1 - HANDLE
BDE-4380310.A4
4380310
|
£18.91
|
£22.69
|
|
|
2 - KNOB
BDE-4380250.A11
4380250
|
£2.78
|
£3.34
|
|
|
3 - LEVER
BDE-4380390.A11
4380390
|
£2.26
|
£2.71
|
|
|
4 - HOUSING
BDE-4380210.A3
4380210
|
£24.39
|
£29.27
|
|
|
5 - GLAND
BDE-3080580.A39
3080580
|
£1.50
|
£1.80
|
|
|
7 - COVER
BDE-1004700-65.A7
1004700-65
|
£2.78
|
£3.34
|
|
|
8 - PIN
BDE-1004700-66.A27
1004700-66
|
£1.50
|
£1.80
|
|
|
9 - SWITCH
BDE-3081450.A11
3081450
|
-
|
|
|
|
10 - FORK
BDE-1004512-08.A20
1004512-08
|
£5.95
|
£7.14
|
|
|
11 - CONNECTOR
BDE-4383200.A14
4383200
|
£10.82
|
£12.99
|
|
|
12 - PUMP SA
BDE-4381450.A0
4381450
|
£157.18
|
£188.61
|
|
|
13 - LEVER
BDE-4380560.A12
4380560
|
£7.18
|
£8.62
|
|
|
14 - KNOB
BDE-4380450.A3
4380450
|
£2.26
|
£2.71
|
|
|
15 - FOOT
BDE-4380370.A1
4380370
|
£12.17
|
£14.60
|
|
|
16 - CARRIER
BDE-4380280.A4
4380280
|
£3.30
|
£3.96
|
|
|
17 - CONVEYOR
BDE-4380170.A23
4380170
|
£14.57
|
£17.48
|
|
|
18 - CONVEYOR
BDE-4380160.A3
4380160
|
£14.57
|
£17.48
|
|
|
19 - BRUSH PAIR
BDE-3082600.A7
3082600
|
£16.03
|
£19.24
|
|
|
20 - GUARD
BDE-4380350.A2
4380350
|
£12.17
|
£14.60
|
|
|
21 - CLIP SA
BDE-4381280.A15
4381280
|
£3.80
|
£4.56
|
|
|
22 - BASE
BDE-4380200.A6
4380200
|
£34.00
|
£40.80
|
|
|
23 - CARRIER
BDE-4380230.A5
4380230
|
£12.17
|
£14.60
|
|
|
24 - COUPLING SA
BDE-1004712-93.A26
1004712-93
|
£7.88
|
£9.45
|
|
|
25 - KIT
BDE-3081280.A14
3081280
|
£16.03
|
£19.24
|
|
|
26 - PISTONS & SEALS KIT
BDE-3081270.A0
3081270
|
£24.39
|
£29.27
|
|
|
27 - VALVES & SEALS KIT
BDE-3081290.A0
3081290
|
-
|
|
|
|
28 - SCREW KIT
BDE-4381470.A15
4381470
|
£7.18
|
£8.62
|
|
|
29 - KNOB
BDE-4381300.A7
4381300
|
£10.85
|
£13.02
|
|
|
30 - GUARD
BDE-4380380.A3
4380380
|
£5.88
|
£7.06
|
|
|
31 - WHEEL
BDE-4380340.A0
4380340
|
£14.57
|
£17.48
|
|
|
32 - BRACKET
BDE-4380470.A9
4380470
|
£5.88
|
£7.06
|
|
|
33 - PLATE
BDE-3080200.A1
3080200
|
£14.57
|
£17.48
|
|
|
34 - BRACKET
BDE-4380460.A13
4380460
|
£5.88
|
£7.06
|
|
|
35 - HANDLE SA
BDE-4381481.A3
4381481
|
£34.00
|
£40.80
|
|
|
36 - EXTENSION
BDE-4381491.A3
4381491
|
£25.70
|
£30.84
|
|
|
37 - HEAD SA
BDE-4100800.A14
4100800
|
£24.39
|
£29.27
|
|
|
38 - HEAD SA
BDE-4381820.A5
4381820
|
£24.39
|
£29.27
|
|
|
39 - TANK
BDE-4381500.A15
4381500
|
£7.85
|
£9.42
|
|
|
40 - HOSE
BDE-3500360.A0
3500360
|
£34.00
|
£40.80
|
|
|
41 - O RING
BDE-5140193-41.A36
5140193-41
|
£1.50
|
£1.80
|
|
|
42 - O RING
BDE-5140206-02.A3
5140206-02
|
£1.51
|
£1.81
|
|
|
43 - O RING
BDE-3083400.A33
3083400
|
£1.50
|
£1.80
|
|
|
44 - ADAPTOR
BDE-40788.A2
40788
|
-
|
|
|
|
45 - BRUSH SA
BDE-40787.A13
40787
|
£14.57
|
£17.48
|
|
|
46 - BRUSH
BDE-3084350.A1
3084350
|
£38.80
|
£46.56
|
|
