1 - MOTOR HOUSING
BSD-2605104332.A35
2605104332
|
£14.75
|
£17.70
|
|
|
2 - FIELD 115V
BSD-2604220440.A5
2604220440
|
£27.23
|
£32.68
|
|
|
3 - ARMATURE 110-115V
BSD-2604010857.A0
2604010857
|
£59.53
|
£71.44
|
|
|
3/50 - FAN
BSD-2606610049.A389
2606610049
|
£2.16
|
£2.59
|
|
|
4 - SWITCH
BSD-2607200210.A7
2607200210
|
£48.38
|
£58.06
|
|
|
5 - POWER SUPPLY CORD GB 110V 2.65m 2 x 1.0mm H05 VV-F
BSD-2604460207.A3
2604460207
|
£18.96
|
£22.75
|
|
|
6 - GROMMET dia6.9 MM
BSD-2600707059.A702
2600707059
|
£3.72
|
£4.47
|
|
|
7 - CABLE CLIP
BSD-2601035001.A1206
2601035001
|
£1.75
|
£2.10
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-2601116664.A2
2601116664
|
£3.72
|
£4.47
|
|
|
12 - SUPPRESSION FILTER
BSD-2607329114.A86
2607329114
|
-
|
|
|
|
13 - BALL BEARING 7x22x7
BSD-1900905018.A1172
1900905018
|
£18.96
|
£22.75
|
|
|
14 - BALL BEARING 9x24x7
BSD-2600905095.A45
2600905095
|
£12.04
|
£14.45
|
|
|
16 - BRUSH HOLDER
BSD-2604337003.A194
2604337003
|
£2.16
|
£2.59
|
|
|
18 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A1078
2603410001
|
£1.75
|
£2.10
|
|
|
19 - SCREW 4x16
BSD-2603490022.A334
2603490022
|
£1.75
|
£2.10
|
|
|
20 - REFERENCE PLATE
BSD-9920490116.A9
9920490116
|
£4.26
|
£5.11
|
|
|
26 - TORX OVAL-HEAD SCREW 4x30
BSD-2603490025.A214
2603490025
|
£1.75
|
£2.10
|
|
|
29 - COVER DISC
BSD-2601328046.A35
2601328046
|
£2.80
|
£3.36
|
|
|
30 - RUBBER BUFFER
BSD-3602391503.A79
3602391503
|
-
|
|
|
|
34 - RETAINING RING
BSD-2604601004.A424
2604601004
|
£1.75
|
£2.10
|
|
|
35 - COUNTERSUNK-HEAD SCREW M6x27
BSD-2603421226.A11
2603421226
|
£1.75
|
£2.10
|
|
|
36 - CHUCK
BSD-1608571088.A8
1608571088
|
£27.23
|
£32.68
|
|
|
37 - THREAD-FORMING TAP. SCREW M4x8
BSD-2603410048.A385
2603410048
|
£1.75
|
£2.10
|
|
|
38 - TORX OVAL-HEAD SCREW 4x20
BSD-2603490023.A1537
2603490023
|
£1.75
|
£2.10
|
|
|
39 - HOUSING COVER
BSD-2605132050.A40
2605132050
|
£10.10
|
£12.12
|
|
|
41 - FLAT SEAL RING
BSD-2601015012.A20
2601015012
|
£1.75
|
£2.10
|
|
|
42 - DRILLING SPINDLE 1/2. SW 17
BSD-2606135011.A29
2606135011
|
£27.31
|
£32.77
|
|
|
43 - BALL BEARING dia15 MM
BSD-1900905110.A56
1900905110
|
£10.10
|
£12.12
|
|
|
44 - RETAINING CLIP DIN 471-15x1-FSt
BSD-2916650006.A334
2916650006
|
£1.75
|
£2.10
|
|
|
45 - RETAINING CLIP DIN 472-32x1.2 MM
BSD-2916660013.A212
2916660013
|
£2.16
|
£2.59
|
|
|
46 - SHIM 0.5 MM
BSD-2600100695.A185
2600100695
|
£1.75
|
£2.10
|
|
|
47 - CYLINDRICAL GEAR
BSD-2606316316.A56
2606316316
|
£27.23
|
