1 - PROTECTIVE COVER
MAF-201019.A1
201019
|
£40.80
|
£48.96
|
|
|
2 - PRISMATIC ROLLER, CPL.
MAF-200856.A0
200856
|
-
|
|
|
|
3 - CLICK-IN BRACKET
MAF-039803.A0
039803
|
-
|
|
|
|
4 - SETTING ROLLER, CPL.
MAF-200857.A0
200857
|
-
|
|
|
|
5 - TABLE TOP
MAF-201407.A1
201407
|
-
|
|
|
|
7 - TABLE INSERT
MAF-201411.A1
201411
|
-
|
|
|
|
9 - CARRIAGE PLATE
MAF-035240.A1
035240
|
-
|
|
|
|
10 - INTERMEDIATE PIECE
MAF-200827.A0
200827
|
-
|
|
|
|
11 - SUPPORT, CPL.
MAF-201395.A0
201395
|
-
|
|
|
|
12 - BEVEL GEAR
MAF-035310.A1
035310
|
-
|
|
|
|
13 - BEVEL WHEEL
MAF-201078.A1
201078
|
-
|
|
|
|
14 - PUSH-BUTTON
MAF-201292.A0
201292
|
-
|
|
|
|
15 - PROTECTIVE COVER
MAF-201187.A1
201187
|
-
|
|
|
|
16 - SAW GUARD COVER
MAF-201188.A1
201188
|
-
|
|
|
|
17 - COVERING HOOD
MAF-036009.A0
036009
|
-
|
|
|
|
18 - SAW GUARD FLAP
MAF-201249.A0
201249
|
-
|
|
|
|
19 - PART NAME NOT AVAILABLE
MAF-201383.A5
201383
|
-
|
|
|
|
20 - HANDWHEEL
MAF-039801.A3
039801
|
-
|
|
|
|
21 - PART NAME NOT AVAILABLE
MAF-039799.A0
039799
|
-
|
|
|
|
23 - FRONT PLATE
MAF-201550.A0
201550
|
-
|
|
|
|
24 - REAR PLATE
MAF-201549.A0
201549
|
-
|
|
|
|
25 - CRADLE, CPL.
MAF-201293.A1
201293
|
-
|
|
|
|
27 - LOCKING BAR
MAF-201863.A2
201863
|
-
|
|
|
|
28 - RIVING KNIFE/SPLITTER SUPPORT
MAF-200851.A0
200851
|
-
|
|
|
|
29 - PINION
MAF-035369.A0
035369
|
-
|
|
|
|
30 - LEVER
MAF-035676.A1
035676
|
-
|
|
|
|
31 - SIDE PLATE
MAF-201414.A1
201414
|
-
|
|
|
|
32 - WASHER
MAF-034208.A1
034208
|
-
|
|
|
|
34 - INDEX LEVER
MAF-201382.A0
201382
|
-
|
|
|
|
36 - RIVING KNIFE/SPLITTER
MAF-202251.A0
202251
|
-
|
|
|
|
37 - CONNECTING BAR
MAF-036513.A0
036513
|
-
|
|
|
|
38 - COVER PLATE
MAF-036514.A1
036514
|
-
|
|
|
|
39 - SHEET METAL ANGLE
MAF-200931.A2
200931
|
-
|
|
|
|
40 - CLAMPING METAL SHEET
MAF-200853.A0
200853
|
-
|
|
|
|
41 - FLANGE, FRONT
MAF-039440.A2
039440
|
-
|
|
|
|
43 - SPINDLE
MAF-038566.A0
038566
|
-
|
|
|
|
44 - COLUMN
MAF-035308.A0
035308
|
-
|
|
|
|
45 - SHOULDER BOLT
MAF-201165.A5
201165
|
-
|
|
|
|
46 - CLAMPING BOLT
MAF-201405.A1
201405
|
-
|
|
|
|
47 - GUIDE PIECE
MAF-201049.A7
201049
|
£8.79
|
£10.55
|
|
|
48 - TENSIONING SCREW
MAF-201419.A1
201419
|
-
|
|
|
|
49 - WASHER
MAF-201294.A0
201294
