1 - MOTOR CASING WITH INDUCTOR
MAF-084512.A0
084512
|
-
|
|
|
|
1.1 - INDUCTOR 230 V
MAF-084584.A2
084584
|
-
|
|
|
|
1.2 - MOTOR CASING, EMPTY
MAF-203637.A1
203637
|
-
|
|
|
|
2 - ARMATURE, BALANCED
MAF-088134.A2
088134
|
£384.68
|
£461.62
|
|
|
3 - TACHOMETER CARRIER
MAF-038975.A43
038975
|
£21.15
|
£25.38
|
|
|
4 - BRAKE LEVER, CPL., RIGHT
MAF-200637.A1
200637
|
£34.42
|
£41.30
|
|
|
5 - BRAKE LEVER, CPL., LEFT
MAF-200638.A0
200638
|
£34.42
|
£41.30
|
|
|
7 - 2-POLE SWITCH
MAF-087599.A12
087599
|
£53.30
|
£63.96
|
|
|
8 - MAINS CABLE 10 M (32.8 FT.)
MAF-087612.A47
087612
|
£76.11
|
£91.33
|
|
|
9 - CONNECTING CABLE
MAF-087807.A1
087807
|
-
|
|
|
|
10 - CONTROL MODULE
MAF-077121.A
077121
|
-
|
|
|
|
12 - GEAR CASING
MAF-202242.A0
202242
|
-
|
|
|
|
13 - BASE PLATE
MAF-202243.A1
202243
|
-
|
|
|
|
14 - FRONT PLATE
MAF-200641.A2
200641
|
£267.89
|
£321.47
|
|
|
15 - INTERMEDIATE COVER
MAF-200643.A1
200643
|
-
|
|
|
|
16 - TILTING PLATE
MAF-200653.A1
200653
|
£227.83
|
£273.40
|
|
|
17 - HANDLE SHELLS (PAIR)
MAF-202518.A10
202518
|
-
|
|
|
|
18 - SWITCH LEVER
MAF-201114.A23
201114
|
£13.89
|
£16.67
|
|
|
19 - COVER
MAF-200649.A2
200649
|
-
|
|
|
|
20 - OIL TANK
MAF-201116.A4
201116
|
£34.48
|
£41.38
|
|
|
21 - FLAP
MAF-200646.A2
200646
|
-
|
|
|
|
23 - SEGMENT FOR TILTING
MAF-201856.A3
201856
|
-
|
|
|
|
24 - AIR CONDUCTING RING
MAF-202245.A1
202245
|
-
|
|
|
|
25 - FAN
MAF-039182.A19
039182
|
£19.45
|
£23.34
|
|
|
26 - LOCKING LEVER
MAF-201745.A55
201745
|
£6.32
|
£7.58
|
|
|
27 - MOTOR COVER
MAF-204037.A13
204037
|
-
|
|
|
|
29 - STOP PLATE
MAF-200659.A0
200659
|
-
|
|
|
|
31 - GUARD PLATE
MAF-200652.A1
200652
|
-
|
|
|
|
32 - HOOK
MAF-200654.A1
200654
|
-
|
|
|
|
33 - RIVING KNIFE/SPLITTER
MAF-200648.A2
200648
|
-
|
|
|
|
35 - OIL TANK CAP
MAF-201153.A0
201153
|
-
|
|
|
|
36 - OIL TUBE
MAF-201131.A0
201131
|
-
|
|
|
|
37 - BOWDEN CABLE, CPL. (BRAKE)
MAF-200645.A1
200645
|
-
|
|
|
|
38 - OIL PUMP, CPL.
MAF-201144.A1
201144
|
£148.99
|
£178.79
|
|
|
39 - BOW HANDLE
MAF-200650.A10
200650
|
-
|
|
|
|
42 - CYLINDER-HEAD SCREW
MAF-200665.A0
200665
|
-
|
|
|
|
43 - BUSH
MAF-200636.A2
200636
|
-
|
|
|
|
44 - BUSH
MAF-200639.A0
200639
|
-
|
|
|
|
45 - DRIVING ARBOR
MAF-202247.A0
202247
|
-
|
|
|
|
46 - DRIVING COVER
MAF-200647.A0
200647
|
£27.62
|
£33.15
|
|
|
47 - HEXAGONAL NUT
MAF-202257.A2
202257
|
-
|
|
|
|
48 - ADAPTER
MAF-006929.A0
006929
|
£68.88
|
£82.65
|
|
|
49 - SHOULDER NUT
MAF-203136.A1
203136
|
-
|
|
|
|
50 - BRAKE DRUM
MAF-201138.A21
201138
|
-
|
|
|
|
51 - CLAMPING NUT
MAF-200655.A1
200655
|
-
|
|
|
|
53 - PINION
MAF-006934.A3
006934
|
£28.52
|
£34.22
|
|
|
54 - GUIDE RAIL
MAF-200651.A0
200651
|
£208.75
|
£250.50
|
|
|
56 - THREADED PIN
MAF-005296.A1
005296
|
-
|
|
|
|
57 - WOODRUFF KEY
MAF-007805.A10
007805
|
£2.72
|
£3.27
|
|
|
58 - CYLINDER-HEAD SCREW
MAF-055229.A23
055229
|
-
|
|
|
|
59 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055061.A230
055061
|
£1.79
|
£2.15
|
|
|
60 - FLAT-HEAD SCREW
MAF-055223.A12
055223
|
-
|
|
|
|
61 - CYLINDER-HEAD SCREW
