1 - MOTOR HOUSING
BSD-2605104332.A9
2605104332
|
£15.49
|
£18.59
|
|
|
2 - FIELD 220-230V
BSD-2604220429.A109
2604220429
|
£23.86
|
£28.63
|
|
|
3 - ARMATURE 230-240V
BSD-2604010739.A14
2604010739
|
-
|
|
|
|
3/60 - FAN
BSD-2606610029.A248
2606610029
|
£2.74
|
£3.29
|
|
|
4 - SWITCH
BSD-2607200209.A16
2607200209
|
£40.80
|
£48.96
|
|
|
5 - POWER SUPPLY CORD CH 230V 4.15m 2 x 1.0mm H05 RN-F
BSD-1604460432.A11
1604460432
|
£11.87
|
£14.24
|
|
|
6 - GROMMET dia6.5-dia6.9x95 MM
BSD-2600703012.A171
2600703012
|
£2.94
|
£3.53
|
|
|
7 - CABLE CLIP
BSD-2601035001.A1887
2601035001
|
£1.84
|
£2.21
|
|
|
9 - STICKER
BSD-3601110333.A2
3601110333
|
£2.27
|
£2.72
|
|
|
12 - SUPPRESSION FILTER
BSD-2607329114.A322
2607329114
|
-
|
|
|
|
13 - BALL BEARING 7x22x7
BSD-1900905018.A146
1900905018
|
£19.91
|
£23.89
|
|
|
14 - GROOVE BALL BEARING 9x24x7
BSD-2600905021.A357
2600905021
|
£8.67
|
£10.41
|
|
|
16 - BRUSH HOLDER
BSD-2604337003.A50
2604337003
|
£2.16
|
£2.59
|
|
|
18 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A1789
2603410001
|
£1.84
|
£2.21
|
|
|
19 - SCREW 4x16
BSD-2603490022.A2004
2603490022
|
£1.84
|
£2.21
|
|
|
20 - STICKER
BSD-3601110334.A2
3601110334
|
£2.27
|
£2.72
|
|
|
25 - GEAR HOUSING
BSD-3605108128.A2
3605108128
|
£28.68
|
£34.41
|
|
|
26 - TAPPING SCREW DIN 7981-ST3.9x32C-H
BSD-2912405082.A8
2912405082
|
£2.05
|
£2.46
|
|
|
27 - RECEPTACLE
BSD-2600400008.A464
2600400008
|
£1.75
|
£2.10
|
|
|
28 - INTERMEDIATE FLANGE
BSD-3605806536.A9
3605806536
|
-
|
|
|
|
29 - COVER DISC
BSD-2601328046.A12
2601328046
|
£2.80
|
£3.36
|
|
|
30 - RUBBER BUFFER
BSD-3602391503.A14
3602391503
|
-
|
|
|
|
31 - THREAD-FORMING TAP. SCREW DIN 7500-CM 4x8-ST
BSD-2914411045.A1
2914411045
|
-
|
|
|
|
32 - TORX OVAL-HEAD SCREW 4x25
BSD-2603490024.A541
2603490024
|
£1.84
|
£2.21
|
|
|
33 - HOUSING COVER
BSD-2605132050.A18
2605132050
|
£10.61
|
£12.73
|
|
|
35 - NOZZLE SOCKET
BSD-3600910505.A7
3600910505
|
-
|
|
|
|
36 - NEEDLE BEARING dia6/12 MM
BSD-2600914017.A44
2600914017
|
£11.30
|
£13.56
|
|
|
37 - SHIM 0.3 MM
BSD-2600100607.A122
2600100607
|
£1.75
|
£2.10
|
|
|
38 - SHIM 0.3 MM
BSD-2600100570.A18
2600100570
|
£1.84
|
£2.21
|
|
|
39 - CYLINDRICAL GEAR Z=31
BSD-3606317035.A0
3606317035
|
£21.68
|
£26.01
|
|
|
41 - CYLINDRICAL GEAR Z=37
BSD-3606317037.A4
3606317037
|
-
|
|
|
|
43 - SPACER SLEEVE
BSD-3600300040.A1
3600300040
|
£12.37
|
£14.84
|
|
|
44 - SPRING RETAINING RING 24X1.2
BSD-3600119012.A1
3600119012
|
£1.38
|
£1.66
|
|
|
45 - GROOVE BALL BEARING
BSD-3600900020.A27
3600900020
|
£13.12
|
£15.75
|
|
|
46 - RATCHET CAP
BSD-2600590006.A109
2600590006
|
£1.84
|
£2.21
|
|
|
47 - SLOTTED SPRING PIN DIN 1481-3x32
BSD-2917760088.A7
2917760088
|
-
|
|
|
|
48 - CLUTCH HOUSING