|
-
|
|
|
|
50 - SHOULDER SLEEVE
MAF-201381.A1
201381
|
-
|
|
|
|
52 - ROLLER ARBOR
MAF-035313.A1
035313
|
-
|
|
|
|
53 - INTERMEDIATE RING
MAF-035338.A1
035338
|
-
|
|
|
|
54 - HEXAGONAL NUT
MAF-005987.A1
005987
|
-
|
|
|
|
55 - PULL ROD
MAF-201291.A1
201291
|
-
|
|
|
|
57 - SPACER BUSHING
MAF-039800.A2
039800
|
-
|
|
|
|
58 - SHIM RING
MAF-061080.A0
061080
|
-
|
|
|
|
59 - SHIM RING
MAF-061141.A3
061141
|
-
|
|
|
|
60 - WASHER
MAF-061134.A6
061134
|
-
|
|
|
|
61 - WASHER
MAF-006144.A0
006144
|
£2.22
|
£2.66
|
|
|
62 - WASHER
MAF-061044.A17
061044
|
£1.73
|
£2.08
|
|
|
63 - WASHER
MAF-006102.A17
006102
|
-
|
|
|
|
64 - WASHER
MAF-006100.A1
006100
|
£2.11
|
£2.53
|
|
|
65 - WASHER
MAF-006101.A13
006101
|
£1.62
|
£1.94
|
|
|
66 - SHIM RING
MAF-061079.A1
061079
|
-
|
|
|
|
67 - SWITCH, CPL.
MAF-087771.A
087771
|
-
|
|
|
|
68 - MOTOR
MAF-087773.A
087773
|
-
|
|
|
|
69 - SCREW-TYPE CABLE CLAMP
MAF-076041.A5
076041
|
-
|
|
|
|
70 - RUBBER BUFFER
MAF-034675.A3
034675
|
-
|
|
|
|
71 - SKIMMER
MAF-035353.A0
035353
|
-
|
|
|
|
72 - STOP BUFFER
MAF-201609.A0
201609
|
-
|
|
|
|
73 - BUFFER
MAF-036841.A0
036841
|
-
|
|
|
|
74 - SKIMMER BLOCK
MAF-036515.A1
036515
|
-
|
|
|
|
75 - WING SCREW
MAF-079062.A14
079062
|
£6.76
|
£8.11
|
|
|
76 - ROUND CAP
MAF-076430.A2
076430
|
£4.47
|
£5.36
|
|
|
77 - WING SCREW
MAF-079071.A1
079071
|
-
|
|
|
|
78 - CUP SPRING
MAF-066027.A0
066027
|
£1.84
|
£2.21
|
|
|
80 - CUP SPRING
MAF-006692.A2
006692
|
-
|
|
|
|
82 - SPRING DOWEL SLEEVE
MAF-058116.A0
058116
|
-
|
|
|
|
83 - SPRING DOWEL SLEEVE
MAF-058115.A0
058115
|
-
|
|
|
|
85 - ARBOR CLAMPING RING
MAF-061087.A0
061087
|
-
|
|
|
|
86 - RETAINING RING
MAF-007102.A5
007102
|
£2.72
|
£3.27
|
|
|
87 - RETAINING RING
MAF-007159.A1
007159
|
-
|
|
|
|
88 - RETAINING RING
MAF-006192.A0
006192
|
-
|
|
|
|
89 - GROOVED BALL BEARING
MAF-062010.A5
062010
|
£15.24
|
£18.29
|
|
|
90 - SLIDING BLOCK
MAF-201280.A2
201280
|
-
|
|
|
|
91 - CABLE BINDER
MAF-076109.A0
076109
|
-
|
|
|
|
92 - PRESSURE BIT, SPRING-LOADED
MAF-005289.A4
005289
|
-
|
|
|
|
93 - TUBULAR RIVET
MAF-201018.A0
201018
|
-
|
|
|
|
94 - TCT SAW BLADE
MAF-092519.A1
092519
|
-
|
|
|
|
95 - STICKER
MAF-077308.A7
077308
|
-
|
|
|
|
96 - PART NAME NOT AVAILABLE
