8 - NAMEPLATE
BSD-160111A6KS.A0
160111A6KS
|
-
|
|
|
|
9 - NAMEPLATE
BSD-1619PB0396.A4
1619PB0396
|
-
|
|
|
|
25 - ARMATURE WITH FAN 110V
BSD-1600A0073E.A1
1600A0073E
|
£553.99
|
£664.79
|
|
|
30 - FIELD 110V
BSD-160422053F.A1
160422053F
|
£306.65
|
£367.98
|
|
|
35 - PRINTED CIRCUIT BOARD
BSD-1600325009.A0
1600325009
|
£116.15
|
£139.38
|
|
|
40 - COOLING SHEET
BSD-1600A0073F.A0
1600A0073F
|
£40.80
|
£48.96
|
|
|
45 - SEAL
BSD-1600A00742.A3
1600A00742
|
£12.04
|
£14.45
|
|
|
50 - INSULATING SLEEVE
BSD-1600325008.A1
1600325008
|
£11.30
|
£13.56
|
|
|
60 - AIR-DEFLECTOR RING
BSD-160059105P.A4
160059105P
|
£13.12
|
£15.75
|
|
|
65 - SEAL
BSD-1600A0073G.A8
1600A0073G
|
£8.67
|
£10.41
|
|
|
70 - TERMINAL BOX
BSD-1600A00MZ7.A1
1600A00MZ7
|
-
|
|
|
|
85 - CARRYING HANDLE
BSD-1600A0073K.A8
1600A0073K
|
£31.64
|
£37.97
|
|
|
90 - GROOVE BALL BEARING
BSD-160090004R.A7
160090004R
|
£37.27
|
£44.72
|
|
|
95 - GROOVE BALL BEARING
BSD-160090004S.A1
160090004S
|
£39.13
|
£46.96
|
|
|
100 - SHIM
BSD-1600A0073L.A0
1600A0073L
|
£5.58
|
£6.70
|
|
|
105 - O-RING
BSD-1600210067.A8
1600210067
|
£3.72
|
£4.47
|
|
|
110 - ROTARY SHAFT LIP SEAL
BSD-1600A004Y0.A10
1600A004Y0
|
£21.68
|
£26.01
|
|
|
115 - HEX SOCKET HEAD CAP SCREW
BSD-1600A0073N.A8
1600A0073N
|
£2.16
|
£2.59
|
|
|
120 - HEX SOCKET HEAD CAP SCREW
BSD-1600A0073P.A0
1600A0073P
|
£12.04
|
£14.45
|
|
|
125 - SOCKET HEAD CAP SCREW
BSD-160341001D.A3
160341001D
|
£2.16
|
£2.59
|
|
|
130 - SOCKET HEAD CAP SCREW
BSD-160341001E.A5
160341001E
|
£1.84
|
£2.21
|
|
|
135 - COUNTERSUNK-HEAD SCREW
BSD-1603490A0D.A3
1603490A0D
|
£1.75
|
£2.10
|
|
|
145 - OVAL-HEAD SCREW
BSD-1600A019B5.A4
1600A019B5
|
-
|
|
|
|
150 - HEX NUT
BSD-1600A0073S.A8
1600A0073S
|
£1.75
|
£2.10
|
|
|
160 - OVAL-HEAD SCREW
BSD-1601A013TB.A0
1601A013TB
|
-
|
|
|
|
165 - LOCKING WASHER
BSD-1600A0073V.A6
1600A0073V
|
£1.75
|
£2.10
|
|
|
170 - SPRING WASHER
BSD-1600150021.A4
1600150021
|
£1.84
|
£2.21
|
|
|
180 - PLAIN WASHER
BSD-1600A0073W.A8
1600A0073W
|
£1.75
|
£2.10
|
|
|
190 - SUPPRESSION CAPACITOR
BSD-1600A0073X.A0
1600A0073X
|
£21.68
|
£26.01
|
|
|
205 - CABLE GLAND
