2 - FELT DISC
BSD-2600108075.A2
2600108075
|
-
|
|
|
|
3 - CUPPED WASHER
BSD-2600500007.A2
2600500007
|
-
|
|
|
|
4 - GROOVE BALL BEARING 12x28x8
BSD-1900900289.A36
1900900289
|
£11.30
|
£13.56
|
|
|
5 - SPRING RETAINING RING DIN 472-28x1.2 MM
BSD-2916660011.A61
2916660011
|
£1.75
|
£2.10
|
|
|
6 - DRILLING SPINDLE
BSD-2606135006.A13
2606135006
|
-
|
|
|
|
7 - SPRING RETAINING RING DIN 471-12x1-FSt
BSD-2916650003.A206
2916650003
|
£1.75
|
£2.10
|
|
|
8 - SHIM
BSD-2600101601.A31
2600101601
|
£1.75
|
£2.10
|
|
|
9 - CYLINDRICAL GEAR Z=38
BSD-2606316101.A16
2606316101
|
-
|
|
|
|
10 - CYLINDRICAL GEAR Z=32
BSD-2606316100.A1
2606316100
|
-
|
|
|
|
11 - FLAT KEY
BSD-2602300001.A48
2602300001
|
-
|
|
|
|
12 - PLAIN WASHER
BSD-2600101001.A45
2600101001
|
-
|
|
|
|
13 - NEEDLE-ROLLER BEARING dia6 MM
BSD-2600914010.A635
2600914010
|
£2.80
|
£3.36
|
|
|
19 - SHIM 0.3 MM
BSD-2600100607.A617
2600100607
|
£1.75
|
£2.10
|
|
|
20 - TOOTHED RACK
BSD-2603070010.A22
2603070010
|
-
|
|
|
|
21 - FORK LEVER
BSD-2602033001.A1
2602033001
|
-
|
|
|
|
23 - SHIM WASHER
BSD-2600100618.A342
2600100618
|
£1.75
|
£2.10
|
|
|
24 - SCREW AND WASHER ASSEMBLY DIN7985-M3x6-Z1-4.8
BSD-2914501011.A237
2914501011
|
£1.75
|
£2.10
|
|
|
25 - SPRING LOCK WASHER A3-FSt
BSD-2916690001.A42
2916690001
|
-
|
|
|
|
26 - ROTARY KNOB
BSD-2602026023.A16
2602026023
|
-
|
|
|
|
27 - RATCHET CAP
BSD-2600590006.A720
2600590006
|
£1.75
|
£2.10
|
|
|
28 - RATCHET CAP
BSD-2600590006.A721
2600590006
|
£1.75
|
£2.10
|
|
|
29 - NEEDLE ROLLER DIN 5402-A3x11.8-G2
BSD-1903201042.A392
1903201042
|
£2.16
|
£2.59
|
|
|
30 - SCREW AND WASHER ASSEMBLY DIN 84-BM 4x35-Z4-8.8
BSD-2914501027.A61
2914501027
|
-
|
|
|
|
31 - SPRING LOCK WASHER DIN 128-A4-FST
BSD-2916690003.A210
2916690003
|
£1.75
|
£2.10
|
|
|
33 - FELT DISC
BSD-2600108000.A246
2600108000
|
-
|
|
|
|
34 - CUPPED WASHER
BSD-2600500030.A30
2600500030
|
-
|
|
|
|
35 - SEAL BUSHING
BSD-2600300049.A21
2600300049
|
-
|
|
|
|
36 - BALL BEARING 8x22x7
BSD-1900905029.A310
1900905029
|
£21.52
|
£25.83
|
|
|
37 - SPRING RETAINING RING
BSD-2600119000.A21
2600119000
|
£1.75
|
£2.10
|
|
|
38 - ARMATURE 220V
BSD-2604010533.A0
2604010533
|
-
|
|
|
|
39 - BALL BEARING 7x22x7
BSD-1900905018.A713
1900905018
|
£18.96
|
£22.75
|
|
|
41 - FIELD 220V
BSD-2604222302.A23
2604222302
|
-
|
|
|
|
42 - COVER DISC
BSD-2601328041.A2
2601328041
|
-
|
|
|
|
43 - COMPRESSION SPRING
BSD-2604611026.A307
2604611026
|
-
|
|
|
|
47 - SPIRAL SPRING
BSD-2604652002.A135
2604652002
|
-
|
|
|
|
48 - TAPPING SCREW 2.2x6.5
BSD-2603435016.A53
2603435016
|
-
|
|
|
|
50 - SCREW AND WASHER ASSEMBLY DIN7985-M3x6-Z1-4.8
BSD-2914501011.A236
2914501011
|
£1.75