MAF-201427.A1
201427
|
-
|
|
|
|
97 - STICKER
MAF-202252.A0
202252
|
-
|
|
|
|
98 - NAME PLATE
MAF-201166.A15
201166
|
£8.54
|
£10.25
|
|
|
101 - PRESSURE SPRING
MAF-066096.A10
066096
|
£4.47
|
£5.36
|
|
|
102 - PRESSURE SPRING
MAF-066084.A5
066084
|
-
|
|
|
|
104 - RETRACTING SPRING
MAF-066022.A0
066022
|
-
|
|
|
|
105 - RETAINING SPRING
MAF-039833.A1
039833
|
-
|
|
|
|
106 - THREADED PIN
MAF-005272.A0
005272
|
-
|
|
|
|
107 - HEXAGON-HEAD SCREW
MAF-005632.A8
005632
|
-
|
|
|
|
108 - HEXAGON-HEAD SCREW
MAF-005645.A10
005645
|
-
|
|
|
|
109 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055091.A1
055091
|
-
|
|
|
|
110 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055079.A5
055079
|
£1.38
|
£1.66
|
|
|
111 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055188.A12
055188
|
-
|
|
|
|
112 - SELF-TAPPING OVAL-HEAD SCREW
MAF-055062.A14
055062
|
-
|
|
|
|
113 - SELF-TAPPING OVAL-HEAD SCREW
MAF-055157.A0
055157
|
-
|
|
|
|
114 - CYLINDER-HEAD SCREW
MAF-055211.A0
055211
|
-
|
|
|
|
115 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055061.A51
055061
|
£1.79
|
£2.15
|
|
|
117 - TRUSS-HEAD SCREW
MAF-057032.A2
057032
|
-
|
|
|
|
118 - OVAL-HEAD SCREW
MAF-055127.A4
055127
|
-
|
|
|
|
119 - CYLINDER-HEAD SCREW
MAF-055147.A0
055147
|
-
|
|
|
|
120 - CYLINDER-HEAD SCREW
MAF-005590.A7
005590
|
-
|
|
|
|
121 - CYLINDER-HEAD SCREW
MAF-055173.A2
055173
|
-
|
|
|
|
122 - CYLINDER-HEAD SCREW
MAF-055013.A5
055013
|
-
|
|
|
|
123 - CYLINDER-HEAD SCREW
MAF-055010.A5
055010
|
-
|
|
|
|
125 - LOCKING WASHER
MAF-006113.A20
006113
|
£2.02
|
£2.43
|
|
|
126 - LOCKING WASHER
MAF-006114.A24
006114
|
-
|
|
|
|
127 - HEXAGONAL NUT
MAF-005920.A0
005920
|
-
|
|
|
|
128 - LOCKING NUT
MAF-005982.A7
005982
|
£1.85
|
£2.22
|
|
|
130 - LOCKING NUT
MAF-005999.A8
005999
|
-
|
|
|
|
131 - HEXAGONAL NUT
MAF-005939.A13
005939
|
-
|
|
|
|
132 - LOCKING NUT
MAF-005979.A3
005979
|
£2.67
|
£3.20
|
|
|
133 - CLAMPING NUT
MAF-039445.A1
039445
|
-
|
|
|
|
135 - SKALE
MAF-039863.A2
039863
|
-
|
|
|
|
136 - SWITCH COVER
MAF-039532.A1
039532
|
-
|
|
|
|
138 - LABEL «SAW DUST TESTED»
MAF-070421.A1
070421
|
-
|
|
|
|
139 - PRECEDING SWITCH
MAF-087761.A0
087761
|
-
|
|
|
|
140 - RELAY, CPL.
