
BSD-2603435015.A325
2603435015
|
£2.27
|
£2.72
|
|
|
81 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A2619
2603410001
|
£1.84
|
£2.21
|
|
|
83 - BALL 5 MM V DIN 5401
BSD-1903230309.A56
1903230309
|
£1.84
|
£2.21
|
|
|
87 - RETAINING RING DIN 7993-A22
BSD-2916540012.A420
2916540012
|
-
|
|
|
|
94 - DETENT PIN
BSD-1613120017.A52
1613120017
|
£1.84
|
£2.21
|
|
|
120 - AUXILIARY HANDLE M8
BSD-1612025041.A16
1612025041
|
£21.42
|
£25.71
|
|
|
121 - SUPPORT CLAMP dia43 MM
BSD-1618040064.A32
1618040064
|
£8.92
|
£10.70
|
|
|
122 - T-HEAD BOLT M8x40 MM
BSD-1613490002.A544
1613490002
|
£4.48
|
£5.37
|
|
|
123 - CLAMPING BAND dia43 MM
BSD-1611316006.A338
1611316006
|
£2.61
|
£3.13
|
|
|
661 - GREASE TUBE 30 ML
BSD-1615430009.A49
1615430009
|
£13.78
|
£16.54
|
|
|
720/8 - AUXILIARY HANDLE dia43 MM
BSD-1612025047.A19
1612025047
|
-
|
|
|
|
751 - DEPTH-GAUGE SW 6x210 MM
BSD-1613001009.A246
1613001009
|
£3.91
|
£4.69
|
|
|
803 - ARMATURE WITH FAN 110-120V
BSD-1614010041.A10
1614010041
|
-
|
|
|
|
808 - NAMEPLATE
BSD-160111A3HD.A51
160111A3HD
|
£2.74
|
£3.29
|
|
|
811 - CARBON BRUSH
BSD-1617014114.A12
1617014114
|
£10.61
|
£12.73
|
|
|
816 - GEAR HOUSING
BSD-1615806081.A13
1615806081
|
£33.45
|
£40.14
|
|
|
827 - STRIKER
BSD-1617000338.A137
1617000338
|
£28.59
|
£34.31
|
|
|
833 - PROTECTION SLEEVE S2S
BSD-1617000168.A24
1617000168
|
£5.87
|
£7.04
|
|
|
843 - BRUSH PLATE
BSD-2601015047.A126
2601015047
|
-
|
|
|
|
890 - CHANGE-OVER SWITCH
BSD-2607200206.A68
2607200206
|
-
|
|
|
