1 - MOTOR CASING WITH INDUCTOR 230 V
MAF-084509.A0
084509
|
-
|
|
|
|
1.1 - INDUCTOR 230 V
MAF-084584.A1
084584
|
-
|
|
|
|
1.2 - MOTOR CASING, EMPTY
MAF-203636.A1
203636
|
£86.12
|
£103.35
|
|
|
2 - ARMATURE, BALANCED
MAF-088155.A0
088155
|
-
|
|
|
|
3 - TACHOMETER CARRIER
MAF-038975.A68
038975
|
£21.15
|
£25.38
|
|
|
4 - WING SCREW
MAF-079070.A29
079070
|
-
|
|
|
|
5 - BRAKE LEVER, CPL.
MAF-201122.A21
201122
|
£23.68
|
£28.41
|
|
|
6 - GUIDE RAIL 260 HM FOR 006968
MAF-204581.A0
204581
|
-
|
|
|
|
7 - FINE-CUT SAW CHAIN
MAF-006955.A0
006955
|
-
|
|
|
|
8 - CONTROL MODULE
MAF-077142.A3
077142
|
£190.26
|
£228.31
|
|
|
9 - ARBOR, CPL.
MAF-201145.A0
201145
|
-
|
|
|
|
10 - TENSIONING SCREW, CPL.
MAF-201146.A7
201146
|
£35.68
|
£42.82
|
|
|
12 - BASE PLATE
MAF-201101.A6
201101
|
-
|
|
|
|
13 - GEAR CASING
MAF-204185.A4
204185
|
-
|
|
|
|
14 - PART NAME NOT AVAILABLE
MAF-204186.A5
204186
|
-
|
|
|
|
15 - TILTING PLATE
MAF-201107.A5
201107
|
-
|
|
|
|
16 - INTERMEDIATE COVER, CPL.
MAF-201751.A1
201751
|
-
|
|
|
|
17 - BEARING COVER
MAF-201111.A2
201111
|
-
|
|
|
|
18 - SEGMENT FOR TILTING, FRONT
MAF-204189.A1
204189
|
-
|
|
|
|
19 - HANDLE SHELLS (PAIR)
MAF-202518.A7
202518
|
-
|
|
|
|
20 - SWITCH LEVER
MAF-201114.A34
201114
|
£13.89
|
£16.67
|
|
|
21 - COVER
MAF-201115.A2
201115
|
-
|
|
|
|
22 - OIL TANK
MAF-201116.A7
201116
|
£34.48
|
£41.38
|
|
|
23 - AIR CONDUCTING RING
MAF-201136.A1
201136
|
-
|
|
|
|
24 - FAN, UPPER
MAF-032355.A23
032355
|
£13.12
|
£15.75
|
|
|
25 - SLIDING BAR
MAF-204184.A2
204184
|
-
|
|
|
|
26 - CLAMP
MAF-201130.A3
201130
|
-
|
|
|
|
27 - MOTOR COVER
MAF-039174.A7
039174
|
-
|
|
|
|
28 - LOCKING LEVER
MAF-201745.A32
201745
|
£6.32
|
£7.58
|
|
|
29 - INTERMEDIATE RING
MAF-202119.A2
202119
|
-
|
|
|
|
30 - COVER
MAF-201128.A4
201128
|
-
|
|
|
|
31 - CHIP DEFLECTOR
MAF-201139.A3
201139
|
£11.80
|
£14.16
|
|
|
32 - GUARD FLAP
MAF-201140.A2
201140
|
-
|
|
|
|
33 - GUARD FLAP
MAF-201141.A4
201141
|
-
|
|
|
|
34 - COVERING RING
MAF-201151.A6
201151
|
-
|
|
|
|
36 - GUARD PLATE
MAF-201156.A0
201156
|
-
|
|
|
|
37 - SHEET METAL COVER
MAF-201740.A3
201740
|
-
|
|
|
|
39 - RIVING KNIFE 260 FOR 006968
MAF-204586.A2
204586
|
-
|
|
|
|
41 - HANDLE
MAF-204181.A5
204181
|
-
|
|
|
|
42 - INDICATOR PLATE
MAF-204182.A2
204182
|
-
|
|
|
|
45 - CLAMPING NUT
MAF-201127.A5
201127
|
£19.22
|
£23.07
|
|
|
46 - GEAR SHAFT
MAF-201135.A3
201135
|
-
|
|
|
|
47 - BRAKE DRUM
MAF-201138.A29
201138
|
-
|
|
|
|
48 - SPROCKET HM FOR 006968
MAF-204584.A0
204584
|
-
|
|
|
|
49 - SPACER SLEEVE
MAF-201137.A7
201137
|
-
|
|
|
|
50 - HEXAGONAL NUT
MAF-201147.A14
201147
|
£7.80
|
£9.36
|
|
|
52 - LOCKING BOLT
MAF-204183.A1
204183
|
-
|
|
|
|
53 - PART NAME NOT AVAILABLE
MAF-204187.A3
204187
|
-
|
|
|
|
54 - SPACER SLEEVE
MAF-204188.A0
204188
|
-
|
|
|
|
55 - CYLINDER-HEAD SCREW
MAF-201743.A3
201743
|
-
|
|
|
|
56 - BEVEL WHEEL
MAF-201123.A6
201123
|
-
|
|
|
|
57 - PINION
MAF-201118.A3
201118
|
-
|
|
|
|
58 - OIL TANK CAP
MAF-201153.A5
201153
|
-
|
|
|
|
59 - OIL TUBE
MAF-201131.A10
201131
|
-
|
|
|
|
62 - BOWDEN CABLE, CPL.
