Makita MS335.4U String Trimmer Spare Parts

An exploded drawing and spare parts listing for the Makita MS335.4U String Trimmer

	Ex VAT	Inc VAT
8 - SCREW ST4X16 UR3000 MSP-DA00000012.A1 DA00000012	£1.66	£1.99
14 - SPRING UR3000 MSP-DA00000018.A3 DA00000018	£1.66	£1.99
26 - BLADE COVER UR3000 MSP-DA00000030.A1 DA00000030	£1.66	£1.99
30 - MOTOR HOUSING SET UR3000 MSP-DA00000049.A3 DA00000049	£16.72	£20.06
31 - LOCK BUTTON UR3000 MSP-DA00000035.A3 DA00000035	£1.66	£1.99
33 - CAPACITANCE UR3000 MSP-DA00000054.A1 DA00000054	£2.49	£2.99
35 - SPRING CABLE UR3000 MSP-DA00000056.A3 DA00000056	£6.63	£7.96
38 - SCREW ST3X6 UR3000 MSP-DA00000059.A1 DA00000059	£1.66	£1.99
A03 - SHOULDER BELT UR3000 MSP-DA00000037.A1 DA00000037	£2.86	£3.43

Attribute Name	Value
Brand	Makita