BSD-3605108125.A7
3605108125
|
-
|
|
|
|
49 - DISC SPRING DIN 2093-A31.5 GR 2
BSD-2916160061.A8
2916160061
|
-
|
|
|
|
50 - TORX OVAL-HEAD SCREW 4x20
BSD-2603490023.A589
2603490023
|
£1.84
|
£2.21
|
|
|
51 - COMPRESSION SPRING
BSD-2604610031.A0
2604610031
|
-
|
|
|
|
52 - GUIDE DISC
BSD-3600106001.A2
3600106001
|
£14.75
|
£17.70
|
|
|
53 - DRIVE BUSHING
BSD-3600313010.A8
3600313010
|
£51.22
|
£61.47
|
|
|
54 - BALL DIN 5401-6 G28
BSD-1903230011.A436
1903230011
|
£2.74
|
£3.29
|
|
|
56 - PROTECTIVE CAP
BSD-3600502008.A1
3600502008
|
-
|
|
|
|
57 - SEAL RING
BSD-2600283012.A49
2600283012
|
£2.94
|
£3.53
|
|
|
58 - GROOVE BALL BEARING
BSD-3600905084.A2
3600905084
|
£14.91
|
£17.89
|
|
|
59 - SPRING RETAINING RING
BSD-3600119013.A8
3600119013
|
£1.75
|
£2.10
|
|
|
60 - COUPLING HALF
BSD-3605405002.A1
3605405002
|
£58.76
|
£70.51
|
|
|
61 - LEAF SPRING
BSD-2601250001.A149
2601250001
|
£3.72
|
£4.47
|
|
|
62 - BALL DIN 5401-2.5MM-III-ST
BSD-1903230003.A97
1903230003
|
£2.74
|
£3.29
|
|
|
63 - COUPLING HALF
BSD-3605405003.A8
3605405003
|
£61.98
|
£74.38
|
|
|
64 - COMPRESSION SPRING
BSD-3604619014.A2
3604619014
|
£2.05
|
£2.46
|
|
|
65 - THRUST BEARING DISC
BSD-1610101608.A45
1610101608
|
£2.27
|
£2.72
|
|
|
66 - THRUST NEEDLE RIM
BSD-1610920001.A29
1610920001
|
£3.72
|
£4.47
|
|
|
67 - ROTOR DISC
BSD-3600103008.A7
3600103008
|
-
|
|
|
|
68 - SHIM
BSD-3600100050.A2
3600100050
|
£1.32
|
£1.58
|
|
|
68 - SHIM
BSD-3600100051.A7
3600100051
|
£1.75
|
£2.10
|
|
|
68 - SHIM
BSD-3600100052.A2
3600100052
|
-
|
|
|
|
69 - FLAT SEAL RING
BSD-3601016502.A7
3601016502
|
-
|
|
|
|
70 - TORX OVAL-HEAD SCREW 3x10
BSD-2603490017.A604
2603490017
|
£2.27
|
£2.72
|
|
|
72 - CABLE L=130 MM
BSD-2604448005.A310
2604448005
|
£1.84
|
£2.21
|
|
|
73 - CONNECTING CABLE L=98 MM
BSD-2604448074.A74
2604448074
|
£2.16
|
£2.59
|
|
|
74 - CONNECTING CABLE L=68 MM
BSD-2604448100.A137
2604448100
|
£1.75
|
£2.10
|
|
|
75 - SUPPRESSION FILTER L=148 MM
BSD-2604465086.A223
2604465086
|
£5.58
|
£6.70
|
|
|
77 - EARTH CONDUCTOR
BSD-2604448103.A6
2604448103
|
-
|
|
|
|
78 - STICKER
BSD-3601110191.A2
3601110191
|
£3.72
|
£4.47
|
|
|
80 - CLIP
BSD-3600690503.A24
3600690503
|
-
|
|
|
|
808 - NAMEPLATE
BSD-160111A3H5.A236
160111A3H5
|
£2.74
|
£3.29
|
|
|
810 - CARBON-BRUSH SET
BSD-2604321905.A113
2604321905
|
£11.87
|
£14.24
|
|
|
840 - TOOTHED SHAFT Z=31/8
BSD-3603120019.A3
3603120019
|
£46.82
|
£56.18
|
|
|
842 - SPINDLE WITH GEAR Z=37
BSD-3603120020.A1
3603120020
|
-
|
|
|
|
855 - D-GROOVE BALL THR BEARING
BSD-3600929022.A1
3600929022
|
£39.61
|
£47.53
|
|
|
871 - CHANGE-OVER SWITCH
BSD-2607200231.A62
2607200231
|
£17.22
|
£20.67
|
|
|
899 - GREASE TUBE 225 ML
BSD-3605430004.A2
3605430004
|
£39.13
|
£46.96
|
|
