1 - HOUSING SECTION
BSD-1615104011.A11
1615104011
|
-
|
|
|
|
2 - POLE HOUSING 14;4-24V
BSD-2610942109.A37
2610942109
|
£21.68
|
£26.01
|
|
|
4 - ON-OFF SWITCH
BSD-1617200067.A21
1617200067
|
£68.42
|
£82.10
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1611110909.A10
1611110909
|
£5.58
|
£6.70
|
|
|
11 - REFERENCE PLATE
BSD-1611110910.A1
1611110910
|
£5.30
|
£6.36
|
|
|
13 - GROOVE BALL BEARING 8x22x7
BSD-1600905033.A17
1600905033
|
£7.36
|
£8.83
|
|
|
14 - GROOVE BALL BEARING 8x22x7
BSD-2600905052.A379
2600905052
|
£7.36
|
£8.83
|
|
|
15 - FAN
BSD-1616610080.A17
1616610080
|
£7.78
|
£9.33
|
|
|
17 - SPIRAL SPRING
BSD-1604652013.A421
1604652013
|
£1.75
|
£2.10
|
|
|
18 - DAMPING RUBBER
BSD-2603100056.A113
2603100056
|
£1.75
|
£2.10
|
|
|
20 - CATCH DISK
BSD-1616409012.A55
1616409012
|
£5.87
|
£7.04
|
|
|
22 - CYLINDRICAL GEAR Z=53
BSD-1616317613.A10
1616317613
|
-
|
|
|
|
27 - STRIKER
BSD-1618710068.A19
1618710068
|
£7.78
|
£9.33
|
|
|
30 - DRIVE LEVER
BSD-1611911000.A67
1611911000
|
-
|
|
|
|
33 - COMPRESSION SPRING
BSD-1614634008.A38
1614634008
|
£1.95
|
£2.34
|
|
|
34 - BEARING PIN
BSD-1613100021.A29
1613100021
|
£2.33
|
£2.80
|
|
|
36 - SUPPORTING DISC
BSD-1610190021.A42
1610190021
|
£2.16
|
£2.59
|
|
|
39 - PROTECTIVE CAP
BSD-1610508021.A51
1610508021
|
£1.95
|
£2.34
|
|
|
43 - SUPPORTING DISC
BSD-1610190020.A35
1610190020
|
£1.95
|
£2.34
|
|
|
45 - DRIVE PINION Z=9
BSD-1616316602.A21
1616316602
|
£14.75
|
£17.70
|
|
|
46 - STRAIGHT PIN
BSD-1613160022.A45
1613160022
|
£1.75
|
£2.10
|
|
|
53 - NEEDLE BEARING
BSD-1610910077.A42
1610910077
|
£4.26
|
£5.11
|
|
|
55 - ROLLER THRUST BEARING
BSD-1610920012.A61
1610920012
|
£3.34
|
£4.01
|
|
|
56 - SUPPORT DISC 1.0 MM
BSD-1610102030.A20
1610102030
|
£2.61
|
£3.13
|
|
|
57 - ROLLER THRUST BEARING
BSD-1610920009.A24
1610920009
|
£3.34
|
£4.01
|
|
|
60 - SEAL RING
BSD-1610280006.A18
1610280006
|
£3.34
|
£4.01
|
|
|
62 - O-RING 18.0x2.5 MM
BSD-1610210125.A82
1610210125
|
£1.95
|
£2.34
|
|
|
63 - BALL DIN 5401-dia7MM-III-ST
BSD-1903230013.A668
1903230013
|
£2.16
|
£2.59
|
|
|
65 - RETAINING RING
BSD-1614601018.A24
1614601018
|
£1.66
|
£1.99
|
|
|
67 - SPRING RETAINING RING
BSD-3600224038.A21
3600224038
|
£1.32
|
£1.58
|
|
|
72 - SHIM WASHER 1.0 MM
BSD-1610100007.A44
1610100007
|
£1.75
|
£2.10
|
|
|
74 - SEALING FRAME
BSD-1611015045.A8
1611015045
|
£5.30
|
£6.36
|
|
|
75 - SEALING FRAME
BSD-1611015041.A71
1611015041
|
£1.95
|
£2.34
|
|
|
76 - SEAL RING
BSD-1610210138.A35
1610210138
|
£1.75
|
£2.10
|
|
|
80 - SEALING DISK
BSD-1610100008.A41
1610100008
|
£1.75
|
£2.10
|
|
|
81 - LOCATING RING
BSD-1610290043.A20
1610290043
|
£2.16
|
£2.59
|
|
|
82 - AIR-DEFLECTOR RING
BSD-1610591017.A25
1610591017
|
-
|
|
|
|
85 - SWITCH SLIDE
BSD-1613231006.A9
1613231006
|
£1.95
|
£2.34
|
|
|
86 - CONTACT RETAINER
BSD-1609280157.A48
1609280157
|
-
|
|
|
|
87 - COMPRESSION SPRING
BSD-1614611012.A18
1614611012
|
£8.49
|
£10.19
|
|
|
90 - CATCH SLIDE
BSD-1613231007.A36
1613231007
|
£1.32
|
£1.58
|
|
|
92 - TAPPING SCREW DIN7981-ST3.9x22-C-Z
BSD-2912401021.A195
2912401021
