1 - MOTOR CASING WITH INDUCTOR 230 V
MAF-084626.A2
084626
|
-
|
|
|
|
1.1 - MOTOR CASING, EMPTY
MAF-204307.A1
204307
|
-
|
|
|
|
1.2 - INDUCTOR 230 V
MAF-084623.A3
084623
|
£165.18
|
£198.21
|
|
|
2 - ARMATURE BALANCED
MAF-088185.A6
088185
|
£282.07
|
£338.48
|
|
|
3 - BASE PLATE
MAF-204320.A4
204320
|
£194.98
|
£233.97
|
|
|
4 - FAN HOUSING
MAF-204319.A6
204319
|
£346.50
|
£415.80
|
|
|
5 - TENSIONING LEVER
MAF-203397.A1
203397
|
-
|
|
|
|
10 - CONTROL MODULE
MAF-077703.A0
077703
|
£216.57
|
£259.88
|
|
|
12 - REVOLVING DEPTH CONTROL TURRET
MAF-038967.A6
038967
|
-
|
|
|
|
13 - PARALLEL GUIDE FENCE
MAF-038980.A5
038980
|
-
|
|
|
|
15 - SLIDING BAR
MAF-038978.A6
038978
|
-
|
|
|
|
16 - FAN
MAF-201606.A7
201606
|
-
|
|
|
|
17 - AIR CONDUCTING RING
MAF-038968.A3
038968
|
-
|
|
|
|
18 - SWITCH COVER
MAF-204306.A3
204306
|
-
|
|
|
|
19 - INDICATOR
MAF-038951.A1
038951
|
-
|
|
|
|
21 - MOTOR COVER
MAF-205502.A3
205502
|
-
|
|
|
|
22 - HANDLE
MAF-038970.A16
038970
|
£8.78
|
£10.53
|
|
|
23 - PRESSURE BOLT
MAF-038952.A5
038952
|
-
|
|
|
|
24 - SETTING WHEEL
MAF-204321.A7
204321
|
-
|
|
|
|
25 - HANDLE
MAF-039101.A9
039101
|
-
|
|
|
|
26 - HANDLE TAB
MAF-038962.A6
038962
|
-
|
|
|
|
28 - KNURLED NUT
MAF-038953.A7
038953
|
-
|
|
|
|
29 - STROKE LIMITER
MAF-200730.A8
200730
|
-
|
|
|
|
30 - SETTING NUT
MAF-205628.A3
205628
|
-
|
|
|
|
30.2 - SEALING RING
MAF-065056.A1
065056
|
-
|
|
|
|
31 - INDEX BOLT
MAF-204304.A3
204304
|
£24.12
|
£28.95
|
|
|
32 - SPACER BUSHING
MAF-201603.A0
201603
|
-
|
|
|
|
33 - TACHOMETER CARRIER
MAF-038975.A9
038975
|
£21.15
|
£25.38
|
|
|
34 - KNURLED-HEAD SCREW
MAF-038977.A4
038977
|
-
|
|
|
|
35 - TRAVERSE
MAF-038976.A7
038976
|
-
|
|
|
|
36 - GUIDE BAR
MAF-039115.A3
039115
|
-
|
|
|
|
37 - COLLET NUT
MAF-201574.A1
201574
|
£36.34
|
£43.61
|
|
|
38 - STEEL BALL
MAF-062042.A7
062042
|
-
|
|
|
|
39 - CABLE CLAMP
MAF-029584.A19
029584
|
-
|
|
|
|
40 - CABLE PROTECTING SLEEVE
MAF-086064.A10
086064
|
£3.53
|
£4.24
|
|
|
41 - MAINS CABLE 4 M (13.1 FT)
MAF-087885.A1
087885
|
-
|
|
|
|
42 - 2-POLE SWITCH
MAF-087548.A3
087548
|
£86.33
|
£103.60
|
|
|
43 - DEPTH SCALE
MAF-077602.A2
077602
|
-
|
|
|
|
44 - SPEED DIAGRAM
MAF-077162.A6
077162
|
-
|
|
|
|
45 - DEPTH STOP
MAF-205626.A3
205626
|
-
|
|
|
|
46 - COLLET NUT
MAF-204324.A5
204324
|
-
|
|
|
|
47 - PRESSURE SPRING
MAF-066043.A0
066043
|
£3.19
|
£3.83
|
|
|
48 - PRESSURE SPRING
MAF-066051.A7
066051
|
-
|
|
|
|
49 - PRESSURE SPRING
MAF-066063.A0
066063
|
-
|
|
|
|
50 - LOOM OF CABLES
MAF-085181.A7
085181
|
-
|
|
|
|
51 - PRESSURE SPRING
MAF-066148.A5
066148
|
-
|
|
|
|
52 - PRESSURE SPRING
MAF-066089.A3
066089
|
-
|
|
|
|
53 - LOCKING WASHER
MAF-006184.A19
006184
|
£1.58
|
£1.89
|
|
|
54 - SEALING RING
MAF-065004.A11
065004
|
£1.72
|
£2.06
|
|
|
55 - LOCKING WASHER
MAF-006183.A13
006183
|
£2.11