BSD-1600A0073Z.A2
1600A0073Z
|
£21.52
|
£25.83
|
|
|
215 - MAINS SWITCH
BSD-1600A00741.A6
1600A00741
|
£102.57
|
£123.08
|
|
|
400 - GEAR HOUSING
BSD-160580659Y.A8
160580659Y
|
£500.46
|
£600.55
|
|
|
430 - PINION SHAFT
BSD-1600A00743.A6
1600A00743
|
£251.67
|
£302.00
|
|
|
435 - GEAR SHAFT
BSD-1600A00744.A2
1600A00744
|
£306.65
|
£367.98
|
|
|
440 - HEX NUT
BSD-1600A0077E.A6
1600A0077E
|
£33.74
|
£40.49
|
|
|
445 - BUSHING
BSD-160030010H.A7
160030010H
|
£48.38
|
£58.06
|
|
|
450 - CYLINDRICAL GEAR
BSD-1600A0076R.A2
1600A0076R
|
£179.37
|
£215.24
|
|
|
455 - CYLINDRICAL GEAR
BSD-1600A0076S.A6
1600A0076S
|
£135.25
|
£162.30
|
|
|
460 - CYLINDRICAL GEAR
BSD-1600A0076T.A2
1600A0076T
|
£251.67
|
£302.00
|
|
|
465 - CYLINDRICAL GEAR
BSD-1600A0076U.A6
1600A0076U
|
£135.25
|
£162.30
|
|
|
480 - PROTECTION SLEEVE
BSD-1600A00746.A8
1600A00746
|
£23.86
|
£28.63
|
|
|
490 - WORM SHAFT
BSD-1600A0076V.A0
1600A0076V
|
£45.67
|
£54.80
|
|
|
495 - GROOVE BALL BEARING
BSD-160090004U.A7
160090004U
|
£45.67
|
£54.80
|
|
|
500 - GROOVE BALL BEARING
BSD-160090004V.A1
160090004V
|
£42.84
|
£51.41
|
|
|
505 - NEEDLE-ROLLER BEARING
BSD-160090004W.A7
160090004W
|
£107.69
|
£129.23
|
|
|
510 - NOZZLE SOCKET
BSD-1600A0076W.A7
1600A0076W
|
£45.67
|
£54.80
|
|
|
515 - NEEDLE BEARING
BSD-1600A0076X.A1
1600A0076X
|
£37.27
|
£44.72
|
|
|
520 - NEEDLE BEARING
BSD-1600A0076Y.A7
1600A0076Y
|
£40.80
|
£48.96
|
|
|
525 - NEEDLE AXIAL BALL BEARIN
BSD-1600A0076Z.A1
1600A0076Z
|
£81.81
|
£98.17
|
|
|
530 - THRUST NEEDLE RIM
BSD-1600A00770.A7
1600A00770
|
£27.23
|
£32.68
|
|
|
535 - THRUST BEARING DISC
BSD-1600A00771.A1
1600A00771
|
£12.04
|
£14.45
|
|
|
540 - O-RING
BSD-1600210068.A2
1600210068
|
£9.11
|
£10.93
|
|
|
545 - O-RING
BSD-1600210069.A6
1600210069
|
£2.27
|
£2.72
|
|
|
550 - O-RING
BSD-1600210063.A10
1600210063
|
£2.16
|
£2.59
|
|
|
555 - O-RING
BSD-1600210064.A2
1600210064
|
£2.27
|
£2.72
|
|
|
560 - SHAFT SEAL
BSD-1600A00772.A8
1600A00772
|
£23.86
|
£28.63
|
|
|
565 - SHAFT SEAL
BSD-1600A00773.A0
1600A00773
|
£23.86
|
£28.63
|
|
|
570 - SHAFT SEAL
BSD-1600A00774.A8
1600A00774
|
£23.86
|
£28.63
|
|
|
