2 - BRUSH HOLDER
BSD-1604336008.A220
1604336008
|
£22.60
|
£27.12
|
|
|
3 - FIELD 220V
BSD-1604220215.A14
1604220215
|
-
|
|
|
|
3/8 - TERMINAL LUG 1.5-4x4
BSD-1901350003.A134
1901350003
|
£1.84
|
£2.21
|
|
|
6 - SPIRAL SPRING
BSD-1604652015.A422
1604652015
|
£2.94
|
£3.53
|
|
|
8 - SEALING CAP
BSD-1605500089.A68
1605500089
|
-
|
|
|
|
9 - HANDLE
BSD-1605132093.A54
1605132093
|
-
|
|
|
|
11 - SEAL
BSD-1600113002.A41
1600113002
|
£1.84
|
£2.21
|
|
|
13 - POWER SUPPLY CORD CH 4.15m 2 x 1.0mm H07RN-F
BSD-1604460447.A61
1604460447
|
£21.68
|
£26.01
|
|
|
17 - COVER PLATE
BSD-1601037006.A141
1601037006
|
-
|
|
|
|
18 - PROFILE STRIP 3.4x7x240 MM
BSD-1601014005.A54
1601014005
|
-
|
|
|
|
19/8 - FELT WASHER
BSD-1600205019.A80
1600205019
|
£1.75
|
£2.10
|
|
|
19/10 - SOCKET HEAD CAP SCREW DIN 84-AM3x8-8.8
BSD-2910021050.A168
2910021050
|
£1.75
|
£2.10
|
|
|
20 - BEARING COVER
BSD-1605808054.A270
1605808054
|
-
|
|
|
|
21 - COVER DISC
BSD-1600102012.A279
1600102012
|
-
|
|
|
|
23 - SEALING DISK
BSD-1600108055.A84
1600108055
|
£1.75
|
£2.10
|
|
|
27 - NEEDLE-ROLLER BEARING dia14 MM
BSD-2600910001.A259
2600910001
|
£4.48
|
£5.37
|
|
|
28 - RUBBER RING 7 MM
BSD-1600206020.A657
1600206020
|
£1.84
|
£2.21
|
|
|
29 - AIR-DEFLECTOR RING
BSD-1600502017.A33
1600502017
|
-
|
|
|
|
30 - SPRING RETAINING RING DIN 472 38X1.5MM
BSD-2916660017.A51
2916660017
|
£4.26
|
£5.11
|
|
|
32 - ROTARY SHAFT LIP SEAL 18.7 MM
BSD-1600290013.A159
1600290013
|
£2.74
|
£3.29
|
|
|
34 - SHIM 0.1 MM
BSD-1600190004.A138
1600190004
|
-
|
|
|
|
34 - SHIM 0.2 MM
BSD-1600190005.A145
1600190005
|
£1.38
|
£1.66
|
|
|
35 - TAB WASHER
BSD-1601030022.A387
1601030022
|
£1.84
|
£2.21
|
|
|
36 - RUBBER RING
BSD-1600206015.A75
1600206015
|
£2.27
|
£2.72
|
|
|
40 - SPRING WASHER dia27.5x38.4 MM
BSD-1600150007.A14
1600150007
|
£1.84
|
£2.21
|
|
|
50 - GROOVE BALL BEARING 17x40x12
BSD-1900905281.A80
1900905281
|
£33.22
|
£39.87
|
|
|
51 - SPRING WASHER DIN 137-A 4-ST
BSD-2916060005.A81
2916060005
|
£1.84
|
£2.21
|
|
|
52 - GROOVE BALL BEARING 15x35x11
BSD-1900905234.A159
1900905234
|
£33.22
|
£39.87
|
|
|
53 - GROOVE BALL BEARING
BSD-1600900029.A72
1600900029
|
-
|
|
|
|
54 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A288
2910021118
|
£1.84
|
£2.21
|
|
|
57 - SOCKET HEAD CAP SCREW DIN 84-AM5x15-5.8
BSD-2910011157.A355
2910011157
|
-
|
|
|
|
58 - TAPPING SCREW DIN 7971-BZ3.9x19
BSD-2910211020.A556
2910211020
|
£2.16
|
£2.59
|
|
|
59 - TAPPING SCREW B4.8x57.5 MM
BSD-1603429000.A64
1603429000
|
£1.84
|
£2.21
|
|
|
60/1 - TAPPING SCREW B4.8x57.5 MM
BSD-1603429000.A65
1603429000
|
£1.84
|
£2.21
|
|
|
61 - SOCKET HEAD CAP SCREW DIN 84-AM5x20-5.8
BSD-2910011162.A333
2910011162
|
£1.84
|
£2.21
|
|
|
62 - HEX NUT
BSD-1603300018.A39
1603300018
|
-
|
|
|
|
63 - TAPPING SCREW B4.8x90 MM
BSD-1603435006.A138
1603435006
|
-
|
|
|
|
66 - SOCKET HEAD CAP SCREW DIN 84-AM4x12-8.8
BSD-2910021122.A157
2910021122
|
£2.27
|
£2.72
|
|
|
69 - TAPPING SCREW DIN 7971-BZ3.5x13
BSD-2910211011.A504
2910211011
|
£1.84
|
£2.21
|
|
|
71 - INTERMEDIATE FLANGE
BSD-1605700020.A18
1605700020
|
-
|
|
|
|
72 - WIREWOUND RESISTOR
BSD-1604503005.A0
1604503005
|
-
|
|
|
|
81 - REFERENCE PLATE
BSD-1601110133.A11
1601110133
|
-
|
|
|
|
100 - GROOVED RING
BSD-1600390011.A35
1600390011
|
-
|
|
|
|
800 - CARBON-BRUSH SET
BSD-1607014103.A73
1607014103
|
£15.65
|
£18.78
|
|
|
801 - ASSEMBLY OF SERVICE PARTS
BSD-1605108902.A47
1605108902
|
-
|
|
|
|
803/2 - TERMINAL LUG
BSD-1601353003.A27
1601353003
|
-
|
|
|
|
809/10 - PAN HEAD SCREW DIN 85-AM4x8-4.8
BSD-2910091118.A133
2910091118
|
£1.84
|
£2.21
|
|
|
813 - PARTS SET
BSD-1607000161.A60
1607000161
|
-
|
|
|
|
817 - BEARING FLANGE
BSD-1607000229.A126
1607000229
|
-
|
|
|
|
830 - ARMATURE 220V
BSD-1604011126.A5
1604011126
|
-
|
|
|
|
831 - ON-OFF SWITCH
BSD-1607200098.A8
1607200098
|
-
|
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A3829
160111A3H3
|
£2.74
|
£3.29
|
|
