1 - MOTOR HOUSING
BSD-1609200638.A7
1609200638
|
-
|
|
|
|
2 - POLE SHOE 220V
BSD-1609200639.A1
1609200639
|
-
|
|
|
|
3 - ARMATURE WITH FAN 220V
BSD-1609200640.A5
1609200640
|
-
|
|
|
|
3/10 - GROOVE BALL BEARING 6 001 LLU C 3/3K DIN 625
BSD-1609200715.A22
1609200715
|
-
|
|
|
|
3/20 - GROOVE BALL BEARING 607 LLB C3/3K DIN 625
BSD-1609200716.A46
1609200716
|
-
|
|
|
|
4 - ON-OFF SWITCH
BSD-1609200748.A72
1609200748
|
-
|
|
|
|
6 - GROMMET dia9x90 MM
BSD-1609207001.A19
1609207001
|
-
|
|
|
|
7 - FASTENING CLAMP
BSD-1609213000.A164
1609213000
|
-
|
|
|
|
9 - REFERENCE PLATE
BSD-1601110044.A17
1601110044
|
-
|
|
|
|
10 - STICKER
BSD-1609200656.A2
1609200656
|
-
|
|
|
|
11 - SUPPRESSION CAPACITOR
BSD-1609200887.A24
1609200887
|
-
|
|
|
|
12 - CARBON-BRUSH SET
BSD-1609202417.A73
1609202417
|
-
|
|
|
|
13 - BRUSH HOLDER
BSD-1609200032.A46
1609200032
|
-
|
|
|
|
14 - HOUSING COVER
BSD-1609201114.A0
1609201114
|
-
|
|
|
|
15 - BEARING COVER
BSD-1609200643.A7
1609200643
|
-
|
|
|
|
16 - GEAR COVER
BSD-1609200644.A1
1609200644
|
-
|
|
|
|
18 - HEX SCREW M 10x70 DIN 933-8.8
BSD-2911061307.A5
2911061307
|
-
|
|
|
|
19 - HANDLE
BSD-1609200642.A1
1609200642
|
-
|
|
|
|
20 - COMPRESSION SPRING
BSD-1604619017.A7
1604619017
|
£2.16
|
£2.59
|
|
|
20 - COMPRESSION SPRING
BSD-1604619017.A8
1604619017
|
£2.16
|
£2.59
|
|
|
21 - HEX NUT DIN 934-M 10-m-8
BSD-2915011010.A28
2915011010
|
-
|
|
|
|
22 - SEALING PLATE
BSD-1609200043.A16
1609200043
|
-
|
|
|
|
23 - ADJUSTING SLIDE
BSD-1609201076.A12
1609201076
|
-
|
|
|
|
24 - BASE PLATE
BSD-1609200648.A7
1609200648
|
-
|
|
|
|
25 - FLAP
BSD-1609200031.A6
1609200031
|
-
|
|
|
|
26 - COILED SPRING
BSD-1609200044.A6
1609200044
|
-
|
|
|
|
27 - FLAP
BSD-1609200021.A20
1609200021
|
-
|
|
|
|
28 - INTERMEDIATE PLATE
BSD-1609200649.A1
1609200649
|
-
|
|
|
|
30 - CUTTER HEAD
BSD-1609201113.A3
1609201113
|
-
|
|
|
|
30/1 - HEX SOCKET HEAD CAP SCREW
BSD-1609201086.A34
1609201086
|
-
|
|
|
|
30/2 - PLAIN WASHER DIN 126-9-A2
BSD-2918660004.A59
2918660004
|
£1.75
|
£2.10
|
|
|
30/3 - PLANING KNIFE
BSD-1609200978.A3
1609200978
|
-
|
|
|
|
30/4 - RECEIVER RAIL
BSD-1609201129.A32
1609201129
|
-
|
|
|
|
31 - NEEDLE BEARING
BSD-1609209006.A27
1609209006
|
-
|
|
|
|
32 - SEAL RING
BSD-1609202009.A32
1609202009
|
-
|
|
|
|
33 - CLAMPING PLATE
BSD-1609200039.A25
1609200039
|
-
|
|
|
|
34 - GROOVE BALL BEARING 6 001 LLU C 3/3K DIN 625
BSD-1609200715.A23
1609200715
|
-
|
|
|
|
35 - PULLEY Z=31
BSD-1609200650.A7
1609200650
|
-
|
|
|
|
36 - DRIVER DISC
