2 - FIELD 230-240V
BSD-2604220483.A9
2604220483
|
-
|
|
|
|
3 - ARMATURE 230-240V
BSD-2604010771.A9
2604010771
|
-
|
|
|
|
3/60 - FAN
BSD-2606610049.A514
2606610049
|
£2.27
|
£2.72
|
|
|
4 - SWITCH
BSD-2607200367.A26
2607200367
|
£7.78
|
£9.33
|
|
|
5 - POWER SUPPLY CORD I / BR 4.15m 2 x 1.0mm H05 RN-F
BSD-2604460284.A1
2604460284
|
-
|
|
|
|
6 - GROMMET dia8.3-dia10.5x81 MM
BSD-1600703033.A11
1600703033
|
£2.16
|
£2.59
|
|
|
7 - CABLE CLIP
BSD-2601035001.A257
2601035001
|
£1.84
|
£2.21
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-2601117954.A6
2601117954
|
-
|
|
|
|
13 - GROOVE BALL BEARING 7x19x6
BSD-1610905025.A585
1610905025
|
£6.85
|
£8.22
|
|
|
14 - GROOVE BALL BEARING 8x22x7
BSD-2600905052.A4
2600905052
|
£7.72
|
£9.27
|
|
|
16 - BRUSH HOLDER
BSD-2604449042.A13
2604449042
|
£1.32
|
£1.58
|
|
|
17 - BRUSH HOLDER
BSD-2604449027.A36
2604449027
|
£1.84
|
£2.21
|
|
|
18 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A104
2603410001
|
£1.84
|
£2.21
|
|
|
19 - SCREW 4x16
BSD-2603490022.A1564
2603490022
|
£1.84
|
£2.21
|
|
|
20 - MANUFACTURER'S NAMEPLATE
BSD-1601110481.A138
1601110481
|
£2.27
|
£2.72
|
|
|
25 - BEARING FLANGE
BSD-2605719003.A15
2605719003
|
-
|
|
|
|
26 - ADJUSTING ECCENTRIC
BSD-2606110001.A2
2606110001
|
£3.91
|
£4.69
|
|
|
27 - NEEDLE-ROLLER BEARING dia8x8 MM
BSD-2600917003.A709
2600917003
|
£2.94
|
£3.53
|
|
|
28 - TOOTHED BELT WHEEL Z=19
BSD-2600324009.A39
2600324009
|
£2.64
|
£3.17
|
|
|
29 - TOOTHED BELT WHEEL Z=43
BSD-2606625009.A2
2606625009
|
£3.51
|
£4.21
|
|
|
30 - ROTARY HANDLE
BSD-2602026004.A17
2602026004
|
-
|
|
|
|
31 - TOOTHED BELT 17 MM. Z=89
BSD-2609995917.A26
2609995917
|
£9.11
|
£10.93
|
|
|
32 - GEAR COVER
BSD-2605510064.A7
2605510064
|
-
|
|
|
|
33 - SCALE PLATE
BSD-2601120001.A7
2601120001
|
£5.87
|
£7.04
|
|
|
34 - CAP-HANDLE
BSD-2605500105.A28
2605500105
|
£2.27
|
£2.72
|
|
|
35 - BRUSH-COVER
BSD-2605510063.A21
2605510063
|
-
|
|
|
|
37 - BEARING BRACKET
BSD-2605819011.A37
2605819011
|
£5.01
|
£6.01
|
|
|
38 - SHEET METAL COVER
BSD-2601098036.A45
2601098036
|
£2.27
|
£2.72
|
|
|
39 - GUIDE BUSHING
BSD-2600324008.A21
2600324008
|
£1.84
|
£2.21
|
|
|
40 - AIR-DEFLECTOR RING
BSD-2600290009.A3
2600290009
|
£3.91
|
£4.69
|
|
|
41 - SPRING PLATE
BSD-2601290016.A42
2601290016
|
£2.27
|
£2.72
|
|
|
42 - THREAD-FORMING TAP. SCREW M 5x12 MM
BSD-2603435027.A28
2603435027
|
£1.75
|
£2.10
|
|
|
43 - COILED SPRING PIN DIN 7343-5x2.5
BSD-2917800053.A20
2917800053
|
£2.16
|
£2.59
|
|
|
44 - SQUARE NUT M6
BSD-2603320004.A38
2603320004
|
£1.84
|
£2.21
|
|
|
45 - TORSION SPRING
BSD-2604651007.A18
2604651007
|
£1.75
|
£2.10
|
|
|
47 - RATCHET SPRING
BSD-2601254000.A24
2601254000
|
£1.84
|
£2.21
|
|
|
48 - SCREW AND WASHER ASSEMBLY
BSD-2603433000.A47
2603433000
|
£1.75
|
£2.10
|
|
