1 - MOTOR HOUSING
BSD-1605108124.A32
1605108124
|
-
|
|
|
|
2 - FIELD 100-110V
BSD-1604220246.A5
1604220246
|
-
|
|
|
|
2/00/08 - TERMINAL LUG 1.5-4x4
BSD-1901350003.A25
1901350003
|
£1.75
|
£2.10
|
|
|
5 - POWER SUPPLY CORD GB 110V 4.15m 2 x 2.5mm H07 RN-F
BSD-1604460202.A20
1604460202
|
£45.67
|
£54.80
|
|
|
5/20 - END SPLICE DIN 46 228-A1-6
BSD-1900452012.A261
1900452012
|
£1.75
|
£2.10
|
|
|
6 - GROMMET dia9.2-dia12x120 MM
BSD-3600703011.A67
3600703011
|
£2.80
|
£3.36
|
|
|
11 - SUPPRESSION FILTER
BSD-1607328034.A195
1607328034
|
£4.26
|
£5.11
|
|
|
15 - SEAL
BSD-1600113002.A162
1600113002
|
£1.75
|
£2.10
|
|
|
16 - BRUSH HOLDER
BSD-1604336008.A153
1604336008
|
£21.52
|
£25.83
|
|
|
17 - COVER PLATE
BSD-1601037006.A192
1601037006
|
-
|
|
|
|
18 - PROFILE STRIP 3.4x7x240 MM
BSD-1601014005.A104
1601014005
|
-
|
|
|
|
19 - CONTROL LEVER
BSD-1602026041.A20
1602026041
|
-
|
|
|
|
19/00/08 - FELT WASHER
BSD-1600205019.A42
1600205019
|
£1.75
|
£2.10
|
|
|
20 - BEARING COVER
BSD-1605808054.A184
1605808054
|
-
|
|
|
|
21 - COVER DISC
BSD-1600102012.A204
1600102012
|
-
|
|
|
|
22 - GRINDING SPINDLE M14x1.5 MM
BSD-1603523032.A110
1603523032
|
£37.27
|
£44.72
|
|
|
23 - SEALING DISK
BSD-1600108055.A26
1600108055
|
£1.75
|
£2.10
|
|
|
25 - GROMMET
BSD-1600306001.A46
1600306001
|
£2.61
|
£3.13
|
|
|
26 - GEAR HOUSING
BSD-1605806346.A7
1605806346
|
-
|
|
|
|
27 - NEEDLE BEARING dia22x11.3 MM
BSD-1600910010.A365
1600910010
|
£45.67
|
£54.80
|
|
|
28 - RUBBER RING
BSD-1600206022.A30
1600206022
|
£2.16
|
£2.59
|
|
|
29 - GUIDE PULLEY
BSD-1600502013.A90
1600502013
|
-
|
|
|
|
30 - SPRING RETAINING RING
BSD-1600119004.A75
1600119004
|
£2.80
|
£3.36
|
|
|
31 - SPIRAL SPRING
BSD-1604652015.A563
1604652015
|
£2.80
|
£3.36
|
|
|
32 - ROTARY SHAFT LIP SEAL
BSD-1600290008.A11
1600290008
|
£2.61
|
£3.13
|
|
|
34 - SHIM 0.1 MM
BSD-1600190004.A27
1600190004
|
-
|
|
|
|
34 - SHIM 0.2 MM
BSD-1600190005.A257
1600190005
|
£1.32
|
£1.58
|
|
|
35 - TAB WASHER
BSD-1601030022.A575
1601030022
|
£1.75
|
£2.10
|
|
|
36 - RUBBER BUSHING
BSD-1600502006.A141
1600502006
|
£1.75
|
£2.10
|
|
|
40 - SPRING WASHER dia32.3xdia43.5x0.6 MM
BSD-1600150009.A30
1600150009
|
£2.80
|
£3.36
|
|
|
41 - SEALING CAP
BSD-1605500089.A155
1605500089
|
-
|
|
|
|
42 - HANDLE
BSD-1605132079.A40
1605132079
|
-
|
|
|
|
44 - FACEPLATE
BSD-1600120070.A24
1600120070
|
-
|
|
|
|
45 - HOLDING BRACKET
BSD-1601331032.A71
1601331032
|
-
|
|
|
|
50 - GROOVE BALL BEARING 6203-2 Z DIN 625
BSD-1900905227.A81
1900905227
|
-
|
|
|
|
51 - RETAINING RING dia22 MM
BSD-2916620011.A70
2916620011
|
£1.75
|
£2.10
|
|
|
52 - GROOVE BALL BEARING 37x12x12
BSD-1600900028.A50
1600900028
|
-
|
|
|
|
53 - GROOVE BALL BEARING
BSD-1600900029.A94
1600900029
|
-
|
|
|
|
54 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A961
2910021118
|
£1.75
|
£2.10
|
|
|
55 - TAPPING SCREW DIN 7971-BZ2.9x13
BSD-2910211006.A309
2910211006
|
£1.75
|
£2.10
|
|
|
56 - PLAIN WASHER DIN 433-3.2-ST 50
BSD-2916011005.A317
2916011005
|
£1.75
|
£2.10
|
|
|
57 - SOCKET HEAD CAP SCREW DIN 84-AM5x15-5.8
BSD-2910011157.A520
2910011157
|
-
|
|
|
|
58 - HEX NUT DIN 934 -M4-m-8
BSD-2915011005.A223
2915011005
|
£1.75
|
£2.10
|
|
|
59 - SCREW B 4.8x45 MM
BSD-3603415560.A249
