1 - MOTOR HOUSING
BSD-3605108145.A29
3605108145
|
£27.23
|
£32.68
|
|
|
4 - SWITCH
BSD-1607200075.A14
1607200075
|
£68.42
|
£82.10
|
|
|
6 - GROMMET dia7.9-dia12.0x120 MM
BSD-1600703022.A32
1600703022
|
£2.80
|
£3.36
|
|
|
7 - FASTENING CLAMP
BSD-1601302014.A882
1601302014
|
£2.61
|
£3.13
|
|
|
11 - SUPPRESSION FILTER
BSD-1607328028.A416
1607328028
|
£5.30
|
£6.36
|
|
|
12 - O-RING 66.0x3.0 MM
BSD-1600210005.A127
1600210005
|
£2.80
|
£3.36
|
|
|
13 - BLADE TERMINAL
BSD-1604477001.A117
1604477001
|
£1.75
|
£2.10
|
|
|
15 - HANDLE
BSD-3605133012.A75
3605133012
|
-
|
|
|
|
16 - INSULATING PLATE 20x20x50 MM
BSD-1602381006.A0
1602381006
|
£1.75
|
£2.10
|
|
|
18 - SPIRAL SPRING
BSD-1604652006.A69
1604652006
|
£1.75
|
£2.10
|
|
|
20 - INTERMEDIATE RING
BSD-1600502011.A242
1600502011
|
£2.61
|
£3.13
|
|
|
21 - BALL BEARING 7x19x6
BSD-2600905032.A862
2600905032
|
£5.30
|
£6.36
|
|
|
22 - SEALING CAP
BSD-3605500063.A17
3605500063
|
£4.26
|
£5.11
|
|
|
23 - AIR-DEFLECTOR RING
BSD-1600502019.A88
1600502019
|
£3.72
|
£4.47
|
|
|
24 - INTERMEDIATE RING
BSD-1600300090.A68
1600300090
|
£3.72
|
£4.47
|
|
|
25 - INTERMEDIATE RING
BSD-1600221003.A103
1600221003
|
£2.61
|
£3.13
|
|
|
26 - INTERMEDIATE HOUSING
BSD-3607031162.A25
3607031162
|
£81.81
|
£98.17
|
|
|
28 - GROOVE BALL BEARING 9x26x8
BSD-3600905131.A106
3600905131
|
£11.30
|
£13.56
|
|
|
29 - ROTARY SHAFT LIP SEAL
BSD-1600290016.A236
1600290016
|
£2.61
|
£3.13
|
|
|
30 - NEEDLE BEARING
BSD-1600910013.A205
1600910013
|
£5.58
|
£6.70
|
|
|
31 - CYLINDRICAL GEAR Z=50
BSD-1606317078.A15
1606317078
|
£31.64
|
£37.97
|
|
|
33 - SHIM 0.5 MM
BSD-1600102003.A30
1600102003
|
£1.75
|
£2.10
|
|
|
34 - STRAIGHT PIN 5 H 8x18 DIN 7
BSD-2917500121.A153
2917500121
|
£1.75
|
£2.10
|
|
|
36 - DRILLING SPINDLE
BSD-3603523053.A0
3603523053
|
£40.80
|
£48.96
|
|
|
37 - RETAINING CLIP DIN 471-15x1-FSt
BSD-2916650006.A300
2916650006
|
£1.75
|
£2.10
|
|
|
38 - SHIM 0.5 MM
BSD-1600100631.A319
1600100631
|
£1.75
|
£2.10
|
|
|
39 - SPINDLE WITH GEAR Z=9/33
BSD-1606328103.A13
1606328103
|
£48.38
|
£58.06
|
|
|
40 - GROOVE BALL BEARING 15x32x9
BSD-1900905162.A46
1900905162
|
£18.96
|
£22.75
|
|
|
42 - TAPPING SCREW ST-4.8x57.5-TORX.T20
BSD-1613435009.A378
1613435009
|
£1.75
|
£2.10
|
|
|
43 - TORX OVAL-HEAD SCREW
BSD-2914201527.A34
2914201527
|
£2.16
|
£2.59
|
|
|
46 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A2285
2910211019
|
£1.75
|
£2.10
|
|
|
47 - CONNECTING CABLE L=290 MM
BSD-1604445006.A67
1604445006
|
£5.58
|
£6.70
|
|
|
49 - TAPPING SCREW DIN 7971-ST3.9x13-F
BSD-2910211018.A110
2910211018
|
£1.75
|
£2.10
|
|
|
51 - NEEDLE BEARING
BSD-1600910013.A206
1600910013
|
£5.58
|
£6.70
|
|
|
52 - STICKER
BSD-3601110359.A20
3601110359
|
£2.80
|
£3.36
|
|
|
53 - CONNECTING CABLE L=360 MM
BSD-3604460027.A9
3604460027
|
£6.52
|
