1 - MOTOR CASING WITH INDUCTOR 230 V
MAF-084594.A3
084594
|
-
|
|
|
|
1.1 - MOTOR CASING, EMPTY
MAF-203935.A2
203935
|
-
|
|
|
|
1.2 - INDUCTOR WITH COIL
MAF-084547.A1
084547
|
£98.81
|
£118.57
|
|
|
1.3 - SWITCH ROD
MAF-203943.A1
203943
|
-
|
|
|
|
2 - ARMATURE, BALANCED
MAF-088187.A2
088187
|
£119.28
|
£143.13
|
|
|
6 - HANDLE SHELLS (PAIR)
MAF-203938.A3
203938
|
-
|
|
|
|
7 - SWITCH LEVER
MAF-203921.A4
203921
|
-
|
|
|
|
8 - PLUNGER, CPL.
MAF-205510.A0
205510
|
£197.51
|
£237.01
|
|
|
9 - SOLE PLATE P1-GP
MAF-204350.A3
204350
|
£91.05
|
£109.26
|
|
|
9.1 - BASE PLATE
MAF-203905.A4
203905
|
£91.05
|
£109.26
|
|
|
9.2 - SLIDING BASE
MAF-205506.A3
205506
|
£33.56
|
£40.27
|
|
|
9.3 - FLAT-HEAD SCREW
MAF-005399.A21
005399
|
£1.33
|
£1.60
|
|
|
11 - CLAMPING PLATE
MAF-204871.A1
204871
|
£15.28
|
£18.33
|
|
|
12 - GEAR CASING
MAF-205507.A0
205507
|
-
|
|
|
|
15 - COUNTERWIGHT
MAF-203909.A4
203909
|
-
|
|
|
|
16 - ROCKER
MAF-203931.A4
203931
|
£57.37
|
£68.84
|
|
|
21 - ROUE DENTÉE
MAF-203904.A1
203904
|
£92.21
|
£110.65
|
|
|
22 - TAKE-UP
MAF-203907.A1
203907
|
-
|
|
|
|
32 - BUSH
MAF-203915.A1
203915
|
-
|
|
|
|
33 - BUSH
MAF-203918.A0
203918
|
-
|
|
|
|
34 - GEAR CASING COVER
MAF-203903.A4
203903
|
-
|
|
|
|
35 - LATCH
MAF-203934.A2
203934
|
-
|
|
|
|
37 - FAN
MAF-203964.A4
203964
|
-
|
|
|
|
38 - MOTOR COVER
MAF-203948.A4
203948
|
-
|
|
|
|
39 - ENGAGING LEVER
MAF-203945.A4
203945
|
-
|
|
|
|
41 - AIR CONDUCTING RING
MAF-203942.A4
203942
|
-
|
|
|
|
42 - GASKET CUP
MAF-203919.A4
203919
|
£6.39
|
£7.67
|
|
|
46 - SLIDING BAR
MAF-204877.A0
204877
|
-
|
|
|
|
48 - GUARD BOW
MAF-203929.A4
203929
|
-
|
|
|
|
49 - CENTRIFUGAL DISK
MAF-203924.A4
203924
|
-
|
|
|
|
50 - TENSIONING LEVER
MAF-203961.A0
203961
|
£11.00
|
£13.20
|
|
|
51 - CLAMPING LEVER
MAF-203916.A3
203916
|
-
|
|
|
|
52 - LIMITATION
MAF-204875.A4
204875
|
-
|
|
|
|
53 - TACHOMETER CARRIER
MAF-205518.A0
205518
|
-
|
|
|
|
57 - LEVER
MAF-205508.A0
205508
|
£22.74
|
£27.29
|
|
|
58 - PRESSURE LEVER
MAF-205509.A0
205509
|
£77.10
|
£92.52
|
|
|
58.1 - ADJUSTING SLEEVE
MAF-203965.A0
203965
|
-
|
|
|
|
58.2 - PRESSURE LEVER
MAF-205514.A2
205514
|
-
|
|
|
|
58.3 - PULLING LEVER
MAF-203974.A4
203974
|
-
|
|
|
|
58.4 - PRESS-IN BOLT
MAF-204419.A1
204419
|
-
|
|
|
|
58.5 - BOLT
MAF-204876.A3
204876
|
-
|
|
|
|
58.6 - BEARING RING
MAF-204881.A0
204881
|
-
|
|
|
|
58.7 - CYLINDRICAL PIN
MAF-058046.A12
058046
|
£2.98
|
£3.57
|
|
|
58.8 - LOCKING WASHER
MAF-061024.A2
061024
|
-
|
|
|
|
58.9 - LOCKING WASHER
MAF-061025.A21
061025
|
-
|
|
|
|
58.10 - WASHER
MAF-062044.A4
062044
|
-
|
|
|
|
60 - WASHER
MAF-204355.A1
204355
|
-
|
|
|
|
62 - ECCENTRIC ARBOR
MAF-203967.A2
203967
|
-
|
|
|
|
64 - SPRING
MAF-204334.A1
204334
|
-
|
|
|
|
65 - SPRING WIRE
MAF-203957.A4
203957
|
-
|
|
|
|
66 - SAFETY GUARD
MAF-204358.A2
204358
|
-
|
|
|
|
70 - SHAFT AXLE
MAF-204883.A0
204883
|
-
|
|
|
|
74 - ROLLER
MAF-204338.A2
204338
|
-
|
|
|
|
75 - LOCKING LEVER
