5 - FELT WASHER
BSD-2600108077.A104
2600108077
|
£1.84
|
£2.21
|
|
|
6 - CUPPED WASHER
BSD-2600500002.A119
2600500002
|
£1.75
|
£2.10
|
|
|
7 - GROOVE BALL BEARING 9x24x7
BSD-2600905039.A162
2600905039
|
£12.64
|
£15.17
|
|
|
8 - SPRING RETAINING RING DIN 472-24x1.2 MM
BSD-2916660008.A847
2916660008
|
£2.16
|
£2.59
|
|
|
9 - RECEPTACLE
BSD-2600400008.A187
2600400008
|
£1.75
|
£2.10
|
|
|
11 - STICKER
BSD-3601110061.A0
3601110061
|
-
|
|
|
|
13 - STICKER
BSD-3601110062.A4
3601110062
|
-
|
|
|
|
21 - NIBBLER-HEAD
BSD-3607030022.A0
3607030022
|
-
|
|
|
|
21/1 - GEAR HOUSING
BSD-3609201156.A0
3609201156
|
-
|
|
|
|
21/2 - PROTECTIVE CAP
BSD-3609201157.A4
3609201157
|
-
|
|
|
|
21/4 - LOWER DIE RING
BSD-3607031195.A8
3607031195
|
-
|
|
|
|
21/5 - RETAINING SNAP RING
BSD-3609201158.A0
3609201158
|
-
|
|
|
|
21/8 - GUIDE PIECE
BSD-3609201159.A4
3609201159
|
-
|
|
|
|
21/9 - HEX SOCKET HEAD CAP SCREW
BSD-3603414028.A0
3603414028
|
£1.84
|
£2.21
|
|
|
21/10 - LOWER DIE
BSD-2608639026.A4
2608639026
|
£74.58
|
£89.50
|
|
|
21/11 - HEX SOCKET HEAD CAP SCREW M5x25 DIN 912-10.9
BSD-2910151164.A37
2910151164
|
£1.75
|
£2.10
|
|
|
21/12 - ECCENTRIC SHAFT
BSD-3609201160.A0
3609201160
|
-
|
|
|
|
21/13 - NEEDLE BEARING
BSD-3609201161.A4
3609201161
|
-
|
|
|
|
21/14 - NEEDLE BEARING
BSD-3609201162.A0
3609201162
|
-
|
|
|
|
21/15 - ANG. CONTACT BALL BEARING
BSD-3609201163.A4
3609201163
|
-
|
|
|
|
21/16 - NEEDLE BEARING dia8xdia12x10 MM
BSD-1610910057.A174
1610910057
|
£2.80
|
£3.36
|
|
|
21/17 - CONNECTING ROD
BSD-3609201164.A0
3609201164
|
-
|
|
|
|
21/18 - PISTON PIN
BSD-3609201165.A4
3609201165
|
-
|
|
|
|
21/19 - PISTON
BSD-3609201166.A0
3609201166
|
-
|
|
|
|
21/20 - NIBBLING PUNCH
BSD-3607031197.A1
3607031197
|
-
|
|
|
|
21/23 - DIE
BSD-3609201167.A4
3609201167
|
-
|
|
|
|
21/24 - CYLINDRICAL GEAR Z=45
BSD-3609201168.A0
3609201168
|
-
|
|
|
|
21/27 - WEDGE
BSD-3609201169.A4
3609201169
|
-
|
|
|
|
21/28 - SPRING RETAINING RING 40x1.75 MM. DIN 472
BSD-2916660018.A6
2916660018
|
£2.61
|
£3.13
|
|
|
21/29 - SPRING RETAINING RING DIN 471-12x1-FSTM
BSD-2916650903.A74
2916650903
|
£1.75
|
£2.10
|
|
|
21/30 - SPINDLE WITH GEAR Z=12/48
BSD-3609201170.A0
3609201170
|
-
|
|
|
|
21/31 - HEX SOCKET HEAD CAP SCREW DIN 912-M5x40-8.8
BSD-2910141170.A124
2910141170
|
£2.61
|
£3.13
|
|
|
21/32 - SPRING LOCK WASHER M6
BSD-2916690005.A38
2916690005
|
-
|
|
|
|
21/33 - SPRING LOCK WASHER DIN 127-B 5
BSD-2916680006.A458
2916680006
|
-
|
|
|
|
21/34 - PLAIN WASHER DIN 433-5.3-ST
BSD-2916011011.A190
2916011011
|
£1.75
|
£2.10
|
|
|
21/35 - STRAIGHT PIN DIN 7-5H8x14
BSD-2917500119.A15
2917500119
|
£1.75
|
£2.10
|
|
|
21/38 - FLANGE
BSD-3609201171.A4
3609201171
|
-
|
|
|
|
21/806 - PARTS SET
BSD-3607031200.A4
3607031200
|
£4.48
|
£5.37
|
|
|
22 - NEEDLE-ROLLER BEARING
BSD-2610063817.A5
2610063817
|
-
|
|
|
|
23 - HEX SOCKET HEAD CAP SCREW DIN 912-M5x40-8.8
