Compact cordless crosscut and mitre saw of the mobile M-class - light, precise, user-friendly
Powerful Brushless motor for powerful sawing like with a mains-powered tool
Up to 205 cuts in soft wood 80 x 80 mm per battery pack charge (LiHD 10 Ah)
Precision Cut Line (PCL): precise shadow cutting line without re-adjustment thanks to cleverly positioned LED
Large cutting capacity thanks to sliding function for wide work pieces
Turntable with fast, precise setting of common angles using stop points
Saw blade inclination from -2 to 47°, therefore also suited for undercuts
Robust die-cast aluminium design for the highest demands
Effective dust extraction via integrated dust scoop
Soft start and overload protection for long service life of motor and drive
Extendable table width extensions, also removable to put underneath extremely long work pieces
Quick-action clamp for secure fixing of the work piece from the top or front
Depth guide for easy creation of grooves
All scales and operating elements are visible from the working position and can be operated intuitively
Ergonomic handle areas for carrying with one or two hands
Many brands, one battery pack system: This product can be combined with all 18V battery packs and chargers of the CAS brands: www.cordless-alliance-systems.com

Specification:
Type of battery pack : Li-Power
Battery voltage : 18 V
Battery pack capacity : 1 x 4 Ah
Support surface : 345 x 760 mm
Maximum cutting width 90°/45° : 305 / 215 mm
Maximum cutting depth at 90°/45° : 92 / 47 mm
Cutting capacity 90°/90° : 305 x 92 mm
Cutting capacity 45°/45° : 215 x 47 mm
Turntable setting left/right : 50 / 50 °
Saw blade tilt left/right : 47 / 2 °
Saw blade : 254 x 30 mm
No-load speed : 4000 rpm
Max. cutting speed : 53 m/s
Weight without battery pack : 14.8 kg
Weight with battery pack : 15.5 kg

Includes:
Saw blade "cordless cut wood - classic", 254x30 Z48
2 Table length extensions
Length Guide
Material clamp
Tool for saw blade change
Chip Collection Bag
Li-Power battery pack (18 V/4.0Ah)
Charger ASC 55 "AIR COOLED"