MAF-055044.A16
055044
|
-
|
|
|
|
62 - CYLINDER-HEAD SCREW
MAF-055172.A22
055172
|
-
|
|
|
|
65 - CYLINDER-HEAD SCREW
MAF-005505.A24
005505
|
-
|
|
|
|
66 - CYLINDER-HEAD SCREW
MAF-005536.A31
005536
|
-
|
|
|
|
67 - CYLINDER-HEAD SCREW
MAF-055041.A34
055041
|
£1.73
|
£2.08
|
|
|
68 - CYLINDER-HEAD SCREW
MAF-055059.A15
055059
|
-
|
|
|
|
69 - RETAINING RING
MAF-006171.A16
006171
|
£2.02
|
£2.43
|
|
|
71 - SHOULDER SCREW
MAF-055118.A55
055118
|
£2.52
|
£3.03
|
|
|
72 - OVAL-HEAD SCREW
MAF-055101.A34
055101
|
£2.14
|
£2.57
|
|
|
73 - OVAL-HEAD SCREW
MAF-055114.A12
055114
|
-
|
|
|
|
74 - SELF-TAPPING OVAL-HEAD SCREW
MAF-055124.A48
055124
|
-
|
|
|
|
75 - SELF-TAPPING OVAL-HEAD SCREW
MAF-055062.A101
055062
|
-
|
|
|
|
76 - COUNTER-SUNK OVAL-HEAD SCREW
MAF-053020.A82
053020
|
£2.11
|
£2.53
|
|
|
78 - HEXAGONAL NUT
MAF-201147.A34
201147
|
£7.80
|
£9.36
|
|
|
79 - LOCKING WASHER
MAF-006113.A65
006113
|
£2.02
|
£2.43
|
|
|
80 - RETAINING RING
MAF-007141.A18
007141
|
£3.73
|
£4.48
|
|
|
81 - TRUSS-HEAD SCREW
MAF-005750.A0
005750
|
-
|
|
|
|
83 - SHIM RING
MAF-061050.A17
061050
|
£2.02
|
£2.43
|
|
|
84 - WASHER
MAF-006102.A71
006102
|
-
|
|
|
|
85 - TRUSS-HEAD SCREW
MAF-005789.A1
005789
|
-
|
|
|
|
87 - TENSIONING LEVER
MAF-039806.A17
039806
|
£7.81
|
£9.37
|
|
|
88 - WING SCREW
MAF-079070.A32
079070
|
-
|
|
|
|
89 - ARBOR, CPL.
MAF-200658.A1
200658
|
-
|
|
|
|
90 - TENSIONING SCREW, CPL.
MAF-201146.A6
201146
|
£35.68
|
£42.82
|
|
|
94 - GROOVED BALL BEARING
MAF-006260.A53
006260
|
£19.06
|
£22.87
|
|
|
95 - NEEDLE BEARING BUSH
MAF-062036.A4
062036
|
£21.67
|
£26.00
|
|
|
96 - SPRING DOWEL SLEEVE
MAF-058143.A1
058143
|
-
|
|
|
|
97 - SPRING DOWEL SLEEVE
MAF-005808.A5
005808
|
-
|
|
|
|
98 - SPRING DOWEL SLEEVE
MAF-058144.A9
058144
|
£2.22
|
£2.67
|
|
|
99 - SPIRAL DOWEL SLEEVE
MAF-058187.A3
058187
|
-
|
|
|
|
100 - CYLINDRICAL PIN
MAF-058185.A1
058185
|
-
|
|
|
|
101 - CYLINDRICAL PIN
MAF-058193.A2
058193
|
-
|
|
|
|
102 - CYLINDRICAL PIN
MAF-058005.A8
058005
|
£3.02
|
£3.62
|
|
|
103 - SEALING RING
MAF-065004.A56
065004
|
£1.72
|
£2.06
|
|
|
104 - SEALING RING
MAF-065032.A2
065032
|
-
|
|
|
|
105 - RETRACTING SPRING
MAF-066136.A6
066136
|
-
|
|
|
|
106 - CUP SPRING
MAF-006660.A28
006660
|
-
|
|
|
|
107 - PRESSURE SPRING
MAF-066043.A148
066043
|
£3.19
|
£3.83
|
|
|
108 - CUP SPRING
MAF-066016.A20
066016
|
£1.82
|
£2.19
|
|
|
109 - CUP SPRING
MAF-006670.A0
006670
|
-
|
|
|
|
110 - CYLINDRICAL PIN
MAF-058019.A5
058019
|
-
|
|
|
|
113 - BRUSH HOLDER
MAF-063148.A81
063148
|
£10.82
|
£12.98
|
|
|
114 - CARBON BRUSH WITH AUTOMATIC CUT-OFF
MAF-063147.A49
063147
|
£15.46
|
£18.55
|
|
|
115 - PAD
MAF-201872.A77
201872
|
-
|
|
|
|
116 - CLAMP
MAF-076499.A3
076499
|
-
|
|
|
|
117 - CABLE CLAMP
MAF-029584.A162
029584
|
-
|
|
|
|
118 - CABLE PROTECTING SLEEVE
MAF-086065.A70
086065
|
£3.63
|
£4.36
|
|
|
501 - COMBINATION SCREW DRIVER
MAF-093272.A6
093272
|
-
|
|
|
|
502 - PARALLEL GUIDE FENCE
MAF-202873.A1
202873
|
-
|
|
|
|
503 - SAW CHAIN 3/8
MAF-006957.A0
006957
|
-
|
|
|
