1 - MOTOR CASING WITH INDUCTOR 230 V
MAF-084606.A3
084606
|
-
|
|
|
|
3 - ARMATURE, BALANCED
MAF-088203.A0
088203
|
£407.49
|
£488.99
|
|
|
4 - MAIN BODY WITH FRONT BASE PLATE, ASSEMBLED
MAF-203311.A0
203311
|
-
|
|
|
|
5 - END PLATE
MAF-202302.A0
202302
|
£316.42
|
£379.70
|
|
|
5.1 - COVERING PLATE
MAF-202288.A5
202288
|
£6.61
|
£7.93
|
|
|
5.2 - FLAT-HEAD SCREW
MAF-005399.A30
005399
|
£1.33
|
£1.60
|
|
|
6 - CENTERING SLEEVE
MAF-036054.A4
036054
|
-
|
|
|
|
7 - CONTROL MODULE
MAF-077165.A2
077165
|
£113.32
|
£135.99
|
|
|
8 - CLAMPING BAR
MAF-035152.A3
035152
|
-
|
|
|
|
9 - CAM DISK
MAF-203317.A2
203317
|
£57.20
|
£68.64
|
|
|
10 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055100.A0
055100
|
-
|
|
|
|
12 - SHOULDER SCREW
MAF-036853.A1
036853
|
£9.31
|
£11.17
|
|
|
13 - CYLINDRICAL PIN
MAF-058125.A7
058125
|
£3.00
|
£3.60
|
|
|
14 - CUP SPRING
MAF-066027.A9
066027
|
£1.84
|
£2.21
|
|
|
15 - COVER
MAF-202297.A0
202297
|
-
|
|
|
|
17 - LID
MAF-036034.A9
036034
|
-
|
|
|
|
18 - GUIDE RAIL
MAF-036854.A6
036854
|
-
|
|
|
|
19 - JACKET
MAF-036861.A2
036861
|
£21.92
|
£26.31
|
|
|
20 - ADHESIVE LABEL
MAF-077651.A11
077651
|
-
|
|
|
|
21 - DRIVING WHEEL, SMALL
MAF-202287.A4
202287
|
-
|
|
|
|
22 - DRIVING WHEEL, LARGE
MAF-202286.A1
202286
|
-
|
|
|
|
23 - MOTOR COVER
MAF-204037.A2
204037
|
-
|
|
|
|
24 - FAN
MAF-035138.A8
035138
|
£13.75
|
£16.50
|
|
|
25 - AIR CONDUCTING RING
MAF-035139.A0
035139
|
-
|
|
|
|
27 - HANDLE INSERT
MAF-203860.A4
203860
|
-
|
|
|
|
28 - PAD
MAF-201872.A49
201872
|
-
|
|
|
|
29 - BOUNDARY DISK
MAF-200680.A3
200680
|
-
|
|
|
|
30 - CLAMPING DEVICE
MAF-203319.A1
203319
|
-
|
|
|
|
31 - SPACER DISK
MAF-035994.A8
035994
|
-
|
|
|
|
32 - PART NAME NOT AVAILABLE
MAF-204217.A2
204217
|
-
|
|
|
|
33 - SPACER RING
MAF-038484.A0
038484
|
-
|
|
|
|
35 - PROTECTIVE COVER
MAF-035140.A2
035140
|
£50.40
|
£60.48
|
|
|
36 - LEVER
MAF-035147.A1
035147
|
-
|
|
|
|
37 - CABLE CLAMP
MAF-029584.A66
029584
|
-
|
|
|
|
38 - KNIFE SUPPORT
MAF-091796.A0
091796
|
-
|
|
|
|
39 - CUTTER HEAD, BALANCED
MAF-203321.A1
203321
|
-
|
|
|
|
40 - THREADED PIN
MAF-005284.A51
005284
|
-
|
|
|
|
42 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055061.A71
055061
|
£1.79
|
£2.15
|
|
|
43 - SELF-TAPPING OVAL-HEAD SCREW
MAF-055062.A41
055062
|
-
|
|
|
|
45 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055091.A16
055091
|
-
|
|
|
|
46 - OVAL-HEAD SCREW
MAF-055082.A6
055082
|
£1.94
|
£2.33
|
|
|
47 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055086.A37
055086
|
-
|
|
|
|
48 - OVAL-HEAD SCREW
MAF-055101.A18
055101
|
£2.14
|
£2.57
|
|
|
49 - HANDLE
MAF-038970.A35
038970
|
£8.78
|
£10.53
|
|
|
50 - HEXAGON-HEAD SCREW
MAF-035103.A2
035103
|
£3.10
|
£3.72
|
|
|
51 - KNURLED KNOB
MAF-065029.A9
065029
|
£9.67
|
£11.61
|
|
|
52 - LOCKING NUT
MAF-005979.A35
005979
|
£2.67
|
£3.20
|
|
|
54 - HEXAGONAL NUT
MAF-005924.A32
005924
|
£1.75
|
£2.10
|
|
|
56 - CYLINDER-HEAD SCREW
MAF-005505.A19
005505
|
-
|
|
|
|
57 - SELF-TAPPING OVAL-HEAD SCREW
MAF-055124.A18
055124
|
-
|
|
|
|
58 - LOCKING WASHER
MAF-061078.A4
061078
|
-
|
|
|
|
59 - GROOVED BALL BEARING