£32.68
|
|
|
48 - CYLINDRICAL GEAR
BSD-2606316317.A3
2606316317
|
£23.86
|
£28.63
|
|
|
49 - FLAT KEY
BSD-2602300033.A58
2602300033
|
£5.58
|
£6.70
|
|
|
50 - SHIM 1.5 MM
BSD-2600101668.A34
2600101668
|
£2.80
|
£3.36
|
|
|
54 - SHIM 0.3 MM
BSD-2600100607.A991
2600100607
|
£1.75
|
£2.10
|
|
|
55 - ADJUSTING SLIDE
BSD-2602033007.A16
2602033007
|
-
|
|
|
|
56 - ROTARY KNOB
BSD-2602026006.A35
2602026006
|
£4.26
|
£5.11
|
|
|
57 - RATCHET CAP
BSD-2600590006.A1152
2600590006
|
£1.75
|
£2.10
|
|
|
58 - SHIM WASHER
BSD-2600100618.A205
2600100618
|
£1.75
|
£2.10
|
|
|
60 - NEEDLE-ROLLER BEARING dia6 MM
BSD-2600914010.A475
2600914010
|
£2.80
|
£3.36
|
|
|
61 - HOLDING PIN
BSD-2603105043.A32
2603105043
|
-
|
|
|
|
63 - TORX OVAL-HEAD SCREW 3x10
BSD-2603490017.A1553
2603490017
|
£2.16
|
£2.59
|
|
|
70 - CABLE L=130 MM
BSD-2604448005.A435
2604448005
|
£1.75
|
£2.10
|
|
|
71 - CONNECTING CABLE L=98 MM
BSD-2604448074.A16
2604448074
|
£2.16
|
£2.59
|
|
|
72 - CONNECTING CABLE L=68 MM
BSD-2604448100.A71
2604448100
|
£1.75
|
£2.10
|
|
|
73 - SUPPRESSION FILTER L=148 MM
BSD-2604465086.A39
2604465086
|
£5.58
|
£6.70
|
|
|
74 - SUPPRESSION FILTER L=126 MM
BSD-2604465097.A148
2604465097
|
£5.58
|
£6.70
|
|
|
75 - EARTH CONDUCTOR
BSD-2604448097.A74
2604448097
|
£1.75
|
£2.10
|
|
|
653/20 - HEX NUT DIN 934-M6-8-A
BSD-2915011007.A893
2915011007
|
-
|
|
|
|
653/30 - WING SCREW M6x(15)55
BSD-1613480007.A322
1613480007
|
£1.75
|
£2.10
|
|
|
653/50 - CLAMPING PLATE M6
BSD-2608040014.A384
2608040014
|
-
|
|
|
|
653/60 - WING SCREW M6x20 MM
BSD-1613480008.A100
1613480008
|
£1.75
|
£2.10
|
|
|
654 - DEPTH-GAUGE
BSD-2609005615.A150
2609005615
|
£4.26
|
£5.11
|
|
|
753 - AUXILIARY HANDLE dia43 MM
BSD-1619P10682.A246
1619P10682
|
£12.49
|
£14.99
|
|
|
808 - NAMEPLATE
BSD-160111A3H3.A2369
160111A3H3
|
£2.61
|
£3.13
|
|
|
810 - CARBON-BRUSH SET
BSD-2604321905.A408
2604321905
|
£11.30
|
£13.56
|
|
|
825 - GEAR HOUSING
BSD-2605806997.A30
2605806997
|
£41.62
|
£49.95
|
|
|
828 - INTERMEDIATE FLANGE
BSD-2605700940.A15
2605700940
|
£24.45
|
£29.34
|
|
|
835 - COUNTERSUNK-HEAD SCREW M6x38/12(dia11)
BSD-2603421208.A30
2603421208
|
-
|
|
|
|
842 - DRILLING SPINDLE
BSD-2606135944.A3
2606135944
|
£27.23
|
£32.68
|
|
|
851 - TOOTHED SHAFT Z=29/18/11
BSD-2606308915.A12
2606308915
|
£36.63
|
£43.96
|
|
|
859 - LOCKING WASHER DIN 6799-4-FSt
BSD-2916080007.A44
2916080007
|
£2.61
|
£3.13
|
|
|
869 - CHANGE-OVER SWITCH
BSD-2607200231.A319
2607200231
|
£16.41
|
£19.69
|
|