MAF-203955.A1
203955
|
-
|
|
|
|
76 - COLLET NUT
MAF-204337.A4
204337
|
-
|
|
|
|
78 - GASKET
MAF-203927.A1
203927
|
-
|
|
|
|
79 - FELT
MAF-203930.A1
203930
|
-
|
|
|
|
80 - FELT GASKET
MAF-203932.A2
203932
|
-
|
|
|
|
81 - FELT GASKET
MAF-205463.A0
205463
|
-
|
|
|
|
82 - COVERING DISC
MAF-204418.A2
204418
|
-
|
|
|
|
84 - BALL BEARING
MAF-062106.A1
062106
|
-
|
|
|
|
85 - GROOVED BALL BEARING
MAF-006292.A6
006292
|
£13.09
|
£15.71
|
|
|
88 - NEEDLE BEARING
MAF-062054.A4
062054
|
£27.63
|
£33.16
|
|
|
91 - SETTING WHEEL
MAF-204340.A2
204340
|
-
|
|
|
|
92 - CARBON BRUSH
MAF-063170.A10
063170
|
£13.45
|
£16.14
|
|
|
93 - BRUSH HOLDER
MAF-063128.A16
063128
|
£2.23
|
£2.68
|
|
|
94 - SNAP-ACTION SWITCH
MAF-087839.A4
087839
|
£13.62
|
£16.35
|
|
|
95 - CONTROL MODULE
MAF-077664.A1
077664
|
£72.03
|
£86.44
|
|
|
96 - CABLE PROTECTING SLEEVE
MAF-086064.A60
086064
|
£3.53
|
£4.24
|
|
|
97 - MAINS CABLE 4 M (13.1 FT)
MAF-077017.A14
077017
|
£33.49
|
£40.19
|
|
|
100 - STICKER
MAF-170222.A4
170222
|
-
|
|
|
|
103 - CUP SPRING
MAF-066165.A0
066165
|
-
|
|
|
|
104 - CUP SPRING
MAF-006664.A6
006664
|
£2.08
|
£2.50
|
|
|
106 - PRESSURE SPRING
MAF-066169.A0
066169
|
-
|
|
|
|
107 - PRESSURE SPRING
MAF-066072.A15
066072
|
£5.22
|
£6.27
|
|
|
108 - PRESSURE SPRING
MAF-066053.A6
066053
|
£2.67
|
£3.20
|
|
|
109 - TORSION SPRING
MAF-076211.A16
076211
|
-
|
|
|
|
111 - FLAT-HEAD SCREW
MAF-053037.A3
053037
|
-
|
|
|
|
112 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055061.A130
055061
|
£1.79
|
£2.15
|
|
|
114 - SELF-TAPPING OVAL-HEAD SCREW
MAF-055058.A33
055058
|
-
|
|
|
|
116 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055233.A69
055233
|
£1.79
|
£2.15
|
|
|
117 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055086.A35
055086
|
-
|
|
|
|
118 - OVAL-HEAD SCREW
MAF-055115.A8
055115
|
-
|
|
|
|
119 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055153.A8
055153
|
-
|
|
|
|
121 - THREADED PIN
MAF-052011.A26
052011
|
-
|
|
|
|
122 - OVAL-HEAD SCREW
MAF-055143.A19
055143
|
-
|
|
|
|
123 - THREADED PIN
MAF-005274.A10
005274
|
-
|
|
|
|
127 - SHIM RING
MAF-061184.A1
061184
|
-
|
|
|
|
128 - RETAINING RING
MAF-006171.A7
006171
|
£2.02
|
£2.43
|
|
|
129 - LOCKING WASHER
MAF-061135.A12
061135
|
-
|
|
|
|
131 - SHIM RING
MAF-061050.A8
061050
|
£2.02
|
£2.43
|
|
|
132 - LOCKING WASHER
MAF-061025.A15
061025
|
-
|
|
|
|
134 - SPIRAL DOWEL SLEEVE
MAF-058186.A10
058186
|
-
|
|
|
|
140 - CYLINDRICAL PIN
MAF-058213.A1
058213
|
-
|
|
|
|
502 - HOSE CONNECTOR P1-AS
MAF-203917.A0
203917
|
£18.02
|
£21.62
|
|
|
503 - CHIP DEFLECTOR P1-SA
MAF-204353.A3
204353
|
£6.70
|
£8.04
|
|
|
504 - GLIDER P1-G
MAF-205464.A4
205464
|
£15.19
|
£18.23
|
|
|
505 - SPLINTER GUARD P1-SS
MAF-205447.A0
205447
|
£10.58
|
£12.69
|
|
|
511 - CARRYING CASE MAX, GR.I
MAF-095076.A4
095076
|
-
|
|
|
|
512 - PLASTIC TRAY FOR TK MAX
MAF-095077.A2
095077
|
-
|
|
|
|
518 - COVER SHEET
MAF-095160.A1
095160
|
-
|
|
|
