1 - MOTOR HOUSING
BSD-16051082BS.A0
16051082BS
|
£18.96
|
£22.75
|
|
|
2 - FIELD 230V
BSD-1604220478.A0
1604220478
|
£30.28
|
£36.33
|
|
|
4 - SWITCH
BSD-1607200256.A30
1607200256
|
£12.64
|
£15.17
|
|
|
5 - POWER SUPPLY CORD EU 4.15m 2x1.0mm H07RN-F
BSD-3604460185.A3
3604460185
|
£22.50
|
£27.00
|
|
|
6 - GROMMET
BSD-160070304J.A0
160070304J
|
-
|
|
|
|
7 - FASTENING CLAMP
BSD-1601302017.A723
1601302017
|
£1.84
|
£2.21
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-160111C2FN.A0
160111C2FN
|
-
|
|
|
|
13 - GROOVE BALL BEARING 7x19x6
BSD-1610905025.A355
1610905025
|
£6.85
|
£8.22
|
|
|
14 - GROOVE BALL BEARING 8x22x7
BSD-1600905032.A236
1600905032
|
£5.58
|
£6.70
|
|
|
17 - SPIRAL SPRING
BSD-1604652021.A95
1604652021
|
£1.84
|
£2.21
|
|
|
18 - SWITCH HANDLE
BSD-1600A00717.A0
1600A00717
|
£2.16
|
£2.59
|
|
|
19 - COMPRESSION SPRING
BSD-1604611031.A119
1604611031
|
£2.94
|
£3.53
|
|
|
20 - ADJUSTING SLIDE
BSD-1602319026.A2
1602319026
|
£1.75
|
£2.10
|
|
|
24 - COVER
BSD-160550029G.A1
160550029G
|
£2.27
|
£2.72
|
|
|
25 - HOUSING COVER
BSD-160550029H.A0
160550029H
|
£10.61
|
£12.73
|
|
|
27 - RUBBER RING
BSD-1600206025.A671
1600206025
|
£2.16
|
£2.59
|
|
|
29 - AIR-DEFLECTOR RING
BSD-1600591047.A0
1600591047
|
£2.16
|
£2.59
|
|
|
30 - AIR DISTRIBUTOR
BSD-160059105N.A7
160059105N
|
£2.16
|
£2.59
|
|
|
31 - BRUSH-COVER
BSD-1605500277.A17
1605500277
|
£2.16
|
£2.59
|
|
|
33 - O-RING 46.0x1.1 MM
BSD-3600210124.A209
3600210124
|
£2.94
|
£3.53
|
|
|
35 - SHIM 0.1 MM
BSD-1600136013.A480
1600136013
|
£2.74
|
£3.29
|
|
|
35 - SHIM 0.2 MM
BSD-1600136014.A40
1600136014
|
£2.74
|
£3.29
|
|
|
35 - SHIM 0.3 MM
BSD-1600136015.A480
1600136015
|
£2.74
|
£3.29
|
|
|
35 - SHIM 0.15 MM
BSD-1600136020.A38
1600136020
|
£3.72
|
£4.47
|
|
|
37 - ROTARY SHAFT LIP SEAL
BSD-1600290016.A387
1600290016
|
£2.74
|
£3.29
|
|
|
40 - RETAINING CLIP
BSD-1600119011.A235
1600119011
|
£2.27
|
£2.72
|
|
|
41 - NEEDLE BEARING dia8xdia12x8 MM
BSD-1600910018.A801
1600910018
|
£5.57
|
£6.68
|
|
|
45 - HEX NUT M7. SW10
BSD-1603300016.A227
1603300016
|
£1.84
|
£2.21
|
|
|
48 - LENS HEAD SCREW 3x10 ST
BSD-1613435034.A19
1613435034
|
£1.84
|
£2.21
|
|
|
49 - TORX OVAL-HEAD SCREW
BSD-3603435055.A2
3603435055
|
£3.91
|
£4.69
|
|
|
50 - TORX OVAL-HEAD SCREW 4x20
BSD-2603490023.A1219
2603490023
|
£1.84
|
£2.21
|
|
|
53 - TORX OVAL-HEAD SCREW
BSD-1603435078.A195
1603435078
|
£1.84
|
£2.21
|
|
|
