1 - MOTOR SA 14.4V
BDE-N139072
N139072
|
£122.02
|
£146.42
|
|
|
2 - BRUSH PAIR
BDE-493511-00.A54
493511-00
|
-
|
|
|
|
3 - ELECTRONIC & SWITCH GB
BDE-N165194.A0
N165194
|
£126.63
|
£151.96
|
|
|
4 - FAN
BDE-329810-00.A2
329810-00
|
£2.71
|
£3.25
|
|
|
5 - ADAPTOR
BDE-583069-00.A0
583069-00
|
£3.22
|
£3.86
|
|
|
6 - SCREW
BDE-812171.A152
812171
|
£1.42
|
£1.70
|
|
|
7 - SCREW
BDE-330045-15.A58
330045-15
|
£1.50
|
£1.80
|
|
|
8 - BUTTON LOCK-OFF
BDE-N060864.A3
N060864
|
£1.50
|
£1.80
|
|
|
10 - PINION
BDE-589147-00.A1
589147-00
|
£37.82
|
£45.38
|
|
|
11 - BLOCK
BDE-N122099.A18
N122099
|
£1.50
|
£1.80
|
|
|
12 - SPRING
BDE-N119679.A25
N119679
|
£1.50
|
£1.80
|
|
|
15 - SCREW
BDE-330019-03.A361
330019-03
|
£1.50
|
£1.80
|
|
|
16 - CLAMSHELL PAIR
BDE-N165199.A0
N165199
|
£24.39
|
£29.27
|
|
|
17 - GUARD
BDE-581269-00.A2
581269-00
|
£10.85
|
£13.02
|
|
|
20 - SCREW
BDE-324006-00.A110
324006-00
|
£1.50
|
£1.80
|
|
|
21 - CASTING
BDE-581577-00.A16
581577-00
|
£12.17
|
£14.60
|
|
|
22 - PIN
BDE-584627-00.A18
584627-00
|
£1.50
|
£1.80
|
|
|
23 - SPRING
BDE-581418-00.A2
581418-00
|
£1.50
|
£1.80
|
|
|
24 - ACTUATOR
BDE-589055-00.A2
589055-00
|
£10.85
|
£13.02
|
|
|
25 - GEARCASE COVER
BDE-N142821.A2
N142821
|
£44.14
|
£52.97
|
|
|
26 - GASKET
BDE-N444301.A16
N444301
|
£1.50
|
£1.80
|
|
|
27 - SCREW
BDE-330045-09.A35
330045-09
|
£1.50
|
£1.80
|
|
|
30 - SCREW
BDE-330045-06.A68
330045-06
|
£1.50
|
£1.80
|
|
|
31 - BOLT
BDE-582837-00.A16
582837-00
|
£1.50
|
£1.80
|
|
|
32 - BLADE CLAMP
BDE-N127658.A0
N127658
|
£12.17
|
£14.60
|
|
|
33 - HOLDER
BDE-582262-00.A25
582262-00
|
£1.50
|
£1.80
|
|
|
34 - FELT SEAL
BDE-582263-00.A0
582263-00
|
£1.50
|
£1.80
|
|
|
35 - SPRING
BDE-586646-00.A17
586646-00
|
£1.50
|
£1.80
|
|
|
36 - BEARING
BDE-490330-00.A5
490330-00
|
£1.50
|
£1.80
|
|
|
37 - SHAFT
BDE-589013-00.A13
589013-00
|
£16.03
|
£19.24
|
|
|
38 - SUPPORT BEARING
BDE-582260-00.A18
582260-00
|
£3.80
|
£4.56
|
|
|
39 - SCREW
BDE-324006-00.A111
324006-00
|
£1.50
|
£1.80
|
|
|
40 - BEARING
BDE-490329-00.A6
490329-00
|
£1.50
|
£1.80
|
|
|
46 - CLAMP
BDE-582261-00.A0
582261-00
|
£1.50
|
£1.80
|
|
|
47 - DRIVE ROLLER
BDE-582257-00.A3
582257-00
|
£7.18
|
£8.62
|
|
|
48 - CLIP
BDE-571181-00.A37
571181-00
|
£1.50
|
£1.80
|
|
|
50 - SCREW
BDE-N127249.A6
N127249
|
£1.50
