1 - MOTOR CASING WITH INDUCTOR
MAF-084502.A
084502
|
-
|
|
|
|
1.1 - INDUCTOR WITH COIL
MAF-084503.A
084503
|
-
|
|
|
|
1.2 - MOTOR CASING, EMPTY
MAF-200006.A2
200006
|
-
|
|
|
|
2 - ARMATURE, BALANCED
MAF-088116.A2
088116
|
£186.05
|
£223.26
|
|
|
4 - GEAR CASING
MAF-201438.A8
201438
|
£145.07
|
£174.08
|
|
|
5 - BASE PLATE
MAF-201432.A3
201432
|
-
|
|
|
|
6 - TILTING SUPPORT
MAF-201429.A
201429
|
-
|
|
|
|
7 - PROTECTIVE COVER
MAF-201439.A2
201439
|
-
|
|
|
|
8 - GEAR CASING COVER
MAF-200035.A10
200035
|
-
|
|
|
|
12 - HANDLE SHELLS (PAIR)
MAF-202741.A17
202741
|
-
|
|
|
|
13 - MOTOR COVER
MAF-200183.A12
200183
|
-
|
|
|
|
14 - SEGMENT FOR TILTING
MAF-200009.A7
200009
|
-
|
|
|
|
15 - PROTECTIVE COVER
MAF-200012.A2
200012
|
-
|
|
|
|
16 - COVER
MAF-200078.A10
200078
|
-
|
|
|
|
17 - AIR CONDUCTING RING
MAF-200013.A14
200013
|
-
|
|
|
|
18 - SLEEVE
MAF-200048.A16
200048
|
-
|
|
|
|
19 - FAN
MAF-200015.A30
200015
|
£8.24
|
£9.89
|
|
|
21 - LOCKING BOLT
MAF-202436.A16
202436
|
-
|
|
|
|
22 - SWITCH TRIGGER
MAF-201434.A12
201434
|
-
|
|
|
|
23 - CAP
MAF-202345.A22
202345
|
£6.02
|
£7.23
|
|
|
25 - BRAKE LEVER
MAF-202347.A33
202347
|
£6.57
|
£7.88
|
|
|
28 - SHEET METAL DEFLECTOR
MAF-200023.A6
200023
|
-
|
|
|
|
30 - LEVER JOINT
MAF-201442.A10
201442
|
£14.84
|
£17.81
|
|
|
33 - CLAMPING CLAWS
MAF-200050.A33
200050
|
£4.53
|
£5.44
|
|
|
34 - RIVING KNIFE/SPLITTER SUPPORT
MAF-201441.A11
201441
|
-
|
|
|
|
35 - RIVING KNIFE/SPLITTER
MAF-202580.A21
202580
|
£10.78
|
£12.93
|
|
|
37 - CLAMPING LEVER
MAF-201433.A18
201433
|
£8.29
|
£9.95
|
|
|
41 - GUIDE COLUMN, SHORT
MAF-202435.A12
202435
|
-
|
|
|
|
42 - GUIDE COLUMN, LONG
MAF-202434.A17
202434
|
£21.27
|
£25.52
|
|
|
43 - SAW SHAFT
MAF-200032.A5
200032
|
-
|
|
|
|
45 - PRESSURE BOLT
MAF-200034.A26
200034
|
-
|
|
|
|
46 - FLANGE, REAR
MAF-200038.A17
200038
|
-
|
|
|
|
47 - ECCENTRIC ARBOR
MAF-202433.A9
202433
|
£29.65
|
£35.58
|
|
|
52 - FLANGE, FRONT
MAF-200037.A12
200037
|
-
|
|
|
|
54 - STOP BUFFER
MAF-034209.A56
034209
|
-
|
|
|
|
55 - BRAKE LINING
MAF-202429.A34
202429
|
-
|
|
|
|
56 - RETRACTING SPRING
MAF-066090.A43
066090
|
-
|
|
|
|
57 - RETRACTING SPRING
MAF-066091.A13
066091
|
-
|
|
|
|
58 - RETRACTING SPRING
MAF-066092.A46
066092
|
£5.22
|
£6.27
|
|
|
59 - PRESSURE SPRING
MAF-066043.A116
066043
|
£3.19
|
£3.83
|
|
|
61 - PRESSURE SPRING