£7.83
|
|
|
56 - CONNECTING CABLE L=375 MM
BSD-3604438027.A48
3604438027
|
£10.10
|
£12.12
|
|
|
57 - WIRE GUIDE
BSD-3601025003.A111
3601025003
|
£1.75
|
£2.10
|
|
|
58 - COMPRESSION SPRING
BSD-1604613006.A164
1604613006
|
£1.75
|
£2.10
|
|
|
59 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A1609
2910021118
|
£1.75
|
£2.10
|
|
|
79 - STICKER
BSD-3601110359.A19
3601110359
|
£2.80
|
£3.36
|
|
|
90 - TAB WASHER
BSD-1601030022.A4
1601030022
|
£1.75
|
£2.10
|
|
|
91 - TORX OVAL-HEAD SCREW
BSD-2914201507.A8
2914201507
|
£1.75
|
£2.10
|
|
|
650 - AUXILIARY HANDLE dia43 MM
BSD-3602025021.A35
3602025021
|
£40.80
|
£48.96
|
|
|
650/1 - AUXILIARY HANDLE M14
BSD-1602025022.A828
1602025022
|
£13.41
|
£16.09
|
|
|
650/1 - AUXILIARY HANDLE M14. dia37x115 MM
BSD-1602025030.A34
1602025030
|
£18.96
|
£22.75
|
|
|
650/2 - SUPPORT CLAMP
BSD-1618040077.A190
1618040077
|
-
|
|
|
|
650/3 - STUD BOLT M8
BSD-1613521001.A135
1613521001
|
£5.58
|
£6.70
|
|
|
650/4 - CLAMPING BAND dia43 MM
BSD-3601038048.A28
3601038048
|
£18.96
|
£22.75
|
|
|
650/5 - STRAIGHT PIN
BSD-1613100012.A212
1613100012
|
£2.61
|
£3.13
|
|
|
650/8 - HANDLE BAR
BSD-3602025022.A16
3602025022
|
£18.96
|
£22.75
|
|
|
651 - KEY CHUCK dia1.5-13 MM. 1/2
BSD-1608571022.A8
1608571022
|
-
|
|
|
|
651/8 - CHUCK WRENCH SG2
BSD-2607950007.A1109
2607950007
|
£6.52
|
£7.83
|
|
|
652 - DEPTH-GAUGE SW 6x330 MM
BSD-1613001008.A27
1613001008
|
£8.67
|
£10.41
|
|
|
802 - FIELD 230V
BSD-3604220122.A6
3604220122
|
£54.42
|
£65.30
|
|
|
805 - POWER SUPPLY CORD
BSD-3607030489.A82
3607030489
|
£31.64
|
£37.97
|
|
|
810 - CARBON-BRUSH SET
BSD-1607014126.A7
1607014126
|
£16.41
|
£19.69
|
|
|
815 - HANDLE
BSD-3605133012.A76
3605133012
|
-
|
|
|
|
817 - BRUSH HOLDER
BSD-1604336017.A113
1604336017
|
£7.36
|
£8.83
|
|
|
824 - INTERMEDIATE RING
BSD-1600300089.A17
1600300089
|
£5.30
|
£6.36
|
|
|
825 - INTERMEDIATE RING
BSD-1600206026.A1
1600206026
|
£1.75
|
£2.10
|
|
|
826 - INTERMEDIATE HOUSING
BSD-3607031162.A24
3607031162
|
£81.81
|
£98.17
|
|
|
827 - RETAINING RING DIN 9045 - dia 30MM
BSD-2916600016.A18
2916600016
|
£1.75
|
£2.10
|
|
|
829 - ROTARY SHAFT LIP SEAL
BSD-1600290012.A9
1600290012
|
-
|
|
|
|
830 - ARMATURE 230V
BSD-1604010272.A4
1604010272
|
£179.37
|
£215.24
|
|
|
832 - SPINDLE HOUSING
BSD-3605806146.A19
3605806146
|
£63.50
|
£76.20
|
|
|
835 - RETAINING SNAP RING
BSD-3607030355.A104
3607030355
|
£18.96
|
£22.75
|
|
|
844 - SUPPORTING DISC
BSD-1600102680.A9
1600102680
|
£1.75
|
£2.10
|
|
|
853 - CONNECTING CABLE L=330 MM
BSD-1604438012.A27
1604438012
|
£7.36
|
£8.83
|
|
|
856 - CONNECTING CABLE L=345 MM
BSD-1604438013.A39
1604438013
|
£7.36
|
£8.83
|
|
|
857 - WIRE GUIDE
BSD-1601025001.A75
1601025001
|
£1.75
|
£2.10
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A2179
160111A3H3
|
£2.61
|
£3.13
|
|
