1 - MOTOR CASING WITH INDUCTOR
MAF-084586.A9
084586
|
£330.33
|
£396.40
|
|
|
1.1 - INDUCTOR 230 V
MAF-084615.A2
084615
|
£247.75
|
£297.30
|
|
|
1.2 - MOTOR CASING, EMPTY
MAF-203849.A8
203849
|
£102.66
|
£123.19
|
|
|
2 - ARMATURE 240v
MAF-088197.A0
088197
|
£365.95
|
£439.14
|
|
|
4 - CONTROL MODULE
MAF-077147.A5
077147
|
£118.98
|
£142.77
|
|
|
5 - BRAKE LEVER, CPL.
MAF-201122.A23
201122
|
£23.68
|
£28.41
|
|
|
6 - PART NAME NOT AVAILABLE
MAF-204566.A3
204566
|
-
|
|
|
|
8 - TENSIONING LEVER
MAF-039806.A16
039806
|
£7.81
|
£9.37
|
|
|
9 - CYLINDRICAL PIN
MAF-058205.A0
058205
|
-
|
|
|
|
10 - LOCKING LEVER
MAF-204607.A2
204607
|
-
|
|
|
|
11 - COVER
MAF-204198.A3
204198
|
-
|
|
|
|
12 - BASE PLATE
MAF-202707.A2
202707
|
-
|
|
|
|
13 - CASING
MAF-202702.A3
202702
|
-
|
|
|
|
14 - CASING COVER
MAF-202704.A0
202704
|
-
|
|
|
|
15 - GEAR CASING
MAF-203839.A5
203839
|
-
|
|
|
|
16 - TILTING SUPPORT, ASSEMBLED
MAF-202708.A4
202708
|
-
|
|
|
|
16.2 - VERTICAL GUIDEWAY
MAF-202189.A17
202189
|
£82.11
|
£98.53
|
|
|
17 - PROTECTIVE COVER
MAF-202706.A3
202706
|
-
|
|
|
|
18 - PART NAME NOT AVAILABLE
MAF-204579.A9
204579
|
-
|
|
|
|
19 - SEGMENT FOR TILTING, REAR
MAF-202196.A16
202196
|
-
|
|
|
|
21 - ANGLE SCALE
MAF-077091.A4
077091
|
-
|
|
|
|
22 - PART NAME NOT AVAILABLE
MAF-204564.A0
204564
|
-
|
|
|
|
23 - PART NAME NOT AVAILABLE
MAF-204217.A18
204217
|
-
|
|
|
|
24 - SWITCH LEVER
MAF-204216.A15
204216
|
-
|
|
|
|
25 - LOCKING LEVER
MAF-201745.A50
201745
|
£6.32
|
£7.58
|
|
|
26 - FAN
MAF-039182.A9
039182
|
£19.45
|
£23.34
|
|
|
27 - MOTOR COVER
MAF-203862.A2
203862
|
-
|
|
|
|
28 - HANDLE
MAF-033468.A19
033468
|
-
|
|
|
|
29 - SLIDING BLOCK
MAF-201129.A11
201129
|
-
|
|
|
|
30 - AIR CONDUCTING RING
MAF-202201.A7
202201
|
-
|
|
|
|
31 - LOCKING BOLT
MAF-202202.A22
202202
|
-
|
|
|
|
32 - HOSE CONNECTOR
MAF-202203.A13
202203
|
-
|
|
|
|
33 - LEVER
MAF-205492.A0
205492
|
-
|
|
|
|
34 - PAD
MAF-201872.A90
201872
|
-
|
|
|
|
35 - BOW HANDLE
MAF-202224.A1
202224
|
£19.48
|
£23.37
|
|
|
36 - END CAP
MAF-202229.A6
202229
|
-
|
|
|
|
37 - SETTING WHEEL
MAF-203729.A30
203729
|
-
|
|
|
|
38 - WASHER
MAF-034731.A13
034731
|
-
|
|
|
|
39 - GUARD PLATE
MAF-202711.A1
202711
|
-
|
|
|
|
40 - COVERING RING
MAF-202205.A12
202205
|
-
|
|
|
|
41 - FIXTURE
MAF-202206.A6
202206
|
-
|
|
|
|
42 - ROUE DENTÉE
MAF-202207.A7
202207
|
-
|
|
|
|
43 - INDICATOR
MAF-202208.A6
202208
|
-
|
|
|
|
44 - RIVING KNIFE/SPLITTER
MAF-202713.A1
202713
|
-
|
|
|
|
45 - DISTANCE SLEEVE
MAF-035272.A19
035272
|
-
|
|
|
|
46 - BRAKE DRUM
MAF-201138.A16
201138
|
-
|
|
|
|
47 - GUIDE PIECE
MAF-201149.A2
201149
|
-
|
|
|
|
