Bosch GSR 12 VPE-2 / 0601946555 / EU 12 Volt Spare Parts

An exploded drawing and listing for the Bosch GSR 12 VPE-2 / 0601946555 / EU 12 Volt

	Ex VAT	Inc VAT
1 - HOUSING SECTION BSD-2605104587.A9 2605104587	-
2/10 - PINION BSD-2606316182.A45 2606316182	£1.75	£2.10
5 - ADJUSTING SLIDE BSD-2601099082.A26 2601099082	£1.75	£2.10
25 - KEYLESS CHUCK BSD-2608572160.A15 2608572160	-
32 - ADJUSTING SLIDE BSD-2601099078.A10 2601099078	£1.32	£1.58
50 - INTERMEDIATE FLANGE BSD-2605719027.A56 2605719027	£2.61	£3.13
91 - SLIDE-IN ACCU PACKAGE 12V.2.0Ah.NiCd BSD-2607335148.A31 2607335148	-
93 - SCREWDRIVER BLADE BSD-2608521018.A4 2608521018	£5.01	£6.01
96 - SUPPORT BSD-2608040131.A109 2608040131	£1.95	£2.34
101 - TORX OVAL-HEAD SCREW 3x18 BSD-2603490018.A471 2603490018	£1.75	£2.10
102 - RETAINING BRACKET BSD-2601329041.A153 2601329041	£2.33	£2.80
107 - COUNTERSUNK-HEAD SCREW BSD-2603421008.A35 2603421008	£1.75	£2.10
798 - CARRYING LOOP BSD-2601398009.A6 2601398009	-
802 - DC MOTOR 12V BSD-2607022964.A1 2607022964	-
804 - ON-OFF SWITCH BSD-2607200421.A84 2607200421	£48.38	£58.06
845 - PLANETARY GEAR TRAIN BSD-2606200908.A31 2606200908	-
899 - CORDLESS DRILL DRIVER BSD-0601946520.A4 0601946520	-

Attribute Name	Value
Brand	Bosch
