2 - FIELD 220-240V
BSD-2604220663.A6
2604220663
|
£25.05
|
£30.06
|
|
|
3 - ARMATURE 230-240V
BSD-2604011322.A3
2604011322
|
£54.42
|
£65.30
|
|
|
3/9 - FAN
BSD-2606610116.A1
2606610116
|
£2.61
|
£3.13
|
|
|
4 - SWITCH
BSD-1607200158.A18
1607200158
|
£9.11
|
£10.93
|
|
|
5 - POWER SUPPLY CORD CH 230V 4.15m 2 x 1.0mm H05 RN-F
BSD-1604460403.A190
1604460403
|
£16.41
|
£19.69
|
|
|
6 - GROMMET dia6.4-dia7.2x76 MM
BSD-2600703017.A887
2600703017
|
£2.74
|
£3.29
|
|
|
12 - SUPPRESSION FILTER
BSD-2607329148.A2
2607329148
|
£7.36
|
£8.83
|
|
|
13 - GROOVE BALL BEARING 7x19x6
BSD-1610905025.A491
1610905025
|
£6.85
|
£8.22
|
|
|
14 - GROOVE BALL BEARING 8x22x7
BSD-2600905052.A208
2600905052
|
£7.72
|
£9.27
|
|
|
16 - BRUSH HOLDER
BSD-2604449026.A83
2604449026
|
£1.84
|
£2.21
|
|
|
17 - BRUSH HOLDER
BSD-2604449027.A8
2604449027
|
£1.84
|
£2.21
|
|
|
19 - SCREW 4x16
BSD-2603490022.A198
2603490022
|
£1.84
|
£2.21
|
|
|
20 - THREAD-FORMING TAP. SCREW M4x12 MM
BSD-2603410049.A58
2603410049
|
£1.84
|
£2.21
|
|
|
25 - BEARING FLANGE
BSD-2605719033.A10
2605719033
|
£27.23
|
£32.68
|
|
|
26 - ADJUSTING ECCENTRIC
BSD-2606110001.A47
2606110001
|
£3.91
|
£4.69
|
|
|
28 - PULLEY WHEEL
BSD-2600324010.A7
2600324010
|
£4.48
|
£5.37
|
|
|
29 - PULLEY WHEEL
BSD-2600324012.A4
2600324012
|
£7.36
|
£8.83
|
|
|
30 - ROTARY HANDLE
BSD-2602026120.A4
2602026120
|
£3.91
|
£4.69
|
|
|
31 - V-BELT
BSD-2604736013.A10
2604736013
|
£10.10
|
£12.12
|
|
|
32 - GEAR COVER
BSD-2605510207.A3
2605510207
|
£5.30
|
£6.36
|
|
|
33 - SCALE PLATE
BSD-2601120009.A2
2601120009
|
£11.87
|
£14.24
|
|
|
34 - CAP-HANDLE
BSD-2605500178.A1
2605500178
|
£6.52
|
£7.83
|
|
|
35 - BRUSH-COVER
BSD-2605510208.A6
2605510208
|
£7.72
|
£9.27
|
|
|
38 - SHEET METAL COVER
BSD-2601098036.A23
2601098036
|
£2.27
|
£2.72
|
|
|
39 - GUIDE BUSHING
BSD-2600324008.A41
2600324008
|
£1.84
|
£2.21
|
|
|
40 - AIR-DEFLECTOR RING
BSD-2600290009.A29
2600290009
|
£3.91
|
£4.69
|
|
|
41 - SPRING PLATE
BSD-2601290016.A62
2601290016
|
£2.27
|
£2.72
|
|
|
42 - THREAD-FORMING TAP. SCREW M 5x12 MM
BSD-2603435027.A12
2603435027
|
£1.75
|
£2.10
|
|
|
44 - SQUARE NUT M6
BSD-2603320004.A85
2603320004
|
£1.84
|
£2.21
|
|
|
45 - TORSION SPRING
BSD-2604651007.A39
2604651007
|
£1.75
|
£2.10
|
|
|
47 - RATCHET CAP
BSD-2600590006.A1252
2600590006
|
£1.84
|
£2.21
|
|
|
48 - SCREW AND WASHER ASSEMBLY
BSD-2603433000.A63
2603433000
|
£1.75
|
£2.10
|
|
|
49 - HANDLE PLATE
BSD-2605133024.A2
2605133024
|
£12.64
|
£15.17
|
|
|
53 - PLAIN WASHER DIN 125-A4.3-ST
BSD-2916011010.A63
2916011010
|
£1.84
|
£2.21
|
|
|
54 - OFFSET SCREWDRIVER
BSD-2607950045.A13
2607950045
|
£2.16
|
£2.59
|
|
|
55 - GROOVE BALL BEARING 10x26x8
BSD-2600905064.A69
2600905064
|
£11.87
|
£14.24
|
|
|
57 - CONNECTING CABLE
BSD-2604448059.A19
2604448059
|
-
|
|
|
|
58 - TORX OVAL-HEAD SCREW 4x20
BSD-2603490023.A1598
2603490023
|
£1.84
|
£2.21
|
|
|
60 - DEFLECTOR PIPE
BSD-2600409028.A2
2600409028
|
£10.61
|
£12.73
|
|
|
61 - PLUG-IN MODULE
BSD-2600508053.A5
2600508053
|
£4.48
|
£5.37
|
|
|
62 - SQUARE NUT M8
BSD-2603320003.A34
2603320003
|
£1.75
|
£2.10
|
|
|
63 - ROUND NUT M6
BSD-2603342006.A84
2603342006
|
£1.84
|
£2.21
|
|
|
70 - PLANER HEAD
BSD-2608584683.A7
2608584683
|
£68.42
|
£82.10
|
|
|
70/2 - PLANING KNIFE
BSD-2608635341.A36
2608635341
|
£16.41
|
£19.69
|
|
|
70/3 - GRIPPING WEDGE
BSD-2603111001.A13
2603111001
|
£13.78
|
£16.54
|
|
|
70/4 - SET SCREW
BSD-2603400016.A3
2603400016
|
£1.84
|
£2.21
|
|
|
70/6 - BEARING BRACKET
BSD-2605819012.A1
2605819012
|
£22.60
|
£27.12
|
|
|
70/7 - NEEDLE BEARING
BSD-2600914025.A2
2600914025
|
-
|
|
|
|
70/8 - COILED SPRING PIN DIN 7343-3.5x8 MM
BSD-2917800303.A39
2917800303
|
£1.75
|
£2.10
|
|
|
71 - PLANING KNIFE
BSD-2608635341.A37
2608635341
|
£16.41
|
£19.69
|
|
|
76 - KNIFE GUARD
BSD-2601329097.A2
2601329097
|
£2.80
|
£3.36
|
|
|
77 - TORSION SPRING
BSD-2604651016.A2
2604651016
|
£1.75
|
£2.10
|
|
|
80 - SPEED GOVERNOR 230-240V
BSD-2607233064.A2
2607233064
|
£59.53
|
£71.44
|
|
|
81 - CONTACT STRAP
BSD-2601329110.A14
2601329110
|
£1.75
|
£2.10
|
|
|
210 - REFERENCE PLATE
BSD-1601110310.A79
1601110310
|
-
|
|
|
|
801 - HOUSING
BSD-2605190917.A5
2605190917
|
£72.18
|
£86.62
|
|
|
808 - NAMEPLATE
BSD-2601116405.A0
2601116405
|
£3.91
|
£4.69
|
|
|
810 - CARBON-BRUSH SET
BSD-2607014016.A14
2607014016
|
£11.87
|
£14.24
|
|
