Bosch ---- / 3608581001 / --- Spare Parts

An exploded drawing and listing for the Bosch ---- / 3608581001 / ---

	Ex VAT	Inc VAT
1 - GEAR HOUSING BSD-3605806029.A0 3605806029	-
2 - COUPLING HALF BSD-3606445025.A1 3606445025	-
3 - HOLDING SPRING BSD-3604682003.A119 3604682003	-
4 - GEAR COVER BSD-1605500064.A4 1605500064	-
5 - RETAINING SNAP RING BSD-1600200019.A1 1600200019	-
6 - BEVEL GEAR BSD-1606333113.A4 1606333113	-
7 - CARRIER BSD-1606455040.A5 1606455040	-
8 - COMPRESSION SPRING BSD-1604625008.A8 1604625008	-
9 - SHIM 0.20 MM BSD-1200101608.A22 1200101608	-
10 - BEVEL GEAR BSD-1606333112.A0 1606333112	-
11 - COUPLING HALF BSD-1606455039.A1 1606455039	-
12 - BUSHING BSD-1600322028.A5 1600322028	-
13 - CONNECTING FLANGE BSD-1605110008.A0 1605110008	-
18 - BALL DIN 5401-3.5 MM-III-ST BSD-1903230006.A279 1903230006	£2.16	£2.59
19 - BALL DIN 5401-3 MM-III-ST BSD-1903230004.A164 1903230004	£2.16	£2.59
20 - RETAINING CLIP DIN 471-15x1-FSt BSD-2916650006.A468 2916650006	£1.75	£2.10
23 - SPRING LOCK WASHER DIN 128-A4-FST BSD-2916690003.A5 2916690003	£1.75	£2.10
24 - SOCKET HEAD CAP SCREW DIN 84-AM3x16-5.8 BSD-2910011060.A6 2910011060	-
25 - SOCKET HEAD CAP SCREW DIN 84-AM4x35-8.8 BSD-2910021136.A4 2910021136	-
27 - HEX SOCKET HEAD CAP SCREW DIN 912-M5x22-8.8 BSD-2910141163.A19 2910141163	£1.75	£2.10