605 - SEAL RING
BSD-1600A004YF.A7
1600A004YF
|
£1.75
|
£2.10
|
|
|
610 - HELICAL COMPRESS. SPRING
BSD-1600A00777.A0
1600A00777
|
£4.26
|
£5.11
|
|
|
615 - BALL
BSD-1600A0077A.A8
1600A0077A
|
£1.75
|
£2.10
|
|
|
625 - PARALLEL KEY
BSD-1600A0077B.A0
1600A0077B
|
£3.72
|
£4.47
|
|
|
630 - PARALLEL KEY
BSD-1600A0077C.A8
1600A0077C
|
£2.80
|
£3.36
|
|
|
635 - PARALLEL KEY
BSD-1600A0077D.A0
1600A0077D
|
£2.61
|
£3.13
|
|
|
655 - SPRING RETAINING RING
BSD-1600150022.A3
1600150022
|
£8.67
|
£10.41
|
|
|
660 - SPRING RETAINING RING
BSD-1600150023.A5
1600150023
|
£1.84
|
£2.21
|
|
|
670 - RETAINING RING
BSD-160460102P.A4
160460102P
|
£1.75
|
£2.10
|
|
|
675 - CYLINDRICAL GEAR
BSD-1600A0079B.A4
1600A0079B
|
£102.57
|
£123.08
|
|
|
680 - HEX SOCKET HEAD CAP SCREW
BSD-1600A0077G.A1
1600A0077G
|
£2.61
|
£3.13
|
|
|
685 - HEX SOCKET HEAD CAP SCREW
BSD-1600A0077H.A7
1600A0077H
|
£2.80
|
£3.36
|
|
|
690 - LOCKING WASHER
BSD-1600A0073V.A5
1600A0073V
|
£1.75
|
£2.10
|
|
|
805 - MOTOR HOUSING
BSD-16051082C1.A6
16051082C1
|
£321.98
|
£386.38
|
|
|
810 - INTERMEDIATE FLANGE
BSD-1600A0077L.A1
1600A0077L
|
£357.27
|
£428.72
|
|
|
820 - COVER
BSD-16055002BL.A0
16055002BL
|
-
|
|
|
|
840 - THREADED JOINT
BSD-1600A0077N.A1
1600A0077N
|
£7.36
|
£8.83
|
|
|
850 - CLAMP HANDLE
BSD-1602026102.A6
1602026102
|
£81.81
|
£98.17
|
|
|
855 - BRUSH HOLDER
BSD-1600A0077P.A7
1600A0077P
|
£93.88
|
£112.65
|
|
|
875 - HOSE
BSD-1600A008WC.A4
1600A008WC
|
£63.50
|
£76.20
|
|
|
878 - SLIDING CLUTCH
BSD-1600A0077R.A1
1600A0077R
|
£120.11
|
£144.13
|
|
|
880 - CARBON-BRUSH SET
BSD-160701417N.A1
160701417N
|
£40.80
|
£48.96
|
|
|
890 - BEARING COVER
BSD-160582023B.A2
160582023B
|
£107.69
|
£129.23
|
|
|
891 - DRILLING SPINDLE
BSD-1600A0077S.A7
1600A0077S
|
£357.27
|
£428.72
|
|
|
892 - ISOLATING VALVE
BSD-1600A005AY.A12
1600A005AY
|
£68.42
|
£82.10
|
|
|
893 - WATER CONNECTION
BSD-1600A0077U.A1
1600A0077U
|
£135.25
|
£162.30
|
|
|
895 - MAINS CABLE
BSD-1600A0077W.A1
1600A0077W
|
-
|
|
|
|
900 - GLIDE RING
BSD-1600A00780.A4
1600A00780
|
£135.25
|
£162.30
|
|
|
915 - O-RING
BSD-160021006D.A3
160021006D
|
£2.94
|
£3.53
|
|
