2 - BRUSH HOLDER
BSD-1604336008.A61
1604336008
|
£21.52
|
£25.83
|
|
|
3 - POLE SHOE 220V
BSD-1604220154.A0
1604220154
|
-
|
|
|
|
6 - SPIRAL SPRING
BSD-1604652015.A302
1604652015
|
£2.80
|
£3.36
|
|
|
8 - SEALING CAP
BSD-1605500089.A266
1605500089
|
-
|
|
|
|
9 - HANDLE
BSD-1605132079.A96
1605132079
|
-
|
|
|
|
11 - SEAL
BSD-1600113002.A301
1600113002
|
£1.75
|
£2.10
|
|
|
12 - GROMMET dia9.2-dia12x120 MM
BSD-3600703011.A936
3600703011
|
£2.80
|
£3.36
|
|
|
13 - POWER SUPPLY CORD CH 4.15m 2 x 1.0mm H07RN-F
BSD-1604460447.A4
1604460447
|
£21.68
|
£26.01
|
|
|
14 - SUPPRESSION FILTER
BSD-1607328034.A434
1607328034
|
£4.26
|
£5.11
|
|
|
15 - FASTENING CLAMP
BSD-1601302013.A145
1601302013
|
£1.75
|
£2.10
|
|
|
17 - COVER PLATE
BSD-1601037006.A75
1601037006
|
-
|
|
|
|
18 - PROFILE STRIP 3.4x7x240 MM
BSD-1601014005.A156
1601014005
|
-
|
|
|
|
19 - CONTROL LEVER
BSD-1602026041.A65
1602026041
|
-
|
|
|
|
19/80 - FELT WASHER
BSD-1600205019.A199
1600205019
|
£1.75
|
£2.10
|
|
|
20 - BEARING COVER
BSD-1605808054.A139
1605808054
|
-
|
|
|
|
21 - COVER DISC
BSD-1600102012.A78
1600102012
|
-
|
|
|
|
22 - GRINDING SPINDLE
BSD-1603523034.A8
1603523034
|
-
|
|
|
|
23 - SEALING DISK
BSD-1600108055.A180
1600108055
|
£1.75
|
£2.10
|
|
|
25 - GROMMET
BSD-1600306001.A383
1600306001
|
£2.61
|
£3.13
|
|
|
27 - NEEDLE BEARING dia22x11.3 MM
BSD-1600910010.A154
1600910010
|
£45.67
|
£54.80
|
|
|
28 - RUBBER RING 10 MM
BSD-1600206014.A77
1600206014
|
£1.75
|
£2.10
|
|
|
29 - AIR-DEFLECTOR RING
BSD-1600502007.A52
1600502007
|
-
|
|
|
|
30 - RETAINING RING
BSD-1600116002.A13
1600116002
|
-
|
|
|
|
32 - ROTARY SHAFT LIP SEAL
BSD-1600290008.A135
1600290008
|
£2.61
|
£3.13
|
|
|
34 - SHIM 0.1 MM
BSD-1600190004.A217
1600190004
|
-
|
|
|
|
34 - SHIM 0.2 MM
BSD-1600190005.A66
1600190005
|
£1.32
|
£1.58
|
|
|
35 - TAB WASHER
BSD-1601030022.A200
1601030022
|
£1.75
|
£2.10
|
|
|
36 - RUBBER BUSHING
BSD-1600502006.A85
1600502006
|
£1.75
|
£2.10
|
|
|
38 - MANUFACTURER'S NAMEPLATE
BSD-1601110003.A26
1601110003
|
-
|
|
|
|
45 - RETAINING RING
BSD-1600116004.A31
1600116004
|
-
|
|
|
|
50 - GROOVE BALL BEARING 17x40x12
BSD-1900905281.A11
1900905281
|
£31.64
|
£37.97
|
|
|
51 - RETAINING RING dia22 MM
BSD-2916620011.A343
2916620011
|
£1.75
|
£2.10
|
|
|
52 - GROOVE BALL BEARING 15x35x11
BSD-1900905234.A84
1900905234
|
£31.64
|
£37.97
|
|
|
53 - GROOVE BALL BEARING
BSD-1600900029.A183
1600900029
|
-
|
|
|
|
54 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A1099
2910021118
|
£1.75
|
£2.10
|
|
|
55 - TAPPING SCREW DIN 7971-BZ2.9x13
BSD-2910211006.A682
2910211006
|
£1.75
|
£2.10
|
|
|
55 - SOCKET HEAD CAP SCREW DIN 84-AM3x8-8.8
BSD-2910021050.A230
2910021050
|
£1.75
|
£2.10
|
|
|
56 - PLAIN WASHER DIN 433-3.2-ST 50
BSD-2916011005.A485
2916011005
|
£1.75
|
£2.10
|
|
|
56 - SPRING WASHER A 3 DIN 137-ST
BSD-2916060003.A384
2916060003
|
£1.32
|
£1.58
|
|
|
57 - SOCKET HEAD CAP SCREW DIN 84-AM5x15-8.8
BSD-2910021157.A60
2910021157
|
£1.32
|
£1.58
|
|
|
58 - HEX NUT DIN 934 -M4-m-8
BSD-2915011005.A557
2915011005
|
£1.75
|
£2.10
|
|
|
59 - TAPPING SCREW ST-4.8x57.5-TORX.T20
BSD-1613435009.A328
1613435009
|
£1.75
|
£2.10
|
|
|
60 - TAPPING SCREW DIN 7971-ST4.8x25-F
BSD-2910211036.A175
2910211036
|
£1.75