BSD-2910141170.A123
2910141170
|
£2.61
|
£3.13
|
|
|
24 - SPRING LOCK WASHER DIN 128-A5-FST
BSD-2916690004.A183
2916690004
|
£1.75
|
£2.10
|
|
|
60 - TORX OVAL-HEAD SCREW 4x25
BSD-2603490024.A90
2603490024
|
£1.84
|
£2.21
|
|
|
60 - TORX OVAL-HEAD SCREW 4x20
BSD-2603490023.A1589
2603490023
|
£1.84
|
£2.21
|
|
|
101 - MOTOR HOUSING
BSD-2605108051.A9
2605108051
|
£22.60
|
£27.12
|
|
|
102 - ARMATURE 220-230V
BSD-3604010040.A2
3604010040
|
-
|
|
|
|
102/50 - FAN
BSD-2606610050.A40
2606610050
|
-
|
|
|
|
103 - SHIM 0.3 MM
BSD-2600101023.A262
2600101023
|
£1.84
|
£2.21
|
|
|
104 - SHIM
BSD-2600150004.A370
2600150004
|
£2.27
|
£2.72
|
|
|
105 - BALL BEARING 7x22x7
BSD-1900905018.A1200
1900905018
|
£19.91
|
£23.89
|
|
|
106 - FIELD 220-230V
BSD-2604220445.A2
2604220445
|
£28.59
|
£34.31
|
|
|
107 - RECESSED-HEAD SCREW DIN 7981-ST3.5x9.5-F
BSD-2603435015.A187
2603435015
|
£2.27
|
£2.72
|
|
|
108 - ADJUSTING SLIDE
BSD-2602319005.A4
2602319005
|
£1.84
|
£2.21
|
|
|
109 - SWITCH HANDLE
BSD-2602026015.A138
2602026015
|
£1.75
|
£2.10
|
|
|
110 - COVER DISC
BSD-2601328045.A116
2601328045
|
£2.16
|
£2.59
|
|
|
111 - BRUSH HOLDER
BSD-1600A003G4.A394
1600A003G4
|
£3.72
|
£4.47
|
|
|
114 - SPIRAL SPRING
BSD-1604652013.A798
1604652013
|
£1.84
|
£2.21
|
|
|
115 - POWER SUPPLY CORD CH 2.65m 2 x 1.0mm H05 VV-F
BSD-1604460427.A62
1604460427
|
£12.04
|
£14.45
|
|
|
116 - GROMMET dia8.3-dia9.4x95 MM
BSD-2600703011.A72
2600703011
|
£2.94
|
£3.53
|
|
|
117 - CABLE CLIP
BSD-2601035001.A976
2601035001
|
£1.84
|
£2.21
|
|
|
118 - TAPPING SCREW DIN 7971-BZ3.5x13
BSD-2910211011.A45
2910211011
|
£1.84
|
£2.21
|
|
|
119 - TAPPING SCREW DIN 7971-ST2.9x9.5-F
BSD-2910211005.A92
2910211005
|
£1.84
|
£2.21
|
|
|
120 - SWITCH
BSD-2607200674.A88
2607200674
|
£16.41
|
£19.69
|
|
|
122 - SUPPRESSION FILTER
BSD-1607328034.A320
1607328034
|
£4.48
|
£5.37
|
|
|
123 - CONNECTING CABLE L=88 MM
BSD-2604448034.A398
2604448034
|
£1.75
|
£2.10
|
|
|
124 - CONNECTING CABLE L=86MM
BSD-2604448044.A115
2604448044
|
£1.75
|
£2.10
|
|
|
125 - CONNECTING CABLE L=136MM
BSD-2604448056.A4
2604448056
|
-
|
|
|
|
128 - HOUSING COVER
BSD-2605500073.A0
2605500073
|
£11.87
|
£14.24
|
|
|
129 - TORX OVAL-HEAD SCREW 4x20
BSD-2603490023.A1588
2603490023
|
£1.84
|
£2.21
|
|
|
139 - TORX OVAL-HEAD SCREW 3x10
BSD-2603490017.A1462
2603490017
|
£2.27
|
£2.72
|
|
|
650 - AUXILIARY HANDLE M10. dia32.5x105 MM
BSD-160202509T.A520
160202509T
|
£3.91
|
£4.69
|
|
|
700 - LOWER DIE
BSD-2608639026.A3
2608639026
|
£74.58
|
£89.50
|
|
|
701 - NIBBLING PUNCH
BSD-3607031197.A0
3607031197
|
-
|
|
|
|
702 - LOWER DIE RING
BSD-3607031195.A9
3607031195
|
-
|
|
|
|
812 - CARBON-BRUSH SET
BSD-1607014116.A149
1607014116
|
£11.30
|
£13.56
|
|
|
825 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A781
2603410001
|
£1.84
|
£2.21
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A1748
160111A3H3
|
£2.74
|
£3.29
|
|