MAF-006657.A28
006657
|
-
|
|
|
|
62 - BRUSH HOLDER
MAF-063150.A2
063150
|
-
|
|
|
|
63 - CARBON BRUSH WITH AUTOMATIC CUT-OFF
MAF-063151.A2
063151
|
-
|
|
|
|
64 - BRAKE DRUM
MAF-200016.A1
200016
|
-
|
|
|
|
65 - SKALE
MAF-077074.A5
077074
|
-
|
|
|
|
67 - GROOVED BALL BEARING
MAF-006282.A85
006282
|
£15.42
|
£18.50
|
|
|
68 - GROOVED BALL BEARING
MAF-006288.A35
006288
|
£9.26
|
£11.11
|
|
|
69 - GROOVED BALL BEARING
MAF-062065.A14
062065
|
£36.61
|
£43.93
|
|
|
71 - WING NUT
MAF-007996.A24
007996
|
-
|
|
|
|
73 - LOCKING WASHER
MAF-061069.A51
061069
|
£1.57
|
£1.88
|
|
|
75 - WING SCREW
MAF-079070.A27
079070
|
-
|
|
|
|
79 - SELF-TAPPING SCREW
MAF-055232.A34
055232
|
£1.77
|
£2.12
|
|
|
81 - SELF-TAPPING SCREW
MAF-055230.A59
055230
|
-
|
|
|
|
83 - CYLINDER-HEAD SCREW
MAF-055096.A53
055096
|
£2.22
|
£2.66
|
|
|
84 - CYLINDER-HEAD SCREW
MAF-055055.A24
055055
|
£3.39
|
£4.07
|
|
|
85 - CYLINDER-HEAD SCREW
MAF-055234.A46
055234
|
£1.25
|
£1.50
|
|
|
89 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055061.A233
055061
|
£1.79
|
£2.15
|
|
|
91 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055233.A104
055233
|
£1.79
|
£2.15
|
|
|
92 - COUNTER-SUNK OVAL-HEAD SCREW
MAF-053020.A98
053020
|
£2.11
|
£2.53
|
|
|
94 - THREADED PIN
MAF-005284.A86
005284
|
-
|
|
|
|
95 - TRUSS-HEAD SCREW
MAF-005718.A26
005718
|
-
|
|
|
|
96 - FEDERSCHEIBE
MAF-061132.A49
061132
|
-
|
|
|
|
97 - RETAINING RING
MAF-061138.A34
061138
|
£2.41
|
£2.89
|
|
|
98 - WASHER
MAF-061013.A79
061013
|
-
|
|
|
|
99 - WASHER
MAF-006101.A137
006101
|
£1.62
|
£1.94
|
|
|
101 - SPIRAL DOWEL SLEEVE
MAF-058164.A8
058164
|
-
|
|
|
|
102 - WASHER
MAF-061167.A14
061167
|
£53.89
|
£64.67
|
|
|
103 - SEALING RING
MAF-065042.A21
065042
|
£1.72
|
£2.06
|
|
|
104 - CUP SPRING
MAF-066093.A11
066093
|
-
|
|
|
|
113 - CABLE PROTECTING SLEEVE
MAF-086064.A85
086064
|
£3.53
|
£4.24
|
|
|
115 - 2-POLE SWITCH WITH LOCK-OFF BUTTON
MAF-087828.A10
087828
|
£22.88
|
£27.45
|
|
|
117 - INTERFERENCE SUPPRESSION CAPACITOR
MAF-076973.A19
076973
|
-
|
|
|
|
118 - MAINS CABLE 4 M (13.1 FT)
MAF-087323.A72
087323
|
£41.38
|
£49.65
|
|
|
120 - CABLE CLAMP
MAF-029584.A130
029584
|
-
|
|
|
|
500 - HOSE CONNECTOR
MAF-200042.A21
200042
|
£15.71
|
£18.85
|
|
|
502 - PARALLEL GUIDE FENCE
MAF-201436.A14
201436
|
£52.71
|
£63.25
|
|
|
508 - ALLEN KEY
MAF-093034.A74
093034
|
-
|
|
|