MAF-201748.A0
201748
|
-
|
|
|
|
63 - OIL PUMP, CPL.
MAF-201144.A8
201144
|
£148.99
|
£178.79
|
|
|
66 - BOW HANDLE
MAF-201142.A14
201142
|
-
|
|
|
|
67 - THREADED PIN
MAF-005276.A19
005276
|
£1.90
|
£2.28
|
|
|
70 - COUNTER-SUNK OVAL-HEAD SCREW
MAF-053020.A86
053020
|
£2.11
|
£2.53
|
|
|
71 - OVAL-HEAD SCREW
MAF-055068.A43
055068
|
-
|
|
|
|
72 - CYLINDER-HEAD SCREW
MAF-005505.A39
005505
|
-
|
|
|
|
73 - CYLINDER-HEAD SCREW
MAF-055038.A8
055038
|
£2.78
|
£3.33
|
|
|
74 - SELF-TAPPING OVAL-HEAD SCREW
MAF-055062.A107
055062
|
-
|
|
|
|
75 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055061.A227
055061
|
£1.79
|
£2.15
|
|
|
76 - CYLINDER-HEAD SCREW
MAF-055172.A17
055172
|
-
|
|
|
|
77 - CYLINDER-HEAD SCREW
MAF-055074.A22
055074
|
£2.23
|
£2.68
|
|
|
78 - OVAL-HEAD SCREW
MAF-055069.A35
055069
|
£2.27
|
£2.72
|
|
|
79 - CYLINDER-HEAD SCREW
MAF-005591.A3
005591
|
-
|
|
|
|
80 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055091.A29
055091
|
-
|
|
|
|
81 - OVAL-HEAD SCREW
MAF-055101.A23
055101
|
£2.14
|
£2.57
|
|
|
83 - SELF-TAPPING OVAL-HEAD SCREW
MAF-055124.A51
055124
|
-
|
|
|
|
84 - OVAL-HEAD SCREW
MAF-055143.A33
055143
|
-
|
|
|
|
85 - SHOULDER SCREW
MAF-055118.A39
055118
|
£2.52
|
£3.03
|
|
|
87 - CYLINDER-HEAD SCREW
MAF-055037.A22
055037
|
-
|
|
|
|
88 - SET SCREW
MAF-057041.A3
057041
|
-
|
|
|
|
89 - PRESSURE SPRING
MAF-066082.A6
066082
|
-
|
|
|
|
90 - CUP SPRING
MAF-066016.A32
066016
|
£1.82
|
£2.19
|
|
|
91 - RIBBED NAIL
MAF-058068.A18
058068
|
-
|
|
|
|
92 - CYLINDRICAL PIN
MAF-058184.A3
058184
|
-
|
|
|
|
93 - LOCKING NUT
MAF-005999.A39
005999
|
-
|
|
|
|
94 - WASHER
MAF-061015.A54
061015
|
-
|
|
|
|
95 - HEXAGONAL NUT
MAF-059008.A7
059008
|
-
|
|
|
|
96 - LOCKING NUT
MAF-005970.A27
005970
|
-
|
|
|
|
97 - HEXAGONAL NUT
MAF-005920.A61
005920
|
-
|
|
|
|
98 - HEXAGONAL NUT
MAF-005978.A12
005978
|
-
|
|
|
|
99 - CASTEL NUT
MAF-059010.A1
059010
|
-
|
|
|
|
100 - SHIM RING
MAF-061110.A16
061110
|
-
|
|
|
|
101 - WASHER
MAF-061038.A24
061038
|
-
|
|
|
|
102 - WASHER
MAF-006102.A96
006102
|
-
|
|
|
|
103 - LOCKING WASHER
MAF-006113.A49
006113
|
£2.02
|
£2.43
|
|
|
104 - LOCKING WASHER
MAF-006114.A42
006114
|
-
|
|
