1 - MOTOR CASING WITH INDUCTOR 230 V
MAF-084640.A11
084640
|
£166.83
|
£200.20
|
|
|
1.1 - INDUCTOR WITH COIL
MAF-084540.A11
084540
|
£87.14
|
£104.57
|
|
|
1.2 - MOTOR CASING, EMPTY
MAF-202045.A10
202045
|
-
|
|
|
|
2 - ARMATURE, BALANCED
MAF-088150.A9
088150
|
£135.58
|
£162.69
|
|
|
3 - GUIDE-RAIL EXTENSION
MAF-203750.A1
203750
|
-
|
|
|
|
3.1 - GUIDE RAIL
MAF-203758.A5
203758
|
-
|
|
|
|
3.2 - WASHER
MAF-204573.A2
204573
|
-
|
|
|
|
3.3 - ADAPTER
MAF-202927.A4
202927
|
-
|
|
|
|
3.4 - CLAMPING DEVICE
MAF-202914.A7
202914
|
-
|
|
|
|
3.5 - CELLULAR RUBBER STRIP
MAF-204029.A16
204029
|
£40.08
|
£48.10
|
|
|
3.6 - TOOTHED BELT SEGMENT
MAF-203766.A0
203766
|
-
|
|
|
|
3.8 - FLAT-HEAD SCREW
MAF-053006.A15
053006
|
-
|
|
|
|
3.9 - SPRING DOWEL SLEEVE
MAF-058204.A7
058204
|
-
|
|
|
|
3.10 - CYLINDRICAL PIN
MAF-058200.A1
058200
|
-
|
|
|
|
3.11 - WASHER
MAF-061119.A9
061119
|
-
|
|
|
|
3.12 - SQUARE NUT
MAF-005977.A5
005977
|
-
|
|
|
|
4 - TENSIONING LEVER
MAF-203397.A25
203397
|
-
|
|
|
|
5 - GUIDE PIECE
MAF-202857.A5
202857
|
-
|
|
|
|
6 - DEPTH STOP
MAF-202912.A7
202912
|
-
|
|
|
|
7 - GEAR CASING
MAF-203765.A5
203765
|
-
|
|
|
|
8 - BASE PLATE
MAF-204561.A2
204561
|
-
|
|
|
|
9 - GEAR CASING COVER
MAF-202851.A3
202851
|
-
|
|
|
|
10 - GUIDE RAIL
MAF-202907.A5
202907
|
-
|
|
|
|
11 - INSERT
MAF-203358.A3
203358
|
-
|
|
|
|
12 - AIR CONDUCTING RING
MAF-203756.A7
203756
|
-
|
|
|
|
13 - FAN
MAF-200015.A19
200015
|
£7.85
|
£9.42
|
|
|
14 - MOTOR COVER
MAF-039220.A1
039220
|
-
|
|
|
|
15 - CAP
MAF-202345.A2
202345
|
£5.74
|
£6.89
|
|
|
16 - LOCKING BOLT
MAF-202436.A2
202436
|
-
|
|
|
|
17 - TERMINAL BOX
MAF-202902.A4
202902
|
-
|
|
|
|
18 - DUST EXTRACTION SHOE
MAF-204560.A2
204560
|
-
|
|
|
|
19 - GUIDE PIECE
MAF-202916.A2
202916
|
-
|
|
|
|
20 - PROTECTIVE COVER
MAF-203764.A7
203764
|
-
|
|
|
|
21 - PLUNGE LEVER HANDLE
MAF-202344.A8
202344
|
£5.94
|
£7.13
|
|
|
22 - CLAMPING DEVICE
MAF-202914.A8
202914
|
-
|
|
|
|
23 - CASING, LOWER PART
MAF-202905.A5
202905
|
-
|
|
|
|
24 - CASING COVER
MAF-202906.A8
202906
|
-
|
|
|
|
25 - SLIDING COVER
MAF-202922.A1
202922
|
-
|
|
|
|
26 - COVERING HOOD
MAF-202938.A1
202938
|
-
|
|
|
|
27 - GUIDE BOLT
MAF-039836.A6
039836
|
-
|
|
|
|
28 - CHIP COLLECTOR
MAF-203643.A5
203643
|
-
|
|
|
|
29 - SEALING PIECE
MAF-203749.A7
203749
|
-
|
|
|
|
30 - SPRING BOLT
MAF-202935.A6
202935
|
-
|
|
|
|
31 - BALL-SHAPED FIXTURE
MAF-203369.A7
203369
