1 - MOTOR HOUSING
BSD-3605108094.A65
3605108094
|
-
|
|
|
|
2 - BRUSH HOLDER
BSD-1604336005.A71
1604336005
|
-
|
|
|
|
3 - SPIRAL SPRING
BSD-1604652001.A22
1604652001
|
-
|
|
|
|
4 - FIELD 220-230V
BSD-1604220082.A22
1604220082
|
-
|
|
|
|
5 - AIR-DEFLECTOR RING
BSD-1600209002.A71
1600209002
|
£5.30
|
£6.36
|
|
|
7 - ARMATURE WITH FAN 240V
BSD-1604010029.A2
1604010029
|
-
|
|
|
|
8 - BALL BEARING 7x19x6
BSD-2600905032.A246
2600905032
|
£5.57
|
£6.68
|
|
|
8 - INTERMEDIATE RING
BSD-1600502011.A47
1600502011
|
£2.74
|
£3.29
|
|
|
12 - SEALING CAP
BSD-3605500057.A191
3605500057
|
-
|
|
|
|
15 - SWITCH
BSD-1607200078.A18
1607200078
|
£42.84
|
£51.41
|
|
|
15 - SWITCH
BSD-1607200037.A116
1607200037
|
£47.95
|
£57.54
|
|
|
16 - POWER SUPPLY CORD EU 4.15m 2 x 1.0mm H07 RN-F
BSD-1607000227.A52
1607000227
|
£23.86
|
£28.63
|
|
|
17 - GROMMET dia9.2-dia12x120 MM
BSD-3600703011.A1072
3600703011
|
£2.94
|
£3.53
|
|
|
19 - SUPPRESSION CAPACITOR
BSD-1607328012.A23
1607328012
|
-
|
|
|
|
20 - REFERENCE PLATE
BSD-1601110058.A231
1601110058
|
£1.75
|
£2.10
|
|
|
21 - INSULATING STRIP 33x10x6 MM
BSD-1602381001.A351
1602381001
|
-
|
|
|
|
24 - NAMEPLATE
BSD-160111A3H3.A394
160111A3H3
|
£2.74
|
£3.29
|
|
|
25 - MANUFACTURER'S NAMEPLATE
BSD-1601110004.A149
1601110004
|
-
|
|
|
|
27 - O-RING 74.0x3.0 MM
BSD-1600210006.A49
1600210006
|
£1.84
|
£2.21
|
|
|
28 - FASTENING CLAMP
BSD-1601302014.A974
1601302014
|
£2.74
|
£3.29
|
|
|
30 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A1761
2910211019
|
£1.84
|
£2.21
|
|
|
31 - SOCKET HEAD CAP SCREW DIN 84-AM5x12-8.8
BSD-2910021154.A64
2910021154
|
£1.75
|
£2.10
|
|
|
33 - SOCKET HEAD CAP SCREW M5x35 DIN 84-5.8
BSD-2910011168.A19
2910011168
|
-
|
|
|
|
33 - SCREW B 4.8x45 MM
BSD-3603415560.A93
3603415560
|
£1.84
|
£2.21
|
|
|
34 - SOCKET HEAD CAP SCREW DIN 84-BM5x55-8.8
BSD-2910021176.A126
2910021176
|
-
|
|
|
|
34 - TAPPING SCREW B 4.8x68 MM
BSD-1613412001.A142
1613412001
|
£1.75
|
£2.10
|
|
|
35 - SOCKET HEAD CAP SCREW DIN 84-AM5x22-8.8
BSD-2910021163.A11
2910021163
|
-
|
|
|
|
36 - SOCKET HEAD CAP SCREW DIN 84-AM4x15-8.8
BSD-2910021125.A401
2910021125
|
£1.75
|
£2.10
|
|
|
37 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A1187
2910021118
|
£1.84
|
£2.21
|
|
|
38 - SOCKET HEAD CAP SCREW DIN 84-AM4x6-8.8
BSD-2910021116.A385