|
£2.53
|
|
|
56 - GUIDE COLUMN
MAF-038972.A2
038972
|
£36.78
|
£44.13
|
|
|
57 - SLIDING SURFACE
MAF-204301.A1
204301
|
-
|
|
|
|
58 - PAD
MAF-201872.A20
201872
|
-
|
|
|
|
62 - CARBON BRUSH WITH AUTOMATIC CUT-OFF
MAF-063184.A5
063184
|
£17.58
|
£21.09
|
|
|
64 - BRUSH HOLDER
MAF-063182.A1
063182
|
-
|
|
|
|
68 - WING SCREW
MAF-079077.A1
079077
|
-
|
|
|
|
69 - WING SCREW
MAF-079080.A4
079080
|
£8.08
|
£9.70
|
|
|
71 - HEXAGON-HEAD SCREW
MAF-005699.A0
005699
|
-
|
|
|
|
72 - SHOULDER SCREW
MAF-055169.A6
055169
|
-
|
|
|
|
73 - HEXAGON-HEAD SCREW
MAF-005618.A2
005618
|
-
|
|
|
|
74 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055086.A11
055086
|
-
|
|
|
|
75 - CAP NUT
MAF-005950.A11
005950
|
-
|
|
|
|
76 - CYLINDER-HEAD SCREW
MAF-055108.A2
055108
|
£1.35
|
£1.62
|
|
|
77 - FLAT-HEAD SCREW
MAF-053006.A6
053006
|
-
|
|
|
|
78 - FLAT-HEAD SCREW
MAF-053031.A13
053031
|
£1.81
|
£2.17
|
|
|
79 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055139.A4
055139
|
-
|
|
|
|
80 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055243.A0
055243
|
-
|
|
|
|
81 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055233.A30
055233
|
£1.79
|
£2.15
|
|
|
82 - COUNTER-SUNK OVAL-HEAD SCREW
MAF-053020.A19
053020
|
£2.11
|
£2.53
|
|
|
83 - CYLINDER-HEAD SCREW
MAF-005531.A1
005531
|
£2.90
|
£3.48
|
|
|
84 - CYLINDER-HEAD SCREW
MAF-055260.A6
055260
|
-
|
|
|
|
85 - CYLINDER-HEAD SCREW
MAF-055261.A3
055261
|
-
|
|
|
|
86 - CYLINDER-HEAD SCREW
MAF-005538.A10
005538
|
-
|
|
|
|
87 - CYLINDER-HEAD SCREW
MAF-055259.A2
055259
|
£4.05
|
£4.86
|
|
|
88 - CYLINDER-HEAD SCREW
MAF-055040.A1
055040
|
-
|
|
|
|
89 - HEXAGONAL NUT
MAF-005911.A11
005911
|
-
|
|
|
|
91 - WASHER
MAF-061119.A1
061119
|
-
|
|
|
|
92 - RETAINING RING
MAF-006165.A7
006165
|
-
|
|
|
|
93 - CUP SPRING
MAF-006660.A3
006660
|
-
|
|
|
|
94 - RETAINING RING
MAF-006176.A5
006176
|
-
|
|
|
|
95 - RETAINING RING
MAF-007102.A12
007102
|
£2.72
|
£3.27
|
|
|
96 - CUP SPRING
MAF-006663.A3
006663
|
-
|
|
|
|
98 - GROOVED BALL BEARING
MAF-006258.A6
006258
|
-
|
|
|
|
99 - GROOVED BALL BEARING
MAF-062073.A18
062073
|
£15.00
|
£18.00
|
|
|
102 - TUBULAR RIVET
MAF-058150.A2
058150
|
-
|
|
|
|
105 - THREADED PIN
MAF-005283.A3
005283
|
-
|
|
|
|
109 - WASHER
MAF-006130.A13
006130
|
-
|
|
|
|
200 - PARALLEL GUIDE FENCE
MAF-204310.A0
204310
|
-
|
|
|
|
505 - CHIP COLLECTOR
MAF-204325.A1
204325
|
-
|
|
|
|
506 - ADAPTER FOR ROUTER BIT
MAF-201575.A4
201575
|
£34.64
|
£41.57
|
|
|
507 - TEMPLATE GUIDE
MAF-038971.A5
038971
|
-
|
|
|
|
509 - SINGLE-END SPANNER
MAF-093012.A0
093012
|
-
|
|
|
|
510 - COLLET
MAF-093256.A5
093256
|
£38.49
|
£46.19
|
|
|
515 - CARRYING CASE MAFELL-MAX
MAF-095043.A3
095043
|
-
|
|
|
|
515.1 - LATCH
MAF-095074.A6
095074
|
-
|
|
|
|
516 - PLASTIC TRAY FOR MAFELL-MAX
MAF-095155.A3
095155
|
-
|
|
|