|
49 - HANDLE PLATE
BSD-2605133026.A3
2605133026
|
£8.17
|
£9.80
|
|
|
50 - COILED SPRING PIN DIN 7343-3.5x8 MM
BSD-2917800303.A16
2917800303
|
£1.75
|
£2.10
|
|
|
51 - PLAIN WASHER DIN 315-M8-GT-C
BSD-2600100041.A75
2600100041
|
£1.84
|
£2.21
|
|
|
52 - SHIM 0.2 MM
BSD-1600100632.A16
1600100632
|
£1.84
|
£2.21
|
|
|
53 - PLAIN WASHER DIN 125-A4.3-ST
BSD-2916011010.A117
2916011010
|
£1.84
|
£2.21
|
|
|
55 - GROOVE BALL BEARING 10x26x8
BSD-2600905064.A45
2600905064
|
£11.87
|
£14.24
|
|
|
57 - CONNECTING CABLE L = 288 MM
BSD-2604448062.A111
2604448062
|
£1.38
|
£1.66
|
|
|
58 - TORX OVAL-HEAD SCREW 4x20
BSD-2603490023.A756
2603490023
|
£1.84
|
£2.21
|
|
|
59 - CONNECTING CABLE L = 275 MM
BSD-2604448207.A13
2604448207
|
£1.95
|
£2.34
|
|
|
60 - DEFLECTOR PIPE
BSD-2600409022.A9
2600409022
|
-
|
|
|
|
72 - SQUARE NUT M8
BSD-2603320003.A66
2603320003
|
£1.75
|
£2.10
|
|
|
73 - ROUND NUT M6
BSD-2603342006.A50
2603342006
|
£1.84
|
£2.21
|
|
|
75 - RUBBER BUFFER
BSD-2603100053.A8
2603100053
|
£1.75
|
£2.10
|
|
|
80 - SPEED GOVERNOR 230-240V
BSD-2604321926.A24
2604321926
|
-
|
|
|
|
81 - CONTACT STRAP
BSD-2601329053.A24
2601329053
|
£1.84
|
£2.21
|
|
|
83 - REFERENCE PLATE
BSD-1601110310.A44
1601110310
|
-
|
|
|
|
86 - SET SCREW
BSD-2603400014.A49
2603400014
|
-
|
|
|
|
87 - HEX SCREW
BSD-2603450005.A43
2603450005
|
-
|
|
|
|
655 - DEPTH-GAUGE
BSD-2607001045.A22
2607001045
|
£6.61
|
£7.93
|
|
|
754 - SINGLE-HEAD ENG. WRENCH
BSD-2607950504.A27
2607950504
|
£2.64
|
£3.17
|
|
|
771/1 - GRIP-SPRING TENSIONING E
BSD-2608040039.A18
2608040039
|
£22.76
|
£27.31
|
|
|
771/10 - PLANING KNIFE
BSD-2608635341.A85
2608635341
|
£16.41
|
£19.69
|
|
|
786 - DUST BAG
BSD-2609170013.A19
2609170013
|
£28.59
|
£34.31
|
|
|
787 - CARRYING CASE
BSD-2605438119.A7
2605438119
|
-
|
|
|
|
788 - SUCTION CONNECTOR
BSD-2605702022.A8
2605702022
|
-
|
|
|
|
789 - PARALLEL-GUIDE
BSD-2607000102.A37
2607000102
|
£22.04
|
£26.45
|
|
|
795 - WIDTH STOP
BSD-2607001077.A15
2607001077
|
£34.12
|
£40.94
|
|
|
796 - KNIFE GUARD
BSD-2607001106.A30
2607001106
|
-
|
|
|
|
797 - BLADE SHARPENING DEVICE
BSD-2608133001.A22
2608133001
|
-
|
|
|
|
798 - STRAIGHTENING DEVICE
BSD-0603095000.A19
0603095000
|
-
|
|
|
|
799 - BASE
BSD-0603095002.A32
0603095002
|
-
|
|
|
|
801 - HOUSING
BSD-2605190914.A2
2605190914
|
-
|
|
|
|
808 - NAMEPLATE
BSD-160111A3H3.A1016
160111A3H3
|
£2.74
|
£3.29
|
|
|
810 - CARBON-BRUSH SET
BSD-2607014002.A1
2607014002
|
-
|
|
|
|
827 - GROOVE BALL BEARING 6x19x6
BSD-2600905037.A15
2600905037
|
-
|
|
|
|
837 - BEARING BRACKET
BSD-2605819004.A6
2605819004
|
-
|
|
|
|
870 - PLANER HEAD
BSD-2603204908.A17
2603204908
|
-
|
|
|
|
876 - KNIFE GUARD
BSD-2601329055.A24
2601329055
|
-
|
|
|
|
880 - SPEED GOVERNOR 230-240V
BSD-2604321926.A22
2604321926
|
-
|
|
|