|
|
106 - LOCKING WASHER
MAF-007113.A3
007113
|
-
|
|
|
|
107 - SHIM RING
MAF-061154.A4
061154
|
-
|
|
|
|
108 - SHIM RING
MAF-061155.A0
061155
|
-
|
|
|
|
109 - FEDERSCHEIBE
MAF-061156.A0
061156
|
-
|
|
|
|
110 - FEDERSCHEIBE
MAF-061157.A3
061157
|
-
|
|
|
|
111 - WASHER
MAF-061013.A68
061013
|
-
|
|
|
|
112 - RETAINING RING
MAF-006195.A5
006195
|
-
|
|
|
|
113 - RETAINING RING
MAF-007161.A16
007161
|
-
|
|
|
|
114 - GROOVED BALL BEARING
MAF-006231.A20
006231
|
£14.33
|
£17.20
|
|
|
115 - GROOVED BALL BEARING
MAF-006260.A52
006260
|
£19.06
|
£22.87
|
|
|
116 - GROOVED BALL BEARING
MAF-006269.A20
006269
|
-
|
|
|
|
117 - GROOVED BALL BEARING
MAF-062073.A56
062073
|
£15.00
|
£18.00
|
|
|
119 - SEALING RING
MAF-065004.A69
065004
|
£1.72
|
£2.06
|
|
|
120 - SEALING RING
MAF-006591.A33
006591
|
£1.73
|
£2.08
|
|
|
121 - CUP SPRING
MAF-006675.A10
006675
|
£2.52
|
£3.03
|
|
|
122 - BRUSH HOLDER
MAF-063148.A43
063148
|
£10.82
|
£12.98
|
|
|
123 - CARBON BRUSH WITH AUTOMATIC CUT-OFF
MAF-063147.A32
063147
|
£15.46
|
£18.55
|
|
|
125 - WING NUT
MAF-065023.A26
065023
|
-
|
|
|
|
126 - PAD
MAF-201872.A92
201872
|
-
|
|
|
|
127 - CABLE CLAMP
MAF-029584.A143
029584
|
-
|
|
|
|
129 - CLAMP
MAF-076499.A4
076499
|
-
|
|
|
|
130 - CABLE PROTECTING SLEEVE
MAF-086065.A77
086065
|
£3.63
|
£4.36
|
|
|
131 - SEALING RING
MAF-065033.A3
065033
|
-
|
|
|
|
132 - PLUG
MAF-076498.A1
076498
|
-
|
|
|
|
133 - RETRACTING SPRING
MAF-066112.A23
066112
|
£5.80
|
£6.96
|
|
|
134 - TORSION SPRING, LEFT
MAF-066114.A7
066114
|
-
|
|
|
|
135 - TORSION SPRING, RIGHT
MAF-066115.A4
066115
|
-
|
|
|
|
136 - PRESSURE SPRING
MAF-066043.A131
066043
|
£3.19
|
£3.83
|
|
|
138 - ANGLE SCALE
MAF-077622.A4
077622
|
-
|
|
|
|
139 - ADHESIVE LABEL
MAF-070468.A1
070468
|
-
|
|
|
|
140 - INTERFERENCE SUPPRESSION CAPACITOR
MAF-087816.A4
087816
|
£18.01
|
£21.61
|
|
|
141 - 2-POLE SWITCH
MAF-087599.A19
087599
|
£53.30
|
£63.96
|
|
|
142 - MAINS CABLE 10 M (32.8 FT.)
MAF-087612.A35
087612
|
£76.11
|
£91.33
|
|
|
143 - CONNECTING CABLE
MAF-087808.A3
087808
|
-
|
|
|
|
501 - PARALLEL GUIDE FENCE
MAF-033030.A0
033030
|
-
|
|
|
|
502 - COMBINATION SCREW DRIVER
MAF-093272.A9
093272
|
-
|
|
|