MAF-076215.A2
076215
|
-
|
|
|
|
141 - ELECTRONIC BRAKE CIRCUIT
MAF-087760.A3
087760
|
-
|
|
|
|
201 - STOP PLATE
MAF-202595.A4
202595
|
-
|
|
|
|
202 - GUIDE BAR
MAF-038259.A6
038259
|
-
|
|
|
|
203 - INDEX PLATE
MAF-038262.A4
038262
|
-
|
|
|
|
204 - CLAMPING FENCE SUPPORT, CPL.
MAF-203277.A4
203277
|
-
|
|
|
|
205 - SLIDING COVER
MAF-038266.A7
038266
|
-
|
|
|
|
206 - WING SCREW
MAF-079062.A4
079062
|
£6.76
|
£8.11
|
|
|
207 - SHOULDER SCREW
MAF-200948.A6
200948
|
-
|
|
|
|
208 - GUIDE BOLT
MAF-038261.A1
038261
|
-
|
|
|
|
209 - GUIDE FENCE EXTENSION
MAF-200878.A3
200878
|
-
|
|
|
|
210 - ECCENTRIC ARBOR
MAF-200946.A5
200946
|
-
|
|
|
|
211 - PRESSURE SPRING
MAF-066051.A11
066051
|
-
|
|
|
|
212 - INDEX PIN
MAF-038264.A1
038264
|
-
|
|
|
|
213 - WASHER
MAF-006101.A24
006101
|
£1.62
|
£1.94
|
|
|
214 - MUSHROOM-SHAPED COVERING PIECE
MAF-038260.A3
038260
|
-
|
|
|
|
215 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055162.A12
055162
|
-
|
|
|
|
216 - SQUARE NUT
MAF-005953.A2
005953
|
-
|
|
|
|
217 - ARBOR CLAMPING RING
MAF-061075.A7
061075
|
-
|
|
|
|
218 - CUP SPRING
MAF-006692.A0
006692
|
-
|
|
|
|
219 - ANGLE SCALE
MAF-077534.A1
077534
|
-
|
|
|
|
220 - TRACTION ELEMENT
MAF-200947.A2
200947
|
-
|
|
|
|
221 - TENSIONING LEVER
MAF-039413.A6
039413
|
-
|
|
|
|
230 - WING SCREW
MAF-079063.A5
079063
|
-
|
|
|
|
231 - WASHER
MAF-006101.A19
006101
|
£1.62
|
£1.94
|
|
|
232 - SPACER SLEEVE
MAF-201330.A4
201330
|
-
|
|
|
|
233 - HEXAGONAL NUT
MAF-005998.A6
005998
|
-
|
|
|
|
501 - UNIVERSAL GUIDE FENCE
MAF-201611.A4
201611
|
£241.20
|
£289.44
|
|
|
503 - CHIP CONDUCTING TUBE
MAF-201344.A3
201344
|
-
|
|
|
|
505 - ALLEN KEY
MAF-093070.A18
093070
|
£13.58
|
£16.29
|
|
|
507 - PUSH STICK
MAF-034901.A10
034901
|
-
|
|
|
|
508 - PUSH BLOCK HANDLE, CPL.
MAF-201788.A5
201788
|
-
|
|
|
|
528 - EXTRACTION HOSE
MAF-093659.A0
093659
|
-
|
|
|
|
529 - BRANCH PIPE
MAF-076425.A4
076425
|
-
|
|
|
|
530 - REDUCING SOCKET
MAF-076431.A0
076431
|
-
|
|
|
|
531 - HOSE SUPPORT
MAF-201770.A0
201770
|
-
|
|
|