|
-
|
|
|
|
32 - ARBOR
MAF-203361.A3
203361
|
-
|
|
|
|
33 - ECCENTRIC ARBOR
MAF-203364.A6
203364
|
-
|
|
|
|
34 - FLANGE, REAR
MAF-200038.A8
200038
|
-
|
|
|
|
35 - SAW SHAFT
MAF-203649.A0
203649
|
-
|
|
|
|
36 - CYLINDRICAL PIN
MAF-058203.A4
058203
|
-
|
|
|
|
37 - CLAMPING PIECE
MAF-202926.A2
202926
|
£24.21
|
£29.05
|
|
|
38 - HEXAGON-HEAD SCREW
MAF-202923.A8
202923
|
-
|
|
|
|
39 - ECCENTRIC BUSH
MAF-203545.A5
203545
|
-
|
|
|
|
40 - GUIDE BOLT
MAF-203356.A4
203356
|
-
|
|
|
|
41 - SLIDING BLOCK
MAF-039436.A5
039436
|
-
|
|
|
|
42 - SLIDING BLOCK
MAF-202911.A5
202911
|
-
|
|
|
|
43 - COVERING PLATE
MAF-203366.A4
203366
|
-
|
|
|
|
44 - RIVING KNIFE/SPLITTER
MAF-202580.A3
202580
|
£10.26
|
£12.31
|
|
|
45 - FLANGE, FRONT
MAF-203648.A1
203648
|
-
|
|
|
|
46 - SUPPORTING LEVER
MAF-202859.A5
202859
|
-
|
|
|
|
47 - RIVING KNIFE/SPLITTER SUPPORT
MAF-202862.A1
202862
|
-
|
|
|
|
48 - CLICK LEVER
MAF-202913.A8
202913
|
-
|
|
|
|
49 - BOUNDARY DISK
MAF-202919.A0
202919
|
-
|
|
|
|
50 - ADJUSTABLE SHEET METAL
MAF-202937.A1
202937
|
-
|
|
|
|
51 - SMALL PLATE
MAF-203546.A4
203546
|
-
|
|
|
|
52 - PLUNGE LEVER
MAF-203362.A7
203362
|
-
|
|
|
|
53 - CHIP GUARD
MAF-203365.A2
203365
|
-
|
|
|
|
54 - SHEET METAL FIXING PLATE
MAF-203549.A7
203549
|
-
|
|
|
|
55 - TILTING PLATE
MAF-203762.A6
203762
|
-
|
|
|
|
56 - THREADED PIN
MAF-052011.A25
052011
|
-
|
|
|
|
57 - FLAT-HEAD SCREW
MAF-005380.A1
005380
|
-
|
|
|
|
58 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055111.A17
055111
|
-
|
|
|
|
59 - CYLINDER-HEAD SCREW
MAF-055043.A8
055043
|
-
|
|
|
|
60 - FLAT-HEAD SCREW
MAF-053016.A13
053016
|
-
|
|
|
|
61 - LOCKING SCREW WITH WASHER
MAF-055155.A20
055155
|
-
|
|
|
|
62 - CYLINDER-HEAD SCREW
MAF-005516.A2
005516
|
-
|
|
|
|
63 - CYLINDER-HEAD SCREW
MAF-005536.A23
005536
|
-
|
|
|
|
64 - CYLINDER-HEAD SCREW
MAF-055096.A39
055096
|
£2.11
|
£2.53
|
|
|
65 - CYLINDER-HEAD SCREW
MAF-055234.A21
055234
|
£1.19
|
£1.43
|
|
|
66 - SHOULDER SCREW
MAF-055186.A6
055186
|
-
|
|
|
|
67 - SHOULDER SCREW
MAF-055118.A19
055118
|
£2.41
|
£2.89
|
|
|
68 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055061.A66
055061
|
£1.71
|
£2.05
|
|
|
69 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055194.A3
055194
|
-
|
|
|
|
70 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055233.A77
055233
|
£1.71
|
£2.05
|
|
|
71 - SELF-TAPPING OVAL-HEAD SCREW
MAF-055058.A14
055058
|
-
|
|
|
|