3603415560
|
£1.75
|
£2.10
|
|
|
60 - TAPPING SCREW DIN 7971-ST4.8x25-F
BSD-2910211036.A74
2910211036
|
£1.75
|
£2.10
|
|
|
61 - SOCKET HEAD CAP SCREW DIN 84-AM5x20-5.8
BSD-2910011162.A238
2910011162
|
£1.75
|
£2.10
|
|
|
63 - TAPPING SCREW B4.8x85 MM
BSD-1603429001.A34
1603429001
|
-
|
|
|
|
66 - SOCKET HEAD CAP SCREW DIN 84-AM4x12-8.8
BSD-2910021122.A440
2910021122
|
£2.16
|
£2.59
|
|
|
82 - SPRING WASHER DIN 137-A5-FST
BSD-2916060006.A308
2916060006
|
£1.32
|
£1.58
|
|
|
650 - AUXILIARY HANDLE M14
BSD-1602025022.A1143
1602025022
|
£13.41
|
£16.09
|
|
|
650 - AUXILIARY HANDLE M14. dia37x115 MM
BSD-1602025030.A1173
1602025030
|
£18.96
|
£22.75
|
|
|
650/01 - STRAP-SHAPED HANDLE
BSD-1600793004.A17
1600793004
|
-
|
|
|
|
651 - SINGLE-HEAD ENG. WRENCH SW17
BSD-2607950511.A10
2607950511
|
£4.26
|
£5.11
|
|
|
652 - PROTECTIVE COVER dia 150 MM (6)
BSD-1605510115.A2
1605510115
|
-
|
|
|
|
652 - PROTECTIVE COVER dia230 MM (9)
BSD-1605510082.A4
1605510082
|
-
|
|
|
|
653 - OFFSET SCREWDRIVER DIN 911-4
BSD-2607950004.A348
2607950004
|
£1.75
|
£2.10
|
|
|
654 - CLAMPING-FLANGE dia 103 MM
BSD-1605703067.A4
1605703067
|
-
|
|
|
|
655 - ROUND NUT WITH 2 HOLES
BSD-1619P09976.A34
1619P09976
|
£2.16
|
£2.59
|
|
|
656 - OFFSET SCREWDRIVER DIN 911;SW6
BSD-1907950007.A21
1907950007
|
£5.30
|
£6.36
|
|
|
661 - CONICAL SPRING WASHER dia 22.2x103x5.5 MM
BSD-1605703066.A4
1605703066
|
-
|
|
|
|
662 - GUIDE BLOCK
BSD-1608190002.A16
1608190002
|
-
|
|
|
|
662/30 - ROUND-HEAD BOLT DIN 603-M 8x25
BSD-2910281244.A52
2910281244
|
-
|
|
|
|
662/40 - WING NUT DIN 315-M8-GT-C
BSD-2915191007.A247
2915191007
|
£3.72
|
£4.47
|
|
|
662/50 - PLAIN WASHER DIN 125-A 8.4-ST
BSD-2916011016.A123
2916011016
|
£1.75
|
£2.10
|
|
|
700 - PARTS SET
BSD-1607000151.A34
1607000151
|
-
|
|
|
|
701 - SUCTION HOOD dia 300 MM (12)
BSD-1605510215.A31
1605510215
|
£87.49
|
£104.99
|
|
|
800 - CARBON-BRUSH SET
BSD-1607014103.A44
1607014103
|
£14.91
|
£17.89
|
|
|
801 - CONNECTING CABLE
BSD-1604440004.A19
1604440004
|
-
|
|
|
|
801/020 - TERMINAL LUG
BSD-1601353003.A83
1601353003
|
-
|
|
|
|
802 - CROWN GEAR Z=62. M8
BSD-1606333206.A2
1606333206
|
-
|
|
|
|
802/01 - CROWN GEAR Z=62
BSD-1606333187.A4
1606333187
|
-
|
|
|
|
803 - BEVEL GEAR Z=13
BSD-1606333227.A15
1606333227
|
-
|
|
|
|
803/01 - BEVEL GEAR Z=13. M12
BSD-1606333185.A12
1606333185
|
-
|
|
|
|
804 - SWITCH KIT
BSD-1607000034.A323
1607000034
|
-
|
|
|
|
805 - SEAL KIT
BSD-1607000060.A24
1607000060
|
-
|
|
|
|
817 - BEARING FLANGE
BSD-1607000229.A174
1607000229
|
-
|
|
|
|
817/029 - O-RING 79.0x1.78 MM
BSD-1600210033.A755
1600210033
|
£1.75
|
£2.10
|
|
|
830 - RUBBER RING dia41xdia37x7.5 MM
BSD-1600206029.A12
1600206029
|
£2.61
|
£3.13
|
|
|
830/052 - GROOVE BALL BEARING 37x12x12
BSD-1600900028.A53
1600900028
|
-
|
|
|
|
830/073 - RETAINING SNAP RING dia44xdia41xdia37x11.8 MM
BSD-1600224034.A6
1600224034
|
-
|
|
|
|
830/0803 - BEVEL GEAR Z=13
BSD-1606333227.A16
1606333227
|
-
|
|
|
|
835 - POWER SUPPLY CORD EU 4.15m 2 x 1.5mm H07 RN-F
BSD-1607000228.A64
1607000228
|
£23.86
|
£28.63
|
|
|
835/020 - END SPLICE
BSD-3604477009.A150
3604477009
|
£2.61
|
£3.13
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A5264
160111A3H3
|
£2.61
|
£3.13
|
|