48 - FLANGE, FRONT
MAF-202716.A2
202716
|
-
|
|
|
|
49 - FLANGE, REAR
MAF-202216.A8
202216
|
-
|
|
|
|
50 - ARBOR
MAF-202217.A3
202217
|
-
|
|
|
|
51 - SAW SHAFT
MAF-202222.A7
202222
|
£107.32
|
£128.78
|
|
|
52 - ROUE DENTÉE
MAF-204571.A1
204571
|
-
|
|
|
|
53 - SHOULDER BOLT
MAF-202227.A15
202227
|
-
|
|
|
|
54 - BOLT
MAF-202231.A7
202231
|
-
|
|
|
|
55 - GUIDE BAR
MAF-202232.A7
202232
|
£28.48
|
£34.18
|
|
|
56 - PART NAME NOT AVAILABLE
MAF-203835.A14
203835
|
-
|
|
|
|
57 - GUIDE FENCE EXTENSION
MAF-202233.A7
202233
|
-
|
|
|
|
58 - SHOULDER NUT
MAF-204210.A6
204210
|
-
|
|
|
|
59 - CABLE CLAMP
MAF-029584.A108
029584
|
-
|
|
|
|
60 - STOP BUFFER
MAF-034209.A39
034209
|
-
|
|
|
|
61 - BUFFER
MAF-037764.A6
037764
|
-
|
|
|
|
62 - HEXAGONAL NUT
MAF-201147.A26
201147
|
£7.80
|
£9.36
|
|
|
63 - SLEEVE
MAF-202225.A10
202225
|
-
|
|
|
|
64 - Guard Cable
MAF-205491.A3
205491
|
£33.10
|
£39.72
|
|
|
65 - BOWDEN CABLE, CPL. (BRAKE)
MAF-202228.A6
202228
|
£50.43
|
£60.52
|
|
|
66 - COUNTER-SUNK OVAL-HEAD SCREW
MAF-053020.A83
053020
|
£2.11
|
£2.53
|
|
|
68 - CYLINDER-HEAD SCREW
MAF-005590.A10
005590
|
-
|
|
|
|
69 - CYLINDER-HEAD SCREW
MAF-055038.A21
055038
|
£2.78
|
£3.33
|
|
|
70 - CYLINDER-HEAD SCREW
MAF-055044.A18
055044
|
-
|
|
|
|
71 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055061.A172
055061
|
£1.79
|
£2.15
|
|
|
72 - SELF-TAPPING OVAL-HEAD SCREW
MAF-055062.A86
055062
|
-
|
|
|
|
73 - SHOULDER SCREW
MAF-055063.A29
055063
|
-
|
|
|
|
74 - CYLINDER-HEAD SCREW
MAF-055059.A27
055059
|
-
|
|
|
|
75 - OVAL-HEAD SCREW
MAF-055101.A36
055101
|
£2.14
|
£2.57
|
|
|
76 - OVAL-HEAD SCREW
MAF-055258.A21
055258
|
£1.73
|
£2.08
|
|
|
78 - OVAL-HEAD SCREW
MAF-055129.A35
055129
|
-
|
|
|
|
79 - OVAL-HEAD SCREW
MAF-055068.A42
055068
|
-
|
|
|
|
80 - SHOULDER SCREW
MAF-055118.A46
055118
|
£2.52
|
£3.03
|
|
|
81 - OVAL-HEAD SCREW
MAF-055102.A8
055102
|
-
|
|
|
|
82 - SHIM RING
MAF-061152.A14
061152
|
-
|
|
|
|
83 - HEXAGON-HEAD SCREW
MAF-005683.A14
005683
|
-
|
|
|
|
84 - HEXAGON-HEAD SCREW
MAF-005697.A27
005697
|
-
|
|
|
|
85 - TRUSS-HEAD SCREW
MAF-005726.A17
005726
|
-
|
|
|
|
86 - TRUSS-HEAD SCREW
MAF-057042.A8
057042
|
-
|
|
|
|
87 - HANDLE INSERT
MAF-203860.A11
203860
|
-
|
|
|
|
88 - THREADED PIN
MAF-005256.A4
005256
|
-
|
|
|
|
89 - RIBBED PIN
MAF-005881.A5
005881
|
-
|
|
|
|
90 - CYLINDRICAL PIN
MAF-058021.A12
058021
|
-
|
|
|
|
92 - HEXAGONAL NUT
MAF-005920.A40
005920
|
-
|
|
|
|
93 - SQUARE NUT
MAF-005953.A67
005953
|
-
|
|
|
|
94 - LOCKING NUT
MAF-005970.A14
005970
|
-
|
|
|
|
95 - LOCKING NUT
MAF-005999.A28
005999
|
-
|
|
|
|
96 - CAP NUT
MAF-005934.A9
005934
|
-
|
|
|
|
97 - CAP NUT