MAF-006260.A40
006260
|
£19.06
|
£22.87
|
|
|
60 - GROOVED BALL BEARING
MAF-006268.A16
006268
|
£16.07
|
£19.28
|
|
|
61 - GROOVED BALL BEARING
MAF-006280.A13
006280
|
£14.33
|
£17.20
|
|
|
62 - GROOVED BALL BEARING
MAF-006282.A70
006282
|
£15.42
|
£18.50
|
|
|
63 - GROOVED BALL BEARING
MAF-062073.A50
062073
|
£15.00
|
£18.00
|
|
|
65 - BRUSH HOLDER
MAF-063157.A2
063157
|
-
|
|
|
|
66 - CARBON BRUSH WITH AUTOMATIC CUT-OFF
MAF-063180.A2
063180
|
£15.98
|
£19.17
|
|
|
67 - RETAINING RING
MAF-007141.A13
007141
|
£3.73
|
£4.48
|
|
|
68 - TOOTHED BELT
MAF-076488.A2
076488
|
£43.75
|
£52.50
|
|
|
69 - TACHOMETER CARRIER
MAF-038975.A37
038975
|
£21.15
|
£25.38
|
|
|
70 - BOW HANDLE
MAF-203316.A4
203316
|
-
|
|
|
|
71 - CABLE PROTECTING SLEEVE
MAF-086065.A41
086065
|
£3.63
|
£4.36
|
|
|
73 - PART NAME NOT AVAILABLE
MAF-087378.A4
087378
|
-
|
|
|
|
75 - 2-POLE SWITCH
MAF-087599.A5
087599
|
£53.30
|
£63.96
|
|
|
77 - SINGLE-END SPANNER
MAF-093258.A16
093258
|
£9.90
|
£11.88
|
|
|
78 - SEALING RING
MAF-065004.A29
065004
|
£1.72
|
£2.06
|
|
|
79 - REVERSIBLE KNIVES (1 Pair)
MAF-091895.A
091895
|
£37.49
|
£44.99
|
|
|
79/1 - REVERSIBLE KNIVES (3 pairs)
MAF-091896.A
091896
|
£100.09
|
£120.11
|
|
|
80 - WASHER
MAF-061015.A40
061015
|
-
|
|
|
|
81 - WASHER
MAF-006101.A78
006101
|
£1.62
|
£1.94
|
|
|
82 - BASE PLATE, FRONT
MAF-203341.A0
203341
|
-
|
|
|
|
83 - COUNTER-SUNK OVAL-HEAD SCREW
MAF-053020.A63
053020
|
£2.11
|
£2.53
|
|
|
84 - SPACER RING
MAF-039007.A7
039007
|
-
|
|
|
|
85 - HEXAGONAL NUT
MAF-201147.A5
201147
|
£7.80
|
£9.36
|
|
|
86 - CONNECTING CABLE
MAF-087800.A6
087800
|
-
|
|
|
|
89 - FLAT-HEAD SCREW
MAF-005399.A15
005399
|
£1.33
|
£1.60
|
|
|
91 - BRAKE LEVER, CPL.
MAF-201122.A3
201122
|
-
|
|
|
|
92 - BOWDEN CABLE, CPL.
MAF-202301.A7
202301
|
-
|
|
|
|
93 - SWITCH LEVER
MAF-204216.A3
204216
|
-
|
|
|
|
94 - CHIP EJECTOR
MAF-202290.A0
202290
|
-
|
|
|
|
95 - SPRING DOWEL SLEEVE
MAF-058144.A2
058144
|
£2.22
|
£2.67
|
|
|
96 - LOCKING LEVER
MAF-201745.A20
201745
|
£6.32
|
£7.58
|
|
|
98 - INTERMEDIATE PLATE
MAF-202289.A4
202289
|
-
|
|
|
|
99 - BRAKE DRUM
MAF-202296.A1
202296
|
-
|
|
|
|
100 - SHOULDER SCREW
MAF-055118.A35
055118
|
£2.52
|
£3.03
|
|
|
101 - STICKER
MAF-077308.A13
077308
|
-
|
|
|
|
102 - PRESSURE SPRING
MAF-066043.A70
066043
|
£3.19
|
£3.83
|
|
|
105 - RETRACTING SPRING
MAF-066112.A7
066112
|
£5.80
|
£6.96
|
|
|
106 - HEXAGONAL NUT
MAF-202403.A6
202403
|
-
|
|
|
|
107 - SHEET METAL AIR DEFLECTOR
MAF-202299.A3
202299
|
-
|
|
|
|
108 - WASHER
MAF-061028.A11
061028
|
-
|
|
|
|
110 - HEXAGON-HEAD SCREW
MAF-005697.A11
005697
|
-
|
|
|
|
112 - WASHER
MAF-006100.A50
006100
|
£2.11
|
£2.53
|
|
|
113 - HEXAGON-HEAD SCREW
MAF-005677.A11
005677
|
£1.38
|
£1.66
|
|
|
114 - NAME PLATE
MAF-201166.A31
201166
|
£8.54
|
£10.25
|
|
|
115 - SHIM RING
MAF-006169.A5
006169
|
-
|
|
|
|
116 - WASHER
MAF-061013.A42
061013
|
-
|
|
|
|
117 - SEALING RING
MAF-006591.A21
006591
|
£1.73
|
£2.08
|
|
|
118 - CLIP CONNECTOR
MAF-006172.A11
006172
|
-
|
|
|
|
119 - LOCKING SCREW WITH WASHER
MAF-055155.A6
055155
|
-
|
|
|
|
120 - CONNECTING CABLE
MAF-085133.A1
085133
|
-
|
|
|
