2 - BRUSH HOLDER
BSD-1604336008.A224
1604336008
|
£22.60
|
£27.12
|
|
|
3 - FIELD 220V
BSD-1604220215.A12
1604220215
|
-
|
|
|
|
3/8 - TERMINAL LUG 1.5-4x4
BSD-1901350003.A126
1901350003
|
£1.84
|
£2.21
|
|
|
6 - SPIRAL SPRING
BSD-1604652015.A432
1604652015
|
£2.94
|
£3.53
|
|
|
8 - SEALING CAP
BSD-1605500089.A77
1605500089
|
-
|
|
|
|
9 - HANDLE
BSD-1605132093.A49
1605132093
|
-
|
|
|
|
11 - SEAL
BSD-1600113002.A35
1600113002
|
£1.84
|
£2.21
|
|
|
12 - GROMMET dia9.2-dia12x120 MM
BSD-3600703011.A463
3600703011
|
£2.94
|
£3.53
|
|
|
13 - POWER SUPPLY CORD CH 4.15m 2 x 1.0mm H07RN-F
BSD-1604460447.A62
1604460447
|
£21.68
|
£26.01
|
|
|
14 - SUPPRESSION FILTER
BSD-1607328034.A170
1607328034
|
£4.48
|
£5.37
|
|
|
15 - FASTENING CLAMP
BSD-1601302013.A552
1601302013
|
£1.84
|
£2.21
|
|
|
17 - COVER PLATE
BSD-1601037009.A20
1601037009
|
-
|
|
|
|
17 - COVER PLATE
BSD-1601037006.A130
1601037006
|
-
|
|
|
|
18 - PROFILE STRIP 3.4x7x240 MM
BSD-1601014005.A49
1601014005
|
-
|
|
|
|
19 - CONTROL LEVER
BSD-1602026058.A38
1602026058
|
-
|
|
|
|
19/8 - FELT WASHER
BSD-1600205019.A82
1600205019
|
£1.75
|
£2.10
|
|
|
19/10 - SOCKET HEAD CAP SCREW DIN 84-AM3x8-8.8
BSD-2910021050.A154
2910021050
|
£1.75
|
£2.10
|
|
|
20 - BEARING COVER
BSD-1605808054.A269
1605808054
|
-
|
|
|
|
21 - COVER DISC
BSD-1600102012.A268
1600102012
|
-
|
|
|
|
22 - GRINDING SPINDLE M14. L=101 MM
BSD-1603523090.A112
1603523090
|
-
|
|
|
|
23 - SEALING DISK
BSD-1600108055.A95
1600108055
|
£1.75
|
£2.10
|
|
|
25 - GROMMET
BSD-1600306001.A143
1600306001
|
£2.61
|
£3.13
|
|
|
27 - NEEDLE-ROLLER BEARING dia14 MM
BSD-2600910001.A256
2600910001
|
£4.48
|
£5.37
|
|
|
28 - RUBBER RING 7 MM
BSD-1600206020.A659
1600206020
|
£1.84
|
£2.21
|
|
|
29 - AIR-DEFLECTOR RING
BSD-1600502017.A31
1600502017
|
-
|
|
|
|
30 - SPRING RETAINING RING DIN 472 38X1.5MM
BSD-2916660017.A48
2916660017
|
£4.26
|
£5.11
|
|
|
32 - ROTARY SHAFT LIP SEAL 18.7 MM
BSD-1600290013.A157
1600290013
|
£2.74
|
£3.29
|
|
|
34 - SHIM 0.1 MM
BSD-1600190004.A140
1600190004
|
-
|
|
|
|
34 - SHIM 0.2 MM
BSD-1600190005.A143
1600190005
|
£1.38
|
£1.66
|
|
|
35 - TAB WASHER
BSD-1601030022.A400
1601030022
|
£1.84
|
£2.21
|
|
|
36 - RUBBER RING
BSD-1600206015.A73
1600206015
|
£2.27
|
£2.72
|
|
|
38 - MANUFACTURER'S NAMEPLATE
BSD-1601110003.A249
1601110003
|
-
|
|
|
|
