1 - MOTOR CASING WITH INDUCTOR 230 V
MAF-084626.A5
084626
|
-
|
|
|
|
1.1 - MOTOR CASING, EMPTY
MAF-204307.A5
204307
|
-
|
|
|
|
1.2 - INDUCTOR 230 V
MAF-084623.A4
084623
|
£157.31
|
£188.77
|
|
|
2 - ARMATURE BALANCED
MAF-088185.A3
088185
|
£268.63
|
£322.36
|
|
|
3 - BASE PLATE
MAF-204320.A2
204320
|
£185.69
|
£222.83
|
|
|
4 - FAN HOUSING
MAF-204319.A0
204319
|
£330.00
|
£396.00
|
|
|
5 - TENSIONING LEVER
MAF-203397.A4
203397
|
-
|
|
|
|
10 - CONTROL MODULE
MAF-077703.A3
077703
|
£206.25
|
£247.50
|
|
|
12 - REVOLVING DEPTH CONTROL TURRET
MAF-038967.A3
038967
|
-
|
|
|
|
13 - PARALLEL GUIDE FENCE
MAF-038980.A0
038980
|
-
|
|
|
|
15 - SLIDING BAR
MAF-038978.A7
038978
|
-
|
|
|
|
16 - FAN
MAF-201606.A5
201606
|
-
|
|
|
|
17 - AIR CONDUCTING RING
MAF-038968.A0
038968
|
-
|
|
|
|
18 - SWITCH COVER
MAF-204306.A6
204306
|
-
|
|
|
|
19 - INDICATOR
MAF-038951.A3
038951
|
-
|
|
|
|
21 - MOTOR COVER
MAF-205502.A0
205502
|
-
|
|
|
|
22 - HANDLE
MAF-038970.A0
038970
|
£8.36
|
£10.03
|
|
|
23 - PRESSURE BOLT
MAF-038952.A3
038952
|
-
|
|
|
|
24 - SETTING WHEEL
MAF-204321.A1
204321
|
-
|
|
|
|
25 - HANDLE
MAF-039101.A0
039101
|
-
|
|
|
|
26 - HANDLE TAB
MAF-038962.A0
038962
|
-
|
|
|
|
28 - KNURLED NUT
MAF-038953.A6
038953
|
-
|
|
|
|
29 - STROKE LIMITER
MAF-200730.A2
200730
|
-
|
|
|
|
30 - SETTING NUT
MAF-205628.A2
205628
|
-
|
|
|
|
30.2 - SEALING RING
MAF-065056.A3
065056
|
-
|
|
|
|
31 - INDEX BOLT
MAF-204304.A5
204304
|
£22.98
|
£27.57
|
|
|
32 - SPACER BUSHING
MAF-201603.A6
201603
|
-
|
|
|
|
33 - TACHOMETER CARRIER
MAF-038975.A12
038975
|
£20.14
|
£24.17
|
|
|
34 - KNURLED-HEAD SCREW
MAF-038977.A7
038977
|
-
|
|
|
|
35 - TRAVERSE
MAF-038976.A8
038976
|
-
|
|
|
|
36 - GUIDE BAR
MAF-039115.A1
039115
|
-
|
|
|
|
37 - COLLET NUT
MAF-201574.A4
201574
|
£34.61
|
£41.53
|
|
|
38 - STEEL BALL
MAF-062042.A0
062042
|
-
|
|
|
|
39 - CABLE CLAMP
MAF-029584.A38
029584
|
-
|
|
|
|
40 - CABLE PROTECTING SLEEVE
MAF-086064.A3
086064
|
£3.37
|
£4.04
|
|
|
41 - MAINS CABLE 4 M (13.1 FT)
MAF-087885.A5
087885
|
-
|
|
|
|
42 - 2-POLE SWITCH
MAF-087548.A7
087548
|
£82.22
|
£98.67
|
|
|
43 - DEPTH SCALE
MAF-077602.A7
077602
|
-
|
|
|
|
44 - SPEED DIAGRAM
MAF-077162.A4
077162
|
-
|
|
|
|
45 - DEPTH STOP
MAF-205626.A2
205626
|
-
|
|
|
|
46 - COLLET NUT
MAF-204324.A1
204324
|
-
|
|
|
|
47 - PRESSURE SPRING
MAF-066043.A40
066043
|
£3.04
|
£3.65
|
|
|
48 - PRESSURE SPRING
MAF-066051.A15
066051
|
-
|
|
|
|
49 - PRESSURE SPRING
MAF-066063.A3
066063
|
-
|
|
|
|
50 - LOOM OF CABLES
MAF-085181.A4
085181
|
-
|
|
|
|
51 - PRESSURE SPRING
MAF-066148.A0
066148
|
-
|
|
|
|
52 - PRESSURE SPRING
MAF-066089.A4
066089
|
-
|
|
|
|
53 - LOCKING WASHER
MAF-006184.A3
006184
|
£1.50
|
£1.80
|
|
|
54 - SEALING RING
MAF-065004.A12
065004
|
£1.63
|
£1.96
|
|
|
55 - LOCKING WASHER
MAF-006183.A2
006183