|
£2.10
|
|
|
60 - SOCKET HEAD CAP SCREW DIN 84-AM5x16-8.8
BSD-2910021158.A10
2910021158
|
£1.32
|
£1.58
|
|
|
61 - SOCKET HEAD CAP SCREW DIN 84-AM5x20-8.8
BSD-2910021162.A59
2910021162
|
-
|
|
|
|
63 - TAPPING SCREW B4.8x90 MM
BSD-1603435006.A69
1603435006
|
-
|
|
|
|
63 - SOCKET HEAD CAP SCREW DIN 84-BM5x82
BSD-1603410001.A128
1603410001
|
-
|
|
|
|
64 - SPRING LOCK WASHER DIN 127-B 5
BSD-2916680006.A319
2916680006
|
-
|
|
|
|
65 - SPRING WASHER DIN 137-A4
BSD-1600150006.A314
1600150006
|
-
|
|
|
|
66 - SOCKET HEAD CAP SCREW DIN 84-AM4x12-8.8
BSD-2910021122.A607
2910021122
|
£2.16
|
£2.59
|
|
|
69 - TAPPING SCREW DIN 7971-BZ3.5x13
BSD-2910211011.A224
2910211011
|
£1.75
|
£2.10
|
|
|
70 - SOCKET HEAD CAP SCREW DIN 84-AM5x25-8.8
BSD-2910021164.A17
2910021164
|
-
|
|
|
|
71 - SHIM 0.05 MM
BSD-1600101635.A84
1600101635
|
-
|
|
|
|
72 - SHIM 0.05 MM
BSD-1600101636.A24
1600101636
|
-
|
|
|
|
73 - SHIM 0.05 MM
BSD-1600101637.A84
1600101637
|
-
|
|
|
|
75 - HEX SCREW M14x16x1.5 MM
BSD-2603450007.A209
2603450007
|
£5.58
|
£6.70
|
|
|
75 - HEX SCREW DIN 933-M 14x16-5.8
BSD-2911051382.A12
2911051382
|
-
|
|
|
|
92 - CONNECTING FLANGE
BSD-1600328012.A52
1600328012
|
-
|
|
|
|
93 - SHUT-OFF TAP
BSD-1607415002.A72
1607415002
|
-
|
|
|
|
95 - ROTARY SHAFT LIP SEAL dia35x22x6/6.5 MM
BSD-1600283004.A21
1600283004
|
£7.36
|
£8.83
|
|
|
96 - CLAMP
BSD-1601300004.A0
1601300004
|
£2.16
|
£2.59
|
|
|
97 - CONNECTING FLANGE
BSD-1605703061.A17
1605703061
|
-
|
|
|
|
650 - AUXILIARY HANDLE M14
BSD-1602025022.A139
1602025022
|
£13.41
|
£16.09
|
|
|
650 - AUXILIARY HANDLE M14. dia37x115 MM
BSD-1602025030.A556
1602025030
|
£18.96
|
£22.75
|
|
|
651 - SINGLE-HEAD ENG. WRENCH SW17
BSD-2607950511.A766
2607950511
|
£4.26
|
£5.11
|
|
|
652/1/2 - HEX NUT DIN 934-M6-8-A
BSD-2915011007.A1035
2915011007
|
-
|
|
|
|
652/1/3 - SOCKET HEAD CAP SCREW DIN 84-M 6x16-8.8
BSD-2910022197.A280
2910022197
|
-
|
|
|
|
652/2/2 - HEX SOCKET HEAD CAP SCREW DIN 912-M8x20-8.8
BSD-2910141242.A34
2910141242
|
£1.75
|
£2.10
|
|
|
652/3/2 - HEX NUT DIN 934-M6-8-A
BSD-2915011007.A1034
2915011007
|
-
|
|
|
|
652/3/3 - SOCKET HEAD CAP SCREW DIN 84-M 6x16-8.8
BSD-2910022197.A279
2910022197
|
-
|
|
|
|
652/20 - HEX SOCKET HEAD CAP SCREW DIN 912-M8x20-8.8
BSD-2910141242.A35
2910141242
|
£1.75
|
£2.10
|
|
|
654 - CLAMPING-FLANGE dia45 MM
BSD-2600501006.A261
2600501006
|
£16.43
|
£19.72
|
|
|
702 - TENSIONER PARTS SET
BSD-1607000030.A62
1607000030
|
-
|
|
|
|
800 - CARBON-BRUSH SET
BSD-1607014103.A169
1607014103
|
£14.91
|
£17.89
|
|
|
801 - ASSEMBLY OF SERVICE PARTS
BSD-1605108902.A81
1605108902
|
-
|
|
|
|
803 - CONNECTING CABLE
BSD-1604440004.A198
1604440004
|
-
|
|
|
|
803/010 - TERMINAL LUG
BSD-1601353003.A130
1601353003
|
-
|
|
|
|
804 - BEVEL GEAR Z=59
BSD-1606333155.A10
1606333155
|
-
|
|
|
|
808 - ARMATURE 220V
BSD-1604011109.A5
1604011109
|
-
|
|
|
|
809 - SWITCH KIT
BSD-1607000034.A1
1607000034
|
-
|
|
|
|
809/040 - PAN HEAD SCREW DIN 85-AM4x8-4.8
BSD-2910091118.A453
2910091118
|
£1.75
|
£2.10
|
|
|
811 - SEAL KIT
BSD-1607000044.A16
1607000044
|
£9.49
|
£11.39
|
|
|
824 - BEARING FLANGE
BSD-1607000229.A9
1607000229
|
-
|
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A937
160111A3H3
|
£2.61
|
£3.13
|
|