72 - OVAL-HEAD SCREW
MAF-055093.A6
055093
|
-
|
|
|
|
73 - SELF-TAPPING SCREW
MAF-055230.A38
055230
|
-
|
|
|
|
74 - SELF-TAPPING SCREW
MAF-055232.A18
055232
|
£1.68
|
£2.02
|
|
|
75 - CYLINDER-HEAD SCREW
MAF-055229.A14
055229
|
-
|
|
|
|
76 - CYLINDER-HEAD SCREW
MAF-055242.A3
055242
|
-
|
|
|
|
77 - CYLINDER-HEAD SCREW
MAF-055228.A7
055228
|
-
|
|
|
|
78 - HEXAGONAL NUT
MAF-005900.A18
005900
|
-
|
|
|
|
79 - HEXAGONAL NUT
MAF-005913.A0
005913
|
-
|
|
|
|
80 - HEXAGONAL NUT
MAF-005915.A19
005915
|
-
|
|
|
|
81 - LOCKING NUT
MAF-005979.A31
005979
|
£2.54
|
£3.05
|
|
|
82 - SQUARE NUT
MAF-005953.A36
005953
|
-
|
|
|
|
83 - LOCKING WASHER
MAF-006183.A19
006183
|
-
|
|
|
|
84 - LOCKING WASHER
MAF-006184.A31
006184
|
£1.50
|
£1.80
|
|
|
85 - WASHER
MAF-006100.A57
006100
|
£2.01
|
£2.41
|
|
|
86 - WASHER
MAF-006101.A82
006101
|
£1.54
|
£1.85
|
|
|
87 - SHIM RING
MAF-006157.A8
006157
|
-
|
|
|
|
88 - WASHER
MAF-061013.A24
061013
|
-
|
|
|
|
89 - WASHER
MAF-061044.A36
061044
|
£1.65
|
£1.98
|
|
|
90 - LOCKING WASHER
MAF-061005.A11
061005
|
-
|
|
|
|
91 - FLAT-HEAD SCREW
MAF-053011.A0
053011
|
-
|
|
|
|
92 - RETAINING RING
MAF-006173.A11
006173
|
-
|
|
|
|
93 - RETAINING RING
MAF-061138.A19
061138
|
£2.29
|
£2.75
|
|
|
94 - RETAINING RING
MAF-007159.A16
007159
|
-
|
|
|
|
95 - GROOVED BALL BEARING
MAF-006282.A26
006282
|
£14.68
|
£17.62
|
|
|
96 - GROOVED BALL BEARING
MAF-006280.A17
006280
|
£13.65
|
£16.38
|
|
|
97 - GROOVED BALL BEARING
MAF-062065.A9
062065
|
£34.87
|
£41.84
|
|
|
98 - BRUSH HOLDER
MAF-063160.A40
063160
|
£10.07
|
£12.08
|
|
|
99 - CARBON BRUSH WITH AUTOMATIC CUT-OFF
MAF-063164.A37
063164
|
£12.41
|
£14.89
|
|
|
100 - CABLE CLAMP
MAF-029584.A84
029584
|
-
|
|
|
|
101 - SPRING DOWEL SLEEVE
MAF-005817.A6
005817
|
-
|
|
|
|
102 - GAS SPRING
MAF-006666.A7
006666
|
£33.91
|
£40.69
|
|
|
103 - PRESSURE SPRING
MAF-006657.A4
006657
|
-
|
|
|
|
104 - CUP SPRING
MAF-006664.A5
006664
|
£1.98
|
£2.38
|
|
|
105 - CLIP CONNECTOR
MAF-006172.A16
006172
|
-
|
|
|
|
106 - RETRACTING SPRING
MAF-066054.A5
066054
|
-
|
|
|
|
107 - RETRACTING SPRING
MAF-066090.A17
066090
|
-
|
|
|
|
108 - LEG SPRING
MAF-066147.A3
066147
|
-
|
|
|
|
109 - KNURLED NUT
MAF-065052.A7
065052
|
-
|
|
|
|
111 - CABLE BINDER
MAF-076492.A5
076492
|
-
|
|
|
|
113 - STICKER
MAF-078415.A2
078415
|
-
|
|
|
|
114 - STICKER
MAF-078416.A6
078416
|
-
|
|
|
|
115 - HEXAGONAL PROTECTIVE CAP
MAF-077009.A10
077009