|
£1.80
|
|
|
51 - BEARING NEEDLE
BDE-330004-02.A15
330004-02
|
£1.50
|
£1.80
|
|
|
52 - CRANK KIT
BDE-479403-00.A15
479403-00
|
£16.03
|
£19.24
|
|
|
53 - COUNTERWEIGHT
BDE-589012-00.A3
589012-00
|
£25.70
|
£30.84
|
|
|
55 - GEAR SA
BDE-589014-01.A3
589014-01
|
-
|
|
|
|
56 - ACTUATOR
BDE-581247-00.A2
581247-00
|
£4.69
|
£5.63
|
|
|
58 - GEARCASE SA
BDE-589011-01.A1
589011-01
|
£43.02
|
£51.63
|
|
|
65 - LEVER
BDE-581255-05.A16
581255-05
|
£1.50
|
£1.80
|
|
|
66 - DETENT
BDE-326467-00.A258
326467-00
|
£1.50
|
£1.80
|
|
|
67 - BODY
BDE-582830-05.A15
582830-05
|
£1.50
|
£1.80
|
|
|
68 - BAFFLE
BDE-582831-00.A3
582831-00
|
£1.50
|
£1.80
|
|
|
70 - SUPPORT BRACKET
BDE-589056-00.A15
589056-00
|
£18.91
|
£22.69
|
|
|
72 - PIN
BDE-330041-29.A47
330041-29
|
£1.50
|
£1.80
|
|
|
73 - NOZZLE
BDE-584450-00.A3
584450-00
|
£1.50
|
£1.80
|
|
|
74 - PIN
BDE-330041-49.A2
330041-49
|
£1.50
|
£1.80
|
|
|
76 - LEVER
BDE-581257-01.A10
581257-01
|
£7.18
|
£8.62
|
|
|
77 - BEARING BALL
BDE-605040-38.A2
605040-38
|
£11.87
|
£14.24
|
|
|
78 - SPRING CLIP
BDE-N089310.A16
N089310
|
£1.50
|
£1.80
|
|
|
85 - SHOE
BDE-581263-00.A3
581263-00
|
£17.48
|
£20.97
|
|
|
87 - ADAPTOR
BDE-581266-00.A3
581266-00
|
£1.88
|
£2.25
|
|
|
88 - PLUNGER
BDE-584686-00.A5
584686-00
|
£2.78
|
£3.34
|
|
|
89 - CLAMP
BDE-496996-00.A4
496996-00
|
£3.30
|
£3.96
|
|
|
90 - BOLT
BDE-582826-00.A16
582826-00
|
£7.85
|
£9.42
|
|
|
91 - WASHER
BDE-582828-00.A15
582828-00
|
£1.50
|
£1.80
|
|
|
92 - BOLT
BDE-582827-00.A10
582827-00
|
£1.50
|
£1.80
|
|
|
93 - VACUUM ADAPTOR
BDE-581281-00.A14
581281-00
|
£4.69
|
£5.63
|
|
|
94 - SOLE PLATE
BDE-581264-00.A15
581264-00
|
£5.88
|
£7.06
|
|
|
95 - SCREW TORX
BDE-N056875.A45
N056875
|
£1.50
|
£1.80
|
|
|
96 - SOLE PLATE
BDE-581268-00.A13
581268-00
|
£2.67
|
£3.20
|
|
|
800 - GREASE
BDE-870889-03.A9
870889-03
|
£7.85
|
£9.42
|
|
|
816 - BRAND LABEL
BDE-N137254.A0
N137254
|
£3.30
|
£3.96
|
|
|
821 - RATING PLATE GB
BDE-N137333
N137333
|
-
|
|
|
|
861 - KITBOX
BDE-581580-03.A9
581580-03
|
£34.00
|
£40.80
|
|
|
866 - BATTERY 14.4V - 4.0AH DCS332M2 GB
BDE-N195932.A15
N195932
|
£144.10
|
£172.92
|
|
|
866 - BATTERY 14.4V - 4.0AH DCS332L2 GB
BDE-N195932.A16
N195932
|
£144.10
|
£172.92
|
|
|
871 - CHARGER 10.8V - 18V GB
BDE-N450537.A74
N450537
|
£157.18
|
£188.61
|
|