2910021116
|
£2.27
|
£2.72
|
|
|
39 - SOCKET HEAD CAP SCREW DIN 84-AM4x18-8.8
BSD-2910021128.A58
2910021128
|
-
|
|
|
|
39 - TAPPING SCREW DIN 7971-B 3.9x19
BSD-2910211220.A30
2910211220
|
-
|
|
|
|
41 - SPRING LOCK WASHER DIN 127-B 5
BSD-2916680006.A252
2916680006
|
-
|
|
|
|
42 - SPRING WASHER DIN 137-A4
BSD-1600150006.A353
1600150006
|
-
|
|
|
|
44 - PAN HEAD SCREW DIN 85 AM 4x6-MS
BSD-2910110116.A18
2910110116
|
£1.84
|
£2.21
|
|
|
45 - SPRING LOCK WASHER DIN 128-A4-FST
BSD-2916690003.A170
2916690003
|
£1.75
|
£2.10
|
|
|
46 - PLAIN WASHER A 4.3 DIN 125-ST
BSD-2916010410.A22
2916010410
|
-
|
|
|
|
60 - SPINDLE BEARING
BSD-1605806222.A16
1605806222
|
-
|
|
|
|
61 - DRILLING SPINDLE
BSD-1603124039.A29
1603124039
|
-
|
|
|
|
62 - GROOVE BALL BEARING 15x32x8
BSD-1900900201.A82
1900900201
|
-
|
|
|
|
63 - RETAINING SNAP RING
BSD-3607030355.A145
3607030355
|
£19.91
|
£23.89
|
|
|
64 - SEALING DISK
BSD-1600108000.A2
1600108000
|
-
|
|
|
|
65 - SPACER BUSHING
BSD-1600300026.A62
1600300026
|
-
|
|
|
|
66 - GROOVE BALL BEARING 15x35x11
BSD-1900900303.A26
1900900303
|
-
|
|
|
|
67 - SHIM 0.5 MM
BSD-1600102003.A94
1600102003
|
£1.75
|
£2.10
|
|
|
68 - SPRING RETAINING RING DIN 472 35x1.5 MM
BSD-2916660014.A322
2916660014
|
£1.75
|
£2.10
|
|
|
69 - SPACER BUSHING
BSD-1600300027.A45
1600300027
|
-
|
|
|
|
70 - CYLINDRICAL GEAR Z=50
BSD-1606317045.A98
1606317045
|
-
|
|
|
|
71 - SPINDLE WITH GEAR Z=9/33
BSD-1606328044.A10
1606328044
|
-
|
|
|
|
72 - SHIM 0.5 MM
BSD-1600100631.A421
1600100631
|
£1.75
|
£2.10
|
|
|
96 - FELT DISC
BSD-1600108003.A57
1600108003
|
£1.38
|
£1.66
|
|
|
97 - BEARING COVER
BSD-1600501019.A471
1600501019
|
£25.05
|
£30.06
|
|
|
98 - GROOVE BALL BEARING 17x35x10
BSD-1600900001.A163
1600900001
|
-
|
|
|
|
99 - BEARING FLANGE
BSD-1605820096.A14
1605820096
|
-
|
|
|
|
100 - SOCKET HEAD CAP SCREW DIN 84-AM4x15-8.8
BSD-2910021125.A402
2910021125
|
£1.75
|
£2.10
|
|
|
650 - AUXILIARY HANDLE M14
BSD-1602025022.A311
1602025022
|
£13.41
|
£16.09
|
|
|
650 - AUXILIARY HANDLE M14. dia37x115 MM
BSD-1602025030.A409
1602025030
|
£19.91
|
£23.89
|
|
|
651 - KEY CHUCK dia1.5-13 MM. B16
BSD-1608571027.A21
1608571027
|
-
|
|
|
|
800 - HANDLE
BSD-3605133012.A179
3605133012
|
-
|
|
|
|
802 - CARBON-BRUSH SET
BSD-1607014101.A51
1607014101
|
£11.87
|
£14.24
|
|