55 - TORX OVAL-HEAD SCREW 4x12
BSD-2603490021.A502
2603490021
|
£1.84
|
£2.21
|
|
|
80 - SEALING DISK
BSD-3600150021.A113
3600150021
|
£3.99
|
£4.79
|
|
|
104 - O-RING 4.5x1.0 MM
BSD-1600210044.A225
1600210044
|
£1.84
|
£2.21
|
|
|
202 - CLAMPING FLANGE dia22.3xdia42 MM
BSD-2605703014.A839
2605703014
|
£7.72
|
£9.27
|
|
|
202/2 - O-RING 20.35x1.78 MM
BSD-1600210055.A20
1600210055
|
-
|
|
|
|
203 - ROUND NUT M14
BSD-1603345043.A811
1603345043
|
£9.11
|
£10.93
|
|
|
205 - REFERENCE PLATE
BSD-3601119236.A1491
3601119236
|
£3.91
|
£4.69
|
|
|
206 - HANDLE
BSD-3602025029.A0
3602025029
|
£40.80
|
£48.96
|
|
|
207 - HEX SCREW
BSD-1619P07611.A6
1619P07611
|
£3.91
|
£4.69
|
|
|
208 - PLAIN WASHER DIN 125-A10.5-ST
BSD-2916011017.A20
2916011017
|
£1.84
|
£2.21
|
|
|
210 - SUCTION HOOD
BSD-1600A01500.A0
1600A01500
|
-
|
|
|
|
211 - SWIVEL ELEMENT
BSD-3605500219.A0
3605500219
|
£18.96
|
£22.75
|
|
|
212 - KNOB
BSD-3602305019.A2
3602305019
|
£5.57
|
£6.68
|
|
|
213 - COMPRESSION SPRING
BSD-3604611042.A2
3604611042
|
£2.74
|
£3.29
|
|
|
214 - METAL RING
BSD-3600190040.A2
3600190040
|
£15.65
|
£18.78
|
|
|
650 - PIN-TYPE FACE-WRENCH
BSD-3607950016.A4
3607950016
|
£15.65
|
£18.78
|
|
|
803 - ARMATURE WITH FAN 230V
BSD-3607031750.A5
3607031750
|
£126.12
|
£151.34
|
|
|
808 - NAMEPLATE
BSD-160111A5KJ.A0
160111A5KJ
|
-
|
|
|
|
810 - CARBON-BRUSH SET
BSD-1607000V37.A76
1607000V37
|
£14.91
|
£17.89
|
|
|
813 - GROOVE BALL BEARING
BSD-3607031751.A0
3607031751
|
£21.68
|
£26.01
|
|
|
816 - BRUSH HOLDER
BSD-1607000V43.A79
1607000V43
|
£3.91
|
£4.69
|
|
|
818 - PAN HEAD SCREW
BSD-1607000V42.A8
1607000V42
|
£1.84
|
£2.21
|
|
|
821 - GEAR HOUSING
BSD-1607000D4T.A0
1607000D4T
|
-
|
|
|
|
828 - BEARING FLANGE
BSD-3607031753.A5
3607031753
|
£39.61
|
£47.53
|
|
|
829 - STRIP BRUSH
BSD-3607031875.A2
3607031875
|
£50.80
|
£60.96
|
|
|
832 - GRINDING SPINDLE
BSD-160312307B.A5
160312307B
|
£62.51
|
£75.01
|
|
|
835 - FAN
BSD-1606610132.A168
1606610132
|
£2.27
|
£2.72
|
|
|
838 - GEAR UNIT
BSD-1607000D4Z.A49
1607000D4Z
|
£22.60
|
£27.12
|
|
|
840 - PUSH-BUTTON
BSD-1600A00716.A0
1600A00716
|
-
|
|
|
|
850 - COMPRESSION SPRING
BSD-1604611025.A0
1604611025
|
£1.84
|
£2.21
|
|
|
851 - SPEED GOVERNOR
BSD-16072335JJ.A5
16072335JJ
|
-
|
|
|
|
866 - STRAP-SHAPED HANDLE
BSD-3607031755.A0
3607031755
|
£68.42
|
£82.10
|
|
|
896 - FAST LOCKING FLANGE M14
BSD-1603340034.A15
1603340034
|
£36.63
|
£43.96
|
|