MAF-005946.A4
005946
|
-
|
|
|
|
98 - WASHER
MAF-061013.A77
061013
|
-
|
|
|
|
99 - WASHER
MAF-006102.A102
006102
|
-
|
|
|
|
100 - LOCKING WASHER
MAF-006113.A74
006113
|
£2.02
|
£2.43
|
|
|
101 - RETAINING RING
MAF-006167.A10
006167
|
-
|
|
|
|
102 - LOCKING WASHER
MAF-006184.A51
006184
|
£1.58
|
£1.89
|
|
|
103 - WASHER
MAF-061044.A44
061044
|
£1.73
|
£2.08
|
|
|
104 - SHIM RING
MAF-061071.A10
061071
|
-
|
|
|
|
105 - RETAINING RING
MAF-061072.A6
061072
|
-
|
|
|
|
106 - LOCKING WASHER
MAF-061073.A45
061073
|
-
|
|
|
|
108 - LOCKING WASHER
MAF-061145.A3
061145
|
-
|
|
|
|
109 - LOCKING WASHER
MAF-006179.A33
006179
|
£1.61
|
£1.93
|
|
|
110 - SHIM RING
MAF-061164.A16
061164
|
-
|
|
|
|
111 - GROOVED BALL BEARING
MAF-006260.A58
006260
|
£19.06
|
£22.87
|
|
|
112 - GROOVED BALL BEARING
MAF-006280.A78
006280
|
£14.33
|
£17.20
|
|
|
113 - GROOVED BALL BEARING
MAF-006269.A26
006269
|
-
|
|
|
|
114 - GROOVED BALL BEARING
MAF-062073.A84
062073
|
£15.00
|
£18.00
|
|
|
115 - GROOVED BALL BEARING
MAF-062018.A35
062018
|
£27.36
|
£32.83
|
|
|
116 - PART NAME NOT AVAILABLE
MAF-061182.A3
061182
|
-
|
|
|
|
117 - CARBON BRUSH WITH AUTOMATIC CUT-OFF
MAF-063180.A13
063180
|
£15.98
|
£19.17
|
|
|
118 - BRUSH HOLDER
MAF-063157.A14
063157
|
-
|
|
|
|
119 - SEALING RING
MAF-006591.A37
006591
|
£1.73
|
£2.08
|
|
|
120 - RETRACTING SPRING
MAF-066094.A3
066094
|
£6.89
|
£8.27
|
|
|
121 - CUP SPRING
MAF-066132.A11
066132
|
-
|
|
|
|
122 - PRESSURE SPRING
MAF-066043.A168
066043
|
£3.19
|
£3.83
|
|
|
123 - PRESSURE SPRING
MAF-066053.A38
066053
|
£2.67
|
£3.20
|
|
|
124 - CUP SPRING
MAF-066021.A5
066021
|
-
|
|
|
|
125 - RETRACTING SPRING
MAF-066112.A22
066112
|
£5.80
|
£6.96
|
|
|
126 - TORSION SPRING
MAF-066122.A8
066122
|
-
|
|
|
|
127 - ADHESIVE LABEL
MAF-070669.A8
070669
|
-
|
|
|
|
128 - ADHESIVE LABEL
MAF-070637.A3
070637
|
-
|
|
|
|
130 - WING NUT
MAF-065023.A2
065023
|
-
|
|
|
|
131 - HANDLE
MAF-038970.A57
038970
|
£8.78
|
£10.53
|
|
|
132 - WING SCREW
MAF-079070.A22
079070
|
-
|
|
|
|
133 - NAME PLATE
MAF-201166.A51
201166
|
£8.54
|
£10.25
|
|
|
135 - CABLE PROTECTING SLEEVE
MAF-086065.A74
086065
|
£3.63
|
£4.36
|
|
|
137 - 2-POLE SWITCH
MAF-087599.A22
087599
|
£53.30
|
£63.96
|
|
|
138 - MAINS CABLE 10 M (32.8 FT.)
MAF-087612.A56
087612
|
£76.11
|
£91.33
|
|
|
139 - CONNECTING CABLE
MAF-087874.A9
087874
|
-
|
|
|
|
140 - ADHESIVE LABEL
MAF-070668.A0
070668
|
-
|
|
|
|
141 - CONNECTING CABLE
MAF-085176.A10
085176
|
£7.03
|
£8.44
|
|
|
142 - SEALING RING
MAF-006580.A4
006580
|
-
|
|
|
|
143 - TCT SAW BLADE
MAF-092536.A4
092536
|
£221.37
|
£265.64
|
|
|
505 - ALLEN KEY
MAF-093081.A23
093081
|
-
|
|
|