40 - SPRING WASHER dia27.5x38.4 MM
BSD-1600150007.A12
1600150007
|
£1.84
|
£2.21
|
|
|
50 - GROOVE BALL BEARING 17x40x12
BSD-1900905281.A90
1900905281
|
£33.22
|
£39.87
|
|
|
51 - SPRING WASHER DIN 137-A 4-ST
BSD-2916060005.A80
2916060005
|
£1.84
|
£2.21
|
|
|
52 - GROOVE BALL BEARING 15x35x11
BSD-1900905234.A144
1900905234
|
£33.22
|
£39.87
|
|
|
53 - GROOVE BALL BEARING
BSD-1600900029.A60
1600900029
|
-
|
|
|
|
54 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A307
2910021118
|
£1.84
|
£2.21
|
|
|
55 - TAPPING SCREW DIN 7971-BZ2.9x13
BSD-2910211006.A57
2910211006
|
£1.75
|
£2.10
|
|
|
56 - PLAIN WASHER DIN 433-3.2-ST 50
BSD-2916011005.A131
2916011005
|
£1.84
|
£2.21
|
|
|
57 - SOCKET HEAD CAP SCREW DIN 84-AM5x15-5.8
BSD-2910011157.A345
2910011157
|
-
|
|
|
|
58 - TAPPING SCREW DIN 7971-BZ3.9x19
BSD-2910211020.A563
2910211020
|
£2.16
|
£2.59
|
|
|
60 - TAPPING SCREW DIN 7971-ST4.8x25-F
BSD-2910211036.A32
2910211036
|
£1.84
|
£2.21
|
|
|
61 - SOCKET HEAD CAP SCREW DIN 84-AM5x20-5.8
BSD-2910011162.A343
2910011162
|
£1.84
|
£2.21
|
|
|
62 - HEX NUT
BSD-1603300018.A31
1603300018
|
-
|
|
|
|
63 - TAPPING SCREW B4.8x90 MM
BSD-1603435006.A150
1603435006
|
-
|
|
|
|
66 - TAPPING SCREW DIN 7971-ST3.9x13-F
BSD-2910211018.A541
2910211018
|
£1.75
|
£2.10
|
|
|
69 - TAPPING SCREW DIN 7971-BZ3.5x13
BSD-2910211011.A514
2910211011
|
£1.84
|
£2.21
|
|
|
100 - GROOVED RING
BSD-1600390011.A23
1600390011
|
-
|
|
|
|
800 - CARBON-BRUSH SET
BSD-1607014103.A83
1607014103
|
£15.65
|
£18.78
|
|
|
801 - ASSEMBLY OF SERVICE PARTS
BSD-1605108902.A31
1605108902
|
-
|
|
|
|
803 - CONNECTING CABLE
BSD-1604440004.A79
1604440004
|
-
|
|
|
|
803/2 - TERMINAL LUG
BSD-1601353003.A35
1601353003
|
-
|
|
|
|
804 - CROWN GEAR Z=52
BSD-1606333198.A2
1606333198
|
-
|
|
|
|
805 - BEVEL GEAR Z=16. dia 10 MM
BSD-1606333217.A8
1606333217
|
-
|
|
|
|
809/10 - PAN HEAD SCREW DIN 85-AM4x8-4.8
BSD-2910091118.A121
2910091118
|
£1.84
|
£2.21
|
|
|
813 - PARTS SET
BSD-1607000161.A61
1607000161
|
-
|
|
|
|
816 - PARTS SET
BSD-1607000905.A5
1607000905
|
-
|
|
|
|
817 - BEARING FLANGE
BSD-1607000229.A109
1607000229
|
-
|
|
|
|
830 - ARMATURE 220V
BSD-1604011126.A3
1604011126
|
-
|
|
|
|
831 - ON-OFF SWITCH
BSD-1607200097.A5
1607200097
|
-
|
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A3826
160111A3H3
|
£2.74
|
£3.29
|
|