BSD-1609200052.A21
1609200052
|
-
|
|
|
|
37 - TOOTHED BELT Z= 60
BSD-1609201215.A5
1609201215
|
£22.76
|
£27.31
|
|
|
38 - PULLEY Z=13
BSD-1609200016.A16
1609200016
|
-
|
|
|
|
40 - SPRING WASHER DIN 137-A5-FST
BSD-2916060006.A115
2916060006
|
£1.38
|
£1.66
|
|
|
41 - PLAIN WASHER DIN 433-5.3-ST
BSD-2916011011.A207
2916011011
|
£1.75
|
£2.10
|
|
|
42 - PLAIN WASHER 5.3 DIN 7349
BSD-2916201003.A8
2916201003
|
-
|
|
|
|
43 - HEX SOCKET HEAD CAP SCREW DIN 912-M5x12-8.8
BSD-2910141154.A54
2910141154
|
£1.75
|
£2.10
|
|
|
44 - HEX SOCKET HEAD CAP SCREW M 5x16 MM
BSD-1609234023.A0
1609234023
|
-
|
|
|
|
45 - TAPPING SCREW B 3.9x32 DIN 7981
BSD-2910611082.A114
2910611082
|
£1.75
|
£2.10
|
|
|
46 - SET SCREW M 4x16 DIN 915-45H
BSD-2912081126.A17
2912081126
|
-
|
|
|
|
47 - TAPPING SCREW DIN 7981-3.9x19-C-Z-ST
BSD-2912401020.A512
2912401020
|
£2.16
|
£2.59
|
|
|
48 - TORX OVAL-HEAD SCREW 3x10
BSD-2603490017.A1301
2603490017
|
£2.27
|
£2.72
|
|
|
56 - PLUG
BSD-1609200048.A34
1609200048
|
-
|
|
|
|
57 - ADHESIVE TAPE
BSD-1609200550.A17
1609200550
|
-
|
|
|
|
650 - SCREWDRIVER SW5
BSD-1609201069.A1
1609201069
|
-
|
|
|
|
651 - WIDTH STOP
BSD-1609200054.A10
1609200054
|
-
|
|
|
|
651/1 - STOP BRACKET
BSD-1609200029.A12
1609200029
|
-
|
|
|
|
651/2 - RUBBER RING G 9x13x3 MM
BSD-1609200056.A65
1609200056
|
-
|
|
|
|
651/3 - WING SCREW M6x20 MM
BSD-1609234016.A49
1609234016
|
-
|
|
|
|
651/4 - WING NUT M6
BSD-1609233000.A164
1609233000
|
-
|
|
|
|
651/5 - ROUND-HEAD BOLT DIN 603-M6x25
BSD-2910281203.A6
2910281203
|
£2.74
|
£3.29
|
|
|
651/6 - ROUND-HEAD BOLT M6x15 DIN 603
BSD-2910281196.A295
2910281196
|
-
|
|
|
|
651/7 - PLAIN WASHER dia6.4xdia16x2 MM
BSD-1609201082.A149
1609201082
|
-
|
|
|
|
651/8 - PLAIN WASHER DIN 125-A 6.4-ST
BSD-2916011014.A7
2916011014
|
£1.84
|
£2.21
|
|
|
651/9 - WIDTH STOP
BSD-1609200054.A11
1609200054
|
-
|
|
|
|
652 - DEPTH-GAUGE
BSD-1608132006.A40
1608132006
|
£3.49
|
£4.19
|
|
|
652/1 - STOP BRACKET
BSD-1601331039.A47
1601331039
|
-
|
|
|
|
652/2 - WING SCREW M 6x16 MM
BSD-2603480003.A175
2603480003
|
£2.74
|
£3.29
|
|
|
652/3 - O-RING 4.0x1.5 MM
BSD-1610210043.A89
1610210043
|
£1.84
|
£2.21
|
|
|
652/4 - PLAIN WASHER DIN 125-A 6.4-ST
BSD-2916011014.A6
2916011014
|
£1.84
|
£2.21
|
|
|
700 - BASE
BSD-1609200980.A13
1609200980
|
-
|
|
|
|
835 - POWER SUPPLY CORD EU 4.15m 2 x 1.0mm H07 RN-F
BSD-1607000227.A358
1607000227
|
£23.86
|
£28.63
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A2497
160111A3H3
|
£2.74
|
£3.29
|
|