|
-
|
|
|
|
56 - GUIDE COLUMN
MAF-038972.A5
038972
|
£35.02
|
£42.03
|
|
|
57 - SLIDING SURFACE
MAF-204301.A4
204301
|
-
|
|
|
|
58 - PAD
MAF-201872.A1
201872
|
-
|
|
|
|
62 - CARBON BRUSH WITH AUTOMATIC CUT-OFF
MAF-063184.A7
063184
|
£16.74
|
£20.09
|
|
|
64 - BRUSH HOLDER
MAF-063182.A0
063182
|
-
|
|
|
|
68 - WING SCREW
MAF-079077.A10
079077
|
-
|
|
|
|
69 - WING SCREW
MAF-079080.A0
079080
|
£7.70
|
£9.24
|
|
|
71 - HEXAGON-HEAD SCREW
MAF-005699.A5
005699
|
-
|
|
|
|
72 - SHOULDER SCREW
MAF-055169.A8
055169
|
-
|
|
|
|
73 - HEXAGON-HEAD SCREW
MAF-005618.A0
005618
|
-
|
|
|
|
74 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055086.A10
055086
|
-
|
|
|
|
75 - CAP NUT
MAF-005950.A10
005950
|
-
|
|
|
|
76 - CYLINDER-HEAD SCREW
MAF-055108.A6
055108
|
£1.28
|
£1.54
|
|
|
77 - FLAT-HEAD SCREW
MAF-053006.A2
053006
|
-
|
|
|
|
78 - FLAT-HEAD SCREW
MAF-053031.A5
053031
|
£1.72
|
£2.07
|
|
|
79 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055139.A7
055139
|
-
|
|
|
|
80 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055243.A4
055243
|
-
|
|
|
|
81 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055233.A11
055233
|
£1.71
|
£2.05
|
|
|
82 - COUNTER-SUNK OVAL-HEAD SCREW
MAF-053020.A31
053020
|
£2.01
|
£2.41
|
|
|
83 - CYLINDER-HEAD SCREW
MAF-005531.A0
005531
|
£2.76
|
£3.31
|
|
|
84 - CYLINDER-HEAD SCREW
MAF-055260.A1
055260
|
-
|
|
|
|
85 - CYLINDER-HEAD SCREW
MAF-055261.A2
055261
|
-
|
|
|
|
86 - CYLINDER-HEAD SCREW
MAF-005538.A13
005538
|
-
|
|
|
|
87 - CYLINDER-HEAD SCREW
MAF-055259.A5
055259
|
£3.86
|
£4.63
|
|
|
88 - CYLINDER-HEAD SCREW
MAF-055040.A5
055040
|
-
|
|
|
|
89 - HEXAGONAL NUT
MAF-005911.A21
005911
|
-
|
|
|
|
91 - WASHER
MAF-061119.A4
061119
|
-
|
|
|
|
92 - RETAINING RING
MAF-006165.A9
006165
|
-
|
|
|
|
93 - CUP SPRING
MAF-006660.A1
006660
|
-
|
|
|
|
94 - V-RING
MAF-061216.A2
061216
|
-
|
|
|
|
95 - RETAINING RING
MAF-007102.A16
007102
|
£2.59
|
£3.11
|
|
|
96 - CUP SPRING
MAF-006663.A2
006663
|
-
|
|
|
|
98 - GROOVED BALL BEARING
MAF-006258.A2
006258
|
-
|
|
|
|
99 - GROOVED BALL BEARING
MAF-062073.A11
062073
|
£14.28
|
£17.14
|
|
|
102 - TUBULAR RIVET
MAF-058150.A0
058150
|
-
|
|
|
|
105 - THREADED PIN
MAF-005283.A6
005283
|
-
|
|
|
|
109 - WASHER
MAF-006130.A10
006130
|
-
|
|
|
|
200 - PARALLEL GUIDE FENCE
MAF-204310.A1
204310
|
-
|
|
|
|
505 - CHIP COLLECTOR
MAF-204325.A5
204325
|
-
|
|
|
|
506 - ADAPTER FOR ROUTER BIT
MAF-201575.A1
201575
|
£32.99
|
£39.59
|
|
|
507 - TEMPLATE GUIDE
MAF-038971.A2
038971
|
-
|
|
|
|
509 - SINGLE-END SPANNER
MAF-093012.A8
093012
|
-
|
|
|
|
510 - COLLET
MAF-093256.A0
093256
|
£36.66
|
£43.99
|
|
|
515 - CARRYING CASE MAFELL-MAX
MAF-095043.A9
095043
|
-
|
|
|
|
515.1 - LATCH
MAF-095074.A11
095074
|
-
|
|
|
|
516 - PLASTIC TRAY FOR MAFELL-MAX
MAF-095155.A4
095155
|
-
|
|
|
