Bosch DAG 230-D / 3601H80160 / GB 110 Volt Spare Parts

An exploded drawing and listing for the Bosch DAG 230-D / 3601H80160 / GB 110 Volt

	Ex VAT	Inc VAT
805 - POWER SUPPLY CORD 93854 BSD-1617A93854.A0 1617A93854	-
806 - GROMMET 364553 BSD-1617D64553.A0 1617D64553	-
810 - CARBON-BRUSH SET 341536 BSD-1617D41536.A0 1617D41536	£14.91	£17.89
810/1 - CATCH SLIDE 2082175 BSD-1617D41564.A2 1617D41564	-
825 - GRINDING SPINDLE 281808 BSD-1617C81808.A2 1617C81808	-
826 - SET OF GEARS 2082871 BSD-1617D41561.A5 1617D41561	£59.53	£71.44
830 - SEAL KIT 2083534 BSD-1617D41562.A3 1617D41562	£23.86	£28.63
834 - SHIM 93877 BSD-1617A93877.A8 1617A93877	-
834/1 - SHIM 93878 BSD-1617A93878.A3 1617A93878	-
834/2 - SHIM 93879 BSD-1617A93879.A8 1617A93879	-
849 - PARTS SET 364554 BSD-1617D64554.A3 1617D64554	-
852 - SOLENOID RING 2082176 BSD-1617D41565.A9 1617D41565	-
860 - THREAD-FORMING TAP. SCREW 364544 BSD-1617D64544.A0 1617D64544	-
861 - TAPPING SCREW 364543 BSD-1617D64543.A12 1617D64543	-
875 - PARTS SET 2082174 BSD-1617D41563.A9 1617D41563	-
890/1 - END SHIELD 2082586 BSD-1617D41556.A5 1617D41556	£116.15	£139.38
890/2 - GEAR HOUSING 2082589 BSD-1617D41558.A3 1617D41558	-
890/3 - ARMATURE 364555 BSD-1617D64555.A0 1617D64555	-
890/4 - HANDLE 364534 BSD-1617D64534.A9 1617D64534	-
890/5 - SWITCH 364550 BSD-1617D64550.A0 1617D64550	£45.67	£54.80
890/6 - MOTOR HOUSING 364536 BSD-1617D64536.A5 1617D64536	-
890/7 - BRUSH HOLDER 364537 BSD-1617D64537.A1 1617D64537	-
890/8 - MANUFACTURER'S NAMEPLATE 364551 BSD-1617D64551.A1 1617D64551	-
890/9 - POLE SHOE 364557 BSD-1617D64557.A1 1617D64557	£57.02	£68.42

Attribute Name	Value
Brand	Bosch
