1 - GRILLE
BDE-1004455-26.A1
1004455-26
|
-
|
|
|
|
1 - HANDLE
BDE-1004700-84.A3
1004700-84
|
£18.91
|
£22.69
|
|
|
2 - KNOB
BDE-1004700-62.A4
1004700-62
|
£7.18
|
£8.62
|
|
|
2 - GRILLE
BDE-1004455-27.A1
1004455-27
|
-
|
|
|
|
3 - LEVER
BDE-1004700-63.A0
1004700-63
|
£1.50
|
£1.80
|
|
|
3 - HOUSING FRONT
BDE-1004455-28
1004455-28
|
-
|
|
|
|
4 - DOOR
BDE-1004455-29.A0
1004455-29
|
£3.30
|
£3.96
|
|
|
4 - CLAMSHELL
BDE-1004700-64.A4
1004700-64
|
£25.70
|
£30.84
|
|
|
5 - GLAND
BDE-1004455-07.A20
1004455-07
|
£7.64
|
£9.17
|
|
|
5 - DOOR
BDE-1004455-30.A7
1004455-30
|
£3.30
|
£3.96
|
|
|
6 - CORDSET GB
BDE-1004690-87.A2
1004690-87
|
£30.08
|
£36.10
|
|
|
7 - COVER
BDE-1004700-65.A0
1004700-65
|
£2.78
|
£3.34
|
|
|
8 - PIN
BDE-1004700-66.A34
1004700-66
|
£1.50
|
£1.80
|
|
|
8 - BASE
BDE-1004455-34
1004455-34
|
-
|
|
|
|
9 - WHEEL
BDE-1004455-35.A0
1004455-35
|
£7.18
|
£8.62
|
|
|
9 - SWITCH SA
BDE-1004700-67.A0
1004700-67
|
£12.17
|
£14.60
|
|
|
10 - GLAND
BDE-1004455-07.A21
1004455-07
|
£7.64
|
£9.17
|
|
|
10 - FORK
BDE-1004512-08.A15
1004512-08
|
£5.95
|
£7.14
|
|
|
11 - HANDLE
BDE-1004455-36
1004455-36
|
-
|
|
|
|
11 - COUPLING SA
BDE-1004700-68.A4
1004700-68
|
£9.41
|
£11.29
|
|
|
12 - PUMP SA
BDE-1004700-85.A0
1004700-85
|
£209.59
|
£251.51
|
|
|
12 - CARRIER
BDE-1004455-37.A0
1004455-37
|
-
|
|
|
|
13 - CARRIER
BDE-1004455-38.A3
1004455-38
|
-
|
|
|
|
13 - SUCTION GROUP
BDE-1004512-17.A28
1004512-17
|
£12.17
|
£14.60
|
|
|
14 - FORK
BDE-1004512-19.A30
1004512-19
|
£1.50
|
£1.80
|
|
|
15 - FILTER & INLET KIT
BDE-1004455-15.A2
1004455-15
|
-
|
|
|
|
15 - PIPE
BDE-1004700-70.A2
1004700-70
|
£4.69
|
£5.63
|
|
|
16 - SERVICE KIT
BDE-1004455-16.A11
1004455-16
|
£24.39
|
£29.27
|
|
|
16 - FILTER
BDE-1004700-71.A2
1004700-71
|
£1.50
|
£1.80
|
|
|
17 - CONVEYOR
BDE-1004700-72.A2
1004700-72
|
£12.17
|
£14.60
|
|
|
18 - CONVEYOR
BDE-1004700-73.A2
1004700-73
|
£9.41
|
£11.29
|
|
|
18 - SERVICE KIT
BDE-1004455-19.A8
1004455-19
|
£9.41
|
£11.29
|
|
|
19 - BRUSH KIT
BDE-1004512-06.A2
1004512-06
|
£9.42
|
£11.30
|
|
|
20 - SUCTION GROUP
BDE-1004700-80.A2
1004700-80
|
£14.57
|
£17.48
|
|
|
21 - TANK
BDE-1004455-43.A2
1004455-43
|
£25.70
|
£30.84
|
|
|
21 - WHEEL
BDE-1004700-87.A3
1004700-87
|
£12.17
|
£14.60
|
|
|
22 - ADJUSTER HANDLE
BDE-1004455-44.A4
1004455-44
|
£41.24
|
£49.49
|
|
|
22 - CLAMSHELL
BDE-1004700-75.A2
1004700-75
|
£25.70
|
£30.84
|
|
|
23 - HOSE SA
BDE-1004455-45.A2
1004455-45
|
£37.35
|
£44.82
|
|
|
23 - GUARD
BDE-1004700-76.A2
1004700-76
|
£7.18
|
£8.62
|
|
|
24 - COUPLING SA
BDE-1004712-93.A41
1004712-93
|
£7.88
|
£9.45
|
|
|
25 - SERVICE KIT
BDE-1004700-78.A1
1004700-78
|
£14.57
|
£17.48
|
|
|
26 - PISTONS & SEALS KIT
BDE-1004512-11.A12
1004512-11
|
£34.00
|
£40.80
|
|
|
27 - VALVES & SEALS KIT
BDE-1004512-12.A2
1004512-12
|
£14.57
|
£17.48
|
|
|
28 - SCREW KIT
BDE-1004700-79.A2
1004700-79
|
£14.57
|
£17.48
|
|
|
29 - HANDLE SA
BDE-3082280.A7
3082280
|
£34.00
|
£40.80
|
|
|
29 - O RING
BDE-1004424-04
1004424-04
|
-
|
|
|
|
30 - O RING
BDE-1004424-05.A0
1004424-05
|
-
|
|
|
|
30 - EXTENSION
BDE-1004700-82.A5
1004700-82
|
£14.57
|
£17.48
|
|
|
31 - O RING
BDE-1004424-06.A1
1004424-06
|
£1.50
|
£1.80
|
|
|
31 - ADAPTOR
BDE-1004512-28.A9
1004512-28
|
£1.50
|
£1.80
|
|
|
32 - O RING
BDE-1004424-07.A0
1004424-07
|
-
|
|
|
|
32 - BRUSH
BDE-1004455-56.A6
1004455-56
|
£14.57
|
£17.48
|
|
|
33 - HEAD SA
BDE-1004700-88.A0
1004700-88
|
-
|
|
|
|
34 - HEAD SA
BDE-1004700-89.A1
1004700-89
|
£24.39
|
£29.27
|
|
|
35 - BRUSH
BDE-3084350.A3
3084350
|
£38.80
|
£46.56
|
|
|
36 - HOSE SA
BDE-1004512-26.A8
1004512-26
|
£37.35
|
£44.82
|
|
|
37 - O RING
BDE-3083400.A28
3083400
|
£1.50
|
£1.80
|
|
|
38 - O RING
BDE-5140193-41.A45
5140193-41
|
£1.50
|
£1.80
|
|
|
39 - O RING
BDE-5140206-02.A11
5140206-02
|
£1.51
|
£1.81
|
|