|
£2.10
|
|
|
52 - ON-OFF SWITCH
BSD-2607200073.A10
2607200073
|
-
|
|
|
|
53 - SUPPRESSION FILTER
BSD-2607329051.A194
2607329051
|
-
|
|
|
|
54 - POWER SUPPLY CORD EU 2.65m 2 x 1.0mm H05 RN-F
BSD-1607000388.A86
1607000388
|
£12.04
|
£14.45
|
|
|
54 - ELEC. CABLE W/CONNECTION CH 2.65m 2 x 1.0mm H05 VV-F
BSD-2604460053.A55
2604460053
|
-
|
|
|
|
55 - GROMMET dia6.9 MM
BSD-2600707059.A355
2600707059
|
£3.72
|
£4.47
|
|
|
55 - GROMMET dia8.8 MM
BSD-2600707061.A211
2600707061
|
£2.80
|
£3.36
|
|
|
56 - CABLE CLIP
BSD-2601035001.A37
2601035001
|
£1.75
|
£2.10
|
|
|
57 - SOCKET HEAD CAP SCREW M3x10 MM
BSD-2603410023.A380
2603410023
|
-
|
|
|
|
58 - TAPPING SCREW DIN 7981-ST3.9x16-C-H
BSD-2910611019.A349
2910611019
|
£2.80
|
£3.36
|
|
|
59 - TAPPING SCREW DIN 7981-3.9x19-C-Z-ST
BSD-2912401020.A817
2912401020
|
£2.16
|
£2.59
|
|
|
60 - HOUSING COVER
BSD-2605132017.A68
2605132017
|
-
|
|
|
|
61 - TORX OVAL-HEAD SCREW 4x20
BSD-2603490023.A774
2603490023
|
£1.75
|
£2.10
|
|
|
62 - CHANGE-OVER SWITCH
BSD-2607200114.A46
2607200114
|
-
|
|
|
|
63 - MANUFACTURER'S NAMEPLATE
BSD-2601110099.A42
2601110099
|
-
|
|
|
|
64 - REFERENCE PLATE
BSD-2601110184.A5
2601110184
|
-
|
|
|
|
65 - SHIM
BSD-2600150004.A66
2600150004
|
£2.16
|
£2.59
|
|
|
66 - SHIM 0.3 MM
BSD-2600101023.A54
2600101023
|
£1.75
|
£2.10
|
|
|
66 - SHIM 0.2 MM
BSD-2600101022.A596
2600101022
|
£1.75
|
£2.10
|
|
|
66 - SHIM 0.5 MM
BSD-2600101020.A54
2600101020
|
£1.75
|
£2.10
|
|
|
67 - END SPLICE DIN 46 228-A1-6
BSD-1900452012.A390
1900452012
|
£1.75
|
£2.10
|
|
|
69 - GROOVED NAIL
BSD-3603133000.A311
3603133000
|
£2.61
|
£3.13
|
|
|
70 - CABLE
BSD-2604411524.A53
2604411524
|
-
|
|
|
|
71 - SUPPRESSOR BOX
BSD-2604465026.A5
2604465026
|
-
|
|
|
|
72 - SUPPRESSOR BOX
BSD-2604465027.A60
2604465027
|
-
|
|
|
|
73 - KEY CHUCK dia1-10 MM. 3/8
BSD-1608571020.A176
1608571020
|
-
|
|
|
|
73 - CHUCK WRENCH SG2
BSD-2607950007.A1404
2607950007
|
£6.52
|
£7.83
|
|
|
78 - STICKER
BSD-2601110230.A77
2601110230
|
-
|
|
|
|
80 - FAN
BSD-2606610021.A38
2606610021
|
-
|
|
|
|
800 - MOTOR HOUSING
BSD-2605104954.A9
2605104954
|
-
|
|
|
|
801 - INTERMEDIATE FLANGE
BSD-2605700929.A5
2605700929
|
-
|
|
|
|
802 - GEAR HOUSING
BSD-2605806963.A5
2605806963
|
-
|
|
|
|
803 - TOOTHED SHAFT Z= 14/20/41
BSD-2606308910.A0
2606308910
|
-
|
|
|
|
805 - LOCKING WASHER DIN 6799-4-FSt
BSD-2916080007.A316
2916080007
|
£2.61
|
£3.13
|
|
|
835 - POWER SUPPLY CORD EU 4.15m 2 x 1.0mm H07 RN-F
BSD-1607000227.A107
1607000227
|
£23.86
|
£28.63
|
|
|
846 - CARBON-BRUSH SET
BSD-2604320902.A209
2604320902
|
-
|
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A665
160111A3H3
|
£2.61
|
£3.13
|
|