|
£1.75
|
£2.10
|
|
|
93 - TAPPING SCREW DIN7981-ST3.9x16-C-Z
BSD-2912401019.A296
2912401019
|
£1.75
|
£2.10
|
|
|
94 - TAPPING SCREW DIN7981-ST2.9x9.5C-Z
BSD-2912401005.A247
2912401005
|
£1.75
|
£2.10
|
|
|
98 - CONNECTING CABLE L=260 MM
BSD-1614416012.A6
1614416012
|
£1.75
|
£2.10
|
|
|
99 - CONNECTING CABLE L=270 MM
BSD-1614416011.A47
1614416011
|
£1.75
|
£2.10
|
|
|
100 - REFERENCE PLATE
BSD-1611110914.A13
1611110914
|
-
|
|
|
|
120 - AUXILIARY HANDLE M8
BSD-1612025019.A188
1612025019
|
£6.52
|
£7.83
|
|
|
121 - SUPPORT CLAMP dia43 MM
BSD-1618040067.A23
1618040067
|
£6.61
|
£7.93
|
|
|
122 - T-HEAD BOLT M8x40 MM
BSD-1613490002.A384
1613490002
|
£4.26
|
£5.11
|
|
|
123 - CLAMPING BAND dia43 MM
BSD-1611316006.A222
1611316006
|
£2.61
|
£3.13
|
|
|
655 - PROTECTIVE CAP
BSD-1610508032.A7
1610508032
|
£2.16
|
£2.59
|
|
|
661 - GREASE TUBE 30 ML
BSD-1615430010.A112
1615430010
|
£6.52
|
£7.83
|
|
|
700 - DRILL CHUCK SHANK
BSD-1617000132.A36
1617000132
|
£16.84
|
£20.21
|
|
|
700/20 - COUNTERSUNK-HEAD SCREW M6x27
BSD-2603421226.A235
2603421226
|
£1.75
|
£2.10
|
|
|
701 - CHUCK
BSD-1608571088.A218
1608571088
|
£27.23
|
£32.68
|
|
|
701/7 - CHUCK WRENCH SG2
BSD-2607950007.A531
2607950007
|
£6.52
|
£7.83
|
|
|
702 - PARTS SET
BSD-1617000133.A189
1617000133
|
-
|
|
|
|
702/10/2 - RETAINING RING
BSD-2604601004.A233
2604601004
|
£1.75
|
£2.10
|
|
|
702/20 - SCREWDRIVER BLADE NR.2.1/4
BSD-1608521004.A56
1608521004
|
-
|
|
|
|
702/30 - SCREWDRIVER BIT
BSD-2607000248.A83
2607000248
|
-
|
|
|
|
702/40 - SCREWDRIVER BLADE GR.1.0x6. 1/4
BSD-1608511020.A72
1608511020
|
-
|
|
|
|
703 - DUST TRAY
BSD-1615439003.A55
1615439003
|
-
|
|
|
|
703/30 - RUBBER BUSHING dia5-7 MM
BSD-1610312001.A21
1610312001
|
-
|
|
|
|
703/651 - RUBBER BUSHING dia8-10 MM
BSD-1610312002.A118
1610312002
|
-
|
|
|
|
720 - AUXILIARY HANDLE dia43 MM
BSD-2602025092.A12
2602025092
|
-
|
|
|
|
752 - DEPTH-GAUGE SW 6x210 MM
BSD-1613001009.A138
1613001009
|
£3.72
|
£4.47
|
|
|
753 - ACCUMULATOR BATTERY 24V. 3.0Ah. NiCd
BSD-2607335216.A4
2607335216
|
-
|
|
|
|
754 - FAST CHARGER EU 230/7.2-24V. 15 MIN.
BSD-2607224484.A4
2607224484
|
-
|
|
|
|
791 - CARRYING CASE
BSD-2605438358.A12
2605438358
|
-
|
|
|
|
803 - ARMATURE WITH FAN 24V
BSD-1617000319.A20
1617000319
|
£72.18
|
£86.62
|
|
|
808 - NAMEPLATE
BSD-160111A3H9.A14
160111A3H9
|
£2.61
|
£3.13
|
|
|
810 - CARBON-BRUSH SET
BSD-1617014131.A27
1617014131
|
-
|
|
|
|
816 - BRUSH HOLDER L=145 MM
BSD-1617000379.A26
1617000379
|
-
|
|
|
|
817 - BRUSH HOLDER L=45 MM
BSD-1617000380.A27
1617000380
|
-
|
|
|
|
821 - HAMMER PIPE
BSD-1617000320.A5
1617000320
|
-
|
|
|
|
821/01 - HAMMER PIPE
BSD-1617000375.A18
1617000375
|
-
|
|
|
|
824 - JACK SHAFT Z=31/12
BSD-1617000314.A5
1617000314
|
£46.82
|
£56.18
|
|
|
841 - PROTECTION SLEEVE
BSD-1617000303.A71
1617000303
|
£14.91
|
£17.89
|
|
|
844 - CLAMP HANDLE
BSD-1617000322.A61
1617000322
|
£3.72
|
£4.47
|
|
|
850 - BUSHING
BSD-1617000975.A36
1617000975
|
£6.61
|
£7.93
|
|
|
864 - STRAIGHT PIN DIN6325-2.5x12-RIKO
BSD-1613100019.A26
1613100019
|
£1.75
|
£2.10
|
|