|
-
|
|
|
|
116 - WING NUT
MAF-007996.A9
007996
|
-
|
|
|
|
117 - CONTROL MODULE
MAF-077043.A1
077043
|
-
|
|
|
|
118 - SELF-TAPPING SCREW
MAF-055240.A1
055240
|
-
|
|
|
|
119 - THREADED PIN
MAF-005285.A0
005285
|
-
|
|
|
|
120 - CABLE PROTECTING SLEEVE
MAF-086064.A41
086064
|
£3.37
|
£4.04
|
|
|
121 - SETTING WHEEL
MAF-203729.A16
203729
|
-
|
|
|
|
123 - FEDERSCHEIBE
MAF-061132.A15
061132
|
-
|
|
|
|
124 - SEALING RING
MAF-006581.A0
006581
|
-
|
|
|
|
125 - CONNECTING CABLE
MAF-203769.A2
203769
|
-
|
|
|
|
126 - CLAMPING STRIP
MAF-087626.A7
087626
|
-
|
|
|
|
127 - MAINS CABLE 4 M (13.1 FT)
MAF-087594.A5
087594
|
-
|
|
|
|
128 - MOTOR WITH SPUR GEAR
MAF-087918.A3
087918
|
£362.62
|
£435.14
|
|
|
128.1 - WOODRUFF KEY
MAF-007804.A11
007804
|
-
|
|
|
|
130 - ENERGY CHAIN
MAF-087859.A3
087859
|
-
|
|
|
|
132 - SNAP-ACTION SWITCH
MAF-087819.A6
087819
|
-
|
|
|
|
133 - SWITCHING PLATE
MAF-204569.A1
204569
|
-
|
|
|
|
134 - BOW HANDLE
MAF-200650.A5
200650
|
-
|
|
|
|
135 - BOW HANDLE
MAF-201142.A2
201142
|
-
|
|
|
|
136 - SPACER RING
MAF-201159.A9
201159
|
-
|
|
|
|
138 - TOOTHED WASHER
MAF-202917.A0
202917
|
-
|
|
|
|
139 - ROLLED SPRING
MAF-203430.A6
203430
|
-
|
|
|
|
140 - SLIDING SHOE
MAF-203425.A0
203425
|
-
|
|
|
|
141 - CONNECTING CABLE
MAF-203768.A7
203768
|
-
|
|
|
|
142 - EXTRACTION HOSE
MAF-203757.A2
203757
|
-
|
|
|
|
143 - ARBOR
MAF-203426.A2
203426
|
-
|
|
|
|
144 - TOOTHED BELT SEGMENT
MAF-202929.A1
202929
|
-
|
|
|
|
145 - 2-POLE REVERSING SWITCH
MAF-087875.A2
087875
|
-
|
|
|
|
146 - ELECTRONIC MODULE
MAF-077080.A0
077080
|
-
|
|
|
|
147 - POTENTIOMETER WITH PLUG
MAF-077059.A3
077059
|
-
|
|
|
|
148 - KNOB
MAF-065047.A0
065047
|
-
|
|
|
|
149 - CONNECTION CIRCUIT BOARD
MAF-077079.A2
077079
|
£41.46
|
£49.75
|
|
|
150 - PROTECTIVE LEDGE
MAF-007605.A8
007605
|
£10.60
|
£12.72
|
|
|
151 - STOP BUFFER
MAF-201609.A7
201609
|
-
|
|
|
|
152 - TCT SAW BLADE
MAF-092533.A5
092533
|
£42.16
|
£50.59
|
|
|
153 - TRANSFORMER
MAF-077077.A0
077077
|
-
|
|
|
|
154 - CELLULAR RUBBER STRIP
MAF-204029.A9
204029
|
£40.08
|
£48.10
|
|
|
155 - HEXAGONAL NUT
MAF-059013.A3
059013
|
-
|
|
|
|
156 - TACHOMETER CARRIER
MAF-038975.A23
038975
|
£20.14
|
£24.17
|
|
|
158 - HEXAGON-HEAD SCREW
MAF-005673.A0
005673
|
-
|
|
|
|
159 - CYLINDER-HEAD SCREW
MAF-055054.A2
055054
|
-
|
|
|
|
500 - ALLEN KEY
MAF-093034.A35
093034
|
-
|
|
|
|
501 - SLIDING AGENT
MAF-076477.A2
076477
|
-
|
|
|
